Title: Clock Distribution


1
Clock Distribution
Rajeev Murgai Advanced CAD Technologies Fujitsu
Labs of America UC Berkeley Feb 15, 2005
2
Defining Clock Skew and Jitter
  • Clock skew
  • The deterministic (knowable) difference in clock
    arrival times at each flip-flop
  • Caused mainly by imperfect balancing of clock
    tree/mesh
  • Can be deliberately introduced using delay blocks
    in order to time-borrow
  • Accounted for in STA by calculating the clock
    arrival times at each flip-flop
  • Clock jitter
  • The random (unknowable, except distribution ?)
    difference in clock arrival times at each
    flip-flop
  • Caused by on-die process, Vdd, temperature
    variation, PLL jitter, crosstalk, Static timing
    analysis (STA) accuracy, layout parameter
    extraction (LPE) accuracy
  • Accounted for in STA by subtracting (3 ?) from
    the cycle time in long path analysis, and adding
    to receiving clock arrival time in race analysis
  • Jitter is always bad, skew can be helpful or
    harmful.
  • Clock uncertainty ? ? skew ? jitter

Long path analysis
Race analysis
Logic
clk
skew
skew
clk
3
Background
  • Technology scaling results in
  • higher clock frequencies possible and requested
    by users
  • prominence of wiring parasitics (R,L,C) in
    electrical behavior
  • increasing noise impact on delays
  • increasing on-chip process variation impact on
    delays
  • Existing ASIC clock synthesis flows
  • Use tree architectures not best for low skew,
    jitter, variations
  • Don't properly address noise issues
  • Rely on STA to calculate the delays through clock
    networks
  • Use inaccurate wiring models
  • Use noise-sensitive clock circuit topologies
  • Ignore or crudely estimate process/voltage/tempera
    ture variations
  • Dont have tight integration of physical
    synthesis clock synthesis
  • Result
  • Predictability of clock delay is poor Clock
    uncertainty (i.e., skew jitter) of 400ps is not
    uncommon
  • Maximum attainable clock frequency is impaired

4
Problems with Existing Clock Methodologies
  • Tree-based Clock Distribution
  • Low power but...
  • Sensitive to mismatching branches, difficult to
    layout
  • Sensitive to noise, especially if wires are not
    shielded
  • Using STA to calculate tree timing results in
    large errors
  • gt high skew and jitter

medium skew and jitter
small skew and jitter
large skew and jitter
5
Problems with Static Timing Analysis (STA)
What we have...
L
R
Cg
Cs
signal wire
What STA uses...
Rup
Rwire
Cload
Cw/2
Cw/2
Rdn
Note driver model is a little better than this
with table look-up
Other problems Cw can match either delay or
slew, but not both interpolation using look-up
tables
6
Clock Distribution Architectures
  • Two basic architectures
  • Tree
  • Grid (mesh)
  • Hybrids of tree and mesh
  • Tree crosslinks
  • Mesh local trees

7
Tree
  • Widely used in ASICs
  • Advantages
  • Low cost
  • Wiring
  • Capacitance
  • Power
  • Clock gating easy
  • Disadvantages
  • Difficult to balance path delays due to
    asymmetric FF distribution
  • Sensitive to variations
  • Topologies
  • Symmetric H-tree
  • Asymmetric trees

8
CAD for Tree Architecture
  • Topology generation
  • H-tree widely used
  • Method of means and medians (MMM) Jackson et al.
    DAC 90
  • Goal reduce wirelength while minimizing skew.
  • Divide set S of points into Sleft and Sright,
    based on median.
  • Sleft Sright
  • Connect/route center of mass (CM) of S to CM of
    Sleft and Sright.
  • Recurse on Sleft and Sright.

9
Method of Means Medians
  • Problem
  • May not result in zero skew
  • Solution
  • One step look-ahead and decide direction of
    splitting.
  • Estimate skews using Penfield Rubenstein model.

10
Topology Recursive Geometric Matching
  • Kahng et al. DAC 91
  • Bottom-up pair-wise merge algorithm
  • Optimum geometric matching on n points (minimum
    wirelength)
  • Determine center point of each match edge
  • Recurse on n/2 points
  • Uses path length skews
  • Tries to balance root to leaf path lengths.

