Title: Equipment Operation & Maintenance Review Digital Imaging


1
Equipment Operation Maintenance
  • Review

2
Objectives
  • Review equipment operation and maintenance.
  • We start out reviewing primary terminology.

3
Basic Physics Terms
  • Familiarize yourself with
  • Matter, Mass, Energy, Potential Energy, Kinetic
    Energy, Chemical Energy, Electrical Energy,
    Thermal Energy, Nuclear Energy, Electromagnetic
    Energy, and Ionizing Radiation

4
Atomic Structure
  • Atomic Mass Number of protons and neutrons.
  • Electron Shells Contain orbital electrons that
    revolve around the nucleus. (Ex. K, L, M, N,
    etc.)
  • Atomic Number The number of protons in the
    nucleus atomic number determines the chemical
    element.
  • Isotopes Atoms with the same number of protons
    but with a different number of neutrons.
  • Electron-Binding Energy Force that holds
    electrons in orbit.
  • Octet Rule The outer shell can contain no more
    than 8 electrons.
  • Particulate Radiation Alpha/Beta particles.

5
Electromagnetic Radiation
  • Photon The smallest amount of any type of
    electromagnetic radiation. Travels at the speed
    of light.
  • Sine Waves Wave height is called amplitude
    distance between peaks is called wavelength
    Photon wavelength is associated with photon
    energy level.
  • Frequency Number of wavelengths passing a given
    point per unit time. measured in hertz.
  • Speed of Travel 186,000 miles per second.
  • Gamma Rays Electromagnetic rays produced in the
    nucleus of radioactive atoms. X-rays and gamma
    rays differ only in origin.
  • Wave-particle Duality X-rays exist as waves,
    but exhibit properties of particles.
  • Law of Conservation of Matter/Energy Created
    nor destroyed.

6
Electricity Magnetism
  • Electrostatics Stationary electric charges.
  • Electrostatic Law Unlike charges attract / Like
    charges repel.
  • Conductor Allows electron flow.
  • Insulator Prohibits electron flow.
  • Current The flow of electrons along a
    conductor.
  • Electromotive Force (EMF) The force with which
    electrons move in an electric circuit.
  • Electrodynamics Electric charges in motion.
  • Semiconductor Material that may act as an
    insulator or conductor under different
    conditions.
  • Electric Resistance Measured in ohms.
  • Ohms Law Voltage Current x Resistance

7
Electricity Magnetism
  • Circuit Path along which electrons flow.
  • Alternating Current Current oscillates back and
    forth.
  • Direct Current Current flows in one direction.
  • Magnetic Field Surrounds an electric charge in
    motion. Can magnetize ferromagnetic material.
  • Magnetic Law Like charges repel while unlike
    charges attract.
  • Solenoid Coil of wire wrapped so magnetic field
    lines overlap.
  • Electromagnet A solenoid with an iron core
    which concentrates the magnetic field.
  • Electromagnetic Induction The process of
    causing current to flow in a conductor when it is
    placed within the force field of another
    conductor.

8
Electricity Magnetism
  • Self Induction Opposing voltage created in a
    conductor by passing alternating current through
    it.
  • Mutual Induction Inducing current in a
    secondary coil by varying current in a primary
    coil.
  • Electric Generator Converts mechanical energy
    to electrical energy.
  • Single-Phase, Two Pulse AC Voltage begins at
    zero, peaks at the full value at the crest of the
    wave, and returns to zero.
  • Three-Phase AC Special wiring (wye, star.
    Delta) allows for three voltage waveforms out of
    phase with one another. Can have 6 or 12 pulses
    per cycle.6 pulse has 360 pulses per second,
    while 12 pulse has 720 pulses per second.

9
Electricity Magnetism
  • Electric Motor Converts electric to mechanical
    energy.
  • Transformer Changes voltage and current into
    higher or lower values.
  • Step-Up Transformer Increases current/voltage
    has more turns on the secondary coil than on the
    primary coil.
  • Step-Down Transformer Decreases current/voltage
    has more turns on the primary coil than the
    secondary coil.
  • Autotransformer A transformer that contains an
    iron core and a single winding of wire Provides
    a small increase in voltage before the step-up
    transformer kVp settings are made at the
    autotransformer.
  • Rectification Changing AC to DC.
  • Line Voltage Compensation Ensures consistent
    voltage supply.

