COSC 6114

1
COSC 6114
Prof. Andy Mirzaian
More Geometric Data Structures Windowing
2
References

• M. de Berge et al 00 chapter 10

• Data Structures
• Interval Trees
• Priority Search Trees
• Segment Trees

• Applications
• Windowing Queries
• Vehicle navigation systems
• Geographic Information Systems
• Flight simulation in computer graphics
• CAD/CAM of printed circuit design

3
Windowing
PROBLEM 1 Preprocess a set S of non-crossing
line-segments in the plane for efficient query
processing of the following typeQuery given
an axis-parallel rectangular query window W,
report all segments in S that intersect W.
4
Windowing
PROBLEM 2 Preprocess a set S of horizontal
or vertical line-segments in the plane for
efficient query processing of the following
typeQuery given an axis-parallel rectangular
query window W, report all segments in S that
intersect W.
5
INTERVAL TREES
PROBLEM 2 Preprocess a set S of horizontal
or vertical line-segments in the plane for
efficient query processing of the following
typeQuery given an axis-parallel rectangular
query window W, report all segments in S that
intersect W.
W
6
INTERVAL TREES
SUB-PROBLEM 1.1 2.1 Let S be a set of n
line-segments in the plane. Given an
axis-parallel query window W, the segments of S
that have at least one end-point inside W can be
reported in O(K log n) time with a data
structure that uses O(n log n) space and O(n log
n) preprocessing time, where K is the number of
reported segments.
Method Use 2D Range Tree on segment
end-points and fractional cascading.
7
INTERVAL TREES
Now consider horizontal (similarly, vertical)
segments in S that intersect W, but their
end-points are outside W. They must all cross the
left edge of W.
W
SUB-PROBLEM 2.2 Preprocess a set SH of
horizontal line-segments in the plane, so that
the subset of SH that intersects a query vertical
line can be reported efficiently.
Method Use Interval Trees.
8
INTERVAL TREES
Imed
Imed
Ileft
Ileft
Iright
Iright
xmed
Associated structure for Imed L left list
of segments in Imed sorted by their left
end-points, L right list of segments in Imed
sorted by their right end-points.
L left 3,4,5
L right 5,3,4
L left 6,7
L right 7,6
L left 1,2
L right 1,2
5
2
3
7
1
4
6
9
INTERVAL TREES

• THEOREM Interval Tree for a set of n
  horizontal intervals
• O(n) storage space
• O(n log n) construction time
• O(K log n) query time
• report all K data intervals that contain a
  query x-coordinate.

10
INTERVAL TREES
SUB-PROBLEM 2.3 Now instead of the query
being on a vertical line, suppose it is on a
vertical line-segment.
(qx, qy)
The primary structure of Interval Trees is still
valid.Modify the associated secondary structure.
q
(qx, qy)
SOLUTION L left Range Tree on left
end-points of Imed ,L right Range Tree on
right end-points of Imed .
(-? qx ? qy qy
q
xmed
11
INTERVAL TREES

• THEOREM Interval Tree for a set of n
  horizontal intervals
• O(n log n) storage space
• O(n log n) construction time
• O(K log2 n) query time
• report all K data intervals that intersect
  a query vertical line-segment.

• COROLLARY Let S be a set of n horizontal or
  vertical line-segments in the plane. We can
  preprocess S for axis-parallel rectangular query
  window intersection with the following
  complexities
• O(n log n) storage space
• O(n log n) construction time
• O(K log2 n) query time
• report all K data intervals that intersect
  the query window.

12
PRIORITY SEARCH TREES
Improving the previous solution the associated
structure can be implemented by Priority Search
Trees, instead of Range Trees.

• P p1, p2, , pn ? ?2. A Priority Search
  Tree (PST) T on P is
• a binary tree, one point per node,
• heap-ordered by x-coordinates,
• (almost) symmetrically ordered by y-coordinates.

13
PRIORITY SEARCH TREES
pmin
pmin ? point in P with minimum
x-coordinate. ymin ? min y-coordinate of
points in P ymax ? max y-coordinate of points
in P P ? P pmin ymed ? y-median of
points in P Pbelow ? p? P py ? ymed
Pabove ? p? P py gt ymed
ymin , ymax
PST on Pbelow
PST on Pabove
p7
p3
y7
y7
p3
p1
pmin
p7
y6
y3
p6
p1
p6
y6
y6
y4
y3
p2
ymed
p2
p5
p5
y4
y2
y5
y5
p4
p4
y4
y4
14
PRIORITY SEARCH TREES

• Priority Search Tree T on n points in the plane
  requires
• O(n) storage space
• O(n log n) construction time
• either recursively, or
• pre-sort P on y-axis, then construct T in
  O(n) time bottom-up. (How?)

• Priority Search Trees can replace the secondary
  structures (range trees) in Interval Trees.
• simpler (no fractional cascading)
• linear space for secondary structure.

15
How to use PST to search for a query range R
(-? qx ? qy qy ?
ALGORITHM QueryPST (v, R) if v nil or pmin
x(v) gt qx or ymin(v) gt qy or ymax(v) lt qy
then return if pmin x (v) ? qx and qy ?
ymin(v) ? ymax(v) ? qy then
Report.In.Subtree (v, qx) else do
if pmin x (v) ? R then report pmin x(v)
QueryPST (lc(v), R) QueryPST
(rc(v), R) end else end
qy
ymax
T v
qx
R
pmin
ymin
qy
Truncated Pre-Order on the Heap O(1 Kv) time.
PROCEDURE Report.In.Subtree (v, qx) if vnil
then return if pmin x (v) ? qx then do
report pmin x(v) Report.In.Subtree (lc(v),
qx) Report.In.Subtree (rc(v), qx) end if end
v
PST
16
LEMMA Report.In.Subtree(v, qx) takes O(1 Kv)
time to report all points in the subtree
rooted at v whose x-cooridnate is ? qx , where Kv
is the number of reported points.

