Classroom presentations to accompany Understanding Earth, 3rd edition

1
Classroom presentations to accompany
Understanding Earth, 3rd edition

• prepared by
• Peter Copeland and William Dupré
• University of Houston

Chapter 20 Plate Tectonics The Unifying Theory
2
Plate TectonicsThe Unifying Theory
Peter W. Sloss, NOAA-NESDIS-NGDC
3
Plate Tectonics

• Fundamental concept of geoscience
• Integrates from many branches
• First suggested based on geology and paleontology
• Fully embraced after evidence from geophysics

4
Mosaic of Earths Plates
Fig. 20.3
Peter W. Sloss, NOAA-NESDIS-NGDC
5
Plates

• Group of rocks all moving in the same direction
• Can have both oceanic and continental crust or
  just one kind.

6
Types of plate boundaries

• divergent mid-ocean ridges
• convergent collision zones volcanic
  arcs
• strike-slip San Andreas fault Alpine fault,
  N.Z.

7
Divergent plate boundaries

• Usually start within continents
• grow to become ocean basin

8
Features of Mid Ocean Ridges

• Central rift valley (width is inversely
  proportional to the rate of spreading)
• Shallow-focus earthquakes
• Almost exclusively basalt

9
Continental Rifts

• East Africa, Rio Grande rift
• Beginning of ocean formation (may not get that
  far)
• Rifting often begins at a triple junction (two
  spreading centers get together to form ocean
  basin, one left behind).
• Rock types basalt and sandstone

10
Rifting and Seafloor Spreading
Fig. 20.4a
11
Rifting and Seafloor Spreading Along the
Mid-Atlantic Ridge
Fig. 20.4a
Peter W. Sloss, NOAA-NESDIS-NGDC
12
Inception of Rifting Within a Continent
Fig. 20.4b
13
Inception of Rifting Along theEast African Rift
System
Fig. 20.4b
Peter W. Sloss, NOAA-NESDIS-NGDC
14
Nile Delta
Gulf of Aqaba
Gulf of Suez
Red Sea
Fig. 20.5a
Earth Satellite Corp.
15
The Gulf of California Formed by Rifting of Baja
California from Mainland Mexico
Fig. 20.5b
Worldsat International/Photo Researchers
16
Fit of the Continents
Fig. 20.1
17
Anomalous Distribution of Fossils
Fig. 20.2
18
Convergent boundaries

• New crust created at MORold crust destroyed
  (recycled) at subduction zones (i.e., the Earth
  is not expanding)
• Relative important densities
• continental crust 2.8 g/cm3
• oceanic crust 3.2 g/cm3
• asthenosphere 3.3 g/cm3

19
Convergent boundaries

• Three types
• oceanocean Philippines
• oceancontinent Andes
• continentcontinent Himalaya

20
OceanOcean

• Island arcs
• Tectonic belts of high seismic ?????
• High heat flow arc of active volcanoes
  (andesitic)
• Bordered by a submarine trench

21
OceanOcean Subduction Zone
Fig. 20.6b
22
OceanContinent

• Continental arcs
• Active volcanoes (andesite to rhyolite)
• Often accompanied by compression of upper crust

23
Ocean-ContinentSubduction Zone
Fig. 20.6a
24
ContinentContinent

• In oceancontinent boundaries convergence,
  collision convergence is taken up by subduction
  ( thrusting).
• Continentcontinent boundaries, convergence is
  accommodated by
• Folding (shortening and thickening)
• Strike-slip faulting
• Underthrusting (intracontinental subduction)

25
Continent-Continent Collision
Fig. 20.6c
26
Himalayas and Tibetan Plateau

• Product of the collision between India and
  Asia.
• Collision began about 45 M yr. ago, continues
  today.
• Before collision, southern Asia looked
  something like the Andes do today.

27
Himalayas and Tibetan Plateau

• Models
• Underthrusting
• Distributed shortening
• Strike-slip faulting

28
Spreading Centers Offset by Transform Boundary
Fig. 20.7
29
Wilson cycle

• Plate tectonics repeats itself rifting, sea-
• floor spreading, subduction, collision,
• rifting,
• Plate tectonics (or something like it)
• seems to have been active since the
• beginning of Earths history.