10
The X-ray Circuit
11
X-ray Production
  • Three things occur
  • 1. Source of electrons
  • 2. Acceleration of electrons
  • 3. Sudden stoppage of electrons
  • against target material.

12
Autotransformer
  • A variable transformer that varies incoming
    voltage to the circuit.
  • Single coil of wire with iron core.
  • Source for selecting kVp.
  • Operates on self induction.
  • Steps up/down voltage by only a small amount.
  • The high voltage transformer then boosts the
    voltage to the kVp.

13
Voltmeter
  • Indicates the voltage that is selected.
  • Placed in the circuit between the autotransformer
    and the high voltage transformer.

14
Timer
  • Regulates the duration of the exposure.
  • Synchronous timer Operates from a motor 60
    rotations per second. Shortest time is 1/60 of a
    second.
  • Impulse timer Counts voltage pulses.
  • mAs timer Provides the safest tube current in
    the shortest possible time. Measures total tube
    current.
  • Electronic timer Microprocessor controlled
    Now in most radiographic equipment Allows
    exposures as low as 1 ms (.001 s).

15
AEC
  • Used to provide consistency of exposure.
  • Contains ionization chamber which is located
    between the patient and the IR. As radiation
    passes through the ionization chamber it ionizes
    the gas within it.
  • The level of ionization is directly proportional
    to the density that will appear on the film. At a
    predetermined level of ionization, the exposure
    is stopped by an electronic switch.
  • A backup timer will stop the exposure in the
    event of a failure.
  • Minimum response time Shortest exposure time
    possible (1ms).

16
Falling Load Generator
  • Modern generator that takes advantage of
    extremely short time capabilities and tube heat
    loading potential.
  • Calculates the most efficient way of obtaining
    mAs.
  • Tube current starts at highest level possible
    until maximum heat load is reached, then the
    generator drops the mA to the next lower level
    that the tube can handle. This continues until
    the desired mAs has been reached.
  • This ultimately results in short exposure times.
  • Disadvantage Exams such as breathing technique
    exams that require a long exposure time.

17
Step-Up Transformer
  • The High-Voltage Transformer.
  • Consists of primary and secondary coils.
  • Requires AC to operate.
  • Operates on principle of mutual induction.
  • The turns ratio determines level of voltage
    increase.

18
The Circuit
High Voltage Transformer
19
Rectifier
  • X-ray tube requires direct current to operate
    properly.
  • Rectifiers change AC from the step-up transformer
    to DC.
  • Rectifiers are solid-state semiconductor diodes.
    They are silicon-based n-type and p-type
    semiconductors.
  • Located between the step-up transformer and the
    x-ray tube.

20
4-Diode/full-wave rectified/single phase
  • Full-wave rectified pulsating current.
  • Resultant waveform contains two pulses per cycle
    (120 pulses/sec).
  • Uses both portions of rectified AC.
  • Results in 100 ripple with voltage dropping to
    zero 120 times per second.

21
Three phase/6 or 12 diodes/fully rectified
  • Voltage never drops to zero with three-phase.
  • Ripple for 3-phase 6 pulse is 13, so voltage
    used is about 87 of the actual kVp set.
  • Ripple for 3-phase 12 pulse is 4, so voltage
    actually used is about 96 of the set kVp.
  • High-frequency ripple is about 1, so 99 of what
    is set is used.

22
MA Meter
  • Located between the rectifier and tube.
  • Measures tube current in milliamperes.

23
mA Control
  • Regulates the number of electrons available at
    the filament to produce x-rays.
  • Voltage is supplied by tapping windings of the
    autotransformer and sending varying voltage to
    the step-down transformer.
  • The step-down transformer reduces voltage and
    increases current in response to variable
    resistors which results in high current to the
    tube filament.

24
X-ray Tube
  • Cathode Negative electrode two filaments
    (focal spot) Made of tungsten (small amount of
    thorium).
  • - Filament heats up and boils off
    electrons (thermionic emission).
  • - Over time the filament vaporizes and
    coats the tube with tungsten
  • which leads to failure.
  • - Assembly includes the focusing cup
    (focuses space charge on the anode).

