C20.0046: Database Management Systems Lecture

1
C20.0046 Database Management SystemsLecture 14

• M.P. Johnson
• Stern School of Business, NYU
• Spring, 2005

2
Summary SQL queries

• Only SELECT, FROM required
• Cant have HAVING without GROUP BY
• Can have GROUP BY without HAVING
• Any clauses used must appear in this order

SELECT LFROM Rs WHERE s GROUP
BY L2 HAVING s2 ORDER BY L3
3
New topic Modifications

• Three kinds of modifications
• Insertions
• Deletions
• Updates
• Sometimes update used as a synonym for
  modification

4
Insertions
General form
INSERT INTO R(A1,., An) VALUES(v1,.,vn)
Example Insert a new purchase to the database
INSERT INTO Knights(name, britnatl, title)
VALUES('Bill Gates', 'n', 'KBE')
Missing attribute ? NULL (or other default value)
5
Insertions

• If were sure we have all values in the right
  order, can just say
• Only do this if youre sure of order in which the
  table fields were defined

INSERT INTO R VALUES(v1,.,vn)
INSERT INTO Knights VALUES('R. Giuliani', 'n',
'KBE') INSERT INTO Knights VALUES('Bernard
Kerik', 'n', 'CBE')
6
Insertions

• Can insert the result of a query Scenario
• Product(name, etc.)
• Purchase(buyerssn, prodName, etc.)
• Maybe some purchases name missing products
• ? add those to the Product table
• Subquery replaces VALUES

INSERT INTO R(As) (query)
7
Insertion example

• Product(name, listPrice, category)
• Purchase(prodName, buyerName, price)
• Premise data corruption ? lose some Product data
• every product referred to in Purchase should
  exist in Product, but some are missing

Product
Purchase
8
Insertion example
INSERT INTO Product(name) SELECT prodName
FROM Purchase WHERE prodName NOT IN
(SELECT name FROM Product)
Purchase
Product
Product
Q Or do we get
A Depends on implementation!
9
Deletions
DELETE FROM Table WHERE condition

• General form
• E.g.
• As usual, WHERE can contain subqueries
• Depending on the DBMS
• Q How do you delete just one row with SQL
  simpliciter?
• Oracle has the ROWID/ROWNUM pseudo-field

INSERT INTO Knights VALUES('R. Giuliani', 'n',
'KBE') INSERT INTO Knights VALUES('Bernard
Kerik', 'n', 'CBE') DELETE FROM Knights WHERE
name 'Bernard Kerik'
10
Updates
UPDATE Product SET field1 value1, field2
value2 WHERE condition

• General form
• Example
• As usual, WHERE can contain subqueries

UPDATE Product SET price price/2 WHERE
Product.name IN (SELECT product FROM
Purchase WHERE Date DATE'Oct, 25, 1999')
11
New topic Defining schemata

• So far, have done queries and data manipulation
• Now doing data definition
• Recall data types
• INT or INTEGER (variant SHORTINT)
• FLOAT or REAL floating-point numbers
• DOUBLE PRECISION
• DECIMAL(n,d)
• E.g. decimal(5,2) five decimal digits, with the
  decimal point two positions from the right e.g.
  123.45
• DATE and TIME
• Character strings
• Fixed length CHAR(n)
• Variable length VARCHAR(n)

12
Creating tables
CREATE TABLE Table-name ( field1 field-type,
field2 field-type, fieldn field-type )

• Form
• E.g.

No comma!
CREATE TABLE People ( name VARCHAR(30),
ssn CHAR(9), age INT, city
VARCHAR(30), gender CHAR(1), dob DATE )
13
Default Values

• Specify defaults when creating table
• The default default NULL

CREATE TABLE People ( name VARCHAR(30),
ssn CHAR(9), age SHORTINT DEFAULT
100, city VARCHAR(30) DEFAULT 'New York',
gender BIT(1), dob DATE DEFAULT DATE
'1900-01-01' )
14
Deleting and modifying schemata

• Delete data, indices, schema
• Delete data and indices
• Either way, exercise extreme caution!
• Add or delete attributes

DROP TABLE Person
TRUNCATE TABLE Person
Q Whats put in the new fields?
ALTER TABLE Person ADD phone CHAR(12)
ALTER TABLE Person DROP age
15
New topic Indices

• Very important speeding up query processing
• Index on field(s) data structure that makes
  searches/comparisons on those fields fast
• Suppose we have a relation
• Person (name, age, city)
• Sequential scan of the whole Person file may take
  a very long time

SELECT FROM Person WHERE name 'Waksal, Sam'
16
Creating Indices

• Syntax
• Here
• No searching by name is much faster
• How much faster?
• Log-time, say
• Base-what? Doesnt matter, but say 2
• If all New Yorkers, comparisons
• 8000000 ? log2(8000000) 23
• (i.e., 223 8000000)

CREATE INDEX index-name ON R(fields)
CREATE INDEX nameIndex ON Person(name)
17
How do indices work?

