Digital Subscribe Line

1
Digital Subscribe Line

• By
• Richard Latham

2
POTS and Local Loops

• POTS stands for Plain Old Telephone Service.
• Bandwidth.
• Telephone (300 to 3,400 Hz).
• DSL (4312.5 Hz wide channels starting between
  10,000 and 100,000 Hz).
• Digital, not analog data.

3
Different Types

• Asymmetrical DSL (ADSL)
• Very high bit-rate DSL (VDSL)
• Symmetric DSL (SDSL)
• Rate-Adaptive DSL (RADSL)

4
Asymmetrical DSL

• ADSL is the type of DSL that favors the idea most
  Internet users download more than they upload.

5
Types of ADSL

• CAP
• Voice conversations (0 to 4 kHz)
• Upstream (25 to 160 kHz)
• Downstream (240 kHz to 1.5 MHz)

6
Types of ADSL

• DMT
• 247 separate channels.
• Each channel is 4 kHz wide.
• Channel Monitoring and Shifting.

7
But Why Filters?

• Low-Pass Filter
• Called LP Filters for short.
• Used for phone if ADSL is installed.
• Block everything above 4 kHz.

8
DSL Transceiver

• DSL Transceiver
• Also called a DSL modem.
• Point where the users computer connects to the
  DSL line.
• Connects to computer via USB or 10 base-T
  Ethernet connection.

9
DSLAM

• DSLAM will allow users to not see performance
  decrease as new users are added. Here the voice
  component gets separated from the upstream and
  the downstream.

10
DSL Network
11
Bibliography

• http//en.wikipedia.org/wiki/Asymmetric_Digital_Su
  bscriber_Line
• http//en.wikipedia.org/wiki/dsl
• http//computer.howstuffworks.com/dsl.htm
• http//computer.howstuffworks.com/dsl1.htm
• http//computer.howstuffworks.com/dsl2.htm
• http//computer.howstuffworks.com/dsl3.htm
• http//computer.howstuffworks.com/dsl4.htm
• http//computer.howstuffworks.com/dsl5.htm
• http//computer.howstuffworks.com/dsl6.htm
• http//computer.howstuffworks.com/dsl7.htm
• http//computer.howstuffworks.com/dsl8.htm
• http//computer.howstuffworks.com/dsl9.htm
• Gralla, Preston. How the Internet Works. 7th
  ed. Indianapolis Que, 2004. 328.
• Template provided by AnimationFactory.com
