National Instruments and FIRST An Engineering Education Continuum

1
National Instruments and FIRSTAn Engineering
Education Continuum
Embargoed until April 17, 2008
2
STEM Education

• Science, Technology, Engineering and Math
  Education
• Prepares students to pursue careers in
  engineering, science or technology-related fields

3
Needs in STEM Education

• Integrate theory with hands-on, experiential
  learning
• Collaborative, project-based learning
• Strong social relevance
• Design, creativity and innovation

4
Where is the engineer of 2020?
In 4th Grade 10 year olds!
5
Transforming the Academic Landscape
Rocket Science
Kindergarten
TRADITIONAL TECHNIQUE
6
Tech Savvy Generation
5 Years Old Music with iPod
22 Years Old Unmanned Vehicles
8 Years Old LEGO
12 Years Old Gaming Consoles
18 Years Old Segway Clone
7
New Wave of Engineering Education
Kindergarten
Rocket Science
HANDS-ON, PROJECT-BASED LEARNING
8
LabVIEW K to Rocket Science!
CERN Large Hadron Collider the most powerful
Instrument on earth
LEGO MINDSTORMS NXT the smartest, coolest toy
of the year
9
Project-Based Learning in High Schools
10
Vision

• to create a world where science and technology
  are celebrated
• where young people dream of becoming science and
  technology heroes
• Dean Kamen
• Founder

11
Organization Programs

• Mission is to INSPIRE, not EDUCATE
• BUT look at what is involved
• Math (algebra, geometry, trig, calculus)
• Science (physics, chemistry, experimentation)
• Language arts (writing, public speaking)
• Business (marketing, PR, fundraising)
• Finance (accounting)
• Computer Science (programming, 3D animation)
• Fabrication (woodworking, metalworking)
• Mentorship Working side-by-side with
  professionals
• Teamwork

12
Organization Programs
FIRST

• 501 (c) (3) not-for-profit public charity
• Founded 1989, by inventor Dean Kamen
• Headquarters in Manchester, NH
• Board Chairman John Abele, Founder Chairman of
  Boston Scientific
• 25 million operating budget
• 2,000 corporate sponsors
• 60,000 volunteers

13
FIRST Program Continuum
Varsity
FIRST Robotics Competition
Sports Model
Junior Varsity
Junior High
Pop Warner
Jr. FIRST LEGO League
FIRST LEGO League
FIRST Tech Challenge
K 1 2 3 4 5
6 7 8 9 10
11 12
Grade Level
14
Organization Programs
FIRST Robotics Competition
FIRST Robotics Competition Team Growth

• 37,000 high school students
• Average 24 students per team
• 31 minority
• 340 teams advance to the FIRST Championship

15
Impact

• Education in Science Technology
• FIRST Students vs. Comparison Group
• Seek Education in Science Technology
• Student twice a likely to go on to college
• Twice as likely to major in science or
  engineering
• More than three times as likely to major
  specifically in engineering

Source Brandeis University, Center for Youth and
Communities, Heller School for Social Policy and
Management
16
NI Robotics Platform for FIRST
Adoption of a Progressive Programming Platform in
2009

• FIRST Robotics Competition FIRST standardizes on
  NI CompactRIO, powered by NI LabVIEW, for the
  2009 robotics competition.
• FIRST Technical Challenge Adoption of the LEGO
  MINDSTORMS NXT platform, programmable with NI
  LabVIEW

17
Benefits of the New FIRST Controller

• Students can build more sophisticated robotics
  systems
• Improved autonomous performance
• Advanced vision capabilities
• Additional sensor choices
• Intuitive, graphical LabVIEW software development
  will increase participation in autonomous
  programming
• Industry-standard technology means students gain
  knowledge for university studies and professional
  careers

18
New 2009 FIRST Robotics Controller
NI CompactRIO, the industrys most compact,
powerful embedded controller - powered by NI
LabVIEW

• Flexible Inputs Outputs (I/O)
• More sensor choices
• More I/O lines
• Customizable I/O for future years

• Superior Performance
• 32 bit real time processor
• 802.11 Wireless Ethernet
• FPGA I/O control

• Advanced Control
• Intelligent Robotics Algorithms
• Real-Time Vision Processing

• Easy to Program
• Programmable in C and LabVIEW, the worlds
  leading graphical language
• Wireless debugging
• Laptop dashboard

• Rugged design
• 50G shock rating
• Easier connectivity

19
NI Investment and Support of FIRST

• Multimillion dollar in-kind donation
• RD investment
• Mentor program
• Technical Support Training
• Microcommunity
• Applications Engineers

20
Primary CompactRIO Suppliers
21
New Platform - FIRST Technical Challenge

• Rugged Based on the LEGO MINDSTORMS NXT
  platform, but with new, stronger metal parts can
  withstand a 40 drop!

Powerful - Intuitive, industry-standard graphical
development Program your robot with NI LabVIEW
, ROBOTC or NXT-G!
Wireless Bluetooth Communication
Smart 32-bit ARM processor for advanced control
Data Visualization Easily monitor data coming
from your robot
22

• Students begin to program at age 6 with
  intuitive, graphical, icon-based software
• Progressive Programming Platform - Technology
  that meets the needs of students of all ages
• Strong Industry Usage Strong adoption of
  LabVIEW in industry means students learn skills
  they can use in college and their careers.

23
Summary

• FIRST Robotics Competition Adoption of new
  CompactRIO control system for advanced robotics,
  powered by NI LabVIEW
• FIRST Tech Challenge Adoption of a ruggedized
  version of LEGO MINDSTORMS NXT that can be
  programmed with LabVIEW, ROBOTC OR NXT-G
• Continuous Programming Continuum for FIRST
  Robotics Programs

24
Questions?
