Title: AT91 Interrupt Handling


1
AT91 Interrupt Handling
2
What are interrupts ?
  • Stops the execution of main software
  • Redirects the program flow, based on an event, to
    execute a different software subroutine
  • Interrupt behaviour

3
Interrupt sources (1/2)
  • External Interrupts
  • Allows an external event to stop program
    execution
  • Can alert the core by an edge transition or a
    level
  • Signal can originate from external peripherals or
    systems
  • Example external switch closure Interrupts

AT91
4
Interrupt sources (2/2)
  • Internal Interrupts
  • Originate from on-chip peripherals
  • Notifies core that peripheral needs servicing
  • Typically can occur at any time
  • Can originate from software

Counter overflow
Timer/Counter
End of conversion
ADC
End of transmission
USART
5
ARM7TDMI Interrupt Sources
  • Two physically independent sources
  • Fast interrupt FIQ
  • Used for fast interrupt handling
  • Private registers
  • Enable/disable with F bit in CPSR
  • Last vector in the exception vector table
  • Interrupt IRQ
  • Standard interrupt request
  • Enable/disable with I bit in CPSR

ARM7TDMI Processor
IRQ
FIQ
6
Advanced Interrupt Controller (1/3)
  • Features
  • 8-level Priority
  • Up to 32 Interrupt sources
  • Individually maskable
  • Hardware interrupt vectoring
  • Internal Interrupt sources
  • Level sensitive or edge triggered
  • External Interrupt sources
  • Low/High level sensitive or positive/negative
    edge triggered

7
Advanced Interrupt Controller (2/3)
  • Block Diagram

8
Advanced Interrupt Controller (3/3)
9
Atomic Interrupt Control (1/2)
  • For multi-task systems, it is sometimes useful to
    share peripherals
  • Interrupt Mask update is interruptible
  • Mask Register may be lost

OS Scheduler
Task 2
Task 1
Read IMR
Task 1
Task 2
Read IMR
Modify
Modify
Peripheral
Write IMR
Write IMR
OS Scheduler
10
Atomic Interrupt Control (2/2)
  • Basic solution is to mask interrupt at core level
    before modifying IMR
  • ARM7TDMI limitations
  • The CPSR is accessible only in ARM state and can
    be updated only from Privileged Mode
  • Usual solution is to switch in Supervisor Mode
    with a SWI
  • AT91 microcontrollers solution
  • Enabling or disabling an interrupt request in
    only one instruction
  • STR rx,ry,IER
  • STR rx,ry,IDR

11
Interrupt Vectors
  • Each interrupt source is associated with a Source
    Vector Register (AIC_SVR0-AIC_SVR31) which
    contains the address of the interrupt handler
  • When the Interrupt Vector Register (AIC_IVR) is
    read, it automatically returns the contents of
    the source vector register corresponding to the
    active interrupt

AIC Source vectors
AIC Interrupt vectors
ARM Exception vectors
AIC_SVR31
0xFFFFF0FC
ldr
pc,pc,-F20
AIC_SVR30
0x0000001C
FIQ
AIC_FVR
0xFFFFF104
IRQ
0x00000018
AIC_IVR
0xFFFFF100
Index
ABORT (Data)
Interrupt Id.
ABORT (Fetch)
SWI
UNDEF
RESET
AIC_SVR1
AIC_SVR0
0xFFFFF080
12
Interrupt Prioritization (1/4)
  • The NIRQ line is controlled by an 8-level
    priority encoder
  • Each source has a programmable priority level of
    7 to 0. Level 7 is the highest priority.
  • The AIC manages the prioritization by using an
    internal stack on which the current interrupt
    level is automatically pushed when AIC_IVR is
    read, and popped when AIC_EOICR is written
  • Between these two events, the software can manage
    the state and the mode of the core in order to
    re-enable the IRQ line and to allow an interrupt
    with a higher priority.

13
Interrupt Prioritization (2/4)
  • When an interrupt is managed by the processor,
    R14_irq and SPSR_irq are automatically
    overwritten without being saved
  • It is mandatory to save these registers before
    re-enabling the IRQ line and to restore them
    before exiting the interrupt routine
  • If the interrupt treatment performs function
    calls (Branch with link), R14_irq is used. In
    this case, IRQ can not be re-enabled while the
    processor is in IRQ mode
  • It is mandatory to first change the processor
    mode to SYSTEM mode in order to keep all
    exceptions available

14
Interrupt Prioritization (3/4)
  • The standard sequence of an interrupt handler is
  • Validate the nested interrupts
  • Save R14_irq and SPSR_irq in the IRQ stack
  • Set the mode bits in CPSR with the SYSTEM Mode
    value
  • Re-enable IRQ by clearing bit I in CPSR
  • Perfom interrupt treatment
  • call C handler
  • Disable the nested interrupts
  • Disable IRQ by clearing bit I in CPSR
  • Set the mode bits in CPSR with the IRQ Mode value
  • Restore R14_irq and SPSR_irq from the IRQ stack
  • This sequence is automatically preceded by a read
    of AIC_IVR and must be followed by a write in
    AIC_EOICR before exiting from the interrupt

15
Interrupt Prioritization (4/4)
16
Spurious Interrupt (1/2)
  • A Spurious Interrupt occurs when the ARM7TDMI
    processor is interrupted and the source of
    interrupt has disappeared when IVR is read
  • With any sources programmed to be level
    sensitive, if the interrupt signal of the AIC
    input is de-asserted at the same time as it is
    taken into account by the ARM7TDMI.
  • If an interrupt is asserted at the same time as
    the software is disabling the corresponding
    source through AIC_IDCR.

Operation
STR xxx_IDR
xxx
xxx
(0x018) Branch to routine
NIRQ
17
Spurious Interrupt (2/2)
  • The AIC is able to detect these Spurious
    Interrupts and returns the Spurious Vector when
    the IVR is read
  • The Spurious Vector can be programmed by the user
    when the vector table is initialized.
  • It is mandatory for the Spurious Interrupt
    Service Routine to acknowledge the Spurious
    behavior by writing to the AIC_EOICR (End of
    Interrupt) before returning to the interrupted
    software.
  • Spurious Interrupt Service Routine Sequence
  • Adjust and save lr_irq in stack
  • Write the End of Interrupt Command Register
  • Run a trace function if necessary
  • Returns by restoring LR directly in PC

18
AT91 Interrupt Control Strengths (1/2)
  • Atomic Interrupt Enable/Disable
  • Interrupt Controller Level
  • Peripheral Level
  • Resolve the problem of RISC
  • No Read/Modify/Write Instruction
  • Limit the Spurious Exceptions
  • Fully Secured
  • Spurious Interrupt Protection
  • Spurious Vector Register
  • Debugger Protection
  • Protect Mode avoids the debugger to start an
    interrupt
  • Automatic Vectoring
  • Speeds up the interrupt handler branching

19
AT91 Interrupt Control Strengths (2/2)
  • Highly Programmable Sources
  • External Sources
  • Edge/Level Selection
  • Internal Sources
  • Edge/Level Selection
  • Built In Test Support
  • Force any Interrupt Assertion
  • High Level Operating System Compatible
  • Source Status Register gives the current source
    number
  • Pending Interrupt Register
  • NIRQ, NFIQ Signals Mirror
