CSCE 715: Network Systems Security

1
CSCE 715Network Systems Security

• Chin-Tser Huang
• huangct_at_cse.sc.edu
• University of South Carolina

2
Network Security Designs

• After discussion of cryptographic tools, we turn
  to look at various network security designs at
  different layers in protocol stack
• Link layer secure address resolution
• Network layer IPsec, hop integrity
• Transport layer SSL/TLS
• Application layer Kerberos, X.509 certificate,
  firewall design

3
Ethernet

• Most widely used LAN technology
• Low cost and high flexibility
• Versions of different speed 10Mbps, 100Mbps,
  Gigabit
• Use globally unique media access control (MAC)
  address (hardware address) for every interface
  card

4
Use of Hardware Address

• Need an address to send a message to receiver on
  same Ethernet
• IP address is not usable because network layer
  does not listen to wire
• Use hardware address to identify receivers
  interface
• Need to resolve receivers hardware address from
  receivers IP address

5
Address Resolution Protocol

• Protocol maps each IP address to corresponding
  hardware address in subnetwork
• For computer i to get hardware address of
  computer j, i broadcasts a rqst message with IP
  address of j to the subnetwork

rqst(ipa.j)
i
default router
Internet
switch
r
j
6
Address Resolution

• If j sees a rqst message from i with its IP
  address, j sends a rply message with its IP
  address and hardware address to i

rply(ipa.j,hda.j)
i
default router
Internet
switch
r
j
7
Functions of ARP

• Three functions of ARP
• Resolving IP addresses
• Supporting dynamic assignment of addresses
• Detecting destination failures

8
ARP Spoofing Attack

• To stop traffic from i to j, an adversary sends
  to i a spoofed rply message with IP address of j
  and a non-existent hardware address

i
default router
Internet
switch
r
j
A
rply(ipa.j,hda.x)
9
Another ARP Spoofing Attack

• To stop traffic from i to default router r, an
  adversary sends to i a spoofed rply message with
  IP address of r and its own hardware address

i
default router
Internet
switch
r
j
A
rply(ipa.r,hda.A)
10
Countering ARP Spoofing Attacks

• Proposed solutions include ARPWATCH and static
  ARP caches
• ARPWATCH monitors transmission of rqst and rply
  messages over Ethernet and check them against a
  database of (IP addr, hardware addr) pairings
• Static ARP cache stores permanent (IP addr,
  hardware addr) pairings of trusted hosts to avoid
  sending rqst and rply messages over Ethernet

11
Insufficiencies of Proposed Solutions

• ARPWATCH does not support dynamic assignment of
  IP addresses
• Static ARP caches does not support dynamic
  assignment of IP addresses and detection of
  destination failures

12
Need for Secure Address Resolution

• When a computer receives a message m, it needs to
  determine whether m was indeed sent by claimed
  source, or was inserted, modified, or replayed by
  an adversary
• Use secure address resolution protocol between
  each computer and a secure server

13
Architecture of Secure Address Resolution
Protocol
14
Adversary

• Adversary can perform three types of actions to
  disrupt communication between server s and any
  computer hi on the Ethernet
• Message loss
• Message modification
• Message replay

15
Secure Address Resolution Protocol

• Use three mechanisms to counter adversarial
  actions
• timeouts to counter message loss
• shared secrets to counter message modification
• nonces to counter message replay

16
Invite-Accept Protocol

• Periodically, server s sends out an invt message
  to every computer on Ethernet
• Every up computer is required to send back an
  acpt message including its IP address and
  hardware address
• s updates its address database according to
  received acpt messages

17
Invite-Accept Protocol

• s ? h0..n-1 invt(nc, md)
• where mdMD(ncscr0)MD(ncscr1)MD(ncs
  crn-1)
• hi ? s acpt(nc, ipai, hdai, d)
• where dMD(ncipaihdaiscri)

18
Request-Reply Protocol

• When a computer needs to resolve a destinations
  hardware address, it sends a rqst message to
  server s
• If destinations hardware address is still valid,
  s sends back a rply message with address
  information
• If destinations hardware address is not valid
  anymore, s sends back a rply message with no
  address information

19
Request-Reply Protocol

• hi ? s rqst(nc, ipaj, d)
• where dMD(ncipajscri)
• If found,
• s ? hi rply(nc, ipaj, hdaj, d)
• where dMD(ncipajhdajscri)
• If not found,
• s ? hi rply(nc, ipaj, 0, d)
• where dMD(ncipaj0scri)

20
Extensions

• Four extensions of secure address resolution
  protocol
• Insecure address resolution
• Backup server
• System diagnosis
• Address resolution across multiple Ethernets

21
Next Class

• IPsec
• Authentication Header (AH)
• Encapsulation Security Payload (ESP)
• key management
• Read Chapter 16
