SUPERNUMERARY BOWS

1
SUPERNUMERARY BOWS

• By
• Katrina Brubacher
• Asha Padmanabhan

2
      Rainbow commonly refers to a single
circular arc of non repeating colors.
3
(No Transcript)
4

• Is the rainbow a spot 42 above your heads
  shadow?

5

• Is the rainbow a spot 42 above your heads
  shadow?
• A spherical raindrop will not prefer one
  direction to another.
• All locations that lie 42 from the shadow of
  your head are equally likely to send the
  concentrated rainbow to you.

6
Therefore the primary rainbow is a circle
with radius 42 and its center at your heads
shadow.
7
Alexanders Dark Band

• Most of the rays that come out of a drop are
  concentrated at 138 from the sun, but some light
  is bent through all angles between 180 and 138

8
SUPERNUMERARY BOWS

• Supernumeraries are much more common than youd
  think but the number that are seen vary.
• Their colors also vary. The most common colors
  are pinks and bluish greens but yellow is
  sometimes also observed as well as violet.

9
Newton believed that the behavior of light was
best explained as a series of small particles
traveling from the light source to the eye but
this does not explain the presence of
supernumerary bows.
10
 Supernumeraries proved to be the midwife that
delivered the wave theory of light to its place
of dominance in the 19th century.
Rainbow Bridge
11
Youngs Theory
12
Youngs Theory

• In the 1800s most scientists agreed with Newton,
  but Robert Hooke and Christiaan Huygens believed
  that light behaved more like waves than
  particles.

13
Youngs Theory

• In the 1800s most scientists agreed with Newton,
  but Robert Hooke and Christiaan Huygens believed
  that light behaved more like waves than
  particles.
• In 1803 Thomas Young asserted that supernumerary
  bows could be explained only if light were
  thought of as a wave phenomenon.

14
Interference

• It is the interference of waves that explains
  supernumerary bows.

15
Interference cont.

• It is the interference of waves that explains
  supernumerary bows.
• If the crests of two waves coincide, they
  reinforce each other to make a larger wave. If a
  crest of one wave sits in the trough of another,
  the two disturbances cancel each other and the
  medium will be at its original level.

16
Interference cont.

• It is the interference of waves that explains
  supernumerary bows.
• If the crests of two waves coincide, they
  reinforce each other to make a larger wave. If a
  crest of one wave sits in the trough of another,
  the two disturbances cancel each other and the
  medium will be at its original level.
• This is called constructive and destructive
  interference.

17

• Supernumerary bows are not caused by the
  interference between two light waves, they are
  caused by the interference of two different
  portions of the same light wave.

18
(No Transcript)
19
Size of raindrops

• Young used the wave theory to account for the
  color and brightness of the supernumerary bows
  and to estimated the sizes of raindrops that
  yielded supernumeraries.

20
Size of raindrops cont.

• The size of the raindrops change the appearance
  of the supernumerary bows.
• A smaller drop gives widely spaced bows, the
  larger drop gives more tightly spaced bows and
  each bow is narrower.
• The first supernumerary for the smaller drop
  occurs at the same deviation angle as the second
  supernumerary of the larger drop.

21
Size of raindrops cont.

• When the drops are small, each bow is broad,
  including the primary. Hence the bows colours
  overlap and appear pastel

22

• Young was able to estimate the raindrop size of a
  shower based on the spacing between supernumerary
  bows. The spacing decreases as the drop
  increases.
• The reason for this is that the spacing of bright
  and dark bands in the folded wave front depends
  on the path length the wave has traversed within
  the drop.

23
Size of raindrops cont.

• In nature, drops with a radius that is greater
  than 0.4mm can make the supernumeraries brighter
  than the primary rainbow.

24

• Supernumeraries of the secondary rainbow?

25

• Young did not give a quantitative account of the
  interference theory of the rainbow.

26

• Young did not give a quantitative account of the
  interference theory of the rainbow.
• For a numerical description we must look to
  Airys Integral.

27
George Biddel Airy (1801-92)

• Airys theory of the rainbow extended and
  mathematically formalized Youngs largely
  empirical explanations of interference within a
  raindrop.

28
AIRYS MATHEMATICS

• The explanation for the supernumerary bows come
  from looking at light exiting a raindrop.
• The light is sharply cut off in the direction of
  minimum deviation and the effects are similar to
  those of a shadow along a straight edge. This
  was first solved by Fresnel.

29
Fresnels Integral

• Total disturbance given by
• Ao sin pt ? cos d dx Ao cos pt ? sin d dx
• where
• ? cosd dx B ? cos(?v²/2) dv
• ? sind dx B ? sin (?v²/2) dv

30

• In a rainbow the effects of diffraction are seen
  just inside the illuminated area. This area is
  cut off by the cone of minimum deviation.
• This leads to bright and dark bands within the
  primary bow or outside the secondary bow
  supernumerary bows.

31
(No Transcript)
32
AIRYS INTEGRAL

• A ( ?a²/(4kcos?))? ? cos ((?/2)(u³-zu) du

33
bow number z at max intensity z at min intensity
1 1.085 2.4955
2 3.4669 4.3631
3 5.1446 5.8922
4 6.5782 7.2436
5 7.8685 8.4788
6 9.0599 9.6300
7 10.1774 10.7161
8 11.2364 11.7496
9 12.2475 12.7395
10 13.2185 13.6925
34

• Weve computed the values of the table by using a
  series developed from Airys Integral.

Pochhammer


35
bow number z at max intensity intensity z at min intensity intensity
1 1 0.2868 2.3 0.0007
2 3.1 0.1392 3.6 0.0016
36
(No Transcript)
37
Things that are NOT possible
38
T H E E N D
T H E E N D
T H E E N D
