EXERCISE STRESS ELECTROCARDIOGRAPHY Dr.Tahsin N

1
Exercise stress Electrocardiography

• Dr.Tahsin N

2
Exercise physiology

• Sympathetic activation
• Parasympathetic withdrawal
• Vasoconstriction, except-
• Exercising muscles
• Cerebral circulation
• Coronary circulation
• ?nor epinephrine and renin

3
Exercise physiology

• ?ventri contractility
• ?O2 extraction(upto 3)
• ?peripheral resistance
• ?SBP,MBP,PP
• DBP no significant change
• Pulm vasc bed can accommodate 6 fold CO
• CO - ? 4-6 times

4
Exercise physiology

• Isotonic exercise(cardiac output)
• Early phase- SVHR
• Late phase-HR

5
? Exercise work ? ? O2 usage ? Persons max. O2
consumption (VO2max) reached
V02 peak
Oxygen consumption (liters/min)
Work rate (watts)
6

• The slope of the    o2work relationship is a
  measure of the biochemical efficiency of exercise

• V o2max is the product of maximal arteriovenous
  oxygen difference and cardiac output
• The V o2max depends on
• Age
• Men than in women
• Genetic factors
• Cardiovascular impairment
• Physical inactivity.

7
The ability to deliver O2 to muscles and muscles
oxidative capacity limit a persons VO2max.
Training ? ? VO2max
V02 peak (trained)
70 V02 max (trained)
V02 peak (untrained)
Oxygen consumption (liters/min)
100 V02 max (untrained)
175
Work rate (watts)
8

• During dynamic exercise of increasing intensity,
  ventilation increases linearly over the mild to
  moderate range, then more rapidly in intense
  exercise
• Workload at which rapid ventilation occurs is
  called the ventilatory breakpoint (together with
  lactate threshold)

Respiration during exercise
Lactate acidifies the blood, driving off CO2 and
increasing ventilatory rate
9
Blood Pressure (BP) also rises in exercise

• Systolic pressure (SBP) goes up to 150-170 mm Hg
  during dynamic exercise diastolic scarcely
  alters
• In isometric (heavy static) exercise, SBP may
  exceed 250 mmHg, and diastolic (DBP) can itself
  reach 180

10
Intense exercise ? Glycolysisgtaerobic
metabolism ? ? blood lactate (other organs use
some)
Blood lactic acid (mM)
Lactate threshold endurance estimation
Relative work rate ( V02 max)
11
Maximum HR

• HR220 - age in years

12
Post exercise phase

• Vagal reactivation
• Imp cardiac deceleration mech
• ?in well trained athletes
• Blunted in CCF

13
MET

• Metabolic Equivalent Term
• 1 MET "Basal" aerobic oxygen consumption to
  stay alive 3.5 ml O2 /Kg/min
• Differs with thyroid status, post exercise,
  obesity, disease states

14
Key MET Values

• 1 MET "Basal" 3.5 ml O2 /Kg/min
• 2 METs 2 mph on level
• 4 METs 4 mph on level
• lt 5METs Poor prognosis if lt 65
• 10 METs same progn with medical thpy as CABG
• 13 METs Excell prognosis,
• regardless of othr
  exercise responses

15
Key MET Values

• 3-5 METs
• Raking leaves,light carpentry,golf,3-4 mph
• 5-7 METs
• Exterior carpentry, singles tennis
• gt9 METs
• Heavy labour, hand ball, squash, running 6-7
  mph

16
Calculation of METs on the Treadmill

• METs Speed x 0.1 (Grade x 1.8) 3.5
  3.5
• Calculated automatically by Device!
• Note Speed in meters/minute
• conversion MPH x 26.8
• Grade expressed as a fraction


17
Treadmill protocol

• Bruce protocol
• Naughton protocol
• Weber protocol
• ACIP(asymptomatic cardiac ischemia pilot)
• Modified ACIP

18
Protocol description (BRUCE)
19
Procedure

• Standard 12 lead ECG- leads distally
• Torso ECG BP
• Supine and Sitting / standing
• HR ,BP ,ECG
• Before, after, stage end
• Onset of ischemic response
• Each minute recovery(5-10 mints)

20
Procedure- Lead systems

• Mason-Liker modification
• RAD
• ?inf lead voltage
• Loss of Q in inf leads
• New Q in AVL

21
Contraindications to Exercise Testing

• Absolute
• Acute MI (lt 2 d)
• High-risk unstable angina
• Uncontrolled cardiac arrhythmias causing
  symptoms or hemodynamic compromise
• Symptomatic severe AS
• Uncontrolled symptomatic CCF
• Acute pulmonary embolus or pulmonary infarction
• Acute myocarditis or pericarditis
• Acute Aortic dissection

