Title: Formation, structure and evolution of the Giant Planets


1
Formation, structure and evolution of the Giant
Planets
  • G.Magni

2
Preliminary questionWhat is a giant
planet?Where it is placed, from stars to
terrestrial planets?Fast (and rough)
answeran object having mass between 0.1 and 10
Jupiter masses, with a gaseous envelope, rich in
H and He, gravitationally bound the the central
star
3
Summary Questions
  • What is the general subject and the specific
    plot of the play Formation of giant planets
    starting from a protostellar disk?
  • What is the subject of the act Formation and
    evolution of OUR Jovian planets?
  • What can we argue from the big amount of
    experimental data (space missions, observations)?
  • How important is the effect of the observative
    selection effects (statistics on extrasolar
    planets, planetary surfaces much better known
    than the internal)?
  • How are the main physical processes driving the
    GP formation?
  • What do we know about their history?
  • What we expect from the Cassini mission and from
    the future missions to better understand the GP
    formation?

4
  • Summary
    Problems
  • Why it is difficult today to develop a general
    theory like a Theory of the planets?
  • At present
  • 1) Only one planetary system well known (our
    one)
  • about 150 extrasolar planets strongly
    affected by observational selection effects
    (large mass, small distance from the central
    star, high eccentricity values privileged)
  •
  • Formation, evolution and structure of the planets
    involve an extremely large amount of physical
    processes (neutral and ionized high pressure
    matter, plasma physics, phase transitions,
    chemical equilibrium and kinetics, interaction
    between solid particles.)
  • Unlike star formation, the growth of a planet
    takes place in matter that is chemically and
    physically strongly disomogeneous (gas and solid
    particles, condensation and sublimation of
    volatiles, accretion of gas around solid bodies

5
4) In a planetary sistem, planets do not form as
single independent events, but their
evolutive tracks are strictly correlated one
another 5) The detectability and observability
of a growing primordial planet is very
difficult due to its low intrinsic luminosity ,
and has a short temporal window 6) The
evolutive timescales of the central star and of
the protoplanetary disk strongly influence
planetary formation and evolution. Slightly
different initial and boundary conditions can
produce (or inhibite) very different
planetary systems   7) What is missing up today
is, before of all, a good statistics of
extrasolar planets, a better knowledge of the
GP interiors and more informations on the
external Solar System (Kuiper Belt objects)
6
1st step Our Solar Systemglobal
characteristicsregular propertiesregular
trendscomparison with the known sample of
extrasolar planets
7
Formation process driven by long scale lenght
processes (gravitation?). The mutual interaction
among the growing planets during their formation
had to be not very important No similar
information for extrasolar planets
8
SS Jovian planets, low eccentricity ExoP
strongly scattered eccentricity (collisional
processes) eccentricity growing with
distance (selection effect?)
9
(No Transcript)
10
SS two classes of planets, mass vs.
distance ExoP large masses , slowly growing with
distance (selection effect, planetary migration)
11
Virtual mass present massHHevolatiles ? Solar
nebula abundances Virtual mass distribution ?
regular trend (except Mars)
12
Snow line in the minimum mass SN where
Psat(H2O,ice)P(SN)
There is a correlation among Giant Planets, snow
line and capture of volatiles
13
In GP is present an increase of the density
gradient in their central regions Continuous
increase of Z (and/or Y) towards the center
(sedimentation of unsoluble elements) Or jump of
Z to larger values (presence of a rocky-icy core)
14
Timescale constraints
  • About 50 of the solar type young stars is
    rounded by disks or rings, 30 of them having
    masses compatible with our Planetary System
  • It is also present a well defined correlation
    between mass of the disk and age of the disk
    itself
  • However, it is very difficult and statistically
    unlikely, at least with the present observational
    tecniques, to directly observe a giant planet
    during its formation (only two hot Jupiters
    very close to the stars observed up today)
  • The constraint on timescales coming from the
    observation of protostellar disks ranges from
    Tdisk lt105 yr (before the onset of the T-Tauri
    phase ) with Mdust100MEarth to Tdisk gt107 yr
    (b Pictoris disk) with strong dust depletion,
    Mdustlt 0.1MEarth

