RETRIEVAL EVALUATION

1
Chapter 2

• RETRIEVAL EVALUATION

2
INTRODUCTION

• Evaluation necessary
• Why evaluate ?
• What to evaluate?
• How to evaluate?

3
WHY EVALUATE

• Need to know the advantages and disadvantages of
  using a particular IRS . The user should be be
  able to decide whether he / she wants to use an
  IRS based on evaluation results.
• The user should also be able to decide whether it
  is cost-effective to use a particular IRS based
  on evaluation results.

4
WHAT TO EVALUATE

• What can be measured and should reflect the
  ability of the IRS to satisfy user needs.
• Coverage of system to what extent the IRS
  includes relevant material
• Time lag average interval between the time the
  user query request is made and the time taken to
  obtain an answer set.
• Form of presentation of output
• Effort involved on part of user in getting
  answers to his / her query request.
• Recall of the IRS - of relevant materials
  actually retrieved in the answer to a query
  request.
• Precision of the IRS - of retrieved material
  that is actually relevant.

5
HOW TO EVALUATE?

• Various methods available.

6
EVALUATION

• 2 main processes in IR
• User query request/query request/ information
  query/query retrieval strategy / search request
• Answer set / Hits
• Need to know whether the documents retrieved in
  the answer set fulfills the user query request.
• Evaluation process known as retrieval performance
  evaluation.
• Evaluation is based on 2 main components
• Test reference collection
• Evaluation measure.

7
EVALUATION

• Test reference collection consists of
• A collection of documents
• A set of example information requests
• A set of relevant documents (provided by
  specialists) for each information request
• 2 interrelated measures RECALL and PRECISION

8
RETRIEVAL PERFORMANCE EVALUATION

• Relevance
• Recall and Precision
• Parameters defined
• I information request
• R set of relevant documents
• R number of documents in this set
• A document answer set retrieved by the
  information request
• A number of documents in this set
• Ra number of documents in the intersection of
  sets R and A

9
RETRIEVAL PERFORMANCE EVALUATION

• Recall fraction of the relevant documents (set
  R) which have been retrieved
• Ra
• R -----
• R

• Precision fraction of the retrieved documents
  (set A) which is relevant
• Ra
• P -----
• A

10
Collection
Relevant docs in answer set Ra
Relevant docs R
Answer set A
Precision and Recall for a given example
information request
11
RETRIEVAL PERFORMANCE EVALUATION

• Recall and precision are expressed as
• Sorted by degree of relevance or ranking.
• User will see a ranked list.

12
RETRIEVAL PERFORMANCE EVALUATION

• a. 10 documents in an IRS with a collection of
  100 documents has been identified by specialists
  as being relevant to a particular query request
  - d3, d5, d9, d25, d39, d44, d56, d71, d89, d123
• b. A query request was submitted and the
  following documents were retrieved and ranked
  according to relevance.

13
RETRIEVAL PERFORMANCE EVALUATION

• d123
• d84
• d56
• d6
• d8
• d9
• d511
• d129
• d187

• d25
• d38
• d48
• d250
• d113
• d3

14
RETRIEVAL PERFORMANCE EVALUATION

• c. Only 5 documents retrieved (d123, d56, d9,
  d25, d3) are relevant to the query and matches
  the ones in (a).

15

• d123 ranked 1st R1/10 x 100 10
• P1/1 x 100 100
• d56 ranked 3rd R2/10 x 100 20
• P2/3 x100 66
•
• d9 ranked 6th R3/10 x 100 30
• P3/6 x 100 50
•
• d25 ranked 10th R4/10 x 100 40
• P4/10 x 100 40
•
• d3 ranked 15th R5/10 x 100 50
• P5/15 x 100 33

16
A relevant documents non-relevant
documentsC retrieved documentsC not
retrieved documentsN total number of documents
in the system Relevant Non-relevantRetr
ieved A ? C Â ? CNot retrieved A ? C Â ? C

• Contigency table

17
RETRIEVAL PERFORMANCE EVALUATION

• Contingency table
• N 100
• A10, A 90
• C15, C 85

Recall 5/10X100 50 , Precision 5/15X100
33
18
OTHER ALTERNATIVE MEASURES

• Harmonic mean a single measure which combines R
  P
• E measures - a single measure which combines R
  P, user specifies whether interested in R or P
• User-oriented measures - based on a the users
  interpretation of which documents are relevant
  and which documents are not relevant
• Expected search length
• Satisfaction focuses only on relevant docs
• Frustration focuses on non-relevant docs

19
REFERENCE COLLECTION

• Experimentations on IR done on test collection
  eg. of test collection
• 1. Yearly conference known as TREC Text
  Retrieval Conference
• Dedicated to experimentation with a large test
  collection of over 1 million documents, testing
  is time consuming.
• For each TREC conference, a set of reference
  experiments designed and research groups use
  these reference experiments to compare their IRS
  TREC NIST site http//trec.nist.gov

20
(No Transcript)
21
REFERENCE COLLECTION

• Collection known as TIPSTER
• TIPSTER/TREC test collection
• Collection composed of
• Documents
• A set of example information requests ot topics
• A set of relevant documents for each example
  information request

22
OTHER TEST COLLECTIONS

• ADI documents on information science
• CACM computer science
• INSPEC abstracts on electronics, computer and
  physics
• ISI library science
• Medlars medical articles
• developed by E.A. Fox for his PhD thesis at
  Cornell University, Ithaca, New York in 1883
  Extending the Boolean and vector space models of
  information retrieval with p-norm queries and
  multiple concept types http//www.ncstrl.org
