Classroom presentations to accompany Understanding Earth, 3rd edition

1
Classroom presentations to accompany
Understanding Earth, 3rd edition

• prepared by
• Peter Copeland and William Dupré
• University of Houston

Chapter 18 Earthquakes
2
Part III Internal Processes, External Effects
3
Earthquakes
Eric Marti/AP Photo
4
Earthquakes

• earthquake movement of rock bodies past other
• fault locus of the earthquake movement
• faults come at all scales, mm to separation of
  lithospheric plates (e.g., San Andreas).

5
Earthquake terms

• focus site of initial rupture
• epicenter point on surface above the focus

6
Elastic Rebound Theory
Fig. 18.1a
7
Elastic Rebound Theory
Fig. 18.1b
8
Elastic Rebound Theory
Fig. 18.1c
9
Elastic Rebound Theory
Fig. 18.1d
10
1906 San Francisco Earthquake
Fig. 18.2
G.K. Gilbert
11
1906 San Francisco Earthquake
Fault Offset (2.5m)
Fault Trace
Fig. 18.2
G.K. Gilbert
12
Seismic Waves Radiate from the Focus of an
Earthquake
Fig. 18.3
13
Seismology

• Study of the propagation of mechanical energy
  released by earthquakes and explosions through
  the Earth.
• When energy is released in this fashion, waves of
  motion (like the effect of a pebble tossed into a
  pond) are set up in the rocks surrounding the
  source of the energy (the focus).

14
Seismic waves

• Waves are started because of initial tension or
  compression in the rock.
• Instruments used to measure these waves are
  called seismographs.

15
Global Positioning System (GPS) to Monitor Ground
Motion
Fig. 18.4
Jet Propulsion Lab/NASA
16
Seismographs Record Vertical or Horizontal Ground
Motion
Vertical
Horizontal
Fig. 18.5a,b
17
Modern Seismograph
Fig. 18.5c
Kinematics
18
Seismograph Record and Pathway of Three Types of
Seismic Waves
Fig. 18.6
19
Two kinds of waves from earthquakes

• P waves (compressional) 68 km/s. Parallel to
  direction of movement (slinky), also called
  primary waves. Similar to sound waves.
• S waves (shear) 45 km/s. Perpen- dicular to
  direction of movement (rope) also called
  secondary waves. Result from the shear strength
  of materials. Do not pass through liquids.

20
Comparison of P-wave and S-wave Motion
Fig. 18.7
21
Two Types of Surface Waves
Fig. 18.8
22
Time Lag Between S and P waves as with Distance
from Epicenter
Fig. 18.9a
23
Seismic Travel-time Curve
Fig. 18.9b
24
Locating the Epicenter
Fig. 18.9c
25
Locating an epicenter

• The difference between the arrival times of the P
  and S waves at a recording station is a function
  of the distance from the epicenter.
• Therefore, you need three stations to determine
  the location of an epicenter.

26
Measuring the force of earthquakes

• 1. Surface displacement
• 1964 Alaska earthquake displaced some parts of
  the seafloor by 50 ft.
• 1906 San Francisco earthquake moved the ground
  8.5 ft.
• 2. Size of area displaced
• Alaska 70,000 sq. miles

27
Measuring the force of earthquakes

• 3. Duration of shaking
• Up to tens of seconds
• 4. Intensity scales
• Based on damage and human perception
• 5. Magnitude scales
• Based on amount of energy released

28
Modified Mercalli Intensity Scale

• I Not felt
• II Felt only by persons at rest
• IIIIV Felt by persons indoors only
• VVI Felt by all some damage to plaster,
  chimneys
• VII People run outdoors, damage to poorly built
  structures
• VIII Well-built structures slightly damaged
  poorly built structures suffer major damage
• IX Buildings shifted off foundations
• X Some well-built structures destroyed
• XI Few masonry structures remain standing
  bridges destroyed
• XII Damage total waves seen on ground objects
  thrown into air

29
Measuring the force of earthquakes

• 5. Magnitude scales, based on amount of energy
  released
• Richter scale amount of energy received 100 km
  from epicenter
• largest quake ever recorded 8.9 (rocks not
  strong enough for more). Earthquakes less than
  M2 are not felt by people

30
Richter scale

• Richter scale amount of energy received 100 km
  from epicenter
• Largest quake ever recorded 8.9 (rocks not
  strong enough for more).
• Earthquakes less than M 2 are not felt by
  people.
• Scale is logarithmic
• Increase 1 unit 10 times greater shaking
• Increase 1 unit 30 times greater energy

31
Maximum Amplitude of Ground Shaking Determines
Richter Magnitude
Fig. 18.10
32
Richter Magnitude Versus Energy
Fig. 18.11
33
Before Fault Movement
Fig. 18.12a
34
Normal Fault
Fig. 18.12b
35
Thrust (reverse) Fault
Fig. 18.12c
36
Strike-slip Fault
Fig. 18.12d
37
First Motion of P wave Arrivals
Fig. 18.13
38
Distribution of earthquakes

• Not random
• Focused around plate margins (but also seen in
  plate interiors)

39
World Seismicity, 19632000
Fig. 18.14
40
Earthquakes Associated with Divergent and
Transform Margins
Fig. 18.15
41
Earthquakes Associated with Convergent Plate
Margins
Fig. 18.16
42
Damage due to earthquakes

• 1. Ground movement
• Earthquakes dont kill people,
• buildings kill people.
• 2. Fire
• 3. Tidal waves (tsunami)
• generate speeds up to 500800 km/hr
• in open ocean only 1m high but get
• larger when water gets shallow.

43
Damage due to earthquakes

• 4. Landslides
• All kinds of mass wasting
• Liquifaction sudden loss of strength of
  water-saturated sediment
• Buildings fall down intact
• 5. Flood
• Dam break courses of rivers change

44
Effects of the 1994 Northridge, CA, Earthquake
Fig. 18.17
1994 Chronmo Sohn/Sohn/Photo Resewarchers, Inc
45
Effects of the 1995 Kobe, Japan, Earthquake
Fig. 18.18
Reuters/Corbis-Bettmann
46
Generation of a Tsunami
Fig. 18.19
47
Destruction Caused by 1998 Tsunami, Papua New
Guinea
Fig. 18.20
Brian Cassey/AP Photo
48
Tsunami Barrier in Taro, Japan
Courtesy of Taro, Japan
49
Earthquake prediction

• Long termimprecise (can be done)
• Short termprecise (very difficult)
• We can't stop earthquakes, so we have to be
  prepared for them.

50
Seismic Hazard Map
Fig. 18.21
Courtesy of Kaye M. Shedlock, USGS
51
New Housing Built Along the 1906 Trace of the San
Andreas Fault
Fig. 18.22
R.E. Wallace, USGS
52
Demonstrating Earthquake Safety in Japan
Yves Gelie/Matriz
53
Recent Earthquakes of Special Interest
Izmit
Loma Prieta
Kobe
Northridge
Papua
Table 18.1
54
Stress Changes Caused by Regional Earthquakes in
Southern California (1979-1992)
55
Table 18.1
56
Table 18.1
