Banner Engineering

• EZ-SCREEN Low Profile

3
EZ-SCREEN Low Profile
4
EZ-SCREEN Low Profile
Overview

• Defined area equals housing length
• End-to-End Sensing
• No Dead Zone
• Continual Sensing
• Very flexible mounting options
• Functionality is the same as the updated standard
  EZ-SCREEN plus a couple of extras
• Cross-section 28 x 26 mm
• System Power 210 mA _at_ 24V dc

5
EZ-SCREEN Low Profile
Overview

• Defined area lengths
• 270 to 1810 mm (140 mm increments)
• Resolution 14 and 25 mm
• 7 m range
• Response times 8 to 43 ms
• Two PNP 500 mA solid-state OSSDs
• PNP auxiliary output at 250 mA
• Emitter Reset input and Test input
• Test input is selectable

6
EZ-SCREEN Low Profile
Overview

• Stand Alone and Cascade Models

No big cable loops
Insert Zoom of Image From Bottom of Pg 19
7
EZ-SCREEN Low Profile
Overview

• Housing styles available in
• Yellow (standard)
• Anodized (brushed) aluminum
• ESD-safe with nickel-plated housing and end
  caps

8
EZ-SCREEN Low Profile
DIP-Switch Selectable Features

• Scan code (SC1 or SC2)
• Trip or Latch output
• 1 or 2 channel EDM (no EDM)
• Invert display
• Aux output (selectable)
• Receiver OSSD follow or Fault
• Emitter Fault
• Emitter TEST input (enable/disable)

9
EZ-SCREEN Low Profile
Fixed Blanking

• Easiest TEACH function on the market
• All but one beam can be fixed blanked
• Sync beam must be clear
• Multiple areas can be fixed blanked
• Removal of blanked object causes lockout
• Reduced resolution can be enabled with fixed
  blanking programmed

10
EZ-SCREEN Low Profile
Fixed Blanking DIP Switch Programming

• TEACH Sequence
• 1. Place object in the defined area
• 2. Set switches as shown (interchangeable)
• One pair of T/L and RED RES to the left
• The other pair to the right
• 3. Press the reset or cycle power
• 4. Set switches for normal operation
• 5. Press the reset or cycle power
• .. Finished !

11
EZ-SCREEN Low Profile
Two Primary Models

• Removable Disconnect (RD)
• Uses two screws to attach the cordsets to
  the sensor
• Order RD cordsets separately or in kits
• 300 mm Pigtail Quick-disconnect
• P8 or P88 designation
• Used with Off-the-Shelf standard
  M12/Euro-Style cordsets
• Order M12 QD mating cordsets separately or in
  kits

12
EZ-SCREEN Low Profile
Removable Disconnect

• RD Cordsets
• RDLP-8xxD with Flying Leads
• DELPE-8xxD with M12/Euro QD used with
  M12/Euro cordsets
• DELP-11xxE for connection of 2nd, 3rd and 4th
  sensors in a cascade system

13
EZ-SCREEN Low Profile
300 mm Pigtail Quick-Disconnect

• M12 (Euro-Style) QD Cordsets
• QDE-8xxD with Flying Leads
• DEE2R-8xxD Double-ended
• CSB Splitters

14
EZ-SCREEN Low Profile
Cordset Options

• Standard cordsets have a yellow PVC cable and
  black overmold connectors
• Black cordsets available by adding a B to the
  end of the cordset model number
• Example, QDE-8xxDB
• Used with anodized (brushed) aluminum and
  ESD-safe models
• Why? Aesthetics

15
EZ-SCREEN Low Profile
Cordset Options

• No special or shielded cables required with 300
  mm Pigtail with M12/Euro QD (P8/P88 models)
• Banner cables and color code minimizes
  possibility of electrical code conflict of color
  vs. function and are 22 awg to allow longer
  lengths
• Generic M12 cables can be used, though user must
  verify suitability for their application
• M12 color code cross-reference listed in manual
• See To Order information in sales brochure
  (p/n 142815) and safety catalog 2009-2010

16
EZ-SCREEN Low Profile
Hookup Options Sensor Swapability

• This optional hookup provides for sensor
  interchangeability (swapability) the ability
  install either sensor on either cordset
• Emitter cable can be connected in a parallel
  connection (color-for-color) to the receiver
  cable
• Besides providing similar cabling, this hookup is
  advantageous during installation, wiring and
  troubleshooting

17
EZ-SCREEN Low Profile
Hookup Options Sensor Swapability

• CSB series splitter cables allow for easy
  connection with a swapable hookup and
  provide a single homerun cable
• Homerun trunk cable from 300 mm (1 ft) to
  8 m (25 ft) with M12 QD or with flying
  leads
• Double-ended cables are used for separation
  between emitter and receiver

18
EZ-SCREEN Low Profile
Hookup Options Sensor Swapability
Different functions are possible depending on
DIP-Switch configuration
R
R
R
E
E
E
19
EZ-SCREEN Low Profile
Intuitive Diagnostics

• Bicolor Status LEDs
• 7-segment diagnostic display
• Displays code by flashing sequence
• Number of blocked beams
• Eight LED zone indicators
• Shows location of blocked and cleared beams

20
EZ-SCREEN Low Profile
Interfacing Options Relay-based Safety Stop
Circuits
Interfacing Modules
Positive-Guided Relay Contactors
Universal Modules
IM-T-9A
IM-T-11A Provides isolated safety stop
circuits

