Project Director Signals Warfare
US Army Security Assistance Command Partnering
Day Hosted by NDIA/USASAC
15 November 2005
PEO IEWS GSS FMS Program Les Simon APM PD SW/CREW
11/14/05
2
Agenda

• PEO IEWS/PD SW Overview
• Contribution to Stability Operations
• Contribution to Strategic Responsiveness
• GSS FMS Program
• Closing Remarks

11/14/05
3
PD SW Product Line
GR/CS
CREW
MARSS
GUARDRAIL/Common Sensor
Medium Altitude Reconnaissance Surveillance System
ARL
Airborne Reconnaissance Low
Tactical SIGINT Payload
DCGS-A/N
Prophet
Aerial Common Sensor
Information Warfare Programs
FMS GSS
71PMSW.1.016
8/16/05
4
Improve Capabilitiesfor Stability Operations

• Improve Intelligence Operations
• Data Format viable for User Consumption
• Common Hardware/Software Architecture
• Technology (Specification)
• Collaborate-Reach-Back US-Host Country Datalink
• Common US Radio
• Stable and Seamless Architecture
• Improve and Integrate HUMINT, MASINT with SIGINT

11/14/05
5
Improve Army Capabilities for Strategic
Responsiveness

• Intelligence Data
• Coordinate and Share Information with Host
  Country
• US Army, US National Forces
• Assist CENTCOM on Intelligence
• Global War on Terrorism
• Conduct Predictive Analysis Operations
• Monitor and Track Terrorism Activity via C4ISR
  Operations
• Location
• Pre-deploy Intelligence Operations in Neighboring
  Countries
• Strategic Importance for On-going Surveillance
  Operations
• Multi-Borne Intelligence
• Operational and Collaborative Coalition INTEL
  Data with Integration of Ground-based/Sea-borne/Ai
  r-Borne Activities

11/14/05
6
GSS FMS

• Provide Status of FMS Program - Ground
  Surveillance (ELINT) System (GSS) for the
  Government of Egypt (GOE)
• Program Objective
• System Baseline Performance
• Operational Scenario
• Schedule
• Funding
• System Sub-components

CS-3000 ELINT System
8/9/05
7
GSS Program Highlights

• GSS Program Objective
• Design, Build, Test and Field 6 Ground
  Surveillance Systems for Gov of Egypt Based on a
  Negotiated, Sole Source Contract
• Base Design on Currently Fielded EDO Dakota
  CS-3000 System
• Conduct In-Plant Government Acceptance, Ship to
  Egypt for Full Fielding Hand-off
• Provide Training, Spares and Field Support for 1
  Year (Warranty) After Fielding

CS-3000 ELINT System
8/9/05
8
FMS Ground Surveillance System (GSS)
Operational Concept
System Description

• Requirements LOA with Government of Egypt (GOE)
  Requirements (w/Provisos)
• CS-3000 Ground-Based Radar (ELINT) Collection
  Systems Mounted in S-280 Shelters
• 0.5-40.0GHz Intercept, DF Location
• Netted Operations (up to 6 Systems) for
  Geo-location
• Comms via Harris RF-5800V VHF Radios
• Signal Analysis/Processing Algorithms and
  Databases Provided by the GOE

FLOT
Control Station for Netted Ops/Shelter Mounted GSS
Funding
Schedule
FY05 FY06 FY07
FY08

• Total FMS Purchase 13,366,763 (11,607,213
  Contract 1,759,550 Govt)
• Annual MIPRS From SAMD to PD SW for Manpower
  Support

• Contract Award
• IPRs
• PMRs
• Design/Build/Integrate
• Test
• Ship to Egypt
• QAT

Contracting

• Contract Type Sole Source, FFP
• Contractor EDO Reconnaissance Surveillance
  Systems, Morgan Hill Thousand Oaks, CA

11/14/05
9
CS-3000 System Major Components
SCSI PULSE STORAGE INTERFACE
AOA-26400.5 TO 40 GHz OMNI ANTENNA
QUALIFIED VIDEO/STRETCHED AUDIO
19-INCHHIGH RESOLUTION COLOR MONITOR
RT-0118SVMICROWAVETUNER
1 GHz IF
IEEE 802.3LAN
160 MHz IF
RS-422TUNER CONTROL
ADF-26400.5 TO 40GHz SPINNING DF
ANTENNADistribution Millimeter Wave
Downconverter(Exterior Mounted Equipment)
RDU-3060 PULSE ANALYZER
RF
OPERATOR WORKSTATION
ACD-2622ANTENNA PEDESTAL CONTROLLER
ANTENNA CONTROLRS-422
RESOLVER ANGLE BUS
ANTENNACONTROL
9/8/05
10
Closing Remarks

• Collective FMS Programs Strive to Meet Top-level
  FMS Imperatives
• PD SW and USASAC/SAMD have Partnered to Manage
  and Execute the GSS Program
• PD SW Stands Ready to Partner on Future FMS
  SIGINT/ECM Related Initiatives
• Challenges are in Releasability of Technologies

11/14/05
