CS 162 Fall 2003

1
CS 162 - Fall 2003

• Chapter 17
• Recursion (part 2)

2
Characteristics of Recursion

• Remember the characteristics of a recursive
  solution
• One or more base cases that solve a problem
  directly
• Some way to "reduce" a more "complex" problem to
  a "simpler" one - one that eventually reaches the
  base case.

3
Factorial

• Factorial problem
• Base case is 1, since 1! 1
• Recursive case, N! N (N-1)!
• Here the recursive function makes one call on
  itself for the simpler version. There are
  problems where this is not the case

4
Towers of Hanoi

• The Towers of Hanoi (Tower of Brahma or End of
  the World Puzzle). Invented by Edouard Lucas in
  1883. Legend tells of a Hindu temple where there
  is a pyramid of 64 gold disks, each different
  size. Goal is to move from one pole to another,
  using a third as assistance. One disk is moved at
  a time, no disk can be placed on a smaller one.
  When all disks are moved, the world ends.

5
Example of Solution

• There is a link to a nice graphical version of
  the puzzle (with far fewer than 64 disks) on the
  links section of the course web page. Now would
  be a good time to go see this.
• Somewhat difficult to solve iterative (you will
  have to trust me on this one)
• Relatively easy to solve recursively.

6
Elements of Recursive Solution

• Key to using recursion -- expressing the problem
  is a recursive fashion.
• How to move a pile of N disks from pole A to B,
  using pole C as a temporary.

7
Recursive Algorithm

• to Move(N, A, B, C)
• Move a pile of N-1 from A to C, using B as
  temporary
• Move a single disk from A to B
• Move a pile of N-1 disks from C to B, using A as
  temporary
• Question Does this satisfy our problem?

8
Base Case

• What should be our base case? Two suggestions
• if N 1, don't need recursion, can move just a
  single disk
• Even better, if N 0, don't need to do anything
  at all! (As I've always said, nothing is easy).

9
Not a simple 1-1 recursive case

• Notice that to perform the solution for case N,
  we make TWO recursive calls on the function.
• While this can lead to a simple solution, also
  leads to exponential execution time. More on that
  in a couple of weeks.
• Fortunate - remember the end of world?

10
Does it solve the problem?

• Seems pretty clear that the recursive technique
  we have described will do the move OK, does it
  satisfy the no disk on top of another condition?
• Key to proving recursion. Prove base case. Assume
  recursive calls work as advertised, and show that
  everything else is correct.

11
Proof. Base Case

• Seems pretty clear that if we have not violated
  the "no disk on top of a smaller one" requirement
  up to some point, then moving (or not moving) a
  pile of size zero cannot cause us to break the
  rule.
• Base case arguments are often pretty trivial.

12
Proof Induction Case

• We assume the recursive calls will work as
  advertised. Need only consider the rest.
• In this case, just the single disk move.
• Must prove that no disk smaller than N is on pole
  B -- but this is easy, since all disks smaller
  than N are now on pole C.

13
The recursive solution

• void hanoi (int N, int A, int B, int C)
• if (N gt 0) // only induction case - base is
  nothing
• hanoi(N-1, A, C, B)
• system.out.println("Move " N " from "
  A " to " B)
• hanoi(N-1, C, B, A)

14
Oh - that End of World thing?

• Not to worry. We will see in a couple of weeks
  how hanoi is an exponential algorithm.
• To move 64 disks would take 18,446,744,073,709,551
  ,615 moves. If they moved one per second, would
  be slightly more than 580 billion years.

15
Another Tricky Recursive Task

• Another problem that is easier to do recursively
  than iteratively.
• Take a word, and generate all permutations.
  Example from "eat" we have "eat", "eta", "aet",
  "ate", "tea", and "tae".
• Part of problem - what does "generate" mean?

16
Generation or Enumeration

• Common way of describing a sequence in Java and
  similar languages. Called the Enumeration
  pattern. Have a pair of functions
• isThereMore - return true if more values
• nextValue - return next value
• Same idea, different names, used a lot.

17
A Enumeration Loop

• The enumeration pattern makes it easy to write a
  loop that does something with all values
• while (isThereMore())
• do something with nextValue()

18
Class PermutationGenerator

• class PermutationGenerator
• public PermutationGenerator(String s)
• public boolean hasMorePermutations()
• public String nextPermutation()
• uses the Enumeration Pattern different names

19
Solving the Problem Recursively

• How do we solve this problem recursively?
• One way. Consider each letter in turn "e", "a",
  "t".
• Form word without that letter - get all
  permutations of that ("at", "ta"), and append e
  to each ("eat", "eta").
• Do same for all letters.

20
Base Case

• Obvious base cases - word of length 1 (only one
  instance) or word of length 0 (nothing)
• Wait and see which one is easier to work with.

21
Tricky

• Conceptually easy. Programming is tricky, because
  when we recurse we get a series of values. Need
  to enumerate over all values - then get next.
• Need to remember current state - in this case,
  three values, current word, character position,
  and the enumerator for the recursive call.

22
Data Areas

• class PermutationGenerator
• ...
• private String word
• private int current
• private PermutationGenerator tailGenerator

23
Initialization

• class PermutationGenerator
• public PermutationGenerator(String aWord)
• word aWord
• current 0
• if (word.length() gt 1)
• tailGenerator new
  PermutationGenerator(word.substring(1))

24
Handling Base Case

• public String nextPermutation()
• if (word.length() 1)
• current
• return word
• ...

25
Handling Recursive Case

• public String nextPermutation()
• ...
• String r word.charAt(current)
  tailGenerator.nextPermutation()
• if (! tailGenerator.hasMorePermutations())
• current
• if (current lt word.length())
• string tailString word.substr(0,
  current) word.substring(current1)
• tailGenerator new permutationGenerator(
  tailString)

26
Compare this to others

• Compare to Factorial and Hanoi
• All use recursion, but use it in slightly
  different ways.
• Key idea, base case, find a way to reduce a
  problem to another of same form, assume the
  recursive call works, and carry on.

27
Questions?
28
Ending Test

• The ending test
• public boolean hasMorePermutations()
• return current lt word.length()
