Programming with JMF

1
Programming with JMF

• Prepared by Tony K. C. Chan.

2
Learning Objectives

• Foundation of media communications
• Setup the voice communication channel with Java
  Media Framework (JMF)
• Complete the simplified Internet phone system

3
1. Background Knowledge

• Java Media Framework (JMF) API for time-based
  media in Java.
• Processing model

4
1. Background Knowledge

• Some Important Terms in JMF
• DataSource an object thatencapsulates the media
  stream(e.g., a file, an incoming stream,etc.).
• Capture device hardware used to capture the
  media data (e.g., microphone).

5
1. Background Knowledge

• Some Important Terms in JMF, cont.
• Player
• a media handler forrendering and
  controllingtime-based media data.
• Processing model of the Player

6
1. Background Knowledge

• Some Important Terms in JMF, cont.
• Player, cont.
• Six states of the Player

7
1. Background Knowledge

• Some Important Terms in JMF, cont.
• Processor
• It extends the Player interface.
• Rendering media data
• Control over the processing of the input output
  media data.
• Processing model of the Processor

8
1. Background Knowledge

• Some Important Terms in JMF, cont.
• Processor, cont.
• Processing stages of the Processor

9
1. Background Knowledge

• Some Important Terms in JMF, cont.
• Processor, cont.
• Two additional states (Configuring Configured).

10
1. Background Knowledge

• Some Important Terms in JMF, cont.
• Format represents the exact format of the media
  (e.g., GSM).
• Manager
• used to implement some other interfaces
• Example
• Manager ? Player, Processor, and DataSource.
• CaptureDeviceManager ? access a list of available
  capture devices.
• RTPManater used to create, maintain and close an
  RTP session.

11
1. Background Knowledge

• Some Useful Event
• ConfigureCompleteEvent
• posed when a Processor finishes Configuring.
• occurs when a Processor moves from Configuring to
  Configured (i.e., Processor is already
  Configured).
• RealizeCompleteEvent
• posted when a Controller finishes Realizing.
• occurs when a Controller moves from Realizing to
  Realized (i.e., the Controller is already
  Realized).

12
1. Background Knowledge

• Some Useful Event, cont.
• EndOfMediaEvent
• indicates that the Controller has reached the end
  of its media and is stopping.
• NewReceiveStreamEvent
• Informs the RTP listener that a new stream of RTP
  data packets has been detected

13
2. Programming with JMF

• Setting up Your Computer
• Setting up the Recording Control
• Setting up the Volume Control
• Testing with Sound Recorder

14
2. Programming with JMF

• Playing Media File Using JMF
• Create MediaLocator that represents the
  mediaMediaLocator mediaLocator new
  MediaLocator(fileName)
• Create DataSource for the MediaLocatordataSource
  Manager.createDataSource( mediaLocator)
• Create Player for the DataSourceplayer
  Manager.createPlayer(dataSource)

15
2. Programming with JMF

• Playing Media File Using JMF, cont.
• Add ControllerListener to the playerplayer.addCon
  trollerListener(this)
• Implement the controllerUpdate methodpublic
  synchronized void controllerUpdate(
  ControllerEvent e) ...
• Realize the Playerplayer.realize()
• Start the Playerplayer.start()

16
2. Programming with JMF

• Playing Media File Using JMF, cont.

/ File name RingPlayer.java / import
java.media. import java.media.protocol. publi
c class RingPlayer Player player public
RingPlayer() String fileName
file//C\\java\\ringin.wav ... public
void start() ... public void stop() ...

17
2. Programming with JMF

• Playing Media File Using JMF, cont.

public class RingPlayer implements
ControllerListener Player player public
RingPlayer() String fileName
file//C\\java\\ringin.wav ...
player.addControllerListener(this) ...
... public synchronized void controllerUpate(
ControllerEvent e) if (e instanceof
EndOfMediaEvent) player.setMediaTime(new
Time(0)) ...
18
3. The ChattingManager for our SIPS

• Details of ChattingManager
• ChattingManager(int mediaPort)
• Creates an instance of ChattingManager.
• Capture the audio device from your computer and
  prepare all stuff for setting up the voice
  communication channel.
• ChattingManager(int mediaPort, boolean
  showProgress)
• Same as ChattingManager(int mediaPort), but with
  debugging output.

19
3. The ChattingManager for our SIPS

• Details of ChattingManager, cont.
• void setupConnection(InetAddress targetIP, int
  targetPort) sets up the RTP session with the
  remote host and waiting for receiving audio
  stream.
• void start() start sending the captured audio
  stream through the connected RTP session.
• void destroy() stop and destroy the RTP session
  (it will not destroy the ChattingManager).

20
3. The ChattingManager for our SIPS

• How to use the ChattingManager
• Save ChattingManager.class and SendProcessor.class
  in the working directory

21
THE END