15
(Montmerle, 1997)
16
(No Transcript)
17
Chemical constraints
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
  • The composition of the gas of GP suggests that
  • it comes from the primordial circumsolar disk
    (D/H for Jupiter and Saturn)
  • but with depletion (gravitational?) processes
    for Helium,
  • a substantial enrichment of refractories
    (capture of solid bodies) and
  • an enrichment (at least for Jupiter) of volatile
    noble gases (capture of cold solid bodies)

22
Effect of metallicity
In protostellar disks with high Z there is a
larger amount of refractory materials to form
protoplanetary cores and /or a higher opacity
that can influence planet formation. Besides,
more and more planets could have migrated up to
fall into the star. The litium overabundance is
instead a direct evidence of this last process
23
  • The steeper slope for GP can be
  • produced by
  • different physical conditions in different
    regions of the SN during planet formation
    (dependence on Sun distance of the mass accretion
    flux from the interstellar protosolar cloud ?
    Different turbulent regimes?)
  • Lower accretion efficiency going outwards due to
    depletion of the SN (larger accretion times?
    Perturbation by previously formed inner planets?)

sM(virtual)/S (feeding zone)
The distribution is different (double slope) for
terrestrial planets and GP
24
R(SN)40 AU
The best fit between present specific angular
momentum of the planets (mainly from GP) and of
SN defines a power law index for sigma of about
1.5 that is generally adopted as a standard
value
25
The inclination of the spin axis of the sun can
be explained by a single impact of an object of 6
10 M(earth) (orbital migration) or 8 13
M(earth) capture from the Asteroids Belt
(resonant ejection)
26
The mass of the impactor is compatible with the
accretional history of the planetesimals and of
the evolution of protoplanetary embryos
(Wetherill, 1988, )
27
  • Formation of giant planets seems to have at least
    two different mechanisms. The first produces
    planets with nearly circular orbits, low
    inclinations and eccentricities, regular trend in
    mass, distance and physical properties (up today,
    statistics only on our SS). The second brings to
    a population with very irregular distribution in
    physical and orbital parameters (strong selection
    effects) .
  • In SS it is present a bimodality in the
    distribution of density, momentum of inertia and
    volatile abundances. The capture of gas starts
    abruptly, and then becomes less efficient, going
    outwards.
  • There are many indications about the presence of
    a central core in all the GP

28
Formation models must respect and explain
  • temporal constraints
  • mass distribution
  • Existence of GP with very different values of
    distance from the central star and of
    eccentricities
  • Abundance anomalies. General enrichment of C N
    O(?) with radial gradient. Helium depletion in
    Jupiter(?) and Saturn. D/H distribution
  • Presence of central cores and relative formation
    mechanism
  • Presence, structure and chemical properties of
    systems of regular satellites,

29
Physical mechanisms for Giant Planet formation
  • The G.P. formation is the most important
    gravitational phase transition after the birth
    of the star and of its gasdust quasi-keplerian
    disk

Constraints Lifetime of the disk 106 107 yr
due to dissipative mechanisms -turbulent
viscosity
-stellar wind
-tidal mass depletion due to
previously formed
planets or
companions in multiple systems
30
Stability and instability factors in a Keplerian
disk
  • Instability autogravitation inside gas and
    solid components
  • dissipative processes 1
    radiative cooling

  • 2 turbulent angular momentum transport

  • 3 sticking processes among solid
    particles

  • 4 condensation of volatiles in ices
  • Stability 5 rotation a) non inertial forces
    transfer angular momentum referred
  • to the Sun in angular
    momentum referred to the protoplanet
  • (centrifugal barrier)
    b) differential rotation in SN disperses
  • regions of the disk at
    different distances from the Sun and acts
  • against thei
    aggregation
  • 6 thermal pressure grows
    during contraction
  • Gas gt processes 1 2 4 5 6
  • Solid particles gt all the processes except 6

