The Coronagraph
Achromatized APLC, optimized for 1.65
µm Apodizer 51 throughput with astrometric
grid Focal Plane Mask 5.37 ?/D at 1.65 µm 370
mas IWA of 200 mas Lyot Stop 2 downsized
from primary, negligible impact on
throughput ADC (designed by C. Shelton) covers
1-1.8 µm from 0 to 50, double prism design in
collimated beam Pupil Viewing camera to monitor
rejected starlight from Lyot Mask Tip/Tilt
system based on Hamamatsu InGaAs quad cell. 1kHz
update Provides f/143 beam to IFU lenslet array
(21 mas/lenslet)
3
Basic Architecture
Apodizer (PPM), Focal plane mask (FPM) , Lyot
Stop
PPM FPM
Lyot Stop Final image
Apodizer transmission Throughput 50
Hard-edge stop Diameter 5 ?/D
Lyot Stop
4
Apodizers, FPMs, Lyot Stops
5
Updated Design Notes

• Improved the APLC design and identified issues
  not previously apparent (FPM f.o.v., e.g.)
• Proven the astrometric and photometric techniques
  with both lab and on-sky data

6
Fabrication - PPM

• Chromium alloy microdots on glass
• MEMS Optical/Jenoptik, 1um, 2um microdots
• Zero order throughput to match APLC profile

MEMS apodizer
7
Fabrication PPM WFE
3.4nm rms focus-subtracted
5.7nm rms
8
Fabrication FPM
5 nm focus-subtracted, 0.5 nm roughness
Superpolished Si Etched 600 µm Hole
36 nm focus
8
9
Fabrication FPM SEM
9

• Edge roughness lt 2 ?m speced by GPI PDR
  tolerancing

10
Project 1640 and Palomar 5-m AO System
1640 Dewar
AO System
Coronagraph Lyot Project Heritage
11
Fold
Focal Plane mask
OAP2
Lyot Stop
OAP3
Fold
Final Sphere (above plate)
Atmospheric Dispersion Prisms
Infrasil window
OAP1
Apodizer
AO input beam
Fast steering mirror
12
(No Transcript)
13
GPI Testbed Contrast

• Short exposure H

• Long exposure H

• Laser 1.55 um

Simulated w/30 nm WFE (expected testbed
performance)
Real Testbed Data
40 nm
20 nm
10 nm
5 nm
No WFE, real ?dot greys
14
GPI Results - Contrast 1.55 micron

• 5 l/D radius

lt10-7
15
GPI Results speckle scaling FeII 1.64um and
Laser 1.55 um
Scaled by wavelength
Unscaled
Centering issue akin astrometry Lyot movement
over 2 day gap
16
10 second 1640 Coronagraphic IFU Exposure
17
Smoothed to remove spectra
