Title: Systems Biology


1
Systems Biology
  • Ophelia Venturelli
  • CS374 December 6, 2005

2
Definition systems biology
  • Quantitative analysis of components and dynamics
    of complex biological systems

Interactome (Tier 1)
Deterministic (Tier 2)
Stochastic (Tier 3)
3
Features of complex systems
  • Nonlinearity

global properties not simple sum of parts
4
Features of complex systems
  • Feedback loops

5
Features of complex systems
  • Open systems (dissipation of energy)

Flagella uses energy
6
Features of complex systems
  • Memory (response history dependent)

adaptation shift in curve requires memory!
Response
Chemical concentration
7
Features of complex systems
  • Nested (modules have complexity)

8
What is Systems Biology?
  • quantitatively account for these properties
  • different levels of modeling
  • Three tiers
  • Interactomes
  • Deterministic
  • Stochastic
  • Principles which transcend tiers

Interactome (Tier 1)
Deterministic (Tier 2)
Stochastic (Tier 3)
9
Principle 1 Modularity
  • Module
  • interacting nodes w/ common function
  • constrained pleiotropy
  • feedback loops, oscillators, amplifiers

10
Principle 2 Recurring circuit elements
  • Network motifs
  • histidine kinase response regulator

11
Principle 3 Robustness
  • Robustness
  • insensitivity to parameter variation
  • Severe constraints on design
  • robustness not present in most designs

12
Aims of systems biology
  • Tier 1 Interactome
  • Which molecules talk to each other in networks?
  • Tier 2 Deterministic
  • What is the average case behavior?
  • Tier 3 Stochastic
  • What is the variance of the system?

13
Aims of systems biology
  • Tier 1
  • get parts list
  • Tier 2 3
  • enumerate biochemistry

14
Aims of systems biology
  • Tier 2 3
  • enumerate biochemistry
  • define network/mathematical relationships
  • compute numerical solutions

15
Aims of systems biology
  • Tier 2 3
  • Deterministic Behavior of system with respect to
    time is predicted with certainty given initial
    conditions
  • Stochastic Dynamics cannot be predicted with
    certainty given initial conditions

16
Aims of systems biology
  • Deterministic
  • Ordinary differential equations (ODEs)
  • Concentration as a function of time only
  • Partial differential equations (PDEs)
  • Concentration as a function of space and time
  • Stochastic
  • Stochastic update equations
  • Molecule numbers as random variables
  • functions of time

17
Tier 1 Static interactome analysis
  • Protein-protein
  • Signal transduction
  • Cell cycle
  • Protein-DNA
  • Gene regulation
  • Metabolic pathways
  • Respiration
  • cAMP

18
Tier 1 Static interactome analysis
  • Goals
  • Determine network topology
  • Network statistics
  • Analyze modular structure

19
Tier 1 Static interactome analysis
  • Limitations
  • Time, space, population average
  • Crude interactions
  • strength
  • types
  • Global features
  • starting point for Tier 2 3

typical interactome
first time-varying yeast interactome (Bork 2005)
20
Tier 1 Static interactome analysis
  • Analysis methods
  • Functional Genomics
  • expression analysis
  • network integration
  • Graph Theory
  • scale free
  • small world

21
Recap
  • Tier 1 Interactome
  • which molecules talk to each other?
  • crude, large scale
  • global set of modules
  • Now zoom in on one module
  • Tier 2 Deterministic Modeling
  • average case behavior of a module

22
Tier 2 Deterministic Models
  • Goal
  • model mesoscale system
  • average case behavior
  • Three levels
  • ODE system
  • ODE compartment system
  • PDE (rare!)
  • data limited

23
Tier 2 Deterministic Modeling
  • Results
  • Robust Chemotaxis (Barkai 1997)
  • MinCDE Oscillation (Howard 2003)
  • Feedback in Signal Transduction (Brandman 2005)
  • Output
  • time series plots (ODE)
  • condition on parameter values

Brandman 2005
24
Tier 2 Deterministic Modeling
  • Example
  • Robustness in bacterial chemotaxis
  • Bacterial chemotaxis robust to parameter
    fluctuations!
  • Chemotaxis bacterial migration towards/away from
    chemicals
  • Parameters
  • concentrations
  • binding affinities

25
Tier 2 Deterministic Modeling
  • Bacterial chemotaxis
  • model as random walk
  • Exact adaptation
  • change in concentration of chemical stimulant
  • rapid change in bacterial tumbling frequency
  • then adapts back precisely to its pre-stimulus
    value!!