31
A typical protoplanetary disks is in principle
stable. If the selfgravitation is low, in every
part of the disk there is a nearly exact
compensation among gravity of the star,
centrifugal forces and pressure. Small or large
scale radial and vertical motions can be present
(convection, turbulence, drag on the solid
particles, meridional circulation due to the weak
gas selfgravitation), but they do not destroy
the global equilibrium state. Density fluctuation
are quickly merged in the gas with a
timescale unless the mass of the disk is large
enough.
  • Two possible accretion mechanisms for GP
  • Gas gravitational instability
  • Nucleated instability

32
Stability of a Keplerian disk
timescales of thermal rearrangement, keplerian
dispersion and free-fall contraction of the
instability
33
(optically thick disk)
  • At Jupiter distance
  • At Saturn distance
  • The gas gravitational instability needs massive
    protoplanetary disks and produces massive giant
    gaseous planets
  • Radial perturbations can fragment and give
    raise to several large protoplanets in similar
    orbits, in mutual interaction and competition
    (spreaded orbital elements, migration towards
    regions very close to the central star)
  • Probable formation mechanism for a large part of
    the observed extrasolar planets

34
Time evolution of gas instabilities
In a rotating disk, the exponential growth of the
instability is slowed down by adiabatic
compression, angular momentum transfer due to
noninertial forces and shock dissipation in
density waves. The evolutive time passes from
the free-fall time
to that of radiative cooling
35
More realistic computations, using N-body codes
with SPH methods and 106 particles (Mayer et
al.,2002) or 3D hydrodynamical simulations
(Boss,2001) find that gravitational instabilities
can grow and survive also with 1 lt Q lt 1.75, and
M(SN) lt 0.1 M(Sun) if the SN is cold enough The
evolution, due to computing limitations, is
followed for few hundreths of years and is driven
from radiative losses and strongly dependent on
physical assumptions (energy transport,
opacity) The results are not significantly
different from the simple first order approach,
but seem well describe, specially in Mayers
approach, the possible formation and evolution of
extrasolar massive giant planets (survival of
several GP around the star after the first
strongly energetic dynamical phase) The
formation of the cores via sedimentation of
refractory elements requires the clumps to be
convectively stable for several thousands of
years
36
Mayer et al.(2002) time evolution of gas
instability for Qmin1.75 (upper) and Qmin 1.4
(lower) after 160 and 350 years. rmax20AU and
MSN0.08MSun
Boss (2002) time evolution of gas
instability,after 304 years, Qmin1.3 (upper)
and local isothermal conditions (upper), and
after 345 years, Qmin1.1 and local adiabatic
conditions (lower). rmax20AU and MSN0.08MSun
37
Nucleated Instability
  • Current theories on the evolution and accretion
    of the solid component of SS (Safronov, 1962
    Wetherill, 1988) make likely the presence, in the
    GP region of bodies of several Earth masses,
    growing with timescales from 105 a 107 years
  • Cores are formed first, through an accumulation
    mechanism, similar to the mechanism generally
    accepted for the formation of the terrestrial
    planets
  • As the core grows larger, more and more nebular
    gas is collected in its sphere of influence,
    still holding quasi hydrostatic equilibrium,
    until a large and massive envelope is formed.
    The accretion rate of gas is nearly proportional
    to the accretion rate of the core

38
  • When a critical mass is reached, the static
    solution for the structure of the gas around the
    core is no more possible, and a dynamical phase
    begins.
  • The gas accretion rate depends on the feedback
    mechanisms that drive the rearrangement of the
    boundary of the gaseous envelope the gas infall
    inside the protoplanets sphere of influence
    (Hill lobe).
  • The feedback process essentially drives the
    accretion timescale
  • At the same time, also planetesimals are
    collected, and they contribute to the core
    heating

