The Heart

1
The Heart
2
Description of the Heart (Part 1)

• Heart location
• Ventral cavity Thoracic cavity Mediastinal
  cavity Pericardial cavity
• 2/3 shifted left
• Extends from rib 2 to 5th intercostal space
• Apex
• Left ventricle
• Points toward left hip
• Base
• Upper posterior surface
• Predominantly left atrium
• Sternocostal surface
• Diaphragmatic surface
• Individuals heart is about the size of the
  persons closed fist

3
Description of the Heart (Part 2)

• Pericardial Sac
• Fibrous pericardium
• Serous pericardium
• Parietal
• Visceral
• Pericardial cavity
• Cardiac Wall
• Epicardium Visceral pericardium
• Myocardium Muscle layer
• Endocardium Lining
• Chambers
• Valves

• Clinical Applications
• CPR
• Cardiac tamponade
• Pericarditis
• Myocarditis
• Endocarditis

4
Gross Anatomy of the Heart (Anterior Aspect)
5
Gross Anatomy of the Heart (Posterior Surface
View)
6
Description of the Heart (Part 3)

• Cardiac Chambers
• Atria
• Thin walls
• Pectinate muscle
• Separated by
• Interatrial septum
• Fossa (foramen) ovalis
• Right
• Receives oxygen depleted blood from body
• Lowest blood pressure in body

• Left
• Receives oxygen enriched blood from lungs
• Ventricles
• Thick walls
• Trabeculae carnae
• Separated by Interventricular septum
• Right
• Receives blood from R. Atrium

7
Description of the Heart (Part 4)

• Pumps blood to lungs
• Left
• Receives blood from L. atrium
• Pumps blood to body
• Highest blood pressure
• Cardiac Valves
• Structure
• Cusp
• Endocardium
• Dense connective tissue
• Chordae tendinae
• Papillary muscle

• Function
• Prevent reverse flow
• Location surface projection
• Tricuspid
• R. atrioventricular valve
• R./L. 5th intercostal space, near sternum
• Pulmonary semilunar
• R. ventricle ? pulmonary trunk
• L., 2nd intercostal space near sternum

8
Gross Anatomy of the Heart (Frontal Section)
9
Description of the Heart (Part 5)

• Bicuspid (mitral)
• L. atrioventricular
• L., 5th intercostal space in midclavicular line
• Aortic semilunar
• L. ventricle ? aorta
• R., 2nd intercostal space, near sternum
• Great vessels of the Heart

10
Description of the Heart (Part 6)

• Inferior vena cava (IVC)
• Coronary sinus
• Superior vena cava (SVC)
• Pulmonary trunk Right ventricle
• Pulmonary veins Left atrium
• Aorta Left ventricle

11
Cardiac Conduction System (Part 1)

• Specialized myocardial cells
• Autorhythmic
• Pacemaker
• Conduction system
• Pacemaker cells set up basic rhythm of
  contractions
• Conduction system coordinates contraction of
  myocardial fibers

• Conduction system components
• Sinoatrial (SA) node
• In R. atrium near SVC opening
• Primary pacemaker
• Impulse transmits to AV node
• Maintains rhythm of 60-100 bpm
• Atrioentricular (AV) node
• In interatrial septum
• Secondary pacemaker
• Impulse transmits to AV bundle

12
The Intrinsic Conduction of the Heart and
Succession of Action Potential Through Selected
Areas
13
Cardiac Conduction System (Part 2)

• Sets basic rhythm if SA node is not functioning
• Maintains rhythm of 40-50
• Atrioventricular bundle (Bundle of His)
• Electrically links atria to ventricles
• In septa
• Impulse transmits to bundle branches
• Maintains rhythm of 20-40

• R.L. bundle branches
• In interventricular septum
• Impulses transmit to myoconduction fibers
• Conduction myofibers (Pukinje fibers)
• In ventricular walls
• Impulses transmit to ventricular walls
• Clinical applications
• Artificial pacemakers
• Bundle branch block
• Complete
• Right
• Left

14
The Sequence of Excitation of the Heart Related
to the Deflection Waves of an ECG Tracing
15
An Electrocardiogram (ECG) Tracing
16
Summary of Events Occurring in the Heart During
the Cardiac Cycle
17
Cardiac Cycle (Part 1)

• Events associated with one heart beat Lasts
  about 0.8 sec
• R. L. sides
• Acts simultaneously
• Develop different pressures
• Expel the same volume
• Chambers fill passively
• Atria contract while ventricles relax
• Ventricles contract while atria relax

• Systole Contraction phase
• Asystole Relaxation phase
• Phases
• Relaxation (Quiescent) period
• At end of heart beat lasts about 0.4 sec
• All 4 chambers relaxed Pressure drops backflow
  of blood
• Trapped by closing of semilunar cusps of vavles
  Dicrotic notch

18
Cardiac Cycle (Part 2)

• All 4 valves closed Isovolumetric relaxation
• Ventricular pressure lt atrial pressure AV
  valves open
• Ventricular filling
• Rapid ventricular filling Passive
• Diastasis
• Atrial systole Final 30mL 0.1 sec
• End diastolic volume (EDV) about 130 mL

19
Cardiac Cycle (Part 3)

• Ventricular systole
• AV valves shut 1st heart sound
• All 4 valves closed Isovolumetric contraction
• Ventricular pressure rises
• Semilunar valves open
• Ventricular ejection 0.5 sec
• Semilunar valves close 2nd heart sound
• Systole begins
• End systolic volume (ESV) 60 mL
• Stroke volume EDV ESV
• Cardiac output stroke volume x heart rate

20
Factors Involved in Regulation of Cardiac Output
21
Generalizing Structure of Arteries, Veins, and
Capillaries
