CBS Overview
2
CBS
Migration process
LET US TAKE CLOSURE LOOK
ROUTER
ROUTER
3
ZNC
BRANCH
ROUTER
NC
4
ROUTER
LAN
5

Network Design
Data Centre
ZNC1
ZNCn
ZNC2
NCn
NC1
NC2
Br11
Br1n
Br21
Brn1
Br2n
Brnn
___ 2 Mbps Leased Line ___ 64 Kbps Leased
Line ---- ISDN PRI link ---- ISDN BRI link
ZNC Zonal Network Centre NC Network
Centre Br Branch
6

• Features of CBS

7
Features of CBS

• Centralized Banking Solution
• Data of all the customers are centralized
• Single data base of all the customers
• Facilitates real time access of customer data
  from any of the connected branch or office.
• Role based access control
• Parameter setup is centralized
• Role out of products and schemes are uniform and
  achieved from central location

8
Features of CBS .contd.

• Standardized procedures across the bank
• Facilitates centralized monitoring
• Single view of the customer
• Same view of the data for all stake holders
  depending on their role and responsibilities.
• Centralized generation of important reports
• Centralized activities for enhanced productivity
  and operational efficiency.

9

• CBS Architecture

10
Finacle Structure - BASICS
Database Server
Application Server
web Server
Storage
Switch
User Interface
Server management console
11
DATABASE SERVER -USERS GET THEIR DATA PROCESSED
STORAGE
4 APPLICATION SERVERS -USERS GET THEIR COMMANDS
EXECUTED
2 WEB SERVERS -USERS GET THEIR FIRST PAGE
12
Surround Applications
ATM
WEB SERVER
IBS
13
How does Surround Application Works?

• Surround applications like ATM , IBS are
  different systems and they can not communicate
  directly with CBS.
• An intermediate server known as Connect 24 (
  Bancsconnect) facilitates the communication.
• Communicate to CBS in ISO8583 standard format.
• ATM and IBS are required to be available to the
  customers on 24 X 7.
• But during the day end , day begin and other
  maintenance period, the CBS server may not be
  available for these ADC ( Alternate delivery
  channels)

14
How to provide the Services?

• Another server known as CSIS (Centralized Stand
  In Server) is introduced
• CSIS will be have the latest / current account
  details ( like balance, transactions etc,) as
  available in CBS DB server.
• It gets the continues updates from CBS DB server
• BC will take ADC transactions to CSIS during the
  outage of CBS DB server.
• Customer is serviced

15

• Precaution to be taken is
• When the CBS DB server is UP, the Transactions
  made in the CSIS server are to be updated first.
• System has been designed to handle so.
• In case it is not updated , the transactions of
  CSIS will not be reflected in CBS DB
• Similarly, in case the CSIS server is down when
  CBS DB is up and functioning, the transaction
  details of CBS DB will not be reflected in CSIS.
• Both are not desirable
• It is monitored and managed 24 x 7 by DC

16
Anytime, Anywhere Banking
17

• Redundancy and Fall back
• Disaster Setup

18

• Technology will face hiccups
• Adequate redundancy is to be build
• In every possible stage of the setup
• Data Centre (DC)
• DRS with 100 computing power
• Data is replicated to DRS continuously from DC,
  with a time gap of 30 mts.
• Storage based replication for cbs
• Oracle based ( data guard).
• DRS can be started within 2 hours of DC
  disruption.

19

• However DRS switch over is the last resort.
• Sufficient redundancy has been build in the DC
  setup
• The servers are in clusters
• DB server has a similar server of same capacity
  and power
• In case the main DB server fails the standby
  server will start functioning within a time lag
  of 10- 15mts.
• This time is required to start the services in
  the standby server
• Web servers are in clusters ( fail over) so as
  application servers.