• What the data structure?
• Different possibilities
• 1st intuition index on field f is an ordered
  list of all values in the tables f field
• each item has address (rowid) of its row
• Where do we get the ordered list?
• 2nd intuition put all f values in a BST
• searching BST take log time (why?)
• DBMSs actually use a variant BTree
• See Ullmans book or data structures texts

18
Creating Indices

• Indexes can be useful in range queries too

CREATE INDEX ageIndex ON Person (age)
SELECT FROM Person WHERE age 25
19
Using indices

• Indices can be created on multiple attributes
• Helps in
• And in
• But not in

CREATE INDEX doubleNdx ON Person (lname, fname)
SELECT FROM Person WHERE fname'Sam' AND
lname 'Waksal'
SELECT FROM Person WHERE lname'Waksal'
Idea our sorted list is sorted on agecity, not
cityage
Q In Movie, should index be on yeartitle or
titleyear?
SELECT FROM Person WHERE fname'Sam'
20
The Index Selection Problem

• Big Q Why not just index all (sequences of)
  fields?
• how does the list/BTree stay up to date?
• We are given a workload a set of SQL queries and
  their frequencies
• Q is What indices should we build to speed up
  the workload?
• Answer
• Attributes in WHERE clauses (queries) ? favor an
  index
• Attributes in INSERT/UPDATE/DELETEs ? discourage
  an index
• In many DBMSs your primary key fields get
  indexed automatically (why?)

21
New topic Views

• Stored relations physically exist and persist
• Views are relations that dont
• in some texts, table stored relation base
  table
• Basically names/references given to queries
• maybe a relevant subset of a table
• Employee(ssn, name, department, project, salary)
• Payroll has access to Employee, others only to
  Developers

CREATE VIEW Developers AS SELECT name,
project FROM Employee WHERE department
'Dev'
22
A Different View

• Person(name, city)
• Purchase(buyer, seller, product, store)
• Product(name, maker, category)
• We have a new virtual table
• NYCview(buyer, seller, product, store)

CREATE VIEW NYCview AS SELECT buyer, seller,
product, store FROM Person, Purchase
WHERE Person.city 'New York' AND
Person.name Purchase.buyer
23
A Different View
CREATE VIEW NYCview AS SELECT buyer, seller,
product, store FROM Person, Purchase
WHERE Person.city 'New York' AND
Person.name Purchase.buyer

• Now we can query the view

SELECT name, NYCview.store FROM NYCview,
Product WHERE NYCview.product Product.name
AND Product.category 'Camera'
24
What happens when we query a view?
SELECT name, NYCview.store FROM NYCview,
Product WHERE NYCview.product Product.name
AND Product.category 'Camera'
SELECT name, Purchase.store FROM Person,
Purchase, Product WHERE Person.city 'New York'
AND Person.name Purchase.buyer AND
Purchase.poduct Product.name AND
Product.category 'Camera'
25
Can rename view fields
CREATE VIEW NYCview(NYCbuyer, NYCseller,
prod, store) AS SELECT buyer, seller,
product, store FROM Person, Purchase
WHERE Person.city 'New York' AND
Person.name Purchase.buyer
26
Types of Views

• Views discussed here
• Used in databases
• Computed only on-demand slow at runtime
• Always up to date
• Sometimes talk about materialized views
• Used in data warehouses
• Pre-computed offline fast at runtime
• May have stale data
• Maybe more later

27
Updating Views
How to insert a tuple into a table that doesnt
exist? Employee(ssn, name, department, project,
salary)
CREATE VIEW Developers AS SELECT name,
project FROM Employee WHERE department
'Development'
If we make the following insertion
INSERT INTO Developers VALUES('Bill', Word')
It becomes
INSERT INTO Employee(ssn, name, dept, project,
sal) VALUES(NULL, 'Bill', NULL, 'Word', NULL)
28
Non-Updatable Views

• Person(name, city)
• Purchase(buyer, seller, product, store)
• How can we add the following tuple to the view?
• ('NYC', 'The Wiz')
• We dont know the name of the person who made the
  purchase
• cannot set to NULL (why?)