39
Hill surface defined by the potential of the
total force
Where the first term is the gravitational one due
to the protoplanet, the second is due to the Sun,
and the third is the centrifugal term coming from
the frame rotating with the protoplanet. The
accretion boundary is the highest closed isoline
around the protoplanet
40
  • Perri and Cameron (1972), Mizuno (1980), Wuchterl
    (1993), Pollack and Bodenheimer (1996) and others
    demonstrate that a static equilibrium structure
    for a gaseous envelope around a core, cannot
    exist beyond a critical value of the core mass,
    for predefinited external boundary conditions.
  • The critical core mass value is reached when the
    selfgravitation energy of the gas becomes
    comparable with the gas-core gravitational
    energy, and depends on the thermodynamical
    properties of the gas, on the energetic balance
    with the surrounding SN and on the opacity of the
    gas ond of the dust. It can change, depending on
    the assumptions, also for two orders of
    magnitude.
  • Even if more and more gas begins to be captured,
    if the critical value is overcome, the time
    evolution of the accretion phase it is not still
    completely clear and is strongly model dependent.

41
From Stevenson (1988)
42
(No Transcript)
43
  • A gap between the envelope limit and the boundary
    of the Hill lobe is produced, that can be
    refilled by the gas of the SN. A dynamical phase
    stars up and the timescale becomes substantially
    smaller than the growth timescale of the core
  • The dynamical phase is driven by the capability
    of the envelope to rearrange its structure. This
    depends on the opacity and on the luminosity
    that, growing, can again allow a nearly
    hydrostatic equilibrium structure.
  • The increase of luminosity brings a loss of
    energy and a contraction of the envelope. So the
    accretion cannot be stopped.

44
  • Strong disequilibrium phases can be anyhow
    possible (Wuchterl, 1993), and shock waves can
    slow, but probably not stop the accretion
    process.
  • The accretion timescale depends essentially on
    the cooling time of the envelope (Safronov.1969).
    The envelope cutoff due to the Hill lobe causes a
    large variety of different equilibrium models
    with constant envelope radius Re RH but very
    different cooling times (103 105 years).
  • The accretion process is strongly nonradial
    (asimmetry of the gravitational potential,
    velocity gradient of the gas in the SN,
    noninertial forces due to rotation). The 3D
    structure of the process can strongly affect the
    evolution and the relative timescales.

45
Nucleated instability accretion models
  • Pollack et al. (1996) use an evolutionary model
    having three major components
  • The growth of the protoplanet is performed
    following the simultaneous growth of the central
    core by planetesimals capture and of the gaseous
    envelope due to the rearrangment of its external
    boundary
  • The capture of planetesimals is computed with a
    central large body surrounded by a swarm of small
    bodies in the feeding zone, in the restricted
    three body approximation
  • The structure of the protoplanet is integrated
    assuming spherical symmetry and quasi-hydrostatic
    equilibrium
  • The (several) free parameters are adjusted to fit
    the properties of the Giant Planets and the
    constraints coming from protostellar disks (heavy
    elements overabundances and disk survival
    timescale).
  • In Pollack et al.s model three main evolutionary
    phases can be identified 1) tlt5 105 yr -
    planetesimals accretion dominates 2) 5 105lttlt107
    yr - gas and planetesimals are comparable 3)
    t107yr runaway gas and planetesimals capture
    holds. This for Jupiter and Saturn. The accretion
    of Uranus and Neptune was terminated during the
    phase 2), as a result of the SN dissipation

46
Time dependence of gas and planetesimals
accretion rate. Planetesimals capture runaway
at t0 and gasplanetesimals runaway at t8 106
yrs (Pollack et al., 1996)
47
  • The main limits of the models come from the large
    amount of initial assumptions, not all
    completely justified. Moreover, the gas accretion
    at the boundary of the Hill lobe is evaluated in
    spherical simmetry and without hydrodynamical
    effects. So, the runaway accretion is a
    mathematical artifact

