National Basin Delineation

1
National Basin Delineation

• Project Team Ken Howard
• Ami Arthur
• Gina Cox
• Dave Slayter
• Nathan Kuhnert
• Cooperative Institute for Mesoscale
  Meteorological Studies (CIMMS)/
• National Severe Storms Laboratory (NSSL)

2
National Basin Delineation

• Project objective
• To delineate flash flood basins using a
  minimum drainage area threshold of 2 mi2 for use
  in the Flash Flood Monitoring and Prediction
  (FFMP) program.

3
FFMP Basin Data Set Shapefiles

• / (main directory)
• 1) _orig_basins
• A polygon shapefile of the original small basins
  (before aggregation).
• 2) _aggr_basins
• A polygon shapefile of the aggregated basins
  within the radar coverage area. These are the
  basins for which the FFMP average rainfall values
  are calculated.
• This is one of the two shapefiles required by
  FFMP. Any basin customization should ultimately
  result in a file named _aggr_basins with the
  specific attributes required by FFMP.

4
FFMP Basin Data Set Shapefiles

• 3) _str_gen
• A polyline shapefile of the synthetic stream
  lines generated from the DEM.
• 4) _bins
• A point shapefile of the radar bin center points
  with the associated Pfafstetter basin IDs
  (aggregated).
• This is the second shapefile required by FFMP.
• 5) _nhd_rch
• A polyline shapefile of stream lines from the
  National Hydrography Dataset (NHD).
• 6) _reg_nhd
• A polygon shapefile of NHD waterbodies including
  lakes, reservoirs, ponds, and swamps.

5
FFMP Basin Data Set Shapefiles

• /custom/
• 1) _ref_basins
• A polygon shapefile of the original basins
  (before aggregation) with the necessary
  hydrologic connectivity attributes for use with
  the AMBER Basin Customization Extension in
  ArcView.
• 2) _ref_sl
• A polyline shapefile of the synthetic stream
  lines (generated from the DEM) with the necessary
  hydrologic connectivity attributes for use with
  the AMBER Basin Customization Extension. There
  is a one-to-one relationship between stream lines
  in this shapefile and basins in the
  _ref_basins shapefile.

6
FFMP Basin Data Set ShapefilesAttributes in
_aggr_basins

• a) Pfaf_id
• 13-character Pfafstetter basin ID
• b) Streamname
• Stream name as available from the NHD
• c) Huc
• 8-digit HUC ID
• d) Huc_name
• Name of the 8-digit HUC

7
FFMP Basin Data Set ShapefilesAttributes in
_aggr_basins

• e) X-outlet
• Longitude of the basin outlet
• f) Y_outlet
• Latitude of the basin outlet
• g) State
• Two-character state abbreviation (based on basin
  outlet)
• h) CWA
• Three-character county warning area ID (based on
  basin outlet)

8
FFMP Basin Data Set ShapefilesAttributes in
_aggr_basins

• i) Countyname
• Name of the county
• j) FIPS
• Five-character FIPS ID
• k) RFC
• Five-character River Forecast Center ID (based on
  basin outlet)
• l) Modified
• Flag to indicate whether a basin has been merged
  with other basins. 0 indicates a basin in its
  original state, 1 indicates a merged basin.

9
FFMP Basin Data Set ShapefilesAttributes in
_aggr_basins

• m) Reservoir
• Flag to indicate whether a basin intersects a
  lake or reservoir according to those water bodies
  included in the NHD. 0 indicates no intersection
  with a reservoir, 1 indicates an intersection.
• n) Area_sq_mi
• Basin area in square miles
• o) Flow_acc
• An approximate flow accumulation value (in
  thousands of grid cells).

10
FFMP Basin Data Set ShapefilesAttributes in
_aggr_basins

• p) X_centroid
• Longitude of the basin centroid
• q) Y_centroid
• Latitude of the basin centroid

11
FFMP Basin Data Set ShapefilesAttributes in
_orig_basins

• The _orig_basins shapefile contains the same
  attributes as the _aggr_basins shapefile,
  with one additional field
• Pfaf_aggr
• Pfafstetter ID of this basin in the
  _aggr_basins shapefile
• In addition, the _orig_basins Pfafstetter ID
  field is named Pfaf_orig to distinguish it from
  the Pfaf_id field in _aggr_basins.

12
FFMP Basin Data Set ShapefilesAttributes in
_bins

• a) Azimuth_dg
• Azimuth of the radar bin center point in degrees
• b) Range_km
• Range of the radar bin center point in kilometers
• c) X_coord
• Longitude of the radar bin center point
• d) Y_coord
• Latitude of the radar bin center point
• e) Pfaf_id
• Pfafstetter ID of the associated FFMP basin
  (aggregated)

13
FFMP Basin Data Set ShapefilesAttributes in
_ref_sl and _ref_basins

• These two shapefiles have the same attributes as
  the _orig_basins shapefile plus the following
  hydrologic connectivity attributes
• a) Basin_id
• The integer basin ID assigned by the AMBER Basin
  Customization Extension
• b) Parent_id
• The Basin_id of the immediate downstream basin
• c) Length_mi
• Length of the synthetic stream reach in square
  miles
• d) Flow_acc
• Area in square miles of the upstream contributing
  drainage area
• e) Upstream
• The Basin_id of the immediate upstream basin(s)

14
FFMP Basin Data Set Shapefiles
Hydrologic Connectivity Attributes
15
FFMP Basin Data Set ShapefilesProjection
Information

• Projection Geographic (lat/lon)
• Datum NAD83
• Units Decimal Degrees
• Spheroid GRS80

