Title: Nuclear Power


1
www.energy.mn.gov
March 26, 2009
Terry Webster
2
Planning for Minnesotas Energy Future
  • Including Nuclear Power in Minnesota Future
    Energy Mix

3
Questions to Explore
  • How has the use of nuclear power developed in the
    US since inception in 1942?
  • What is the current energy picture?
  • What is the outlook for future nuclear power?
  • Is there a potential role for expanded use of
    nuclear power?
  • V. What are the new designs of nuclear power
    reactors?
  • What are the regulatory policies in other
    states?
  • What are the subsidies for electric power
    production?

4
I. U.S. Nuclear Electricity Milestones
1942-Present
Sourer selected milestones from www.nei.org
5
I. U.S. Nuclear Electricity Milestones
1942-Present
6
I. U.S. Nuclear Electricity Milestones
1942-Present
7
II. Current Nuclear Power Use
  • Worldwide
  • United States
  • Minnesota

8
Worldwide Nuclear Power Use
  • 436 nuclear power reactors operating in 30
    countries.
  • Combined capacity of over 370 GWe.
  • In 2007, nuclear power provided 2608 billion
    kWh, about 16 of the world's electricity.

9
Worldwide Nuclear Power Use
http//www.insc.anl.gov/pwrmaps/map/world_map.tif
10
Top 10 Nuclear Generating Countries 2007,
Billion kWh
Source International Atomic Energy Agency, U.S.
is from Energy Information Administration Updated
9/08
11
Worldwide
Source http//www.iaea.or.at/programmes/a2/
12
Worldwide
Source http//www.iaea.or.at/programmes/a2/
13
United States Nuclear Power Reactors
  • 104 nuclear power reactors operating.
  • 28 nuclear power reactors shutdown.
  • 1 nuclear power reactor under construction (Watts
    Bar-2, Tennessee).
  • 806501.261 GWh of electricity produced in 2007.
  • In 2007, nuclear power provided about 20 of the
    US electricity.

http//www.iaea.or.at/programmes/a2/
14
Map of the United States Showing Locations of
Operating Nuclear Power Reactors
http//www.nrc.gov/info-finder/reactor/
15
Minnesota Nuclear Highlights
  • 31 States with nuclear capacity, Minnesota ranks
    21st.
  •
  • Monticello Unit 1 597 MWe 37
  • Prairie Island Unit 1, Unit 2 1,049 MWe 63
  • Total 3 Reactors 1,646 MWe 100
  •
  • The Prairie Island nuclear power plant ranks
    second in capacity among Minnesotas power
    plants.
  • The Monticello nuclear plant ranks fourth in the
    State.

Source Form EIA-860, "Annual Electric Generator
Report"
16
Minnesota Electric Capacity
source EIA
17
III. What is the future of Nuclear Power?
  • Minnesota
  • US
  • World

18
Future Nuclear Power Use
  • Nuclear Powered Electric is part of current
    energy mix.
  • With relicensing, Minnesotas nuclear power
    production will remain constant (but a decrease
    percent of energy mix.)
  • With relicensing and new construction, US and
    World nuclear production will increase.

19
Minnesota Electric Capacity 1990 2006
source REIS Data Base
20
Status of Minnesotas Nuclear Generation
Facilities
  • Original license application for the Monticello
    nuclear power plant scheduled to expire in 2010.
    License renewal application filed 03/24/05 and
    renewed license for 20 year issued 11/08/06.
  • The Minnesota Public Utilities Commission granted
    a Certificate of Need for a 71 MW increase
    (uprate) in the generating capability at
    Monticello.
  • Original license for Prairie Island unit 1
    scheduled to expire in 2013, and that for unit 2
    expires in 2014. License renewal application
    filed 04/15/08 with NRC decision anticipated on
    10/15/10.
  • Xcel has filed for Certificate of Need for a 164
    MW increase (uprate) (82 MW per unit) in the
    generating capability at Prairie Island.
  • No new facilities are planned due to Minnesota
    Law.