48
  • A thorough study of the critical core mass and of
    its dependance on physical quantities and
    processes like opacity and convection, together
    with hydrodynamical calculations of the
    evolution of a protoplanet after the onset of
    the core nucleated instability have been
    performed by Wuchterl (1991, 1993, 1995, 2000).
  • Wuchterl finds that
  • The critical mass value depend strongly on the
    cooling process into the envelope. For purely
    radiative transport, the critical mass is
    independent on nebula density and mass accretion
    rate, and depends inversely on opacity and
    molecular weight (icy cores and Z-depleted
    nebulas have lower critical mass values). If
    convection holds, the critical mass depends
    inversely on molecular weight and density, and
    again does not depend on accretion rate

49
  • After the onset of the CNI the envelope starts
    to pulsate (driven by H2 dissociation) after a
    short contraction phase. This pulsation-driven
    wind depends directly on the nebula density. For
    more massive disks, a large convective region in
    the envelope appears and pulsation can be
    damped.
  • The difference in envelope mass between Jupiter,
    Saturn, Uranus and Neptune derives frome this
    density dependent oscillation-damping mechanism.
  • In spite of the complex physics treatment in
    Wuchterls models, (also time dependent
    convection), the main limitations in its results
    come from
  • Spherical symmetry
  • In the real SN the accretion of the envelope is
    very far from spherical symmetry
  • Spherically simmetrical boundary conditions can
    be valid for a model in quasy-hydrostatic
    equilibrium, but can strongly bias the treatment
    of fast energetic processes like shocks or
    pulsations

50
Nucleated instability 3D accretion model
  • The model (Coradini and Magni, 1997, 2004)
    intends to treat the problem of the accretion
    onto the growing planet in the most possible
    general way, even if the physical treatment must
    be simplified. So
  • A 3D mesh simulates the rotating Keplerian
    feeding zone, with the structure of the grid that
    takes into account the two main gravitational
    attractors (Sun and protoplanet)
  • Spherical symmetry is abandoned everywhere, and
    the Hill lobe is only virtually present. Boundary
    conditions are only in the external edge of the
    SN, in radial and vertical direction, and in the
    mesh point corresponding to the protoplanet.
    However, quasi-hydrostatic equilibrium spherical
    structures for the envelope are computed at any
    time step, to define standard physical parameters
    as protoplanet mass, luminosity, effective
    temperature, effective radius of the region in
    quasi-equilibrium.

51
  • Disk-like structures can form around the
    protoplanet, that can be identified as primordial
    satellitary disks.
  • The structure of the protoplanet is computed
    taking into account radiative and convective
    transport, and the luminosity is produced by the
    energy released by the infalling
    gasplanetesimals, in the approximation of
    homologous variations of the structure.
  • The thermal structure of the SN is computed with
    a simplified treatment of adiabaticradiative
    exchanges

52
The grid
53
Jupiter
Saturn
S
J
54
Surface density in the central plane of SN at the
end of the accretion ( exploded view)
55
Accretion time
56
Mass inside the Hill lobe
Luminosity
57
  • Envelope radius
    Accretion time and
    cooling time

58
(No Transcript)
59
Area where the gas has prograde motion ?Accretion
disk
60
Mp 0.25 MSaturn
Mp 0. 5 MSaturn
Mp MSaturn
61
  • Results (3D model, Saturn)
  • - A core of 15 MEarth accretes gas up to
    MSaturn in 104 years for a Minimum Mass
    Solar nebula
  • - The pulsational instability mechanism seems
    to be not able to stop the accretion vgtcs
    well inside the envelope and in the strongly
    distorted flow paths near the Hill boundary,
    the gas finds in any case channels to fall onto
    the core
  • The cooling time drives efficiently the accretion
    process, and flattens the curve (accretion time
    SN mass).
  • Runaway phases
  • can rise, but they are strongly model dependent