UM-FA-9A
UM-FA-11A Provides isolated safety stop
circuits

Banner
11-BG00-31-D-024 (10 amp)
BF1801L-024 (18 amp)
21
EZ-SCREEN Low Profile
Interfacing Options Logic Devices

• SC22-3 Safety Controller
• Muting Modules
• MMD-TA-11B and 12B
• MM-TA-12B
• Safety PLCs
• Compatible
• Safety Bus Nodes
• Compatible

22
EZ-SCREEN Low Profile
Interfacing Options Safety BUS I/O Modules

• DEE8-4xxD and DEE8-5xxD Adaptor Cordsets
• 4 or 5 pin interfacing to a
• Safety BUS gateway
• Safety module
• Safety controller or
• Safety PLC
• Connections for 24V dc, 0V dc and two
  OSSDs
• DEE8-5xxD has GND/PE

23
EZ-SCREEN Low Profile
Interfacing Options AC Supply
EZ-SCREEN AC Interface 100 to 250V ac _at_ 50-60 Hz
EZAC-R9-QE8 EZAC-R11-QE8 Provides DC
power and 8A Safety Stop Circuits
24
EZ-SCREEN Low Profile
Cascading
Unique patented method of combining safety light
screens to form a single stop command

• Any length
• Any resolution
• Any number of beams
• Up to four pairs
• Minimal impact to response time
• Can be used as a stand alone system
• E-Stop/Interlocking Switch Input

25
EZ-SCREEN Low Profile
Cascading Response Time
Individual Tr 40 2 2 2 46 ms
Same as the standard EZ-SCREEN Adds a nominal 2
ms for each additional sensor pair
Individual Tr 15 2 2 19 ms

• Maximum response time is determined by the system
  with the greatest number of beams and then
  adding 2, 4 or 6 ms, (depending on position)
• Or, can be calculated individually
• Worse case, the 6 ms adder results in 0.4" in
  the separation distance

Individual Tr 15 2 17 ms
Individual Tr 15 ms
Max System Tr 46 ms
26
EZ-SCREEN Low Profile
Cascade Interconnect Options
Standard connection DELP-8xxD cordsets
Optional connection DELPEF-81D cordset
DEE2R-8xxD cordset (optional) DELPE-8xxD (or P8
models)
E-Stop / Interlocking Switch With RDLP6G-4xxD
cordset, orDELPEF-81D and QDE2R4-8xxD cordsets
27
EZ-SCREEN Low Profile
Cascading
Extremely Flexible Interconnection
With a 15' machine interface QDE or RDLP cable
(L1), up to 156' (47 m) of cabling between two
sensors pairs (L2) is possible with DELP-11xxE
cascade cables
Three Sensors Pairs
Four Sensors Pairs
Other lengths and combinations are possible
28
EZ-SCREEN Low Profile
Cascading

• System is required to be configured to prevent
  defeat or unauthorized bypassing or manipulation
• Similar DIP-Switch configuration as standard
  EZ-SCREEN
• Procedure accomplished only on first receiver in
  the string (Example the receiver connected to
  the machine control)

29
EZ-SCREEN Low Profile
Cascading DIP Switching Configuration

• Identifies position/type of sensorsand whether
  E-Stop is used
• 1. Install system and apply power
• 2. Set switches as shown (interchangeable)
• Mismatch one pair of T/L and RED RES
• The other pair is opposite
• 3. Press the Reset or cycle power
• 4. Set switches for normal operation
• 5. Press the Reset or cycle power

30
EZ-SCREEN Low Profile
Cascading and MMD Muting Module

• The MMD-TA-xxx can be used as a Dual Controller
  if the muting function is not used
• One MMD can monitor up to eight sensing fields if
  cascaded EZ-SCREENs are used
• The MMD-TA-11B has 2 NO/1 NC relay outputs
• The MMD-TA-12B has 2 x PNP OSSD outputs

31
EZ-SCREEN Low Profile
Very Flexible Mounting
32
EZ-SCREEN Low Profile
Very Flexible Mounting
1?" 33 mm
33
EZ-SCREEN Low Profile
Very Flexible Mounting

• Standard Mounting Brackets
• 360º end mount
• 10º/-30º side brackets
• Both styles included with Emitter and Receiver !!!

34
EZ-SCREEN Low Profile
Very Flexible Mounting

• Accessory brackets
• Pivoting
• Universal
• Fixed Angle
• P1000 Unistrut

90 (L) 120 (60) 135 (45)
180 (straight)
35
EZ-SCREEN Low Profile
Very Flexible Mounting

• LPA-MBK-90, -120, -135, -180
• Continual 25 mm resolution with fixed angle
  brackets

36
EZ-SCREEN Low Profile
Very Flexible Mounting

• LPA-MBK-22
• Used with customer supplied P1000 Unistrut and
  channel spring nuts (M6 or 1/4")

37
EZ-SCREEN Low Profile
Certifications

• CE Certification to
• Compliant with the new Machinery Directive
  2006/42/EC
• Type 4 per IEC 61496-1/-2
• Category 4, PL e per EN ISO 13849-1 (2008)
• SIL 3 per IEC 61508
• SIL CL 3 per IEC 62061
• UL Certification to
• cULus to category NIPF
• Requirements to UL 61496 and UL1998

38
EZ-SCREEN Low Profile
Applications
39
EZ-SCREEN Low Profile
Applications
40
EZ-SCREEN Low Profile
Applications
41
EZ-SCREEN Low Profile
Applications
42
EZ-SCREEN Family
EZ-SCREEN Low Profile
Great addition to the EZ-SCREEN family

• 14 and 30 mm Type 4 Standard
• Grid and Points
• Type 2
