EART 160: Planetary Science

1
EART 160 Planetary Science
2
Last Time

• Celestial Mechanics
• Keplers Laws
• Newtons Laws of Motion
• Law of Universal Gravitation

3
Today

• Celestial Mechanics
• Explain Kepler with Newton
• Conservation
• Solar System Origin
• Formation of the Solar System
• Nebular Theory
• Distribution of solar system materials
• Planet formation, composition, structure

4
Explanation of Keplers Laws

• Kepler observed orbital periods and distances,
  but didnt know what caused it.
• Third Law only works for the Sun, using Earth as
  a reference.
• Newton finds force of gravity is what moves
  planets toward the sun.
• Can extend Keplers Third Law for any object.
• Lets do that now!

5
Keplers Third Law

• Compare orbital velocity to period
• Ill show this for a circular orbit
• Works for elliptical orbit as well, but the
  derivation is unpleasant and not very
  informative.
• Should recover Keplers version if we stick in
  the Suns Mass, keep times in years, and
  distances in AU.

6
Circular Velocity

• Gravity imposes a centripetal acceleration to an
  orbiting object.

v
a
r
This is why planets dont fall into the Sun. And
why its so hard to get to Mercury!
7
Conservation Laws

• Momentum
• If the vector sum of the external forces on a
  system is zero, the total momentum of the system
  is constant.
• Momenta of individual objects can change.
• Angular Momentum
• When the net external torque on a system is zero,
  the total angular momentum of the system is
  constant.
• Angular Momenta of individual objects can change.
• Energy
• Cannot be created or destroyed
• Can be converted from one form to another(e.g.
  from potential to kinetic)

8
Escape Velocity

• How fast does an object have to go to escape the
  gravitational pull of a planet?
• Conservation of Energy
• Balance the Potential Energy due to gravity
  against the Kinetic Energy due to motion
• Collapse of solar nebula ? lots of potential
  energy lost. Where does it go?

9
Keplers Second Law
v
v- v sin j
j
r
dq
10
Law of Areas

• Conservation of Angular Momentum
• Object moves fast near periapse (short lever
  arm), slow near apoapse (long lever arm.
• Energy shifts from kinetic to potential and back.

11
Earth-Moon System

• The Moon is moving away from the Earth!
• The day is getting longer!
• Earths spin angular momentum turns into Moons
  orbital angular momentum.
• This will continue until the spins and orbits
  match (syncrhonous rotation)
• Common for nearly all satellites

12
Keplers First Law

• Derivation is unpleasant
• Requires Differential Equations
• Pure mathematics, no science involved
• Shall we skip it?
• Bound orbits are ellipses (or circles)
• Not enough KE to escape, keep orbiting
• Negative total energy! KE lt -U ? KE U lt 0
• Unbound orbits are hyperbolae (or parabolae)
• One pass and gone for good (e.g. many comets)
• Positive total energy. KE U gt 0.

13
Collisions

• Conservation of Momentum
• Inelastic collison Kinetic energy not conserved
• But total energy is! Some goes into heating or
  deformation
• Objects may stick together (completely inelastic)
• Elastic collision Kinetic energy is conserved

14
Inelastic Collisions
Impacts

• Dust Grains colliding during solar system
  formation

15
Elastic Collisions
Collision with no impactJust Gravity
Without this, solar system explortation would be
slow and expensive.Saved 19 years off Voyager
2s trip to Neptune!
16
Two-body problem

• All this is derived for two bodies, as if nothing
  else exists in the universe.
• Good approximation if one body is very large.
• Third body causes perturbations
• Three-body problem is analytically unsolvable in
  general.
• Good treatment of restricted three-body problem
  in Murray and Dermott (1999) Solar System
  Dynamics.

17
Solar System Formation

• Why do we care?
• Current state of the solar system controlled by
  the initial conditions
• Recall Stevenson 2000
• Composition, Distribution, Rotation
• To understand planets, we need to know how they
  got here.

18
A successful theory must explain

• All planets orbits in a single plane.
• Suns rotation in same plane.
• Prograde orbits of all planets
• Planetary orbits nearly circular
• Angular momentum distribution
• Some meteorites contain unique inclusions
• Correlation of planetary composition with solar
  distance.

• Meteorites different from terrestrial and lunar
  rocks
• Spacing of the planets
• Giant impacts on all planetary bodies
• Prograde rotation, low obliquity of most planets
• Similar rotation periods for many planets
• Spherical distribution of comets
• Satellite sysems of giant planets

19
Prelude to the Solar System

• Big Bang (14 Ga)
• Creation of Matter (75 H, 25 He)
• Star Formation
• Nucleosynthesis (All elements up to Fe)
• Supernovae
• All other elements formed
• Material ejected into interstellar space
• Nebula Dense cloud of gas and dust
• Thousands of M?