22
Contraindications to Exercise Testing

• Relative
• LMCA stenosis
• Moderate stenotic valvular heart disease
• Electrolyte abnormalities
• Severe HTN
• Tachyarrhythmias or bradyarrhythmias
• HOCM and other forms of outflow tract obstruction
• Mental or physical impairment leading to
  inability to exercise adequately
• High-degree AV block

23

• Both MI and deaths have been reported and can be
  expected to occur at a rate of up to 1 per 2500
  tests

24
Classification of chest pain

• Typical angina
• Atypical angina
• Noncardiac chest pain

• Substernal chest discomfort with characterstic
  quality and duration
• Provoked by exertion or emotional stress
• Relieved by rest or NTG

Meets 2 of the above characteristics
Meets one or none of the typical characteristics
25
Bayes' theorem A theory of probability
The post test probability is proportional to
the pretest probability
26
Pretest Probability

• Based on the patient's history ( age, gender,
  chest pain ), physical examination and initial
  testing, and the clinician's experience.
• Typical or definite angina ?pretest probability
  high - test result does not dramatically change
  the probability.
• Diagnostic testing is most valuable in
  intermediate pretest probability category

27
Pre Test Probability of Coronary Disease by
Symptoms, Gender and Age
28
INDICATIONS OF EXERCISE TESTING
29
TO DIAGNOSE OBSTRUCTIVE CAD

• Class I
• Adult patients (including RBBB or lt1 mm of
  resting ST?) with intermediate pretest
  probability of CAD
• Class IIa
• Patients with vasospastic angina.

30
TO DIAGNOSE OBSTRUCTIVE CAD

• Class IIb
• 1. Patients with a high pretest probability of
  CAD
• 2. Patients with a low pretest probability of CAD

• 3. Patients with lt1 mm of baseline ST ?and on
  digoxin.
• 4. Patients with LVH and lt1 mm baseline ST ?.

31
TO DIAGNOSE OBSTRUCTIVE CAD

• Class III
• Patients with the following baseline ECG
  abnormalities
• Pre-excitation syndrome
• Electronically paced ventricular rhythm
• gt1 mm of resting ST depression
• Complete LBBB

32
in Asymptomatic PersonsWithout Known CAD

• Class IIa
• Evaluation of asymptomatic T2 DM pts who plan to
  start vigorous exercise ( C)
• Class IIb
• 1. Evaluation of pts with multiple risk factors
  as a guide to risk-reduction therapy.
• 2. Evaluation of asymptomatic men gt 45 yrs and
  women gt55 yrs
• Plan to start vigorous exercise
• Involved in occupations which impact public
  safety
• High risk for CAD(e.g., PVOD and CRF)
• Class III
• Routine screening of asymptomatic

33
RISK ASSESSMENT AND PROGNOSIS IN PATIENTS WITH
SYMPTOMS OR A PRIOR HISTORY OF CAD

• Class I
• 1. Initial evaluation with susp/known CAD,
  includingRBBB or lt1 mm of resting ST Depression
• 2.Susp/ known CAD, previously evaluated, now
  significant change in clinical status.
• 3. Low-risk UA pts gt8 to 12 hrs free of active
  ischemia/CCF
• 4. Intermed-risk UApts gt 2 to 3 days no active
  ischemia/ CCF
• Class IIa
• Intermed-risk UA pts initial markers (N),rpt
  ECG no signi change, and markers gt6-12 hrs (N)
  no other evidence of ischemia during observation.

34
AFTER MYOCARDIAL INFARCTION

• Class I
• 1. Before discharge (submaximal --4 to 6 days).
• 2. Early after discharge if the predischarge
  exercise test was not done (symptom limited --14
  to 21 days).
• 3. Late after discharge if the early exercise
  test was submaximal (symptom limited --3 to 6
  weeks).
• Class IIa
• After discharge as part of cardiac rehabilitation
  in patients who have undergone coronary
  revascularization.

35
AFTER MYOCARDIAL INFARCTION

• Class IIb
• 1. Patients with the following ECG abnormalities
• Complete LBBB
• Pre-excitation syndrome
• LVH
• Digoxin therapy
• gt1 mm of resting ST-segment depression
• Electronically paced ventricular rhythm
• 2. Periodic monitoring in patients who continue
  to participate in exercise training or cardiac
  rehabilitation.