CREATE VIEW CityStore AS SELECT Person.city,
Purchase.store FROM Person, Purchase
WHERE Person.name Purchase.buyer
29
Constraints in SQL

• A constraint a property that wed like our
  database to hold
• The system will enforce the constraint by taking
  some actions
• forbid an update
• or perform compensating updates

30
Constraints in SQL
simplest

• Constraints in SQL
• Keys, foreign keys
• Attribute-level constraints
• Tuple-level constraints
• Global constraints assertions
• The more complex the constraint, the harder it is
  to check and to enforce

Mostcomplex
31
Keys
CREATE TABLE Product ( name CHAR(30) PRIMARY
KEY, category VARCHAR(20) )
CREATE TABLE Product ( name CHAR(30),
category VARCHAR(20) PRIMARY KEY (name) )

• Or

32
Keys with Multiple Attributes
CREATE TABLE Product ( name CHAR(30),
category VARCHAR(20), price INT, PRIMARY
KEY (name, category) )
33
Other Keys

• There is at most one PRIMARY KEY there can be
  many UNIQUE
• Primary key v. candidate keys

CREATE TABLE Product ( productID CHAR(10),
name CHAR(30), category VARCHAR(20), price
INT, PRIMARY KEY (productID), UNIQUE (name,
category) )
34
Foreign Key Constraints

• prodName is a foreign key to Product(name)
• name should be a key in Product
• Purchase Product is many-one
• NB referenced field specified with parentheses,
  not dot

Referentialintegrityin SQL
CREATE TABLE Purchase ( prodName CHAR(30)
REFERENCES Product(name), date DATETIME )
35
Product
Purchase
36
Foreign Key Constraints

• Or
• (name, category) must be a key (primary/unique)
  in Product (why?)

CREATE TABLE Purchase ( prodName CHAR(30),
category VARCHAR(20), date DATETIME,
FOREIGN KEY (prodName, category)
REFERENCES Product(name, category)
37
What happens during updates?

• Types of updates
• In Purchase insert/update
• In Product delete/update

Product
Purchase
38
What happens during updates?

• SQL has three policies for maintaining
  referential integrity
• Reject violating modifications (default)
• Cascade after a delete/update do a delete/update
• Set-null set foreign-key field to NULL

39
Constraints on Attributes and Tuples

• Constraints on attributes
• NOT NULL -- obvious meaning...
• CHECK condition -- any condition on row itself
• Some DBMS support subqueries here, but many dont
• Constraints on tuples
• CHECK condition

40
How is this different from aForeign-Key?
CREATE TABLE Purchase ( prodName CHAR(30)
CHECK (prodName IN SELECT
Product.name FROM Product),
date DATETIME NOT NULL )
41
General Assertions

• Supported in SQL standard
• Implemented/approximated in MySQL and Oracle as
  stored procedures
• PL/SQL in Oracle

CREATE ASSERTION myAssert CHECK (NOT EXISTS(
SELECT Product.name FROM Product, Purchase
WHERE Product.name Purchase.prodName GROUP
BY Product.name HAVING count() 200) )
42
Final Comments on Constraints

• Can give them names, and alter later
• We need to understand exactly when they are
  checked
• We need to understand exactly what actions are
  taken if they fail

43
Example with nulls

• look at emp table
• get names, salaries, commissions, total salaries
• What if commission is null?
• nvl in Oracle, ifnull in MySQL

44
Live examples

• Inner joins require an ON clause
• Like a where clause
• Arbitrary boolean expression
• If always true (11), reduces to cross join
• New compar op BETWEEN
• a between 5 and 10 ? a 5 and a
• Q produce a list of employees with their salary
  grades
• emp, salgrade

45
Live examples

• Q produce a list of employees and their bosses
• What if no boss? Or no subordinate?
• Joins on emp, emp man
• Comma-based
• Cross
• Natural
• Inner
• Must use INNER JOIN in MySQL
• If want non-managers, do outer join
• No FULL OUTER JOIN in MySQL yet

46
Live examples

• Q produce list of bosses and underling-counts,
  for bosses with 1 underling
• Just add HAVING clause

47
Finally R.A./SQL has limitations

• Can easily find Alices direct subordinates
• But find all of Kings underlings
• Cannot compute transitive closure
• Cannot express in R.A./SQL!
• SQL is not Turing-Complete

48
Live examples

• Examples from sqlzoo.net

SELECT L FROM R1, , Rn WHERE C
PL(sC(R1 x Rn)
