Program 3

1
Program 3

• BCNF vs 3NF

2
BCNF

• Written recursively
• Pseudo code

doBCNF(schema r , fds) Let fd BCNF violating
dependency in fds if fd is null then
return else split into two tables table1
fddomain U fdrange table2 r
fdrange doBCNF(table2, fds)
3
BCNF Results

• Average time taken to do decomposition
• 36ms
• Pros
• Easy to code
• Fast
• Cons
• Fds lost (see sample inputs)

4
BCNF Sample Inputs

• Example From Class
• Input
• R A,B,C,D,E,G
• F AB-C, C-A, BC-D, ACD-B, D-EG,
  BE-C,CG-BD,CE-AG
• Output
• C,A, D,E,G, B,C,D
• Lost Fds
• ACD-B, AB-C,BE-C,GC-BD,CE-AG

5
Another BCNF Example

• From Class Also
• Input
• R C,T,H,R,S,G
• F CS-G, C-T, HR-C, HS-R, HT-R
• Output
• C,S,G, C,T, H,R,C, H,R,S
• Lost Fds
• HT-R

6
Beers Example (from book)

• Input
• R beer, manf, bar, bar_addr, license, person,
  phone, person_addr, price
• F beer - manf, bar - bar_addr license,
  person - person_addr, phone, bar, beer -
  price
• Output
• beer, manf, bar, bar_addr, license,
  person, phone, person_addr, beer, bar, price

• Lost Fds
• None

7
Movies Example

• Input
• RMovie, Year, Director, Studio, LeadActor,
  LeadActress, Duration, BoxOfficeRevenue, Awards,
  Rating
• F Movie,Year - Director,Studio,Duration,BoxO
  fficeRevenue, Awards, Rating, Director, Studio,
  Year - Movie, LeadActor,Year - Movie
  LeadActress, Year - Movie
• Output
• Movie,Year,Director,Studio,Duration,BoxOfficeReve
  nue,Awards,Rating, Year,LeadActor,Movie
  ,Year,LeadActor,LeadActress
• Lost Fds
• LeadActress,Year-Movie

8
3NF Synthesis

• Implementation
• Broke into modules that performed a separate step
  in the algorithm
• MinimalCover, MergeLHS, FormSubSchema,
  MergeSubShema, AddMissing, AddKey
• Average Time Taken 200ms
• Pros
• Lossless
• Cons
• Slow and complex

9
3NF Example 1

• Example From Class
• Input
• R A,B,C,D,E,G
• F AB-C, C-A, BC-D, ACD-B, D-EG,
  BE-C,CG-BD,CE-AG
• Output
• A,B,C, B,C,D, D,E,G, B,E,C, C,G,B,
  C,E,G

10
3NF Example 2

• From Class Also
• Input
• R C,T,H,R,S,G
• F CS-G, C-T, HR-C, HS-R, HT-R
• Output
• S,C,G, C,T, R,H,C, S,H,R, T,H,R

11
3NF Example 3

• Input
• R beer, manf, bar, bar_addr, license, person,
  phone, person_addr, price
• F beer - manf, bar - bar_addr license,
  person - person_addr, phone, bar, beer -
  price
• Output
• beer, manf, bar,bar_addr,license,
  person,phone,person_addr, beer,bar,price
• Same as BCNF

12
3NF Example 4

• Input
• RMovie, Year, Director, Studio, LeadActor,
  LeadActress, Duration, BoxOfficeRevenue, Awards,
  Rating
• F Movie,Year - Director,Studio,Duration,BoxO
  fficeRevenue, Awards, Rating, Director, Studio,
  Year - Movie, LeadActor,Year - Movie
  LeadActress, Year - Movie
• Output
• Movie,Year,Director,Studio,Duration,BoxOfficeReve
  nue,Awards,Rating, Year,LeadActor,Movie
  ,Year,LeadActor,LeadActress, Year,LeadActress,M
  ovie

13
Hybrid Approach

• First use 3NF to generate temporary schemas
• Next, use BCNF on each of the temporary schemas
  to further decompose
• Eliminate possible redundancies
• Average Time 227ms (which is to be expected)

14
Hybrid Example 1

• Example From Class
• Input
• R A,B,C,D,E,G
• F AB-C, C-A, BC-D, ACD-B, D-EG,
  BE-C,CG-BD,CE-AG
• Output
• C,A, B,C,D, D,E,G, E,B,C, G,C,B,
  E,C,G
• Lost Fds
• ?

15
Hybrid Movies

• Input
• RMovie, Year, Director, Studio, LeadActor,
  LeadActress, Duration, BoxOfficeRevenue, Awards,
  Rating
• F Movie,Year - Director,Studio,Duration,BoxO
  fficeRevenue, Awards, Rating, Director, Studio,
  Year - Movie, LeadActor,Year - Movie
  LeadActress, Year - Movie
• Output
• Movie,Year,Director,Studio,Duration,BoxOfficeReve
  nue,Awards,Rating, Year,LeadActor,Movie
  ,Year,LeadActor,LeadActress, Year,LeadActress,M
  ovie
• Same as 3NF

16
Program 4

• Data Mining

17
Data Mining

• Artificial Neural Network
• Weka Implementation
• ANN with error back propagation
• Oracle-XE Database
• Java Connectivity
• Oracle Thin Driver
• Get database data with java and use Weka to build
  ANN and classify

18
Data Set

• Census Data
• Predict Income Class of US citizens given census
  data.
• Income Class 50,000
• For simplicity (difficult to predict exact
  income)
• 30,000 tuples
• CSV
• http//cs.uga.edu/mcknight/nlp/data.csv
• Database (login required)
• http//128.192.101.749090/apex

19
Results

• ANN with 27 internal nodes, 55 input nodes
• Training Data
• 66 of original data used for training
• the remaining 33 used as test set for
  classification
• Training Time 2050.91 seconds
• Error

Correctly classified 84.0665 Mean absolute
error 0.1698 Root mean
squared error 0.3558 Relative
absolute error 46.6323 Root
relative squared error 83.9026