36
AFTER MYOCARDIAL INFARCTION

• Class III
• 1. Severe comorbidity likely to limit life
  expectancy and/or candidacy for
  revascularization.
• 2. At any time to evaluate pts with AMI with
  uncompensated CCF, arrhythmia, or noncardiac
  exercise limiting conditions.
• 3. Before discharge to evaluate pts who have
  already been selected for, or have undergone,
  cardiac cath.
• Although a stress test may be useful
  before or after cath to evaluate or identify
  ischemia in the distribution of a coronary lesion
  of borderline severity, stress imaging tests are
  recommended.

37

• Submaximal protocols
• Predetermined end point
• Peak HR 120 bpm, or
• 70 predicted max HR or
• Peak MET - 5
• Symptom-limited tests
• To continue till signs or symptoms necessitating
  termination (i.e., angina, fatigue, 2 mm of
  ST?,ventricular arrhythmias, or 10-mm Hg drop in
  SBP from the resting blood pressure)

38
Before and After Revascularization

• Class I
• 1. Demonstration of ischemia before
  revascularization.
• 2. Evaluating recurrent symps suggesting
  ischemia after revascularization.
• Class IIa
• After discharge for activity counseling and/or
  exercise training as part of rehabilitation in
  pts aft revascularization.

39
Before and After Revascularization

• Class IIb
• 1. Detection of restenosis in selected, high-risk
  asymptomatic pts lt first 12 months aft PCI.
• 2. Periodic monitoring of selected, high-risk
  asymptomatic ps for restenosis, graft occlusion,
  incomplete coronary revascularization, or disease
  progression.
• Class III
• 1. Localization of ischemia for determining the
  site of intervention.
• 2. Routine, periodic monitoring of asymptomatic
  pts after PCI or CABG without specific
  indications.

40
Stress Testing
41
Investigation of Heart Rhythm Disorders

• Class I
• 1. Identification of appropriate settings in pts
  with rate-adaptive pacemakers.
• 2. Evaluation of cong CHB in pts considering
  ?activity/competitive sports. (C)
• Class IIa
• 1. Evaluating known or suspected exercise-induced
  arrhythmias.
• 2. Evaluation of medical, surgical, or ablative
  therapy in exercise-induced arrhythmias

42
Investigation of Heart Rhythm Disorders

• Class IIb
• 1. Isolated VPC in middle-aged pts without other
  evidence of CAD.
• 2. Prolonged 1AV block or type I-2AV block ,
  LBBB, RBBB, or VPC in young pts considering
  competitive sports. (C)
• Class III
• Routine investigation of isolated VPC in young
  pts.

43
Interpreting TMT
44
Normal ECG changes during exercise

• ? PR, QRS, QT
• ? P amplitude
• Progressive downsloping PR in inf leads
• j point depression

45
The Exercise ECG
1 Iso-electric 2 J point 3 J 80 msec
ST 60 -- HR gt 130/min ST 80 -- HR 130/min
46
Criteria for Reading ST-Segment Changes on the
Exercise ECG

• ST DEPRESSION
• Measurements made on 3 consecutive ECG complexes
• ST level is measured relative to the P-Q junction
• When J-point is depressed relative to P-Q
  junction at baseline
• Net difference from the J junction determines
  the amount of deviation
• When the J-point is elevated relative to P-Q
  junction at baseline and becomes depressed with
  exercise
• Magnitude of ST depression is determined from the
  P-Q junction and not the resting J point

47
(No Transcript)
48
Criteria for Abnormal and Borderline ST-Segment
Depression

• ABNORMAL
• 1.0 mm or greater horizontal or downsloping ST
  depression at 80 msec after J point on 3
  consecutive ECG complexes
• BORDERLINE
• 0.5 to 1.0 mm horizontal or downsloping ST
  depression at 80 msec after J point on 3
  consecutive ECG complexes
• 2.0 mm or greater upsloping ST depression at 80
  msec after J point on 3 consecutive ECG complexes

49
Normal
Rapid Upsloping
Minor ST Depression
Slow Upsloping
50
Horizontal
Downsloping
Elevation (non Q lead)
Elevation (Q wave lead)
51

• In lead V4 , the exercise ECG result is
  abnormal early in the test, reaching 0.3 mV (3
  mm) of horizontal ST segment depression at the
  end of exercise.
• Consistent with a severe ischemic response.