62
What stops the accretion?
  • Growing the protoplanet, the region from where
    the gas can be collected enlarges,
  • and more and more matter could reach in principle
    the Hill lobe of the protoplanet
  • For M(SN)0.02M(Sun), the feeding zones contain
    matter enough for several
  • planets like Jupiter or Saturn.
  • Several stopping mechanisms are possible
  • Dissipation and/or photoevaporation of the SN (
    Safronov, 1969, Shu, 1982)
  • Pulsational instability of the outer regions of
    the envelope
  • Slowing down of the accretion efficiency due
    overheating of the envelope (runaway growth of
    outer planetesimals accretion due to planetary
    migration)
  • Tidal confinement of the feeding zone and
    formation of a gap gas depleted around the
    protoplanet

63
Evolution of Giant Planets
64
  • The way to the present state, asoon as the
    gaseous envelope has been accreted, is stillo
    long for a giant planet
  • Giant planets, in their primordial evolutive
    phases, coexist with the disk where they have
    been born.
  • At the same time, several planets already formed
    can mutually interact
  • The central star is still not in Main Sequence
    and can be strongly active (bipolar flows,
    T-Tauri wind)
  • The evolution of the young planet is so
    characterized by cooling and contraction of its
    envelope, and orbital changes that eventually
    drive it into the atmosphere of the star or
    towards the interstellar space

65
Gap formation
  • Papaloizou and Lin (1984) and Bryden et al.(1999)
    have firstly proposed that the accretion could be
    stopped by the formation of an annular gap that
    surrounds the orbit of the protoplanet, where the
    gas is strongly depleted and the accretion slowed
    for several orders of magnitude.
  • Later on, the problem of gap formation has been
    examined by several authors (Artymowicz and
    Lubow, Winters et al., for example),
    investigating which the constraints about the
    main physical parameters (mass, density, thermal
    transport, turbulence) of the gas disk and of the
    growing planet that can produce the onset of a
    nearly gas free region around the protoplanet

From Bryden et al., 1999
66
Interaction planet-disk
  • Tidal interaction of a planet with the disk
    leads to the formation of spiral density
    perturbations that, because of the differential
    rotation, lead the planet in the inner region,
    and trail it in the outer region. Inner disk
    loses and outer disk gains angular momentum.
  • Thus, the planet can progressively deplete of
    gas and solid matter an annular region along its
    orbit.
  • The angular momentum exchange is asymmetric
    and the net balance can produce a torque that
    usually drives the planet to migrate inward.

Coradini and Magni, 2004
- There is a strong connection between planet
migration, gap onset, physical and
thermodynamical conditions inside the
protoplanetary disk, and evolutive history of the
central star, that strongly influence the
evolution of the Giant Planets (see extrasolar
planets)
Lubow et al., 1999
67
  • If waves experience damping of any kind their
    energy and angular momentum get transferred to
    the disk fluid disk evolves
  • The dissipation takes place in the farther
    branches of the density waves, where non-linear
    growth holds and shock phenomena can be active
  • Dissipative mechanisms can be turbulent viscous
    shear or radiative cooling of the fronts of the
    waves, heated by gas compression .
  • Both the cooling process and viscous dissipation
    are scarcely efficient in the linear region of
    the wave, but can produce a significant
    transport of energy and angular momentum along
    the nonlinear branches
  • Turbulent viscosity is difficult to describe in a
    correct way because it is difficult to find and
    correctly describe the energy source that feeds
    it (convection, MHD instabilities, gas-dust
    interface). The most common way to model it is
    through the a-parameter of the Shakura-Sunyaev
    model

