Title: Chapter 10: Earthquakes


1
Chapter 10 Earthquakes
photo credit USGS
2
elastic rebound theory
what happens along a fault to generate an
earthquake?
3 m offset
1906 San Francisco earthquake
3
elastic rebound animation
4
offset lettuce rows - El Centro, CA
5
earthquake focus (hypocenter) and epicenter
6
earthquake focus animation
7
when faults rupture to cause earthquake, energy
is released
energy is in form of seismic waves
  • types and behavior of seismic waves
  • body waves
  • primary or compressional
  • secondary or shear
  • surface waves
  • Raleigh (large vertical displacements)
  • Love (shear)

8
seismic wave types
body waves
surface waves
9
displacement parallel to wave motion
P wave
displacement normal to wave motion
S wave
from http//www.personal.umich.edu/vdpluijm/gs20
5.html
P waves faster than S waves
10
equations for velocities
Vp k 4/3µ r
1/2
density
r
µ
shear modulus (rigidity)
Vs µ r
k
bulk modulus (rigidity)
1/2
because shear modulus (rigidity) for fluid is
zero, S waves cannot propagate through a fluid
consequence of equations is that P waves are 1.7x
faster than S
can infer physical properties from P and S waves
11
wave animations
12
locating and measuring earthquakes
  • determining the location of an earthquake
  • measuring the size of an earthquake

13
vertical component seismometer
14
horizontal component seismometer
15
seismograph animation
16
seismograph animation 2
17
sample seismogram
P, S, L, R are arrivals of P, S, Love and
Rayleigh waves from same earthquake
18
determining distance to earthquake from
seismograms
use arrival times of S and P waves on 3
seismograms (triangulation problem)
remember that P waves travel faster than do S
waves
note time between P and S wave arrivals (S-P
interval)
from http//vcourseware5.calstaela.edu/cgi-bin
19
examine 3 seismograms from Japan and measure
S-P interval in seconds
Akita
Pusan
Tokyo
from http//vcourseware5.calstaela.edu/cgi-bin
20
relationship of P and S wave velocities and S-P
interval
find time of arrival of S and P waves use time
difference between S and P arrivals
from http//vcourseware5.calstaela.edu/cgi-bin
21
for our Japan example S-P interval Tokyo
44 sec Pusan 56 sec Akita 71 sec
distance Tokyo 434 km Pusan 549
km Akita 697 km
from http//vcourseware5.calstaela.edu/cgi-bin
22
plot circles centered on stations with radii
of appropriate distance
intersection of circles is epicenter
from http//vcourseware5.calstaela.edu/cgi-bin
23
measuring earthquake magnitudes
  • Three distinct methods to measure earthquakes.
    Two based on energy and one based on intensity.
  • Richter Magnitude Scale originally developed for
    southern California. Log scale, which has no
    upper bound. Small earthquakes may yield
    negative values. Tends to be inaccurate at gt7
    magnitudes.
  • Moment Magnitude Scale measurement of the amount
    of work done during the earthquake. Based on rock
    strength, area of rupture, and displacement
    during event.
  • Modified Mercalli Intensity Scale based on the
    damage associated with a particular event at a
    particular location. Ranges from I (less damage)
    to XII (more damage).

24
determining earthquake magnitude (generalized)
once again, use seismograms
measure maximum amplitude of S wave
(this is one method others exist)
from http//vcourseware5.calstaela.edu/cgi-bin
25
measure maximum amplitudes of S waves from 3
seismograms (these are the same one)
Akita 30 mm Pusan 90 mm Tokyo 170 mm
Akita
Pusan
Tokyo
from http//vcourseware5.calstaela.edu/cgi-bin
26
use figure to left which plots distance magnitude
amplitude
from http//vcourseware5.calstaela.edu/cgi-bin
27
distance Tokyo 434 km Pusan 549
km Akita 697 km
amplitude
Akita 30 mm Pusan 90 mm Tokyo 170 mm
magnitude 6.8
from http//vcourseware5.calstaela.edu/cgi-bin
28
modified Mercalli Intensity Index
1886 Charleston, SC earthquake
29
frequency-intensity-magnitude relations
30
effects of earthquakes
  • ground displacement
  • liquefaction/landslides
  • seiches
  • tsunamis
  • fires

31
pancaked building - 1985 Mexico City
Earthquakes dont kill people - buildings do!
32
ground rupture, 1906 Olema, CA
33
surface displacement - 1964 Alaska
34
deformed fence - Gallatin County, MT
35
buckled concrete - 1971 San Fernando, CA
36
soil liquefaction - 1964 Nigata, Japan
shaking disturbs clay particles in soil and they
collapse like a house of cards
37
tsumani generation
38
tsunami devastation - 1964 Alaska earthquake
39
tsunami animation
40
tsunami wave propagation times
41
earthquakes and plate tectonics
42
(No Transcript)