52

• The J point at peak exertion is depressed 2.5 mm,
  the ST segment slope is 1.5 mV/sec, and the ST
  segment level at 80 msec after the J point is
  depressed 1.6 mm.
• This slow upsloping ST segment at peak exercise
  indicates an ischemic pattern in patients with a
  high coronary disease prevalence pretest.
• A typical ischemic pattern is seen at 3 minutes
  of the recovery phase when the ST segment is
  horizontal and 5 minutes after exertion when the
  ST segment is downsloping.

53

• Becomes abnormal at 930 minutes (horizontal
  arrow right) of a 12-minute exercise test and
  resolves in the immediate recovery phase.
• This ECG pattern in which the ST segment becomes
  abnormal only at high exercise workloads and
  returns to baseline in the immediate recovery
  phase may indicate a false-positive result in an
  asymptomatic individual without atherosclerotic
  risk factors.

54
ST Elevation(localising)

• Abnormal response
• J ? 0.10mV(1 mm)
• ST 60 0.10mV(1 mm)
• Three consecutive beats
• Q wave lead (Past MI)
• Severe RWMA, ?EF, ?Prognosis
• Non Q wave lead (Past MI)
• Severe ischemic response
• Non Q wave lead (No past MI)-1
• Transmural reversible myocardial ischemia-
  ----vasospasm, ?coronary
  narrowing

55

• This type of ECG pattern is usually associated
  with a full-thickness, reversible myocardial
  perfusion defect in the corresponding left
  ventricular myocardial segments and high-grade
  intraluminal narrowing at coronary angiography.
  Rarely, coronary vasospasm produces this result
  in the absence of significant intraluminal
  atherosclerotic narrowing.

56
ECG Patterns Indicative of Myocardial Ischaemia
ECG Patterns Not Indicative of Myocardial
Ischaemia
57
ECG changes during stress test
58
ST Heart Rate Slope

• Maximal change in ST with heart rate calculated
  at the end of each stage
• Heart rate adjustment of ST segment depression -
  improve the sensitivity
• Calculation of the maximal ST/heart rate slope in
  mV/beats/min - linear regression
• An ST/heart rate slope
• gt2.4 mV/beats/min - abnormal
• gt6 mV/beats/min - three-vessel CAD.

59
The ST/heart rate index

• Average change of ST segment depression with
  heart rate throughout the course of the exercise
  test.
• gt1.6 - abnormal

60
Confounders of Exercise Treadmill Test
Interpretation

• Digoxin
• Abnormal ST-segment response to exercise
• In 25 to 40 of healthy subjects
• Related to age.
• Left Ventricular Hypertrophy
• Decreased specificity
• sensitivity is unaffected.
• Resting ST Depression
• Decreased specificity

61
Confounders of Exercise Treadmill Test
Interpretation

• Left Bundle-Branch Block
• Up to 1 cm of ST depression can occur in healthy
  normal subjects
• Right Bundle-Branch Block
• Does not reduce the sensitivity, specificity, or
  predictive value of the stress ECG
• Beta Blocker Therapy
• Reduced diagnostic or prognostic value because of
  inadequate heart rate response

62
Early repolarization and resting ST?

• Return to the PQ junction is normal
• Hence ST? determined from PQ junction
• Not from the elevated J point before exercise

63
Duke Treadmill Score

• Treadmill ScoreExercise time
• -5X (amount of ST-seg. deviation in mm) - 4X
  exercise angina index
• (0-no angina, 1 angina, 2 if angina stops test).
• High Risk -11, mortality gt5 annually.
• Low Risk 5, mortality 0.5 annually.
• Ann Intern Med 1987106793.

64
ACC/AHA Guidelines

• Patients with a high-risk exercise test result
  (mortality 4/yr), should be referred for
  cardiac catheterization.
• Pts. with an intermediate-risk result (mortality
  of 2 to 3/yr), should be referred for
  additional testing, either cardiac
  catheterization, or an exercise imaging study.

65
Pseudo normalization pattern

• No prior MI
• Nondiagnostic finding
• Prior MI
• Suggests Reversible myocardial ischemia
• Needs substantiation by rev myo perfusion defect

66
R wave amplitude

• LVH Voltage criteria
• ST seg less reliable to ? CAD even in the
  absence of LV strain pattern
• Loss of R wave (MI)
• ?Sensitivity of ST response in that lead

67
U inversion

• Occasionally in precordial leads at HRlt120
• Relatively nonsensitive
• Relatively specific

68
Abnormal BP Response

• Failure to ?SBP gt120 mmHg
• Sustained ?(15 secs) gt10mmHg
• ?SBP below resting BP during progressive exercise
• Inadequate ? of CO
• 3VD LMCA disease
• Cardiomyopathy Arrhythmias
• Vasovagal LVOT obstruction
• Hypovolemia Prolonged vigorous exercise