68
Feedback mechanisms
  • - In an inviscid disk the characteristic
    timescales of gap opening and tidal migration are
  • - While planetary torques repel disk away, planet
    might migrate out of the forming gap. This is
    important for small planets
  • - Feedback from the surface density
    inhomogeneities slows the migration facilitating
    gap opening (Ward Hourigan89) but the non
    conservation of vertical hydrostatic equilibrium
    near the edges of the gap fills the gap.
  • - Viscosity opposes gap formation by filling the
    gap
  • The theory of gap opening requires that three
    simultaneous effects have to be considered
    simultaneously
  • Realistic density wave damping
  • Planetary migration
  • Contribution of feedback mechanisms

-
69
Important timescales

70
Gap formation in an inviscid disk
71
(No Transcript)
72
(No Transcript)
73
Numerical models
From Balbus et al.,2003
From Bryden et al.,1999
From Trilling et al.,1999
Numerical models have studied with sophisticated
methods (SPH smoothed particles, 2D and 3D
hydrodynamics, MHD turbulence the process
gapmigration in the phase space of the physical
parameters governing them. While it is difficult
to give a direct correlation between a regular
system like our one and the rearrangement, driven
by the gapmigration process, of the primordial
planetary system (Bryden et al.,1999, Balbus et
al.,2003), the large variety of dynamical and
physical characteristics of extrasolar planets
well agree with the large spectrum of evolutive
patterns produced by this process (Tirring et
al.,1999)
74
Migration driven by secular perturbations
  • The dynamical evolution of GP does not end when
    the first gas driven phase (gas and/or
    nucleated instability, gap formation and tidal
    migration) is exhausted due the dissipation of
    the SN gas, leaving a planetary system possibly
    quite different from that we know today. The
    rearrangement of the system can be produced
    again by interactions among solid bodies
    (planets residual planetesimals disk) with
    timescales of 106 108 years.
  • All the models studyng this process are based on
    N-bodies numerical integrations, and choose a
    certain number of free parameters (number,
    masses, initial distances of planets, mass and
    structure of the planetesimals disk, number of
    objects contained inside) that are varied in
    order to obtain the best representation of the
    present Solar System and of some dynamical
    parameters.
  • The agreement between the numerical planetary
    system and the present is generally good, but
    often the initial values of free parameters are
    not sufficiently justified by reasonable
    hypotheses

75
  • Thommes et al. (1999)
  • The authors assume that, starting from a system
    of four or five protoplanets placed between the
    present orbits of Jupiter and Saturn, plus an
    external planetesimal disk, it is possible to
    explain the actual position of Uranus and Neptune
    and their depletion of H and He.
  • Uranus and Neptune migrate from the initial
    position, between Jupiter and Saturn distances,
    and circularize their orbits owing to
    interactions with the planetesimals disk.
  • Jupiter and Saturn can firstly accrete the gas
    envelope, gain mass being able to scatter the
    orbits of the other protoplanets (or eject them
    outside the SS).
  • The model can explain the morphology of the
    Kuiper Belt and of the scattered disk
  • The most questionable assumption of this model is
    the initial position of the cores in a very
    narrow belt (5-10 AU). What happened in the outer
    regions?

76
The best run
Integration time t5 106 years At t0 rJ5.3
AU rS9 AU rC16.35 AU rC27.6
AU Planetesimals disk 10 AU lt r lt 60 AU At
t5 106 yr rJ4.9 AU rS10.2 AU rC119.7
AU rC231.1 AU
77
  • Morbidelli et al. (2005)
  • A planetary system with initial quasi-circular,
    coplanar orbits would have evolved to the current
    orbital configuration of the SS, provided that
    crossed their 12 orbital resonance.
  • This resonance crossing could have occurred as
    the GP migrated due their gravitational
    interactions with a planetesimals disk.
  • The four planets start with their present mass.
    The initial positions of Jupiter and Saturn are
    forced to be close to their 12 resonance
  • The (hot or cold) disk of planetesimals has a
    total mass of 10-50 MEarth and is composed of
    1000-5000 bodies
  • During migration, the eccentricities and mutual
    inclinations of the planets are damped by their
    gravitational interaction with the disk of
    planetesimals (dynamical friction).
  • The crossing of the resonance 12 causes a sudden
    jump on eccentricities and inclinations of
    Jupiter and Saturn has a drastic effect on the
    whole planetary system.
  • The final orbital configuration depends on the
    planetary configuration immediately after the
    resonance crossing