http//www.nrc.gov/reactors/operating/licensing/re
newal/applications.htmlplant
21
United States Electricity Capacity
http//www.eia.doe.gov/oiaf/archive/aeo08/overview
.html
22
Status of U.S. Nuclear Generation Facilities
  • The US has over 100 nuclear reactors providing
    almost 20 of its electricity.
  • The first operating license will expire in the
    year 2009 approximately 10 percent will expire
    by the end of 2010 and more than 40 percent will
    expire by 2015.
  • The decision to seek license renewal is strictly
    voluntary and nuclear power plant owners (i.e.,
    licensees) must decide whether they are likely to
    satisfy NRC requirements and whether license
    renewal is a cost-effective venture.
  • There have been 17 license applications to build
    26 new nuclear reactors since mid 2007, following
    several regulatory initiatives preparing the way
    for new orders.

23
U.S. Nuclear Industry Yearly Power Uprates
1977-2008
Source Nuclear Regulatory Commission Updated
11/08
24
Cumulative Capacity Additions at U.S. Nuclear
Facilities 1977-2013
Source Nuclear Regulatory Commission Updated
2/09
25
Location of Projected New Nuclear Power
Reactors in the US
http//www.nrc.gov/reactors/operating/map-power-re
actors.html
26
World Electricity Capacity
http//www.eia.doe.gov/oiaf/ieo/pdf/0484(2007).pdf
27
Status of Worlds Current Nuclear Generation
Facilities
Source http//www.iaea.or.at/programmes/a2/
28
Nuclear Units Under Construction Worldwide
29
Status of Worlds Nuclear Future Generation
Facilities
  • About 35 power reactors are currently being
    constructed in 11 countries notably China (11),
    India (6), S. Korea (5) and Russia (6).
  • IAEA anticipates at least 70 new plants in the
    next 15 years, putting 470 to 750 GWe in place in
    2030.
  • OECD estimates range up to 680 GWe in 2030 based
    on specific plans and actions in a number of
    countries. The fastest growth is in Asia.
  • This would give nuclear power a 17 share in
    electricity production in 2020.
  • In the 1980s, 218 power reactors started up, an
    average of one every 17 days. With China and
    India getting up to speed with nuclear energy and
    a world energy demand double the 1980 level in
    2015, a realistic estimate of what is possible
    might be the equivalent of one 1000 MWe unit
    worldwide every 5 days.

http//www.world-nuclear.org/info/inf17.html
30
IV. Potential role for expanded use of nuclear
power in Minnesotas electricity future
  • Minnesotas electric fuel generation is changing.
  • Expected growth cannot be addressed with the
    Minnesota aging coal plant fleet.
  • Renewables and energy efficiency will not address
    our baseload energy needs.
  • Energy planning for 2025 and beyond must start
    now.
  • Nuclear power is part of energy mix.
  • Contribution of nuclear power will remain
    constant with renewal of the three current units
    until operating expires in 2034.
  • Coal power electric generation is the largest
    portion of Minnesotas energy mix. The age of
    Minnesotas coal plan must be acknowledged.
  • The Non-carbon and low-carbon energy mix options
    can be identified.

31
Minnesota Current Electric Fuel Mix
(source EIA)
32
Minnesotas Coal Plant Additions
source REIS Data Base
33
Coal Plant Fleet Vintage Comparison
source REIS Data Base
34
With Coal Plant Fleet Aging,what are the
Non-carbon options?
  • Non-carbon emitting resources are necessary to
    achieve reductions in CO2 emissions.
  • Sources of Non-carbon or low carbon emitting
    resources include
  • Hydro
  • Renewables
  • Natural Gas
  • Coal and IGCC(with sequestration) and
  • Nuclear.