69
Maximum work capacity

• Important prognostic measurement
• Work performed in METs
• Not the no of minutes of exercise

70
Exercise Capacity

• VO max (mph x 26.8) x (0.1 grade X 1.8
  3.5
• 1 MET (metabolic equivalent) 3.5 ml 0
  /kg/min
• Stage 1 5 METS
• Stage 2 6 - 8 METS
• Stage 3 8 -10 METS

2
2
71
Exercise Capacity
The strongest predictor of the risk of death
among both normal subjects, and those with
cardiovascular disease. Each 1-MET increase in
exercise capacity conferred a 12 improvement in
survival.
NEJM 2002346793-801.
72
For each 1-MET increase in exercise capacity, the
survival improved by 12 percent N Engl J Med 2002
73
Exercise Capacity

• In pts. with CAD gt 13 METS (Stage IV) prognosis
  excellent regardless of whether medical or
  surgical therapy is selected.
• Documented CAD, 2 mm ST-segment depression.
  Stage IV had a 100 5-year survival rate.
• In the Coronary Artery Surgery Study (CASS),
  patients with 3-vessel disease, and high exercise
  capacity ( 10 METS), showed no benefit from
  surgery. (JACC 19868741 748)
• Circ 198470226.
• Circ 198265482.

74
Heart rate response

• Inappropriate ? at low work load
• Anxiety (lt1minute-transient)
• Persisting several minutes
• AF Physically deconditioned
• Hypovolemia Anemia
• Marginal LV function

75
Heart rate response

• Chronotropic incompetence
• Inability to attain THR OR
• Abnormal HR Reserve(lt80)
• HR Reserve(HRpeak-HRrest)/(220-age- HRrest)
• Autonomic dysfunction SN dysfuntion,
• Drugs Myocardial ischemia
• ?long term mortality (not on ß blockers)

76
Chronotropic Incompetence
Framingham Heart Study
Circ 1996931520.
77
Heart Rate Recovery

• During exercise, HR increases due to withdrawal
  of vagal tone, and increase of sympathetic tone.
• During recovery, there is a rapid reactivation of
  vagal tone leading to a decrease in heart rate.
• Delayed recovery is a marker of poor outcome

78
Heart Rate Recovery

• Abnormal
• 1 minute
• TMT (upright) lt 12 bpm
• TMT (supine) lt 18 bpm
• An upright value lt22 bpm at 2 minutes is abnormal
• Poor prognosis independent of other factors

79
Exercise induced Chest discomfort

• Usually after ischemic ST changes
• May be associated with increased DBP
• In some, only chest discomfort
• In CSA, CP less freq than ST?
• Angina with no ST ?- MPI useful to assess
  ischemic severity.

80
Angina during Stress Test

• Mortality
• () ve Stress Test with angina 5/yr.
• () ve Stress Test, no angina 2.5/yr.

Circ 198470547-551.
81
Markedly Positive Stress Test

• ECG changes in the first three minutes.
• ECG changes that last through recovery.
• Hypotensive response.

82
Adverse prognosis multivessel CAD

• Symptom limiting exercise lt 5METs
• Abnormal BP response
• ST?2mm or downsloping ST?
  lt5METs, 5 leads,
  persisting 5 mins into reco
• ST?
• Angina at low exercise work loads
• Reproducible sustained/symptomatic VT

83
Indications for Terminating Exercise Testing

• Absolute indications
• Drop in systolic BP gt10 mm Hg from baseline when
  accompanied by other evidence of ischemia
• Moderate to severe angina
• ? CNS sympts (ataxia, dizziness, or
  near-syncope)
• Signs of poor perfusion (cyanosis or pallor)
• Technical difficulties in monitoring ECG or
  systolic BP
• Subjects desire to stop
• Sustained VT
• ST ? (1.0 mm) in leads without Q-waves (other
  than V1 or aVR)

84
Indications for Terminating Exercise Testing

• Relative indications
• ? in systolic BP (10 mm Hg) in the absence of
  other evidence of ischemia
• ST or QRS changes such as excessive ST? (gt2 mm
  of horizontal or downsloping ST? ) or marked axis
  shift
• Arrhythmias other than sustained VT, including
  multifocal PVCs, triplets of PVCs, SVT, heart
  block, or bradyarrhythmias
• Fatigue, shortness of breath, wheezing, leg
  cramps, or claudication
• Development of BBB or IVCD that cannot be
  distinguished from VT
• Increasing chest pain
• Hypertensive response

85

• THANK YOU
