Genetic Inheritance

1
Genetic Inheritance
2
Mendels Laws

• Gregor Mendel was an Austrian monk who in 1860
  developed certain laws of heredity after doing
  crosses between garden pea plants.

3
Gregor Mendel

• Gregor Mendel combined his farmers skills with
  his training in mathematics.
• Mendels law of segregation states that each
  individual has two factors (called genes today)
  for each trait.
• Alternative forms of a gene affecting the same
  trait are now referred to as alleles.

4

• The factors segregate during the formation of the
  gametes and each gamete has only one factor from
  each pair.
• Fertilization gives each new individual two
  factors again.

5
The Inheritance of a Single Trait

• A capital letter indicates a dominant allele,
  which is expressed when present.
• An example is W for widows peak.
• A lowercase letter indicates a recessive allele,
  which is only expressed in the absence of a
  dominant allele.
• An example is w for continuous hairline.

6
Widows peak
7
Genotype and Phenotype

• Genotype - the genes of an individual.
• Homozygous - both alleles are the same for
  example, WW stands for homozygous dominant and ww
  stands for homozygous recessive.

8

• Heterozygous means that the members of the
  allelic pair are differentfor example, Ww.
• Phenotype refers to the physical or observable
  characteristics of the individual.
• Both WW and Ww result in widows peak, two
  genotypes with the same phenotype.

9
One-Trait Crosses

• In one-trait crosses, one trait is considered.
• When performing crosses, the original parents are
  called the parental generation, or the P
  generation.
• All of their children are the filial generation,
  or F generation.

10
(No Transcript)
11

• If you know the genotype of the parents, it is
  possible to determine the gametes and use a
  Punnett square to determine the phenotypic ratio
  among the offspring.
• This ratio is used to state the chances of a
  particular phenotype.

12
Monohybrid cross
13

• In the cross of Ww x Ww, what is the chance
  having a homozygous dominant child? what is the
  chance of having a heterozygous child? what is
  the chance of having a child with widows peak?
• Chance of W ½, or chance of w ½
• The probability of these genotypes is
• The chance of WW ½ x ½ ¼
• The chance of Ww ½ x ½ ¼
• The chance of wW ½ x ½ ¼
• The chance of ww ½ x ½ ¼
• The chance of widows peak (WW, Ww, wW) is ¼ ¼
  ¼ ¾ or 75.

14
The One-Trait Testcross

• A testcross is used to determine the genotype of
  a phenotypically dominant individual.
• A testcross crosses the dominant phenotype with
  the recessive phenotype.
• Why?

15
(No Transcript)
16
The Inheritance of Many Traits

• The Law of Independent Assortment
• -each pair of alleles segregates independently
  and all possible combinations of alleles can
  occur in the gametes.
• What gametes can a individual with the genotype
  AaBb produce?

17

• Answer
• AB, Ab, aB, ab
• What is the probability that a person homozygous
  dominant for two traits will have a child that is
  phenotypically dominant for both traits?

18
(No Transcript)
19
What is the expected phenotypic ratio if you
cross two individuals that are heterozygous for
widows peak and short fingers? First- determine
the possible gametes then draw a Punnett square.
20
(No Transcript)
21
What is the expected phenotypic ratio if you
cross an individual heterozygous for widows peak
and short fingers with a person with continuous
hairline and long fingers? First- determine the
possible gametes then draw a Punnett square.
22
(No Transcript)
23
Two-Trait Crosses and Probability

• It is possible to use the laws of probability to
  arrive at a phenotypic ratio for a two-trait
  cross without using a Punnett square.
• If you flip two coins, what is the probability of
  getting two heads?
• If you flip two coins, what is the probability of
  getting one head?

24

• The probabilities for the dihybrid cross between
  heterozygotes
• Probability of widows peak and short fingers ¾
  x ¾ 9/16
• Probability of widows peak and long fingers ¾
  x ¼ 3/16
• Probability of straight hairline and short
  fingers ¼ x ¾ 3/16
• Probability of straight hairline and long fingers
  ¼ x ¼ 1/16

25
Probability and the Hexahybrid Cross

• What is the probability that a cross between two
  individuals heterozygous for each of six traits
  will have an offspring dominant for each of those
  seven traits?

26
Genetic Disorders

• Patterns of Inheritance
• pedigree charts shows pattern of inheritance of
  a characteristic within a family.

27

• males are squares
• females are circles.
• Filled squares or circles indicate that the
  individual has the condition
• Patterns often indicate the mode of inheritance

28
(No Transcript)
29
(No Transcript)
30
Autosomal Recessive Disorders

• Tay-Sachs Disease
• Tay-Sachs disease is common among United States
  Jews of central and eastern European descent.
• An affected infant develops neurological
  impairments and dies by the age of three or four.

• Tay-Sachs results from a lack of hexosaminidase A
  and the storage of its substrate in lysosomes.

