Title: LITHIUM BATTERY PRODUCTION DRY ROOMS


1
LITHIUM BATTERY PRODUCTION DRY ROOMS
  • Robert Smith
  • Harris Environmental Systems Inc
  • March 2001

2
How Dry Do You Need Your Dry Room To Be?
  • With Lithium Metal Primary Batteries, 2RH or
    Less Is Typical
  • For Li Polymer, Do Lower dewpoints Higher
    Yields??
  • 1RH -34 C Dewpoint 246 ppmv
  • .5RH -40 C Dewpoint 127 ppmv
  • .04RH -60 C Dewpoint 10.6 ppmv
  • -60 C Is Now Available, But Is It Needed?

Harris Environmental Systems
3
Li Ion and Li Primary Dry Room Dewpoints
  • Return Air Supply Air
  • Sony (Ion) -36 C (198 ppmv) -56 C (18
    ppmv)
  • PolyStor (Ion) -29 C (430 ppmv) -48 C (50
    ppmv)
  • LG (Ion) -34 C (246 ppmv) -60 C (10
    ppmv)
  • UltralifePrimary-29 C (430 ppmv) -48 C (50ppmv)
  • What dewpoint is correct??? Possibly all of the
    above based on the battery materials utilized.

Harris Environmental Systems
4
Automation Higher Dry Room Heat Loads
  • Increased Heat Loads Will Increase Room Cooling
    Requirements
  • Higher Loads Greater Refrigeration HP
    Additional Dry Room Air Handlers
  • RESULT Increased Dry Room Energy
    Costs Higher Cell Variable Costs
  • Be Careful !! Most Facilities Overestimate
    Machine Automation BTUH

Harris Environmental Systems
5
The Benefits of HPX Rotors
  • No Chance of Rotor Washout or Breakdown With a
    Loss of Reactivation Heat
  • Lower Dewpoints, -60 C is Easy Now
  • 10 Year Structural Warranty if Filters Are
    Cleaned
  • Rotors Can Be Washed With Water If Dirty
  • Dry Room Performance is Improved
  • Proven in Harris Dry Rooms Since 1993

Harris Environmental Systems
6
Compare HPX 9000 CFM D/H System at-48 C Dewpoint
vs. -60C Dewpoint
  • With -48 C Dewpoint supply air, you get
  • 6635 CFM supply
  • 1738 CFM exhaust
  • 35 people at 2
  • 17 people at 1
  • 105 HP refrigeration
  • 142,000 BTUH Room Cooling Capacity
  • With -60 C Dewpoint supply air, you get
  • 4800 CFM supply
  • 1000 CFM exhaust
  • 29 people at 2
  • 14 people at 1
  • 80 HP refrigeration
  • 100,000 BTUH Room Cooling Capacity

Harris Environmental Systems
7
Comparison of HPX Composite vs. LiCL Desiccant
Rotors
  • HPX Rotors
  • Can supply air at -60 C Dewpoint (10.6 ppmv)
  • No wheel structural breakdown with loss of
    reactivation heat
  • 10 year life expectancy
  • With same size rotors and identical dewpoints,HPX
    can process 50 more air than a LiCL rotor
  • Lithium Chloride Rotors
  • Can supply air at -48 C Dewpoint (49.7 ppmv)
  • Wheel structure may breakdown if low temp
    reactivation continues
  • 3-10 year life expectancy

8
Harris DryWare DDC Dry Room Control System
Architecture
Supervisory Controller
Local Controller For 1st D/H System
Modem for Harris/Client Service Access
Local Controller for 1st Refrigeration System
Terminal for Client Access
Local Controller For 2nd D/H System
Touchscreen for System Access
Local Controller For 2nd Refrigeration System
Harris Environmental Systems
9
Variables Measured with Harris Dry Room DDC
Controls
  • Blended air temperature entering the
    dehumidifier.
  • Discharge air temperature off the dehumidifier
    wheel.
  • Room supply and return temperature.
  • Leaving air temperature off the pre-cool coils
    for return and make up air.
  • Suction temperature on each condensing unit.
  • Discharge temperature on each compressor.
  • Discharge pressure on each condensing unit.
  • Dewpoint control monitoring.

10
Comparison of HX Desiccant vs. LiCL Rotors 9000
CFM
  • HPX Rotors at -48 C DP
  • Max. Volume 9000 CFM
  • Max. Supply Air 6635 CFM
  • Max. Exhaust 1738 CFM
  • 35 People at 2RH
  • 17 People at 1RH
  • Can supply air at -60 C Dewpoint (10.6 ppmv) for
    ultradry applications if required
  • LiCL Rotors at -48 C DP
  • Max. Volume 6000 CFM
  • Max. Supply Air 4455 CFM
  • Max. Exhaust 1091 CFM
  • 23 People at 2RH
  • 12 People at 1RH
  • Can supply air at -48 C Dewpoint (49.7 ppmv)

11
Sony Harris DH Series Skid, 9000 CFM,
1 of 3 Systems
Harris Environmental Systems
12
Sony Harris DH skid, Steam Reactivation
Piping Ducting
Harris Environmental Systems
13
Sony Harris DH System Air Cooled Condensing
Units
Harris Environmental Systems
14
Sony Li Polymer Dry Room Layout
Harris Environmental Systems
15
Typical Li Battery Dry Room
  • Multiple D/H Systems
  • Clean/Dry Room
  • DryWare DDC Controls

Harris Environmental Systems
16
(No Transcript)