11
Topology Simulated Annealing
  • Topology generation
  • Cheng et al improve initial topology by
    simulated annealing
  • effective in reducing delay

12
CAD for Tree Architecture
  • Routing wire sizing
  • Tsay, TCAD 93 zero-skew routing
  • first paper to use Elmore delay as delay model
  • earlier work used pathlength
  • DME, planar DME
  • make faster paths slower by detours/snaking to
    match delays
  • may use wire-sizing make slower paths faster
  • Wire spacing
  • Buffering
  • Tellez Sarrafzadeh, TCAD 97
  • insert minimum buffers on a given topology to
    meet skew and slew constraints.

13
Grid/Mesh
  • n x n uniform mesh
  • Distributed array of k x k buffers drives the
    mesh.
  • Buffers driven by global H-tree.
  • Flip-flops directly connected to the nearest
    mesh segment
  • Used in modern processors
  • Advantages
  • Excellent for low skew
  • Robust to variations
  • Disadvantages
  • Higher wiring area, capacitance, power
  • Difficult to analyze
  • Loops and redundancy

14
Mesh
  • Sizing of clock distribution networks for high
    performance CPU chips
  • Desai et al., DEC DAC 1996
  • goal size grid interconnect segments with
    constraints on clock latency and average current
  • assume initial grid and interconnect sizes
  • width explicit gt non-linear program practical
    for small networks/trees.
  • consider width as implicit solve using sequence
    of network problems.
  • Results applied on clock networks of two actual
    processors DC21046A and DC21164. Results for
    DC21046A
  • 275MHz clock
  • grid has 1 million edges, 15.5K drivers, 81K
    receivers
  • 16 reduction in capacitance - without increasing
    clock latency.
  • Runtime 3 days.
  • Optimal Wire and Transistor Sizing for Circuits
    with Non-tree Topology
  • Vandeberghe et al., Stanford University ICCAD
    97
  • RC circuit with tree topology gt sizing problem
    is convex optimization
  • meshes have R loops use dominant time constant
    as measure of delay
  • solve using semi-definite programming
    (quasi-convex function)

15
Hybrid Architecture Tree Cross-links
  • Reducing Clock Skew Variability via Cross Links
  • Rajaram et. al., DAC 2004
  • tree short-circuit some sink pairs gt non-tree
    topology
  • clock signal propagates through multiple paths
    reduces skew and skew variability between shorted
    sinks
  • reduces skew variability by 30-70
  • very small wire-length penalty (2) over tree
    topology
  • Drawback
  • does not consider buffering

16
Hybrid Architecture Mesh Trees
  • Hybrid Structured Clock Network Construction Hu
    Sapatnekar, ICCAD 01
  • Hybrid clock topology
  • simple top-level global mesh
  • zero-skew local trees at bottom
  • Presents wire sizing scheme to achieve latency
    and skew reduction.
  • iterative LP to minimize wire width (area) of
    top-level mesh, given delay bound
  • uses Elmore delay t G-1C
  • sensitivity-based post-layout clock tree tuning
    to reduce skew.

(Da, CDa)
a
c
d
b
17
Clock Architectures
18
Processors
  • Traditionally two hierarchies
  • Global clock network
  • Local clock network
  • Skew control
  • Global network balanced trees or grids
  • Local network de-skewing buffers

19
Pentium4 IJSSC Nov 2001
  • 0.18u, 6 metal layers, 42 million transistors
  • Core medium clock frequency 2 GHz
  • Used by most core blocks
  • High speed scheduling and execution 4GHz
  • Non critical blocks (e.g., bus interface logic)
    1GHz
  • Global clock distribution
  • 3 spines each spine has binary clock
    distribution
  • jitter reduction schemes
  • low-pass RC-filtered power supply for clock
    drivers
  • shield clock wires

spines
20
IBM IJSSC 2001
  • Same clock architecture for 6 chips (including
    PowerPC)
  • Design priorities min. clock skew, sharp rise
    and fall times (below 100 ps for 1ns clock), 50
    duty cycle, low power consumption
  • Global buffered H-trees (on top 2 layers) drive
    sector buffers.
  • length-matched
  • Each sector buffer drives tuneable tree, which
    drives global mesh
  • Tree wire-widths tuned to minimize skew over long
    distances
  • Mesh minimizes local skew by connecting nearby
    points directly.
  • For each chip, 10-20 complete tuning cycles
  • Buffer placement, wiring
  • Flip-flops connected to closest point on mesh
  • Global clock skew of 22ps
  • Inductance included in analysis
  • Mesh difficult to analyze due to loops
  • cut the mesh

