3.3Pathfinding Design Architecture

• ? ? Dan Higgins
• ??? ???

2
Abstract

• Hundreds of units could pathfind without bogging
  down the system
• How to split paths up over time?
• Keep the user believing that paths are computed
  instantaneously

3
Terms

• A machine
• Generic A engine described in article 3.2
• Unit
• Anything else that wish to pathfind from one
  point to another
• Node
• A node which encompasses information like
  Position, cost
• Pathfinding revolution
• Single iteration through the A engines main
  loop
• Out-of-sync
• It occurs in network game, the game ceases to be
  the same.
• Major problem for multi-player games

4
The Road to Cross

• The first of many hurdles to cross
• Game freeze plague of pathfinders
• In large map, A consume much time
• Time-sliced pathfinding
• Split the paths up over time
• In the real-time strategy game, giant maps,
  thousands of units
• by using a three-step path architecture
• Quick path
• Full path
• Splice path

5
Quick path

• To get unit moving
• To respond quickly
• High speed
• short-distance pathfinder
• To buy us time to compute the real path in the
  background
• How works?
• 10 revolution limit
• Five-tile path is generated

6
Full path

• The real deal
• Search thousands of A nodes to find the correct
  path
• Put the full path on the pathfinding queue

7
Splice path

• When quick path and full path are completed
• Path quick path full path
• Correct and Smooth out
• The errors made by the quick path
• High-speed path
• Same as quick path
• From the units current position
• To some point further down the complete path

8
Splice path
9
Priority paths

• What happens?
• If a unit gets to the end of its quick path
• before the full path is finished computing
• How it works?
• Takes the unit out of the pathfinding queue
• Sets its max revolutions cap a little bit higher
• Then finishes the path

10
Managing the paths

• Single revolution
• 1. Get the cheapest node
• 2. Look at its neighbors
• 3. Put the node on the closed list
• Path manager
• Use revolutions to balance performance
• Path manager update
• Consists of performing X number of overall
  revolution per game tick

11
Managing the paths

• Time-slicing technique
• Equal time
• Divide the revolutions by the number of paths in
  the queue
• All pathfinding engines get an equal amount of
  processing time each tick
• Progressive
• Start with a low number of max revolutions per
  tick
• Each time through the queue, this number should
  get larger
• Biased
• In order to get quick paths for the user

12
3.4 How to Achieve Lightning-Fast A
13
Abstract

• A optimization
• Implementing the pathfinding engine
• Focus on high-level and low-level optimization
• Speed up optimization

14
Optimization

• High-level
• Redefine search space
• Bound the amount of A node flooding
• Group pathfinding
• Low-level
• C optimization

15
For fast A

• Don't use STL
• while STL is amazing, pathfinding warrants a
  hand-written linked-list and hash-table system
• Memory pool
• Use limits on your pools to handle typical
  situations

16
For fast A

• Caching
• make a flags
• Flags array to indicate the state of each node
• The array is 1 byte per tile
• The incredible lookup speed and optimization

Clear unexamined Passable passable for
A Blocked not passable for A open in open
list Closed in closed list
17
For fast A

• Sliding window
• if you can't afford the memory to dedicate to a
  flags array
• try using a sliding window system

18
For fast A

• Hash table
• transform open and closed lists into hash tables
• Make sure to play with the hash function
• Cheapskate
• Use a cheap list
• Sorted heap structure - Slow insertion, Fast
  removal
• Unsorted list - Fast insertion, slow removal
• Cheap list
• List of 15 node that are the cheapest on the open
  list
• Search for the cheapest node on the Open list

19
For fast A

• Fast storage
• Used more memory
• Only one fast-storage pathfinder for entire game
• An array of pointers to nodes for searches
• long-distance pathfinders use
• STL map, hash_map, hash_set
• To store all nodes for fast lookups