30
Examples of Plate Boundaries
O-C convergent
O-O divergent
C-C divergent
O-O divergent
O-O convergent
O-O divergent
O-C convergent
Fig. 20.8a,b
31
OceanContinent Convergent Boundaries
Fig. 20.8c
32
ContinentContinent Convergent Boundary
Fig. 20.d
33
Rates of plate motion

• Mostly obtained from magnetic
• anomalies on seafloor
• Fast spreading 10 cm/year
• Slow spreading 3 cm/year

34
Magnetic Anomalies
Fig. 20.9
35
Formation of Magnetic Anomalies
Fig. 20.10
36
Age of Seafloor Crust
Fig. 20.11
R. Dietmar Muller, 1997
37
Relative Velocity and Direction of Plate Movement
Fig. 20.12
Data from C. Demets, R.G Gordon, D.F. Argus, and
S. Sten, Model Nuvel-1, 1990
38
Opening of the Atlantic by Plate Motion
Fig. 20.13
After Phillips Forsyth, 1972
39
Rock assemblages and plate tectonics

• Each plate tectonic environment produces a
  distinctive group of rocks.
• By studying the rock record of an area, we can
  understand the tectonic history of the region.

40
Idealized Ophiolite Suite
Deep-sea sediments
Pillow basalt
Gabbro
Peridotite
Fig. 20.14
41
Model for Forming Oceanic Crust at Mid-ocean
Ridges
Fig. 20.15
42
Precambrian Ophiolite Suite
Pillow basalt
Fig. 20.16
M. St. Onge/Geological Survey of Canada
43
Volcanic and Nonmarine sediments are deposited in
rift valleys
Fig. 20.17a
44
Cooling and subsidence of rifted margin allows
sediments to be deposited
Fig. 20.17b
45
Carbonate platform develops
Fig. 20.17c
46
Continental margin continues to grow supplied
from erosion of the continent
Fig. 20.17d
47
Parts of an OceanOcean Convergent Plate Boundary
Fig. 20.18
48
Parts of an OceanContinentConvergent Plate
Boundary
Fig. 20.19
49
Continued Subduction
Fig. 20.20a
50
Continent Continent Collision
Fig. 20.20b
51
Approaching Arc or Microcontinent
Fig. 20.21a
52
Collision
Fig. 20.21b
53
Accreted Microplate Terrane
Fig. 20.21c
54
Microplate terranes Added to Western North
America Over the Past 200 Million Years
Fig. 20.22
After Hutchinson, 1992-1993
55
After Hutchinson, 1992-1993
Fig. 20.22
56
Tectonic reconstructions

• A variety of evidence traces the motion of
  continents over time

• Paleomagnetism
• Deformational structures
• Environments of deposition
• Fossils
• Distribution of volcanoes

57
Assembly of Pangaea
Fig. 20.23
I.W.D. Dalziel, 1995
58
Breakup of Pangaea
200 million years ago
Fig. 20.24a
After Dietz Holden, 1970
59
Breakup of Pangaea
140 million years ago
Fig. 20.24b
After Dietz Holden, 1970
60
Breakup of Pangaea
65 million years ago
Fig. 20.24c
After Dietz Holden, 1970
61
Breakup of Pangaea
Today
Fig. 20.24d
After Dietz Holden, 1970
62
Driving mechanism of plate tectonics

• Thought to be convection of the mantle.
• Friction at base of the lithosphere transfers
  energy from the asthenosphere to the lithosphere.
• Convection may have overturned asthenosphere 46
  times.

63
Other factors

• Trench pull
• Ridge push

64
Fig. 20.25a
65
Fig. 20.25b
66
Fig. 20.25c
67
Fig. 20.25d
68
Cross Section of Western Canada
69
What tectonics theory explains

• Distribution of earthquakes and volcanoes
• Relationship of age and height of mountain
  belts
• Age distribution of oceanic crust
• Magnetic information in rocks

70
Questions about plate tectonics

• What do we really know about convection cells
  in the mantle?
• Why are some continents completely surrounded
  by spreading centers?
• Why are tectonics in continental crust and
  oceanic crust so different?

71
Examining Deep-sea Drill Cores
Texas AM University
72
Age of the Ocean Basins
After map by Sclater Meinke
