Awareness-Level Lesson 4 Presentation

1
Awareness-Level Lesson 4 Presentation

• Hazardous Materials for First Responders, 3rd
  Ed.

2
Typical Components of PPE

• Respiratory equipment
• Protective clothing
• Structural fire-fighting protective clothing
• High-temperature protective clothing
• Chemical protective clothing

3
What Appropriate PPE Protects

• Skin
• Eyes
• Face
• Hands

• Feet
• Body
• Head
• Respiratory system

(1 of 2)
4
What Appropriate PPE Protects

(2 of 2)
5
PPE and Hazardous Materials

• Structural fire-fighting and high-temperature
  protective clothing Offer limited protection
  against chemical hazards
• Chemical-protective clothing Offers protection
  against hazardous materials
• Requires training above the first responder
  Awareness Level

6
Requirements of PPE

• NFPA standards state requirements for personal
  protective equipment
• Design
• Certification
• Testing

7
Structural Fire-Fighting Protective Clothing

• Provides protection from
• Heat
• Moisture
• Ordinary hazards associated with structural fire
  fighting

8
Components of Structural Fire-Fighting Protective
Clothing

• Helmet
• Coat
• Pants
• Boots

• Gloves
• Personal alert safety system (PASS) device
• Hood

9
Limitations of Structural Fire-Fighting Clothing

• Limited protection against hazardous materials
• Neither corrosive-resistant nor vapor-tight
• Gaps occur in clothing
• Chemicals can be absorbed into the equipment
• Rubber or neoprene in boots, gloves, and SCBA
  facepieces can become permeated by chemicals and
  rendered unsafe for use

10
Structural Fire-Fighting Protective Clothing at
Haz Mat Incidents

• Structural fire-fighting protective clothing is
  commonly used at haz mat incidents when the
  following conditions are met
• Contact with splashes of extremely hazardous
  materials is unlikely
• Total atmospheric concentrations do not contain
  high levels of chemicals that are toxic by way of
  skin contact
• There is a chance of fire or there is a fire

11
Purpose of Chemical-Protective Clothing and
Equipment

• To shield or isolate individuals from the
  chemical, physical, and biological hazards that
  may be encountered during haz mat operations

12
Types of CPC

• Liquid-splash protective clothing
• Vapor-protective clothing

13
CPC Combinations

• Single or multipiece garment
• Encapsulating
• Nonencapsulating

14
Selection of CPC

• Depends on specific chemical and on specific
  tasks
• Selection considerations
• Most CPC is impermeable to moisture
• Garments permeation, degradation, and
  penetration abilities
• Service life

15
CPC Permeation

• Permeation Occurs when a chemical passes
  through the CPC fabric on a molecular level

Chemical spill
16
CPC Degradation

• Degradation Occurs when the characteristics of
  the material in use are altered through contact
  with chemical substances

(1 of 2)
17
CPC Degradation
An acid eating away the outer layers of
structural fire-fighting protective clothing is
an example of chemical degradation.
(2 of 2)
18
CPC Penetration

• Penetration Occurs when there is an opening or
  a puncture in the protective material

(1 of 2)
19
CPC Penetration
Chemicals can penetrate PPE through gaps, tears,
punctures, or other openings.
(2 of 2)
20
CPC Service Life

• Reusable
• Limited use
• Disposable

21
CPC Written Management Program

• All emergency responders and organizations who
  routinely select and use CPC should establish a
  written CPC management program.

22
Positive-Pressure SCBA Components

• Facepiece
• Pressure regulator
• Compressed air cylinder
• Harness assembly
• End-of-service-time indicators

23
Advantages of Positive-Pressure SCBA

• Maintains air pressure inside the facepiece
  slightly higher than normal atmospheric pressure
  outside
• Independence
• Maneuverability

24
Disadvantages of Positive-Pressure SCBA

• Heavy weight of the units
• Limited air supply duration
• Change in profile that may hinder mobility
• Limited vision caused by facepiece fogging
• Limited communications if not equipped with a
  microphone or speaking diaphragm

25
Level D Ensembles

• Used for nuisance contamination and used only
  when no atmospheric hazards exist
• Provide no respiratory protection and minimal
  skin protection
• May not be worn in the hot zone

26
Level D Ensemble Components

• Consist of typical work uniforms, street
  clothing, or coveralls
• Includes items such as
• Gloves
• Safety glasses
• Boots
• Hardhats

27
Level D Ensemble Use

• Atmosphere contains no hazard
• Work functions preclude splashes, immersion, or
  the potential for unexpected inhalation of or
  contact with hazardous levels of any chemicals

28
PPE Care and Inspection

• The user must take all steps to ensure that the
  protective ensemble performs as expected
• All PPE and respiratory equipment must be
  inspected on a routine basis
• Records must be kept of all inspection procedures

29
Summary

• Personal protective equipment is essential in
  emergency response. The type of PPE used depends
  on the specific incident. Typical PPE consists of
  respiratory equipment and either structural
  fire-fighting, high-temperature, or
  chemical-protective clothing.
• Structural fire-fighting clothing provides very
  limited protection against hazardous materials.

(1 of 3)
30
Summary

• Chemical-protective clothing provides protection
  against hazardous materials. No one type of CPC
  protects against all hazards.
• Positive-pressure SCBA is often used at incidents
  and has both advantages and disadvantages.

(2 of 3)
31
Summary

• Level D ensembles are typical work uniforms,
  street clothes, or coveralls and are only
  appropriate for nuisance contamination.
• PPE care and inspection is an important component
  in ensuring that PPE is properly maintained and
  safe for the user.

(3 of 3)
32
Awareness-Level Lesson 4 Presentation

• Hazardous Materials for First Responders, 3rd
  Ed.