21
Alpha, DEC JSSC, Nov 98
  • 0.35u, 4 metal layers, 15.2 million transistors,
    600 MHz at 2.2V
  • 3 hierarchies in clock distribution
  • Global, major (regional) and local
  • Multi-level mesh
  • global trees to global GCLK grid
  • Uses 3 of M3/M4 interconnect
  • M3/M4 shielding M2, M4 Vdd/Vss
  • power 16W skew 72ps
  • Major (regional)
  • six grids over execution units
  • use 6 of M3, M4
  • power 14W
  • Local clock
  • tree structure, not shielded
  • conditional/unconditional clocks
  • less than 10ps skew power 15.6W
  • Clock simulation
  • AWE-reduction SPICE

s
PLL
GCLK grid
22
Summary of Processor Clock Design
  • Three basic routing structures for global clock
  • H-tree
  • low skew, smallest routing capacitance, low power
  • Floorplan flexibility is poor
  • Grid or mesh
  • low skew, increases routing capacitance, worse
    power
  • Alpha uses global clock grid and regional clock
    grids
  • Spine
  • Small RC delay because of large spine width
  • Spine has to balance delays difficult problem
  • Routing cap lower than grid but may be higher
    than H-tree.

High
23
Estimation of Process-dependent Clock Skew in
CMOS VLSI, Shoji JSSC, Oct. 86
  • Given two paths from clock source to FFs
  • Conventional design method
  • design paths such that skew between S1 and S2 is
    zero at a (fixed) process corner
  • However,
  • skew may not be zero at another process corner
  • Novel idea in the paper
  • design the two paths such that skew between S1
    and S2 is zero for different process corners
  • TA TB TC TD TE (typical corner)
  • For high-current process corner H,
  • TA(H) TA 1/fN TB(H) TB 1/fP (fN, fP gt 1)
  • Zero-skew condition at H
  • TA(H) TB(H) TC(H) TD(H) TE(H)
  • (TATC) 1/fN TB/FP TD/fN TE/fP
  • (TE TB)/fN (TE - TB)/fP

S1
S2
C
E
B
D
A
CLK
24
Estimation of Process-dependent Clock Skew in
CMOS VLSI, Shoji JSSC, Oct. 86
  • Either TE TB or fN fP.
  • But fN may not be same as fP (for PH-NL process)
  • In general, TE TB gt TD TA TC.
  • Pull-up and pull-down delays of two paths should
    be identical.
  • Determine NMOS PMOS transistor widths of
    inverters to achieve this.
  • Results
  • 1.75 u process
  • Widths selected manually
  • Lead to very small skews at all process corners
  • Drawbacks
  • only analyzes two paths
  • assumes identical percentage delay variation for
    all NMOS (PMOS) devices
  • uses simplistic delay model ignores wire cap

S1
S2
C
E
B
D
A
CLK
25
Optimal Clock Skew Scheduling
  • Long short path constraints impose lower/upper
    bounds on skew.
  • long path analysis aj ? ai ?logic_max
    tset_up - Tcycle
  • short path analysis aj ? ai ?logic_min - thold
  • Leads to a set of linear inequalities ai aj ?
    cij
  • Given a clock cycle, feasibility can be solved
    using linear program, more efficiently with
    Bellman-Ford shortest path Fishburn TCAD90.
  • If wish to compute optimum clock cycle,
  • Perform binary search using above feasibility
    check.
  • Perform parametrized shortest path Tarjan et
    al.
  • One challenge realize each ai
  • Other objectives minimize power or switching
    noise.

26
Optimal Clock Skew Scheduling Tolerant to Process
Variations Neves Friedman, 96
  • Long path and short path constraints impose lower
    and upper bounds on skew.
  • long path analysis aj ? ai ?logic_max
    tset_up - Tcycle
  • short path analysis aj ? ai ?logic_min - thold
  • Try to choose skews in the middle of the bounds
    for maximum protection against process
    variations.
Write a Comment
User Comments (0)
About PowerShow.com
