Recursion and Recursive Algorithms

1
Recursion and Recursive Algorithms

• Module 4CC050
• Software Development I

2
Recursion

• Recursion happens when a method calls itself
  either directly or indirectly
• A recursive method has to deal with two cases
• Base Case The case to which we can provide an
  answer
• General Case The case that expresses the
  solution in terms of a call to itself with a
  smaller version of the problem

3
Recursion

• The classic example of using recursion is to find
  the factorial of a number
• The factorial is defined as the number times the
  product of all the numbers between itself and 0
• N! N (N 1)!
• For example
• 6! 6 5!

4
Recursion

• Factorials
• Base Case
• Factorial(0) 1 (0! is 1)
• General Case
• Factorial(N) N Factorial(N-1)

5
Recursion

• static double Factorial(double number)
• if (number 0)
• return 1
• else
• return number Factorial(number - 1)

6
Questions

• Why does the previous example use values of type
  double rather than type int (given that you can
  only find the factorial of an integer?)
• What happens if you ask this method to find the
  factorial of a negative number?

7
Stack for 4!
4
Factorial(4)
Return Address
3
calls Factorial(3)
Return Address
2
calls Factorial(2)
Return Address
1
calls Factorial(1)
Return Address
0
calls Factorial(0)
Return Address
8
Stack for -1!
-1
Factorial(-1)
Return Address
-2
calls Factorial(-2)
Return Address
-3
calls Factorial(-3)
Return Address
-4
calls Factorial(-4)
Return Address
-5
calls Factorial(-5)
Return Address
...
9
Should Recursion Be Used Here?

• Factorials are calculated using a recursive
  algorithm.
• However, just because an algorithm is recursive,
  it does not mean that recursion is always the
  most efficient mechanism to use, even if the
  algorithm is recursive.
• In this case, a simple loop will do the job much
  more efficiently. This is often the case when
  the algorithm has tail recursion.

10
A Better Use of Recursion

• QuickSort
• Uses recursion to sort items

11
Bubble Sort

• Repeat until no more swaps occur
• Starting with the first list element, compare
  successive pairs of elements, swapping whenever
  the bottom element of the pair is smaller than
  the one above it

12
Bubble Sort Example - First Pass
5
4
4
4
4
4
5
3
3
3
3
3
5
2
2
2
2
2
5
1
1
1
1
1
5
13
Bubble Sort Example - Second Pass
4
3
3
3
3
3
4
2
2
2
2
2
4
1
1
1
1
1
4
4
5
5
5
5
5
14
Bubble Sort Example - Third Pass
3
2
2
2
2
2
3
1
1
1
1
1
3
3
3
4
4
4
4
4
5
5
5
5
5
15
Bubble Sort Example - Fourth Pass
2
1
1
1
1
1
2
2
2
2
3
3
3
3
3
4
4
4
4
4
5
5
5
5
5
16
Bubble Sort Example Fifth Pass

• A final loop through the array would happen.
• Since no swaps occur, the array must be sorted.

17
Quicksort

• Works on the basis that it is easier to sort a
  smaller number of items.
• The array is partitioned such that all numbers in
  the upper partition are greater than the numbers
  in the lower partition (the partitions do not
  need to be equal sizes).
• Then each partition is recursively sorted.

18
Quicksort
If (there is more than one item in
listfirst..listlast) Select
splitVal Split the list so that listfirst..
listsplitPoint-1 lt splitVal listsplitPoint
splitVal listsplitPoint1..listlast gt
splitVal Quicksort the left half Quicksort the
right half
19
Quicksort
