Title: Energy Power System


1
Energy Power System
2
Electricity
  • Electricity is the flow of electrons through a
    conductor
  • Electricity will only move through a closed
    circuit, if the circuit is broken the flow of
    electrons stops

3
Electricity (cont.)
  • Voltage - Electric potential or potential
    difference, provided by the battery, expressed in
    volts
  • Amperage - The strength of an electric current,
    flows through the conductors to the load,
    expressed in amperes
  • Resistance - Is present in any load, expressed in
    ohms

4
Light to Power
  • Solar Panels collect sunlight and convert them
    into electrical power
  • For maximum power solar arrays need to be
    perpendicular to the light rays hitting them.

5
Orbit Cycle
  • During the 30 minute eclipse period the batteries
    supply power
  • While in insolation period the solar arrays
    provide power while the batteries charge for the
    next eclipse period

6
Primary and Secondary power
  • Primary power is high voltage power generated at
    a centralized source
  • Before power is delivered to users it is stepped
    down by a transformer to a set voltage (secondary
    power)
  • Secondary power is then delivered to the user

7
System Overview
  • Internal and external systems
  • Internal system distributes secondary power
  • External distributes primary power
  • 8 identical channels of power (0-7)
  • Each channel supplies 100 amps of current

8
Internal EPS
  • Loads, RPDA, SPDA, DDCU, MBSU, ICC
  • Converts primary power to secondary power
  • Routes secondary power to any internal systems

9
Loads
  • A load is anything that needs electricity to
    function.
  • Computers, Lights, Pumps, etc.
  • Each load requires a certain current (amps) which
    is specific to that device
  • Not all loads are physically inside the station,
    but all are supplied by the same internal
    distribution network

10
SPDA/RPDA/DDCU
  • Secondary Power Distribution Assembly
  • Supports a single channel of power
  • A is even channel B is odd channel
  • Routes power to one RPDA and six loads
  • Reserve Power Distribution Assembly
  • Routes power to six loads
  • Direct current to Direct current Converter Unit
  • This is the unit that converts primary power
    (160 V dc) to secondary power (124 V dc)

11
MBSU/ICC
  • Main Buss Switching Unit
  • Each support 2 channels of power with a total of
    200 amps
  • Routes power to two SPDAs
  • Interconnecting Cables
  • Create a bridge for two or more MBSUs to share
    power across them

12
External EPS
  • SARJ, IEA, ECU, SSU, PCU, BGA, PVA
  • Produces primary power from the solar arrays, and
    stores power in batteries for eclipse phase

13
SARJ
  • Solar Alpha Rotary Joint
  • Rotates 4 channels of power at one time
  • Controls rotation parallel to the main station
    truss

14
IEA
  • Integrated Equipment Assembly
  • Battery Charge Discharge Unit (BCDU)
  • When signaled by the ECU the BCDU begins charging
    or discharging the batteries
  • Batteries (BAT)
  • Batteries store power for use during the eclipse
    phase of the stations orbit

15
IEA (continued)
  • Direct Current Switching Unit (DCSU)
  • Routes power from BGA to batteries, IEA, and
    Internal system
  • Direct current to Direct current Converter Unit
    (DDCU)
  • Provides Secondary power for IEA components only.

16
IEA Thermal control system
  • IEA has a self contained thermal control system
    for each channel
  • Small radiators under each IEA dissipate heat
    from the SSU as well as batteries and other IEA
    components
  • This system functions in the same manner as the
    main TCS for the station
  • Pump and Flow Control Subassembly (PFCS) and
    Photovoltaic Radiator (PVR)

17
ECU/SSU
  • Electronic Control Unit
  • Manages when to charge and discharge the
    batteries
  • Sequential Shunt Unit
  • Shunts any excess power generated as heat
  • Small radiator beneath each PVA radiates heat

18
Grounding
  • To prevent electricity from arcing across the
    station all electrical devices are grounded to
    the main truss.
  • Plasma Contractor Unit (PCU)
  • Emits a stream of plasma to ground the space
    stations main truss to space
  • Prevents arcing to any external spacecraft during
    docking or EVA

19
BGA/PVA
  • Beta Gimbal Assembly
  • Rotates one channel of power per BGA
  • Controls rotation perpendicular to the main
    station truss
  • Photovoltaic Array
  • Collects sunlight and converts it into electrical
    power

20
Warning Signs of a SOBE
  • Red indicator light on the system wall
  • Loss of Power (I.e. lights or computer
    unexpectedly shut down)
  • Warning through HAL or other system
  • Contingency of another SOBE

21
Things to check during a SOBE
  • For maximum power the panels must be
    perpendicular to the sunlight, if misaligned they
    may not produce enough power
  • There are many points were power can be stopped,
    be sure to check them all