35
The Current Energy PictureThe Limitation of
Non-Carbon Options
  • Hydro limited build options
  • Renewables geographic limitations, limited
    potential, intermittent, non-baseload generation
  • Natural Gas limited resource, needed for other
    uses
  • Coal and IGCC with sequestration not commercial
    demonstrated
  • Nuclear cost, safety, waste disposal

36
Nuclear Power Generation is an Option
  • Nuclear Power generation is currently used.
  • 439 operating reactors worldwide providing 16
    percent of electricity
  • 104 operating reactors in US providing 20 percent
    of electricity
  • 3 operating reactors (at 2 facilities) in
    Minnesota providing 16 percent of electricity
  • Reliable operation baseload, dispatchable
  • Existing plants have low production costs
  • Available fuel supply from diverse resources
  • Older plants being re-licensed and new plants are
    planned.
  • New Plants have advance safety designs.

37
Nuclear Power Production Issues
  • Safety
  • Improving Safety (reduction in average number of
    accidents)
  • Improving Safety (reduction in number of
    significant events ).
  • Cost/Time
  • New Plant Construction Costs from recent
    regulator filings
  • Comparative Costs for Alternative New Electric
    Generation
  • Construction Time lines
  • Waste disposal
  • On-site storage for waste from current and new
    plants.
  • Permanent national geologic repository is
    necessary.

38
U.S. Nuclear Industrial Safety Accident
RateOne-Year Industry Values
ISAR Number of accidents resulting in lost
work, restricted work, or fatalities per 200,000
worker hours. Source World Association of
Nuclear Operators Updated 4/08
39
Comparative Safety Record(2004 Lost-time
Accident rate per 200,000 hours)
40
Significant Events at U.S. Nuclear Plants
Annual Industry Average, Fiscal Year 1988-2006
Significant Events are those events that the NRC
staff identifies for the Performance Indicator
Program as meeting one or more of the following
criteria A Yellow or Red Reactor Oversight
Process (ROP) finding or performance indicator
An event with a Conditional Core Damage
Probability (CCDP) or increase in core damage
probability (?CDP) of 1x10-5 or higher An
Abnormal Occurrence as defined by Management
Directive 8.1, Abnormal Occurrence Reporting
Procedure An event rated two or higher on the
International Nuclear Event Scale
Source NRC Information Digest, 1988 is the
earliest year data is available. Updated 11/07
41
New Nuclear Power Plant Costs

See Paper titled The Cost of New Generating
Capacity in Perspective at http//www.nei.org/res
ourcesandstats/nuclear_statistics/costs
42
New Nuclear Power Life-Cycle Costs Comparison
See Paper titled The Cost of New Generating
Capacity in Perspective at http//www.nei.org/res
ourcesandstats/nuclear_statistics/costs
43
Power Plant Costs Comparison

http//www.eia.doe.gov/oiaf/aeo/assumption/pdf/ele
ctricity.pdf
44
New Nuclear Construction Timelines
http//www.nei.org/resourcesandstats/documentlibra
ry/newplants/factsheet/key_steps_in_building_a_new
_reactor
45
Nuclear Power Production Waste Disposal
  • U.S. nuclear energy industry in 50 years of
    operation has produced approximately 60,000
    metric of used nuclear fuel produced.
  • Used fuel is a solid material that is stored at
    nuclear power plant sites, either in enclosed,
    steel-lined concrete pools filled with water, or
    in steel or reinforced concrete containers with
    steel inner canisters.
  • Research is ongoing to develop advanced
    technologies to recycle used nuclear fuel to
    reduce the amount of radioactive byproducts in
    the material, while recovering valuable energy.
  • Under any used fuel management scenario, disposal
    of radioactive byproducts in a permanent geologic
    repository is necessary.

46
On-Site Used Nuclear Fuel Amounts
Source ACI Nuclear Energy Solutions and
Department of Energy
47
European Nuclear Waste Amounts(in tons of
heavy metal)
Data source (OECD, 2007), (IAEA, 2003b), (NEA,
2007)
http//themes.eea.europa.eu/Sectors_and_activities
/energy/indicators/EN132C2008.11/Fig1/view
48
Nuclear Waste Disposal Status and Trends(not
an exhaustive listing)

