Title: Electron Configurations and the Periodic Table


1
Electron Configurations and the Periodic Table
  • Chapter 3 Section 2

2
Electron Configurations
  • Electron configuration the arrangement of
    electrons in an atom
  • The most important of these electrons are the
    valence electrons or outermost electrons.

3
Valence Electrons
  • The number of valence electrons for all
    representative elements is determined by the
    number of the group in which the atom is found.
  • Examples
  • Hydrogen - Group IA or 1
  • 1 valence electron.
  • Fluorine Group VIIA or 17
  • 7 valence electrons

4
NOW YOU TRY!
  • How many valence electrons do the following
    elements contain?
  • A. Lithium
  • B. Carbon
  • C. Aluminum
  • D. Sulfur
  • E. Krypton

1
4
3
6
8
5
So, who cares?
  • Valence electrons are important because they
    determine how atoms interact with each other to
    form compounds!

6
Arrangement of Electrons in Atoms according to
the Quantum Mechanical Model
  • Electrons in atoms are arranged as
  • ENERGY LEVELS
  • SUBLEVELS
  • ORBITALS

7
Energy Levels
  • Each energy level has a number called the
    PRINCIPAL QUANTUM NUMBER, n
  • Currently n is 1 thru 7 because of the elements
    known, but there is a possibility of infinite
    levels.

8
Relative sizes of the spherical 1s, 2s, and 3s
orbitals of hydrogen.
9
Sublevels AKA Subshells
  • The sublevels are named s, p, d, and f and are
    listed in increasing energy.
  • We specify both the energy level and sublevel
    when describing an electron, i.e. 1s, 2s, 2p.

10
Determining the number of sublevels
  • The number of sublevels in any given level is
    equal to n.
  • The first energy level has 1 sublevel 1s.
  • The second energy level has 2 sublevels 2s and
    2p.
  • How many sublevels exist on the 3rd energy level?
  • What would they be called?

3
3s, 3p, 3d
11
Orbitals
Orbital a specific region of a sublevel
containing a maximum of 2 electrons.
  • The p sublevel has 3 orbitals.
  • They are called px, py, and pz.

The s sublevel has 1 orbital.
The d sublevel has 5 orbitals.
The f sublevel has 7 orbitals.
12
Shapes of Orbitals
Typical s orbital (sphere)
(peanut)
(double peanut)
Typical f orbital (flower)
13
How many electrons can be in a sublevel?
Remember A maximum of two electrons can be
placed in an orbital.
s sublevel
d sublevel
p sublevel
f sublevel
Number of orbitals
1
3
5
7
Number of electrons
6
10
14
2
14
Aufbau Principle
  • An electron occupies the lowest-energy orbital
    that can receive it.
  • This guides how electron configurations are
    written.

15
Rules to Remember when Writing Electron
Configurations
  • Obtain the number of total electrons from the
    periodic table.
  • Electrons occupy the lowest energy orbitals
    first.
  • Each energy level (n) only contains n sublevels.
  • The s sublevel holds 2 e-, the p 6 e-, the d 10
    e-, and the f 14 e-.
  • Follow the filling pattern only moving once each
    sublevel is full.

16
Diagonal Rule
  • The diagonal rule is a memory device that helps
    you remember the order of the filling of the
    orbitals from lowest energy to highest energy.
  • Steps
  • Write the energy levels top to bottom.
  • Write the sublevels in s, p, d, f order. Write
    the same number of sublevels as the energy level.
  • Draw diagonal lines from the top right to the
    bottom left.
  • To get the correct order, follow the arrows!

17
Diagonal Rule
1 2 3 4 5 6 7
s
By this point, we are past the current periodic
table so we can stop.
s 2p
s 3p 3d
s 4p 4d 4f
s 5p 5d 5f
s 6p 6d 6f
s 7p 7d 7f
18
You may have learned it this way!
19
Periodic Table Method Steps
  • Find the element for which you are writing the
    configuration.
  • Starting with Hydrogen, write down the energy
    level and sublevel.
  • Count the boxes in the sublevel and add it as a
    superscript.
  • Continue moving through the sublevels until you
    reach your destination.

20
Electron Configurations
  • 3d7

Number of electrons in the sublevel
Energy Level
Sublevel
1s2 2s2 2p6 3s2 3p6 4s2 3d10 4p6 5s2 4d10 5p6 6s2
4f14 etc.
21
OVERLAPSWhy are d and f orbitals always in lower
energy levels?
  • d and f orbitals require LARGE amounts of energy
    to create.
  • According to the Aufbau principle we must skip a
    sublevel that requires a large amount of energy
    (d and f orbtials) for one in a higher level but
    lower energy
  • OVERLAPS are the reason for the diagonal rule!
  • FOLLOW THE ARROWS IN ORDER!

22
Lets Try It!
  • Write the electron configuration for the
    following elements
  • H
  • Li
  • N
  • Ne
  • K
  • Zn
  • Pb

23
Lets Try It!
  • Write the electron configuration for the
    following elements
  • H 1s1
  • Li 1s2 2s1
  • N 1s2 2s2 2p3
  • Ne 1s2 2s2 2p6
  • K 1s2 2s2 2p6 3s2 3p6 4s1
  • Zn 1s2 2s2 2p6 3s2 3p6 4s2 3d10
  • Pb 1s2 2s2 2p6 3s2 3p6 4s2 3d10 4p6 5s2 4d10 5p6
    6s2 4f14 5d10 6p2

24
Noble Gas Notation
  • A way of abbreviating long electron
    configurations
  • Since we are only concerned about the outermost
    electrons, we can skip to places we know are
    completely full (noble gases), and then finish
    the configuration

25
Noble Gas Notation
  • Step 1 Find the closest noble gas to the atom,
    WITHOUT GOING OVER the number of electrons in the
    atom. Write the noble gas in brackets .
  • Step 2 Find where to resume by finding the next
    energy level (row in periodic table).
  • Step 3 Resume the configuration starting with
    ns2 where n is the next level

26
Noble Gas Notation
  • Chlorine
  • Longhand is 1s2 2s2 2p6 3s2 3p5
  • You can abbreviate the first 10 electrons with a
    noble gas, Neon. Ne replaces 1s2 2s2 2p6
  • The next energy level after Neon is 3
  • So you start at level 3 on the diagonal rule (all
    levels start with s) and finish the configuration
    by adding 7 more electrons to bring the total to
    17
  • Ne 3s2 3p5

27
Practice Noble Gas Notation
  • Write the noble gas notation for each of the
    following atoms
  • Cl
  • K
  • Ca
  • I
  • Bi

28
Practice Noble Gas Notation
  • Write the noble gas notation for each of the
    following atoms
  • Cl Ne3s2 3p5
  • K Ar4s1
  • Ca Ar4s2
  • I Kr5s2 4d10 5p5
  • Bi Xe6s2 4f14 5d10 6p3