25
X-ray Tube
  • Anode Tungsten embedded in molybdenum rotating
    positive target. Must withstand high heat loads.
  • - Rotates 3300 to 10,000 rpm Faster
    rotations dissipates heat
  • better.
  • - Tube rotation is achieved by an induction
    motor.
  • - Electrons strike the focal track.
  • - Target design allows for a large actual
    focal spot with a smaller
  • effective focal spot Line-focus
    principle.

26
X-ray Tube
  • Glass Envelope/Window Leaded Pyrex glass.
    Window had a thinner leaded area to absorb low
    energy photons. Tube contains a vacuum.
  • Encased in the tube housing which is made of
    aluminum with lead lining.
  • - Supports and protects the tube,
    while limiting leakage.
  • - Also contains oil which
    provides cooling and insulation.

27
X-ray Production
  • Review the overview of the x-ray production
    circuit on page 53.
  • Brems Radiation Occurs when electrons are
    slowed or braked when they come under the
    influence of the nucleus of target atoms. This
    loss of kinetic energy results in x-ray creation.
    At diagnostic levels, most x-rays produced are
    from brems interactions.

28
X-ray Production
  • Characteristic Radiation A projectile electron
    collides with an inner shell electron and ionizes
    it. As outer shell electrons fall down to
    stabilize the atom, characteristic radiation is
    given off.
  • - Characteristic rays are produced at kVp
    levels above 70, but only
  • in small numbers.
  • - Only characteristic rays produced at the
    K-shell have sufficient energy to be used in
    diagnostic radiography.

29
X-ray Properties
  • Part of the electromagnetic spectrum
  • Highly penetrating
  • Invisible
  • Travel at the speed of light
  • Travel in straight lines as waves Short
    wavelength high frequency high energy. Long
    wavelength low frequency loe energy.
  • Can ionize
  • Have characteristics of waves and particles
    (wave-particle duality)
  • Can cause biologic damage

30
Heating Units
  • Single-phase, fully rectified kVp x mAs
  • Three-phase, 6 pulse, fully rectified kVp x mAs
    x 1.35
  • Three-phase, 12 pulse, fully rectified kVp x
    mAs x 1.41
  • Most modern equipment will not allow overloading
    the tube.

31
Fluoroscopy
  • Provides dynamic visualization of internal
    anatomy.
  • C-arm design ensures proper and safe distance
    between tube IR.
  • Tube is operated at 3-5 mA.
  • Automatic brightness control Process that
    automatically adjusts kVp and mA during the
    procedure.
  • Image-intensifier converts x-ray energy into
    light and then into an electronic image that can
    be displayed on a monitor.

32
Image-Intensifier
  • Input Phosphor Cesium iodide Receives exit
    rays from patient and converts them into light.
  • Visible light strikes the photocathode which
    releases electrons directly proportional to the
    light that struck it.
  • The electrons are focused toward the other end of
    the tube by electrostatic lenses.
  • The electrons strike the output phosphor zinc
    cadmium sulfide.
  • The energy of the electrons is converted into
    visible light that is 50 -75 times greater than
    at the photocathode.
  • The increase in brightness is called the flux
    gain.
  • The output phosphor is smaller than the input
    phosphor resulting in an increase in brightness
    minification gain.

33
Image Intensifier
Total brightness gain ranges from 5,000 to 20,000
and decreases with tube age. Images are sent to
a monitor by a vidicon or plumbicon or a
charge-coupled device (CCD).
34
Digital Imaging
  • Computed Radiography ( CR ) Uses an imaging
    plate which contains a photostimulable phosphor.
    Absorbs energy exiting the patient. IP is scanned
    with a laser. Energy released as blue light which
    is detected and converted with an ADC, and
    viewed.
  • Direct Digital Radiography (DR) Uses fixed
    detectors which communicate directly with a
    computer. Direct uses amorphous selenium to
    convert x-rays directly into electrons. Indirect
    uses a scintillator to convert x-rays into light,
    then into electrons.
  • Review key terms on page 63.

35
QC Facts
  • Filtration-beam quality Tested with half-value
    layer measurement.
  • Timer Testing Single-phase Spinning top test
    one dot appears every 1/120 second.
  • - Three-phase
    Motorized spinning top
  • or other digital
    timer.
  • Review key terms on page 74.

36
The End
  • Perform the chapter tutorial at this point.
Write a Comment
User Comments (0)
About PowerShow.com