78
  • Results
  • Explorating with several simulation the phase
    space of the initial parameters of the planetary
    system, the best runs seem to reproduce the
    most important chacteristics of the giant planets
    orbits, namely final semimajor axes,
    eccentricities and mutual inclinations.
  • The survivability of the regular satellites of
    Jupiter and Saturn is assured during their close
    encounters (rltRHill), but not that of the
    irregular satellites. This give a constraint on
    the time of theit capture.
  • The model can explain the Late Heavy Bombardment
    (700 My after the planets formed. This was due
    both to the rapid migration of the planets, that
    destabilized the outer disk of planetesimals, and
    to the strong perturbation of the asteroid belt
  • The orbital characteristics of the Jupiters
    Trojan asteroids can be explained if they were
    captured during a short period of time, just
    after the crossing of the 12 resonance, when the
    dyinamics of the Trojan region was chaotic

79
  • The model of Morbidelli et al. finds in a very
    brilliant way very well a channel in the space of
    the possible evolutive histories, through which
    we can reach a very satisfactory agreement with
    the present SS. The problem is their initial
    planetary system is realistic?

80
(No Transcript)
81
  • A new model origin of the large eccentricities
    of extrasolar planets (Namouni, 2005)
  • The existence of phases of continuous
    acceleration due to mass loss (asymmetrical
    bipolar jets or winds from protoplanetary disks)
    can explain many of the peculiarities of the
    orbital parameters of extrasolar planets (higly
    scattered in eccentricities and semimajor axes)
  • Two modes of eccitation of eccentricities are
    possible secular, for planets closer to the
    star, and star acceleration smaller than
    gravitational acceleration of the companion, and
    sudden, at large distances, when the two
    accelerations are comparable.
  • Depending on the duration, direction and time
    dependence of the acceleration, not only large
    eccentricities can be excited, but also inward
    migration and ejection (in multiplanet systems)
  • In multiplanet systems the distribution of final
    eccentricities can give constraints on the
    parameters of the acceleration processes
    (duration and alignment) and also on the physical
    mechanism producing it.
  • The Namouni model starts from a known physical
    process, that can be utilized in reasonable
    conditions in order to explain a large variety of
    orbital characteristics of extrasolar planets

82
(No Transcript)
83
  • I modelli di evoluzione planetaria con
    modellizzazione contemporanea gapmigrazionepertu
    rbazioni secolari riescono a render conto di
    tutta una serie di evidenze osservative,
    intervenendo sui parametri fisici (massa ed
    evoluzione termica del disco, entità dello shear
    viscoso, popolazione di planetesimi) che
    governano il fenomeno. Più difficile è adattare
    il modello ai singoli sistemi planetari. Poiché
    ci sono ancora molte incertezze nella
    modellizzazione, linversione dai dati
    osservativi ai parametri base dei modelli non è
    facilmente praticabile.
  • Le probabili grandi differenze nelle condizioni
    iniziali e nelle storie evolutive dei vari
    sistemi planetari fin qui osservati è comunque in
    accordo con la grande varietà di situazioni
    osservate, che sarebbe probabilmente ancora più
    grande se non ci fosse leffetto della selezione
    osservativa.
  • La migrazione planetaria deve avere
    verosimilmente unincidenza molto diversa. Certi
    sistemi planetari possono essere completamente
    spariti cadendo sulla stella centrale, mentre il
    altri, come il nostro, le perturbazioni sono
    state soltanto un effetto secondario
Write a Comment
User Comments (0)
About PowerShow.com
