Introduction to Game Theory and Networks

1
Introduction to Game Theoryand Networks

• Networked Life
• CSE 112
• Spring 2007
• Prof. Michael Kearns

2
Game Theory

• A mathematical theory designed to model
• how rational individuals should behave
• when individual outcomes are determined by
  collective behavior
• strategic behavior
• Rational usually means selfish --- but not always
• Rich history, flourished during the Cold War
• Traditionally viewed as a subject of economics
• Subsequently applied by many fields
• evolutionary biology, social psychology
• Perhaps the branch of pure math most widely
  examined outside of the hard sciences

3
Prisoners Dilemma
cooperate defect
cooperate -1, -1 -10, -0.25
defect -0.25, -10 -8, -8

• Cooperate deny the crime defect confess
  guilt of both
• Claim that (defect, defect) is an equilibrium
• if I am definitely going to defect, you choose
  between -10 and -8
• so you will also defect
• same logic applies to me
• Note unilateral nature of equilibrium
• I fix a behavior or strategy for you, then choose
  my best response
• Claim no other pair of strategies is an
  equilibrium
• But we would have been so much better off
  cooperating

4
Penny Matching
heads tails
heads 1, 0 0, 1
tails 0, 1 1, 0

• What are the equilibrium strategies now?
• There are none!
• if I play heads then you will of course play
  tails
• but that makes me want to play tails too
• which in turn makes you want to play heads
• etc. etc. etc.
• But what if we can each (privately) flip coins?
• the strategy pair (1/2, 1/2) is an equilibrium
• Such randomized strategies are called mixed
  strategies

5
The World According to Nash

• A mixed strategy is a distribution on the
  available actions
• e.g. 1/3 rock, 1/3 paper, 1/3 scissors
• Joint mixed strategy for N players a vector P
  (P1, P2, PN)
• Pi is a distribution over the actions for
  player i
• assume everyone knows all the distributions Pj
• but the coin flips used to select from Pi
  known only to i
• private randomness
• two digressions
• mixed strategy simulation in Kings and Pawns?
• can people randomize?
• P is an equilibrium if
• for every player i, Pi is a best response to
  all the other Pj
• Nash 1950 every game has a mixed strategy
  equilibrium
• no matter how many rows and columns there are
• in fact, no matter how many players there are
• Thus known as a Nash equilibrium
• A major reason for Nashs Nobel Prize in
  economics

6
Facts about Nash Equilibria

• While there is always at least one, there might
  be many
• zero-sum games all equilibria give the same
  payoffs to each player
• non zero-sum different equilibria may give
  different payoffs!
• Equilibrium is a static notion
• does not suggest how players might learn to play
  equilibrium
• does not suggest how we might choose among
  multiple equilibria
• Nash equilibrium is a strictly competitive notion
• players cannot have pre-play communication
• bargains, side payments, threats, collusions,
  etc. not allowed
• Computing Nash equilibria for large games is
  difficult

7
Digression Board Games and Game Theory

• What does game theory say about richer games?
• tic-tac-toe, checkers, backgammon, go,
• these are all games of complete information with
  state
• incomplete information poker
• Imagine an absurdly large game matrix for
  chess
• each row/column represents a complete strategy
  for playing
• strategy a mapping from every possible board
  configuration to the next move for the player
• number of rows or columns is huge --- but finite!
• Thus, a Nash equilibrium for chess exists!
• its just completely infeasible to compute it
• note can often push randomization inside the
  strategy

8
Games on Networks

• Matrix game networks
• Vertices are the players
• Keeping the normal (tabular) form
• is expensive (exponential in N)
• misses the point
• Most strategic/economic settings have much more
  structure
• asymmetry in connections
• local and global structure
• special properties of payoffs
• Two broad types of structure
• special structure of the network
• e.g. geographically local connections
• special payoff functions
• e.g. financial markets

9
Case Study Interdependent Security Games on
Networks
10
The Airline Security Problem

• Imagine an expensive new bomb-screening
  technology
• large cost C to invest in new technology
• cost of a mid-air explosion L gtgt C
• There are two sources of explosion risk to an
  airline
• risk from directly checked baggage new
  technology can reduce this
• risk from transferred baggage new technology
  does nothing
• transferred baggage not re-screened (except for
  El Al airlines)
• This is a game
• each player (airline) must choose between
  I(nvesting) or N(ot)
• partial investment mixed strategy
• (negative) payoff to player (cost of action)
  depends on all others
• on a network
• the network of transfers between air carriers
• not the complete graph
• best thought of as a weighted network

11
The IDS ModelKunreuther and Heal

• Let x_i be the fraction of the investment C
  airline i makes
• p_i probability of explosion due to directly
  checked bag
• S_i probability of catching a bomb from
  someone else
• a straightforward function of all the
  neighboring airlines j
• incorporates both their investment decision j
  (x_j) and their probability or rate of transfer
  to airline i
• Payoff structure (qualititative, can be made
  quantitative)
• increasing x_i reduces effective direct risk
  below p_i
• but at increasing cost (x_iC)..
• and does nothing to reduce effective indirect
  risk S_i, which can only be reduced by the
  investments of others
• network structure influences S_i
• Typical strategic incentives
• when your neighbors are under-investing, your
  incentive to invest is low
• basic problem so much indirect risk already that
  you cant help yourself much
• when your neighbors are all fully investing, your
  incentive to invest is high
• because your fate is in your own control now ---
  can reduce your only remaining source of risk
• What are the Nash equilibria?
• fully connected network with uniform transfer
  rates full investment or no investment by all
  parties!

12
Abstract Features of the Game

• Direct and indirect sources of risk
• Investment reduces/eliminates direct risk only
• Risk is of a catastrophic event (L gtgt C)
• can effectively occur only once
• May only have incentive to invest if enough
  others do!
• Note much more involved network interaction than
  info transmittal, message forwarding, search,
  etc.

13
Other IDS Settings

• Fire prevention
• catastrophic event destruction of condo
• investment decision fire sprinkler in unit
• Corporate malfeasance (Arthur Anderson)
• catastrophic event bankruptcy
• investment decision risk management/ethics
  practice
• Computer security
• catastrophic event erasure of shared disk
• investment decision upgrade of anti-virus
  software
• Vaccination
• catastrophic event contraction of disease
• investment decision vaccination
• incentives are reversed in this setting

14
An Experimental Study

• Data
• 35K N. American civilian flight itineraries
  reserved on 8/26/02
• each indicates full itinerary airports,
  carriers, flight numbers
• assume all direct risk probabilities p_i are
  small and equal
• carrier-to-carrier xfer rates used for risk xfer
  probabilities
• The simulation
• carrier i begins at random investment level x_i
  in 0,1
• at each time step, for every carrier i
• carrier i computes costs of full and no
  investment unilaterally
• adjusts investment level x_i in direction of
  improvement (gradient)

15
Network Visualization
Airport to airport
Carrier to carrier
16
The Price of Anarchy is High
least busy
most busy
17
Tipping and Cascading
18
Necessary Conditions for Tipping