16
FFMP Basin Data Set Shapefiles
The _orig_basins shapefile contains all small
basins in the HUCs covering the area. There is
one stream reach per basin.
17
FFMP Basin Data Set Shapefiles
The _aggr_basins shapefile contains
aggregated basins within the radar coverage area.
There may be multiple stream reaches per basin.
18
FFMP Basin Data Set Shapefiles
The NHD reach and water body shapefiles are
included for all HUCs covering the area. These
are a good reference for "the real world".
19
FFMP Basin Data Set Shapefiles
The _ref_basins and _ref_sl shapefiles
contain the hydrologic connectivity attributes
necessary for use with the AMBER Basin
Customization Extension in ArcView.
20
Basic Basin DelineationProcedure

• Begin with a Digital Elevation Model (DEM)
• A digital map of terrain
• Gridded or "raster" format
• Rows columns of elevations
• Integer elevation values

21
How are DEMs created?
Created from various scale maps.... 124000 11000
00 1250000
22
A Bunch of Blocks to Represent the Earth
23
A DEMWhat the Computer Sees What You See
24
Other Views
25
DEM (90-meter)
26
Basins Derived from the 90-meter DEM
27
DEM (30-meter)
28
Basins Derived from the 30-meter DEM
29
The National Elevation Dataset (NED)

• Produced at the USGS EROS Data Center
• A 30-meter resolution seamless mosaic of
  7.5-minute DEMs for the U.S.
• Base DEMs have been edge-matched to ensure there
  are no gaps or missing data

30
The National Elevation Dataset (NED)
Filtering techniques have been applied to
minimize artifacts from the original DEM creation
methods.
31
The National Elevation Dataset (NED)
The NED is a dynamic dataset-updates are made
when better quality or higher resolution DEMs are
available.
32
NSSLs Partnership with the USGS EROS Data Center

• NSSL assisted EROS with the blind pass"
  processing for Stage 1 of their Elevation
  Derivatives for National Applications (EDNA)
  project.
• This involved producing a hydrologically
  conditioned (filled) DEM, flow direction and flow
  accumulation grids, slope, contours, basins, and
  synthetic streams from the NED.
• Access to the NED and basin delineation scripts,
  along with the guidance and expertise of several
  EROS scientists ensured the highest quality basin
  delineation attainable from a blind pass process.

33
Begin with the USGS 8-Digit Hydrologic Cataloging
Units of the U.S.
Delineation Methodology
34
8-digit Hydrologic Unit Code (HUC) basin with a
25000-meter buffer.
Delineation Methodology
NED tiles covering the buffered area are merged
and clipped.
35
Delineation Methodology
The DEM must be projected from Geographic
coordinates to the Albers Equal Area projection
with units in meters. Note Basins should not
be delineated in Geographic coordinates (lat/lon)
because flow direction may be incorrectly derived.
36
Delineation Methodology

• Projection Information (CONUS)
• Projection Albers Equal Area
• Datum NAD 83
• Units Meters
• Spheroid GRS1980
• Parameters
• 1st standard parallel 29 30 0.000
• 2nd standard parallel 45 30 0.000
• Central meridian -96 00
  0.000
• latitude of projections origin 23 00 0.000
• false easting (meters) 0.00000
• false northing (meters) 0.00000

37
Delineation Methodology

• Filling the DEM
• Sinks in the DEM are filled to remove small
  imperfections in the data.
• A sink is a cell with undefined drainage
  direction (all neighboring cells are higher
  elevations).
• Sinks are filled to a point where water will flow
  out of the cell.
• The pour point is the boundary cell with the
  lowest elevation for the contributing area of a
  sink.

38
Delineation Methodology

• Flow Direction
• Derived from the filled DEM
• Each cell flows to a neighboring cell based on
  the steepest slope.

32
64
128
16
1
2
4
8
39
Delineation Methodology
Flow Direction Grid
40
Delineation Methodology
Flow Accumulation

• Note that each grid cell flows into another grid
  cell and so forth.
• One could tally or keep track of the total number
  of grid cells that flow into each downstream
  grid cell.
• This is generally known as a flow accumulation
  data set.
• Grid cells with high flow accumulation values are
  areas of concentrated flow and are identified as
  stream channels according to the specified flow
  accumulation threshold.
• Grid cells with flow accumulation values of zero
  are topographic highs or ridges.

This grid cell has a flow accumulation value of
15.
41
Delineation Methodology
Flow Accumulation Grid
42
Delineation Methodology
Stream Network

• Derived from the flow accumulation grid.
• Based on the specified minimum flow accumulation
  threshold.
• Cells with flow accumulation greater than the
  threshold are designated as "stream channel"
  cells and will form the stream network.
• A minimum flow accumulation threshold of 5000
  grid cells (1.74 mi2) was used to delineate the
  FFMP basins.

43
Delineation Methodology
44
Delineation Methodology
Outflow Points

• Outflow points are the cells with the maximum
  flow accumulation along a stream segment.
• Derived from the flow accumulation and stream
  link grids.

45
Delineation Methodology
Catchments

• Basins are delineated to each outflow point.
• Derived from the flow direction and outflow point
  grids.

46
National Basin Delineation Project Related
Websites

• National Basin Delineation Project
• http//www.nssl.noaa.gov/wrd/wish/basins
• National Elevation Dataset (NED)
• http//ned.usgs.gov
• Elevation Derivatives for National Applications
  (EDNA)
• http//edna.usgs.gov
• National Hydrography Dataset (NHD)
• http//nhd.usgs.gov
• Pfafstetter Basin Codification System
• http//edcdaac.usgs.gov/gtopo30/hydro/P311.html