http//www.world-nuclear.org/info/inf04.html
49
V. Designs of New Nuclear Power Reactors
http//www.gen-4.org/Technology/evolution.htm
50
Todays Nuclear Plant Design (LWRs)
  • Name Vendor Type Size(MWe)
  • ABWR a, b, c(1997), d GE/Hitachi, or
  • Advanced Boiling Water Reactor
    Toshiba BWR 300
  • AP1000 b, c(2006), d, e
  • Advanced Pressurized (Water Reactor)
    Westinghouse PWR 1150
  • ESBWR c(2009), d, e
  • Economic Simplified Boiling Water
    Reactor GE/Hitachi BWR 1400
  • EPR b, c(2010), d
  • Evolutionary Pressurized (Water)
    Reactor Areva PWR 1600
  • APWR b, c(2010), d
  • (US-)Advanced Pressurized Water
    Reactor Mitsubishi PWR 1700
  • a Plants in operation worldwide
  • b Plants under construction worldwide
  • c Design certification by NRC (year certified or
    expected)
  • d Plant named in a license application in the US
  • e Passively safe design

51
ABWR The U.S. Advanced Boiling Water
Reactor
  • Uses a single-cycle, forced circulation design
    with a rated power of 1,300 megawatts electric
    (MWe).
  • The design incorporates features of the BWR
    designs in Europe, Japan, and the United States,
    and uses improved electronics, computer, turbine,
    and fuel technology.
  • Improvements include the use of internal
    recirculation pumps, control rod drives that can
    be controlled by a screw mechanism rather than a
    step process, microprocessor-based digital
    control and logic systems, and digital safety
    systems.
  • The design also includes safety enhancements such
    as protection against overpressurizing the
    containment, passive core debris flooding
    capability, an independent water makeup system,
    three emergency diesels, and a combustion turbine
    as an alternate power source.

http//www.nrc.gov/reading-rm/doc-collections/fact
-sheets/new-nuc-plant-des-bg.html
52
AP1000 The Advanced Passive 1000
  • A larger version of the previously approved AP600
    design.
  • This 1,100 MWe advanced pressurized water reactor
    incorporates passive safety systems and
    simplified system designs.
  • It is similar to the AP600 design but uses a
    longer reactor vessel to accommodate longer fuel,
    and also includes larger steam generators and a
    larger pressurizer.

http//www.nrc.gov/reading-rm/doc-collections/fact
-sheets/new-nuc-plant-des-bg.html
53
ESBWR The Economic and Simplified Boiling
Water Reactor
  • A 1,500 MWe, natural circulation boiling water
    reactor that incorporates passive safety
    features.
  • This design is based on its predecessor, the 670
    MWe Simplified BWR (SBWR) and also utilizes
    features of the certified ABWR.
  • The ESBWR enhances natural circulation by using a
    taller vessel, a shorter core, and by reducing
    the flow restrictions.
  • The design utilizes an isolation condenser system
    for high-pressure water level control and decay
    heat removal during isolated conditions.
  • After the automatic depressurization system
    operates, a gravity-driven cooling system
    provides low-pressure water level control.
  • Containment cooling is provided by a passive
    system.

http//www.nrc.gov/reading-rm/doc-collections/fact
-sheets/new-nuc-plant-des-bg.html
54
EPR The Evolutionary Power Reactor
  • 1,600 MWe pressurized water reactor of
    evolutionary design.
  • Design features include four 100 capacity
    trains of engineered safety features, a
    double-walled containment, and a core catcher
    for containment and cooling of core materials for
    severe accidents resulting in reactor vessel
    failure.
  • The design does not rely on passive safety
    features.
  • The first EPR is under construction at the
    Olkiluoto site in Finland, with another planned
    for the Flammanville site in France.

http//www.nrc.gov/reading-rm/doc-collections/fact
-sheets/new-nuc-plant-des-bg.html
55
APWR Advanced Pressurized Water Reactor
  • An evolutionary 1,700 MWe pressurized water
    reactor currently being licensed and built in
    Japan.
  • The design includes high-performance steam
    generators, a neutron reflector around the core
    to increase fuel economy, redundant core cooling
    systems and refueling water storage inside the
    containment building, and fully digital
    instrumentation and control systems.