20

• Storages are in RAID 10
• Every bit of data is written in 2 disks (
  Mirroring)
• Any one disk failure will enable us to retrieve
  the data from the mirrored disk
• System handles it automatically.
• NETWORK redundancy
• ZNCs are connected to DC and DRS through separate
  lease line
• DC and DRS are connected through link from BSNL
  and Reliance ( 2 separate links)
• Any link failure between ZNC and DC
• Connectivity can be established through ZNC
  -gtDRS-gtDC

21

• ZNCs and DC / DRS have ISDN connection , which
  shall be used for connectivity in case of lease
  line failure
• The connection between NC ZNC and BOs NC /
  ZNC
• Are established with LL and ISDN
• Now the second connection is established with
  VSAT or RF.
• But, still the connectivity is lost at branch
  level
• BCP is to be followed for uninterrupted customer
  service.

22

• CBS Flow of Transactions

23

• User access CBS either from PC or Thin client.
• It is a web browser based access ( I.E)
• Similar to Internet browsing
• URL is intranet address
• Access is granted after authentication of userid
  and password
• User command is transmitted from PC on commit
• F4 or F10

24
router
25

• CBS Finacle Architecture

26
Finacle Technology Platform

• Unix
• different flavors of Unix
• RDBMS
• Oracle
• Browser
• universal client

27
Finacle Functional Architecture
B A N K
C U S T O M E R
External Interfaces
Browser based Teller
Other applications connected on-line
ATM/ POS
Phone banking
BankAway
Bancs_at_Web
BancsConnect
Application and User level Security
Multilingual Workflow Report Writer
Signature Display Interest
Services
Business Rules
Customer information
Parameterised
Trade Finance
Retail Corporate
Tools and Utilities
Help Inventory Memo Pad Letter
Generator Audit Trail Charges Menu
Upload Security Register SWIFT
Purge Clearing
Accounting Backbone
General Ledger Transaction Manger
Multi-currency
Database OS Security
OS RDBMS
Oracle Unix variants
28
Finacle Retail Corporate
29
Finacle - Trade Finance
30

• USER GROUPS
• IN CBS

31

• All users logging into the application have a
  unique user ID and a password.
• Based on the kind of banking operations performed
  by these users they are grouped into different
  user Groups.

32
Work Class

• 010 CLERK
• 015 CTO Category A
• 020 CTO Category B
• 030 SPECIAL ASSISTANT
• 040 OFFICER
• 050 ASSISTANT MANAGER
• 055 DEPUTY MANAGER
• 060 MANAGER
• 070 SENIOR MANAGER
• 080 CHIEF MANAGER
• 090 ASSISTANT GENERAL MANAGER
• 095 DEPUTY GENERAL MANAGER
• 099 GENERAL MANAGER
• 100 INCUMBENT IN-CHARGE
• 200 AUDITOR
• 300 DBA

33
Type of Users in CBS

• AD ADMINISTRATIVE OFFICE
• BO BACK OFFICE USERS
• DB SYSTEM INCHARGE
• DC DBA - DATA CENTER
• DQ DATA CENTRE-INQUIRY
• GU GENERAL USER
• HO HO DIVISIONS USERS
• IN INSPECTORS

34
Captive / Free users

• CAPTIVE The CAPTIVE user with a captive status
  can access the data belonging to his service
  outlet alone but can inquire on the accounts
  belonging to other SOL.
• FREE FREE user can access the data belonging
  to all service outlets.

35

• CBS Case Setup at PNB

36

• It is one of the largest Single instance Oracle
  database
• Maximum number of concurrent users 17000
• The size of the database is around 4 TB
• Daily transactions of around 20 22 Lacs
• ADC transactions is around 2 Lacs (daily)
• Separate MIS server

37
Central data repository -improve quality -removes
in consistency -avoids duplicity.

• Proposed IT Infrastructure to meet the total
  business needs

The surround application will be managed by
focused teams
CBS Transaction Processing system
EDW MIS and Data Mining system
User will interact with CBS and EDW only
New Business requirements can be met with either
a new application or customisation of CBS
38
YOUR QUERIES ?