Random walk
26
Experimental Design
  • Is exact adaptation robust to substantial
    variations in biochemical parameters?
  • Systematically varied concentrations of
    chemotaxis-network proteins and measured
    resulting behavior

27
Distinguish between robust-adaptation and
fine-tuned models of chemotaxis
Tumbling frequency
IPTG inducer
pUA4
pUA4
Adaption time
pUA4
pUA4
E. Coli cheR -/- population
Express CheR over a 100-fold range
Adaption precision
1 mM L-aspartate
Adaptation precision ratio of steady-state
tumbling frequency of unstimulated to stimulated
cells
Summary of results
Tumbling frequency 0.3 0.06 (20-fold)
Adaption time 3 1 (3-fold)
Adaption precision 1.04 0.07
28
Tumbling frequency as a function of time for
wild-type cells
29
Conclusions from study
  • Exact adaptation is maintained despite
    substantial varations in network-protein
    concentrations
  • Exact adaptation is a robust property
  • but adaptation time and steady-state behavior
    are fine-tuned

CheR fold expression
30
Recap
  • Just saw Tier 2
  • Deterministic modeling
  • average case behavior
  • robustness canonical avg. case property
  • Tier 3
  • Stochastic modeling
  • variance of system

31
Tier 3 Stochastic analysis
  • Fluctuations in abundance of expressed molecules
    at the single-cell level
  • Leads to non-genetic individuality of isogenic
    population

32
Tier 3 Stochastic Analysis
  • When stochasticity is negligible, use
    deterministic modeling
  • Molecular noise is low
  • System is large
  • molar quantities
  • Fast kinetics
  • reaction time negligible
  • Large cell volume
  • infinite boundary conditions

33
Tier 3 Stochastic Analysis
  • Molecular noise is high
  • System is small
  • finite molecule count matters
  • Slow kinetics
  • relative to movement time
  • Large cell volume
  • relative to molecule size
  • Need explicit stochastic modeling!

34
Tier 3 Ensemble Noise
  • Transcriptional bursting
  • Leaky transcription
  • Slow transitions between chromatin states
  • Translational bursting
  • Low mRNA copy number

35
Tier 3 Temporal Noise
Canonical way of modeling molecular stochasticity
36
Tier 3 Spatial Noise
Finite number effect translocation of molecules
from the nucleus to the cytoplasm have a large
effect on nuclear concentration
Nucleus
Cytoplasm
  • N average molecular abundance
  • ? (coefficient of variation) s/N
  • Decrease in abundance results ina 1/vN scaling
    of the noise (?1/vN)

37
Recap
  • Three tiers
  • Interactomes
  • Deterministic
  • Stochastic
  • Principles which cross tiers
  • Modularity
  • Reuse
  • Robustness

Interactome (Tier 1)
Deterministic (Tier 2)
Stochastic (Tier 3)
38
Major challenges and limitations
  • Measurement of chemical kinetics parameters and
    molecular concentrations in vivo
  • Differences between in vitro and in vivo data
  • Compartmental specific reactions
  • Data is the limit!!!

39
Major challenges and limitations
  • Data is the limit!!!
  • Functional genomic data (Interactomes)
  • E. Coli chemotaxis (Leibler, deterministic/robustn
    ess)
  • Important
  • parameter estimation
  • feedback based estimation methods

Sachs 2005
40
Software
  • Tier 1 Interactomes
  • Graphviz, Bioconductor, Cytoscape
  • Tier 2 Deterministic
  • Matlab (SBtoolbox), Mathematica (PathwayLab)
  • Tier 3 Stochastic
  • R, Stochsim

41
Algorithms
  • High-performance algorithms to solve systems of
    PDEs
  • Virtual Cell
  • Automated parsing of networks into stochastic and
    deterministic regimes
  • H-GENESIS
  • STOCK

42
Conclusion
  • Three tiers
  • Interactomes
  • Deterministic
  • Stochastic
  • Principles which cross tiers
  • Modularity
  • Reuse
  • Robustness

Interactome (Tier 1)
Deterministic (Tier 2)
Stochastic (Tier 3)