http//www.nrc.gov/reading-rm/doc-collections/fact
-sheets/new-nuc-plant-des-bg.html
56
Pebble Bed Modular Reactor (PBMR) in
Pre-Application Review
  • Differences between PBMR and current US
    light-water reactors
  • Fuel design - Tennis ball-sized pebbles of
    ceramic graphite, impregnated with thousands of
    tiny, coated particles of low-enriched uranium,
    fuel the PBMR.
  • Cooling mechanism - a PBMR site would not require
    large water supplies, because it uses helium (not
    water) to cool the reactor.
  • Electricity output/Plant Size - The main PBMR
    building of an eight module (1320MWe) plant fit
    into two soccer fields (113m x 103m), allowing
    for a phase-in of new units as electricity demand
    grows.
  • Construction process - The PBMR concept consists
    of pre-fabricated modules assembled at the plant
    site in just two years.
  • Waste Management - Safe storage is ensured since
    the encapsulating graphic spheres provide
    corrosion protection and prevents environmental
    contamination by the release of fission products.
    products isolated from one another.
  • Safety Features - The PBMR technology has a
    simple basis which requires no human
    intervention.
  • A modular high-temperature gas reactor that uses
    helium as its coolant.
  • PBMR design consists of eight reactor modules,
    165 MWe per module, with capacity to store 10
    years of spent fuel in the plant).
  • The PBMR core is based on German high-temperature
    gas-cooled reactor technology and uses spherical
    graphite elements containing ceramic-coated fuel
    particles.


The fuel consists of low-enriched uranium
particles, measuring about 0.5 mm in diameter,
contained in four coated layers of protective
graphite sphere.
Fun figures - One pebble contains 9g of Uranium,
with an enrichment level of 9.6, burnt to 92
000MWdays/ton of heavy metal 71.5GJ. Converted
into electricity it is about 8MWh per pebble.
The converted electrical energy in one pebble is
(8MWh) Enough to power 132 500 light bulbs
(60W) for 1 hour or Enough to power one 60W light
bulb for 30 years, 3 months, burning 12
hours/day.
http//www.nrc.gov/reading-rm/doc-collections/fact
-sheets/new-nuc-plant-des-bg.html
57
VI. Regulatory Activity in Other States
  • States that prohibition on construction of new
    nuclear power plants
  • -Minnesota
  • States that require waste disposal by federal
    government
  • -California - Kentucky -Connecticut -
    Illinois
  • States that require waste disposal is operational
    and is accepting waste products
  • -Maine -Oregon -West Virginia
  • -Massachusetts -Wisconsin
  • States that require that costs of any nuclear
    proposal be economically feasible or advantages
    to ratepayers
  • -Wisconsin - West Virginia

58
VI. Regulatory Activityin Other States
(continued)
  • States that require legislative ratification to
    license a nuclear power plant
  • -California -Illinois -Rhode Island -Vermont
  • States with specific cost provisions regarding
    financing of nuclear power plants
  • -New York -Kansas -Rhode Island -Connecticut
  • States that require voter ratification
  • -Maine - Oregon
  • -Montana - Massachusetts
  • States that are re-visiting nuclear legislation
  • -Minnesota -Wisconsin -Kentucky

59
VII. Electricity Production Subsidies
http//www.eia.doe.gov/oiaf/servicerpt/subsidy2/pd
f/chap5.pdf
60
Summary Observations
  • New nuclear plants will likely begin construction
    in a few years, in the Southeast US and around
    the world. If the first wave is successful
    (cost schedule), the potential is there for
    development in other states.
  • Acceptance in Minnesota depends on addressing
    nuclear power production limitation of cost,
    safety, waste disposal.
  • If prohibition is lifted and nuclear power is an
    option, construction continues to depend on the
    relative cost of nuclear power and how it fits
    into Minnesotas and the regions energy plans.
  • Nuclear is and can continue to be a critical part
    of our nations energy mix with safe, reliable
    and low cost energy.
Write a Comment
User Comments (0)
About PowerShow.com