31
Cystic Fibrosis

• Cystic fibrosis is the most common lethal genetic
  disorder among Caucasians.
• A chloride ion transport protein is defective in
  affected individuals.
• Normally when chloride ion passes through a
  membrane, water follows.
• In cystic fibrosis patients, a reduction in water
  results in a thick mucus which accumulates in
  bronchial passageways and pancreatic ducts.

32
Phenylketonuria (PKU)

• Individuals with phenylketonuria lack an enzyme
  needed for the normal metabolism of
  phenylalanine, coded by an allele on chromosome
  12.
• Newborns are regularly tested for elevated
  phenylalanine in the urine.
• If the infant is not put on a phenylalanine-restri
  ctive diet in infancy until age seven when the
  brain is fully developed, brain damage and severe
  mental retardation result.

33
(No Transcript)
34
Autosomal Dominant Disorders

• Neurofibromatosis
• Small benign tumors, made up largely of nerve
  cells, occur under skin or on various organs.
• The effects can range from mild to severe, and
  some neurological impairment is possible this
  disorder is variably expressive.
• The gene for this trait is on chromosome 17.

35
Huntington Disease

• Individuals with Huntington disease experience
  progressive degeneration of the nervous system
  and no treatment is presently known.
• Most patients appear normal until middle age.
• The gene coding for the protein huntingtin
  contains many more repeats of glutamines than
  normal.

36
Huntington disease
37
(No Transcript)
38
Beyond Simple Inheritance Patterns

• Polygenic Inheritance
• Polygenic traits are governed by more than one
  gene pair.

39
Skin Color

• The inheritance of skin color, determined by an
  unknown number of gene pairs, is another example
  of polygenic inheritance.

40
(No Transcript)
41
Multiple Allelic Traits

• more than two alternative alleles exist for a
  particular gene locus.
• blood type is an example

42
ABO Blood Types

• Alleles IA,IB,I
• Genotype Phenotype
• IA IA A
• IA i A
• IB IB B
• IB i B
• IA IB AB
• i i O

43

• What are the possible blood types of children
  from a mother with type A blood and a father with
  type B blood?

44
(No Transcript)
45
Incompletely Dominant Traits

• Codominance -both alleles are equally expressed
  in a heterozygote. (blood type)
• Incomplete dominance - heterozygote shows an
  intermediate phenotype (curly vs. wavy hair
  sickle cell anemia)

46
(No Transcript)
47

• Many genetic disorders and other traits are
  inherited according to laws first established by
  Gregor Mendel.
• Inheritance is often more complex, providing
  exceptions to Mendels laws but helping to
  explain an even wider variety in patterns of gene
  inheritance.

48
Sex-Linked Traits

• Sex Determination-
• XX female
• XY male
• Traits controlled by genes on the X or Y
  chromosomes are sex-linked
• An allele is termed X-linked.

49

• Duchenne muscular dystrophy involves the absence
  of a protein called dystrophin that is involved
  in the release of calcium from the sarcoplasmic
  reticulum of muscle cells.
• The lack of dystrophin causes calcium to leak
  into the cell, which promotes the action of an
  enzyme that dissolves muscle fibers.
• A test is now available to determine the carriers
  of Duchenne muscular dystrophy.

50
Hemophilia

• Hemophilia refers to the lack of one of several
  clotting factors that leads to excessive bleeding
  in affected individuals.
• Hemophiliacs bleed externally after injury, but
  also bleed internally around joints.
• Hemorrhages can be stopped with blood
  transfusions or a biotechnology clotting factor.

51
Muscular Dystrophy

• Muscular dystrophy is characterized by the
  wasting of muscles.
• The most common form is Duchenne muscular
  dystrophy this is an X-linked disorder,
  occurring in 1 of 3,600 males.
• Muscles weaken, frequent falls and difficulty in
  rising occur early death occurs by age 20.

52
Color Blindness

• Three types of cones are in the retina detecting
  red, green, or blue.
• Genes for blue cones are autosomal those for red
  and green cones are on the X chromosome.
• Males are much more likely to have red-green
  color blindness than females.
• About 8 of Caucasian men have red-green color
  blindness.

53
X-Linked Disorders
54
X-Linked Alleles

• The key for an X-linked problem shows the allele
  attached to the X as in
• XB normal vision
• Xb color blindness.
• Females with the genotype XBXb are carriers
  because they appear to be normal but each son has
  a 50 chance of being color blind depending on
  which allele the son receives.
• XbXb and XbY are both colorblind.

55
(No Transcript)
56
(No Transcript)
57

• Why are there so few Y-linked or X-linked
  dominant disorders?

58
Linked Genes

• Alleles are inherited as a group, rather than
  according to the law of independent assortment
• What are the linkage groups
• Changes expected ratios (example)
• Are the basis of some genetic tests.
• Crossing over can tell us how far apart genes
  are.
