Title: Intrusion Detection Systems


1
Intrusion Detection Systems
2
Definitions
  • Intrusion
  • A set of actions aimed to compromise the security
    goals, namely
  • Integrity, confidentiality, or availability, of a
    computing and networking resource
  • Intrusion detection
  • The process of identifying and responding to
    intrusion activities

3
Elements of Intrusion Detection
  • Primary assumptions
  • System activities are observable
  • Normal and intrusive activities have distinct
    evidence
  • Components of intrusion detection systems
  • From an algorithmic perspective
  • Features - capture intrusion evidences
  • Models - piece evidences together
  • From a system architecture perspective
  • Audit data processor, knowledge base, decision
    engine, alarm generation and responses

4
Components of Intrusion Detection System
system activities are observable
normal and intrusive activities have distinct
evidence
5
Intrusion Detection Approaches
  • Modeling
  • Features evidences extracted from audit data
  • Analysis approach piecing the evidences together
  • Misuse detection (a.k.a. signature-based)
  • Anomaly detection (a.k.a. statistical-based)
  • Deployment Network-based or Host-based
  • Development and maintenance
  • Hand-coding of expert knowledge
  • Learning based on audit data

6
Misuse Detection
Example if (src_ip dst_ip) then land attack
Cant detect new attacks
7
Anomaly Detection
probable intrusion
activity measures
Relatively high false positive rate -
anomalies can just be new normal activities.
8
Key Performance Metrics
  • Algorithm
  • Alarm A Intrusion I
  • Detection (true alarm) rate P(AI)
  • False negative rate P(AI)
  • False alarm rate P(AI)
  • True negative rate P(AI)
  • Architecture
  • Scalable
  • Resilient to attacks

9
Host-Based IDSs
  • Using OS auditing mechanisms
  • E.G., BSM on Solaris logs all direct or indirect
    events generated by a user
  • strace for system calls made by a program
  • Monitoring user activities
  • E.G., Analyze shell commands
  • Monitoring executions of system programs
  • E.G., Analyze system calls made by sendmail

10
Network IDSs
  • Deploying sensors at strategic locations
  • E.G., Packet sniffing via tcpdump at routers
  • Inspecting network traffic
  • Watch for violations of protocols and unusual
    connection patterns
  • Monitoring user activities
  • Look into the data portions of the packets for
    malicious command sequences
  • May be easily defeated by encryption
  • Data portions and some header information can be
    encrypted
  • Other problems

11
Architecture of Network IDS
Alerts/notifications
Policy script
Policy Script Interpreter
Event control
Event stream
Event Engine
tcpdump filters
Filtered packet stream
libpcap
Packet stream
Network
12
Firewall Versus Network IDS
  • Firewall
  • Active filtering
  • Fail-close
  • Network IDS
  • Passive monitoring
  • Fail-open

IDS
FW
13
Requirements of Network IDS
  • High-speed, large volume monitoring
  • No packet filter drops
  • Real-time notification
  • Mechanism separate from policy
  • Extensible
  • Broad detection coverage
  • Economy in resource usage
  • Resilience to stress
  • Resilience to attacks upon the IDS itself!

14
Case Study Snort IDS
15
Problems with Current IDSs
  • Knowledge and signature-based
  • We have the largest knowledge/signature base
  • Ineffective against new attacks
  • Individual attack-based
  • Intrusion A detected Intrusion B detected
  • No long-term proactive detection/prediction
  • Statistical accuracy-based
  • x detection rate and y false alarm rate
  • Are the most damaging intrusions detected?
  • Statically configured.

16
Firewalls
17
What is a Firewall?
  • A choke point of control and monitoring
  • Interconnects networks with differing trust
  • Imposes restrictions on network services
  • only authorized traffic is allowed
  • Auditing and controlling access
  • can implement alarms for abnormal behavior
  • Itself immune to penetration
  • Provides perimeter defence

18
Classification of Firewall
  • Characterized by protocol level it controls in
  • Packet filtering
  • Circuit gateways
  • Application gateways
  • Combination of above is dynamic packet filter

19
Firewalls Packet Filters
20
Firewalls Packet Filters
  • Simplest of components
  • Uses transport-layer information only
  • IP Source Address, Destination Address
  • Protocol/Next Header (TCP, UDP, ICMP, etc)
  • TCP or UDP source destination ports
  • TCP Flags (SYN, ACK, FIN, RST, PSH, etc)
  • ICMP message type
  • Examples
  • DNS uses port 53
  • No incoming port 53 packets except known trusted
    servers

21
Usage of Packet Filters
  • Filtering with incoming or outgoing interfaces
  • E.g., Ingress filtering of spoofed IP addresses
  • Egress filtering
  • Permits or denies certain services
  • Requires intimate knowledge of TCP and UDP port
    utilization on a number of operating systems

22
How to Configure a Packet Filter
  • Start with a security policy
  • Specify allowable packets in terms of logical
    expressions on packet fields
  • Rewrite expressions in syntax supported by your
    vendor
  • General rules - least privilege
  • All that is not expressly permitted is prohibited
  • If you do not need it, eliminate it

23
Every ruleset is followed by an implicit rule
reading like this.
Example 1 Suppose we want to allow inbound
mail (SMTP, port 25) but only to our gateway
machine. Also suppose that mail from some
particular site SPIGOT is to be blocked.
24
Solution 1
Example 2 Now suppose that we want to
implement the policy any inside host can send
mail to the outside.
25
Solution 2
This solution allows calls to come from any port
on an inside machine, and will direect them to
port 25 on the outside. Simple enough So why
is it wrong?
26
  • Our defined restriction is based solely on the
    outside hosts port number, which we have no way
    of controlling.
  • Now an enemy can access any internal machines and
    port by originating his call from port 25 on the
    outside machine.
  • Now for a better solution

27
  • The ACK signifies that the packet is part of an
    ongoing conversation
  • Packets without the ACK are connection
    establishment messages, which we are only
    permitting from internal hosts

28
Backup Slides
29
SYN Flooding Attack
  • 90 of DoS attacks use TCP SYN floods
  • Streaming spoofed TCP SYNs
  • Takes advantage of three way handshake
  • Server start half-open connections
  • These build up until queue is full and all
    additional requests are blocked

30
Security Performance of Packet Filters
  • IP address spoofing
  • Fake source address to be trusted
  • Add filters on router to block
  • Degradation depends on number of rules applied at
    any point
  • Order rules so that most common traffic is dealt
    with first
  • Correctness is more important than speed

31
Port Numbering
  • TCP connection
  • Server port is number less than 1024
  • Client port is number between 1024 and 16383
  • Permanent assignment
  • Ports lt1024 assigned permanently
  • 20,21 for FTP, 23 for Telnet 25 for server SMTP,
    etc.
  • Variable use
  • Ports gt1024 must be available for client to make
    any connection
  • This presents a limitation for stateless packet
    filtering
  • If client wants to use port 2048, firewall must
    allow incoming traffic on this port
  • Better stateful filtering knows outgoing requests

32
Stateful Filtering
