Reactivity Series

1
Reactivity Series

• Metals

2
Objectives

• That this order is called the Reactivity Series
• That in the reactivity series the most reactive
  metal is at the top
• That the more reactive metals can displace the
  less reactive (including hydrogen)
• That the series an predict reactions and the
  extraction method
• To know the metals can be written in an order of
  reactivity

3
Reactivity Series
4
Reaction with acids
Hydrogen gas from the reaction of magnesium metal
with acid
When magnesium metal is treated with acid
evolution of hydrogen gas results
5
Concepts

• Single Replacement Reactions

• A BC ? AC B

6
How?
The weak are displaced by the strong!
7
Single Replacement Reactions

• A single replacement reaction is of the general
  form
• A BC ? AC B
• In order for a single replacement reaction to
  occur, A must be more reactive than B in order to
  combine with C
• In this reaction
• Mg (s) 2HCl (g) ? MgCl2 (aq) H2(g)
• Since the reaction occurs, we must conclude that
  magnesium is more reactive than hydrogen

8
Metal displacement
Cu(s) 2AgNO3 (aq) ? Cu(NO3)2 (aq)
2Ag(s) Coppersilver nitrate ?copper nitrate
silver

• Copper is higher than silver in the Reactivity
  Series.
• Copper can displace silver from it silver
  compounds (e.g. silver nitrate)

9
Objectives

• To observe a chemical reaction between a metal
  and an acid
• To measure rate of hydrogen gas produced
• To consider the factors which can affect
  reactions rates

10
Checkpoint

• a) Zn (s) Cu(NO3)2 (aq) ?
• zinc copper nitrate ?
• b) Ca (s) 2H2O (l) ?
• calcium water ?
• Mg (s) AgNO3 (aq) ?
• magnesiumsilver nitrate ?
• Cu (s) H2SO4(aq) ?
• copper sulphuric acid ?

• Zn(NO3)2 (aq) Cu (s
• zinc nitrate copper
• Ca(OH)2 (aq) H2(g )
• calcium hydroxide hydrogen
• Mg(NO3)2 (aq) Ag(s)
• Copper nitrate silver
• No reaction

11
Magnesium acid

• Hydrogen evolution began as soon as the magnesium
  metal was added to the water
• The hydrogen was less dense than water so it rose
  through it
• The hydrogen gas was able to be collected in a
  burette or gas syringe

12
Reaction Rates

• Magnesium hydrochloric acid

13
But how fast?
Displaced air
Gas syringe
hydrogen
Hydrochloric acid
magnesium
Note volume of hydrogen produced volume of
displaced air
14
Typical Results
15
Graph
Gradient initial rate of hydrogen production
volume of hydrogen 50 13
cm3/min time 3.6
16
Graph shape
17
Collisions
For a reaction to occur the reactant molecules
must collide with enough energy (the activation
energy) to react.
On collision the reactant molecule re-arrange to
form product molecules
18
Factors which can affect reaction rates

• Concentration how crowded the solution is,
  higher concentrations increase the chance of a
  collision
• Temperature affects the speed molecules are
  moving and the energy available to break bonds on
  collision
• Surface area how big a target the moving
  particles have to hit
• Catalyst speeds up the reactions by lowering
  the energy needed to break bonds.

19
Concentration
At higher concentrations there is more chance of
a collision so more chance of a reaction taking
place.
20
Temperature
cold
hot
At higher temperatures there are more collisions
with enough energy for a reaction to take place
21
Surface area
Block
Same block broken into 8
Which has the larger surface area, the block or
the same size block broken? Which has the larger
surface area? Which will increase the chance of a
collision and therefore a faster reaction rate?
22
Which has the most surface area?
Each of these represents 10g of limestone
A
B
C
Which has the largest surface area? Which will
react with acid the fastest?
23
Catalyst
Catalysts speed up a reaction. They do this by
making it easier for bonds to be broken in the
reactants so new bonds can be made in the
products. A catalyst does this by lowering the
energy to break bonds, they lower the activation
energy. This leads to more successful collisions
per second so a faster reaction rate