• THEOREM Priority Search Tree for a set P of n
  points in the plane has complexities
• O(n) Storage space
• O(n log n) Construction time
• O(K log n) Query time report all K points
  of P in a query range R (-? qx ? qy
  qy .

PST
qy
qy
17
SEGMENT TREES
Back to Problem 1 Arbitrarily oriented line
segments.
Solution 1 Bounding box method.
Bad worst-case. Many false hits.
W
W
18
SEGMENT TREES
Back to Problem 1 Arbitrarily oriented line
segments.
Solution 2 Use Segment Trees. a) Segments with
end-points in W can be reported using
range trees (as before). b) Segments that
intersect the boundary of W can be reported
by Segment Trees.
SUB-PROBLEM 1.1 Preprocess a set S of n
non-crossing line-segments in the plane
into a data structure to report those segments in
S that intersect a given vertical query
segment q qx ? qy qy
efficiently.
19
SEGMENT TREES
Elementary x-intervals of S (-? p1), p1
p1, (p1 p2), p2 p2, , (pm-1 pm), pm
pm, (pm ?). Build a balanced
search tree with each leaf corresponding
(left-to-right) to an elementary intervals (in
increasing x-order). Leaf v Int(v) set
of intervals (in S) that contain the elementary
interval corresponding to v.
p1
p2
p3
pm
. . .
IDEA 1 Store Int(v) with each leaf v.
Storage O(n2), because intervals in S that
span many elementary intervals will be stored in
many leaves.
20
SEGMENT TREES
IDEA 2 ? internal node v Int(v) union of
elementary intervals corresponding to the
leaf-descendents of v.Store an interval xx
of S at a node v iff Int(v) ? xx but
Int(parent(v)) ? xx. Each interval of S is
stored in at most 2 nodes per level (i.e., O(log
n) nodes).Thus, storage space reduces to O(n log
n).
What should theassociated structure be?
s2,s5
s5
s1
s1
s3
s1
s3,s4
s3
s4
s2,s5
s2
s3
s1
s5
s4
21
SEGMENT TREES
v1
S(v1) s3
v3
S(v3) s5 , s7
v2
S(v2) s1 , s2
s7
s3
s6
s2
s5
s4
s1
22
SEGMENT TREES
Associated structure is a balanced search tree
based on the vertical ordering of segments S(v)
that cross the slab Int(v) ? (-? ?).
s6
s6
s5
s5
s4
s4
s3
s2
s3
s2
s1
s1
23
SEGMENT TREES

• THEOREM Segment Tree for a set S of n
  non-crossing line-segments in the plane
• O(n log n) Storage space
• O(n log n) Construction time
• O(K log2 n) Query time report all K
  segments of S that intersect a vertical query
  line-segment.

COROLLARY Segment Trees can be used
to solve Problem 1 with the above
complexities. That is, the above complexities
applies if the query is with
respect to an axis-parallel rectangular window.
24
Exercises
25

• Let P be a set of n point sin the plane, sorted
  on y-coordinate. Show that, because S is
  sorted,a Priority Search Tree of the points in P
  can be constructed in O(n) time.
• Windowing queries in sets of non-crossing
  segments are performed using range query on the
  set of end-points and intersection queries with
  the four boundary edges of the query window.
  Explain how to avoid reporting segments more than
  once. To this end, make a list of all possible
  ways in which an arbitrary oriented segment can
  intersect a query window.
• Segment Trees can be used for multi-level data
  structures. (a) Let R be a set of n
  axis-parallel rectangles in the plane. Design a
  data structure for R such that the
  rectangles in R that contain a query point q can
  be reported efficiently. Analyze the
  amount of storage and the query time of your
  data structure. Hint Use a segment tree on
  the x-intervals of the rectangles, and store
  canonical subsets of the nodes in this segment
  tree in an appropriate associated
  structure. (b) Generalize this data structure
  to d-dimensional space. Here we are given a set
  of axis- parallel hyper-rectangles, i.e.,
  polytopes of the form x1 x1 ? x2 x2 ?
  ? xd xd , and we want to report the
  hyper-rectangles that contain a query point.
• Let I be a set of intervals on the real line. We
  want to store these intervals such that we can
  efficiently determine (a) those intervals that
  are completely contained in a given interval x
  x. Describe a data structure that uses
  O(n log n) storage and solves such queries in O(K
  log n) time, where K is the output size.
  Hint Use a range tree. (b) The same
  question as in part (a), except that we want to
  report the intervals that contain a query
  interval x x.

26

• Consider the following alternative approach to
  solve the 2-dimensional range searching problem
  We construct a balanced search tree on the
  x-coordinate of the points. For a node v in the
  tree, let P(v) be the set of points stored in the
  subtree rooted at v. For each node v we store
  two associated priority search trees of P(v), a
  tree T left allowing for range queries that are
  unbounded to the left, and a tree T right for
  range queries that are unbounded to the right.
  A query with a range x x ? y y is
  performed as follows. We search for the node
  vsplit where the search paths toward x and x
  split in the tree. Now we perform a query with
  range x ? ) ? y y on T right(lc(v))
  and a query with range (-? x ? y y on T
  left(rc(v)). This gives all the answers (there
  is no need to search further down in the tree!).
  (a) Work out the details of this approach. (b)
  Prove that the data structure correctly solves
  range queries. (c) What are the bounds for
  preprocessing time, storage space, and query time
  of this structure? Prove your answers.

27
END