20
The Solar Nebula

• Gravitational collapse of part of cloud
• Virial Theorem
• Central part heats up
• Why?
• Conservation of Energy!
• Protostar (becomes star if M gt 0.08 M?)
• Rotation rate increases
• Why?
• Conservation of Angular Momentum!
• Flattens into protoplanetary disk (proplyd)

21
Jeans Collapse

• A perturbation will cause the density to increase
  locally
• Runaway Process
• Increased density ? increased gravity ? more
  material gets sucked in

Gravitational potential energy
M,r
Thermal energy
R
Equating these two and using MrR3 we get
Does this make sense?
Mmass rdensity Rradius kBoltzmanns
constant Ttemperature (K) Nno. of atoms
matomic weight MHmass of H atom
22
Proplyds in the Orion Nebula
Disks radiate in the infrared All very young few
My
Beta Pictoris 50 ly
Bipolar Outflow
HH-30 in Taurus
HST Images Courtesy NASA/ESA/STSci
23
Minimum Mass Solar Nebula
Density drops off with distance. COINCIDENCE?!?!?
!

• We can use the present-day observed planetary
  masses and compositions to reconstruct how much
  mass was there initially

24
Timeline of Planetary Growth

• 1. Nebular disk formation
• 2. Initial coagulation (10km, 104 yrs)
• 3. Runaway growth (to Moon size, 105 yrs)
• 4. Oligarchic growth, gas loss(to Mars size,
  106 yrs)
• 5. Late-stage collisions (107-8 yrs)

25
Collisional Accretion (104 y)
Inelastic Collisions between dust grains
Dust grains also accrete onto chondrules
solidified molten fragments
Forms Planetesimals R lt few km
Vertical Motions canceled out Disk orientation
controlled by angular momentum Disks gravity
also draws material toward midplane
26
Runaway Growth (105 y)

• Slow-moving planetesimals accrete
• Protoplanets grow to size of moon (3500 km)

Fg GMm / R2
vorbital lt vesc
vorbital gt vesc
The rich get richer! -- Bender
27
Oligarchic Growth (105 y)

• Cosmic Feudal System
• Only a few dozen big guys left (oligarchs)
• And a lot of very small stuff (serfs?)
• Oligarchs sweep up everything in their feeding
  zones
• Gas drag slows large objects down, circularizes
  orbits
• Brightening sun clears away nebular gas.

28
Composition

• Solar Nebula
• 98.4 gas (H, He)
• 1.1 ices (e.g. H2O, NH3, CH4)
• 0.4 rock (e.g. MgSiO4)
• 0.1 metal (mostly Fe, Ni)
• How do we know this?
• Look at the Sun!
• Absorpiton lines indicate elements
• Discovery of He

Volatile
Refractory
Image courtesy N.A.Sharp, NOAO/NSO/Kitt Peak
FTS/AURA/NSF
29
Condensation in the Nebula
Metals and Rocks Ices 1600 K 180 K
The Frost Line
30
Terrestrial v. Jovian

• Only refractories in inner SS
• Planets can only grow to Earth-size
• Too small to hold onto gas
• Ices also available beyond frost line
• Much more material
• Ice-rock planets up to 20 M? possible
• Big enough to accrete H, He ? can get huge, 300
  M?
• How big do we need to get?
• Why no giant planets farther out than Neptune?

31
Final Compositions
Io
Ganymede

• Terrestrial Planets
• Iron Core (Red), Silicate Mantle (Grey)
• Mercury has v. thin mantle. Why?
• Very few volatiles, thin atmospheres?
• Jovian Planets
• Rock (Grey) and Ice (Blue Cores)
• Gas envelope (Red, Yellow)
• Jupiter and Saturn mostly H, He
• Uranus, Neptune mostly ice

Guillot, Physics Today, (2004).
32
Satellites

• Satellites formed from mini-accretion disks about
  giant planets
• Explains why they all orbit the same way and in
  the same plane
• Irregular satellites (including Marss moons)
  captured later (high e, i)
• What about our own freakishly large Moon?

33
Problems with this

• Why exactly four terrestrial planets?
• Numerical models cant do this.
• What is up with the Moon?
• Gas Loss Timing
• As star heats up, gas in disk is blown away
• Gas causes planets to spiral in
• Gas must stick around long enough to form giant
  planets
• Why are Uranus and Neptune so shrimpy?
• Why are extrasolar planets so close in?
• Alan Boss
• Rapid giant planet formation by disk instability
  (100s of years)
• But computer models dont go all the way to end
  state
• Migration (next time)

34
Next Time

• Late-stage Accretion
• Formation of the Moon
• The Late Heavy Bombardment
• Planetary Migration
• You should now have everything you need to
  complete the homework

35
Late-stage accretion (107-108 y)

• Oligarchic growth results in dozens of
  planetesimals
• Perturb each other until orbits cross
• Giant Impacts
• Retrograde rotation of Venus
• Obliquity of Uranus
• Formation of the Earths Moon

36
Jupiter The Cosmic Bully

• Its huge! Perturbs anything nearby
• Disrupted accretion at 2-3 AU
• No planet here where we expected one.
• Location of the asteroid belt
• Ejected icy planetesimals
• Gravitational slingshot effect
• Scattered in all directions ? The Oort Cloud

37
From Albarede, Geochemistry An introduction
38
Observations (2)

• We can use the present-day observed planetary
  masses and compositions to reconstruct how much
  mass was there initially the minimum mass solar
  nebula

• This gives us a constraint on the initial nebula
  conditions e.g. how rapidly did its density fall
  off with distance?
• The picture gets more complicated if the planets
  have moved . . .
• The observed change in planetary compositions
  with distance gives us another clue silicates
  and iron close to the Sun, volatile elements more
  common further out
