Title: Unit 3: Thermochemistry


1
Unit 3 Thermochemistry
  • Chemistry 3202

2
Unit Outline
  • Temperature and Kinetic Energy
  • Heat/Enthalpy Calculation
  • Temperature changes (q mc?T)
  • Phase changes (q n?H)
  • Heating and Cooling Curves
  • Calorimetry (q C?T above formulas)

3
Unit Outline
  • Chemical Reactions
  • PE Diagrams
  • Thermochemical Equations
  • Hesss Law
  • Bond Energy
  • STSE What Fuels You?

4
Temperature and Kinetic Energy
  • Thermochemistry is the study of energy changes
    in chemical and physical changes
  • eg. dissolving a solid
  • burning
  • phase changes

5
  • Temperature - a measure of the average kinetic
    energy of particles in a substance
  • - a change in temperature means particles are
    moving at different speeds
  • - measured in either Celsius degrees or degrees
    Kelvin
  • Kelvin Celsius 273.15

6
p. 628
7
(No Transcript)
8
Kinetic Energy
9
  • The Celsius scale is based on the freezing and
    boiling point of water
  • The Kelvin scale is based on absolute zero -
    the temperature at which particles in a substance
    have zero kinetic energy.

10
Heat/Enthalpy Calculations
  • system - the part of the universe being studied
    and observed
  • surroundings - everything else in the universe
  • open system - a system that can exchange matter
    and energy with the surroundings
  • eg. an open beaker of water
  • a candle burning
  • closed system - allows energy transfer but is
    closed to the flow of matter.

11
  • isolated system a system completely closed to
    the flow of matter and energy
  • heat - refers to the transfer of kinetic energy
    from a system of higher temperature to a system
    of lower temperature.
  • - the symbol for heat is q
  • WorkSheet Thermochemistry 1

12
Part A Thought Lab (p. 631)
13
Part B Thought Lab
14
Heat/Enthalpy Calculations
  • specific heat capacity - the amount of energy ,
    in Joules (J), needed to change the temperature
    of one gram (g) of a substance by one degree
    Celsius (C).
  • The symbol for specific heat capacity is a
    lowercase c

15
  • A substance with a large value of c can absorb or
    release more energy than a substance with a small
    value of c.
  • ie. For two substances, the substance with the
    larger c will undergo a smaller temperature
    change with the same amount of heat applied

16
FORMULA
  • q heat (J)
  • m mass (g)
  • c specific heat capacity
  • ?T temperature change
  • T2 T1
  • Tf Ti
  • q mc?T

17
  • eg. How much heat is needed to raise the
    temperature of 500.0 g of water from 20.0 C to
    45.0 C?
  • Solve q m c ?T
  • for c, m, ?T, T2 T1
  • p. 634 s 1 4
  • p. 636 s 5 8
  • WorkSheet Thermochemistry 2

18
  • heat capacity - the quantity of energy , in
    Joules (J), needed to change the temperature of a
    substance by one degree Celsius (C)
  • The symbol for heat capacity is uppercase C
  • The unit is J/ C or kJ/ C

19
FORMULA
  • C heat capacity
  • c specific heat capacity
  • m mass
  • ?T T2 T1
  • C mc
  • q C ?T

Your Turn p.637 s 11-14 WorkSheet
Thermochemistry 3
20
Enthalpy Changes
  • The difference between the potential energy of
    the reactants and the products during a physical
    or chemical change is the Enthalpy change or ?H.
  • AKA Heat of Reaction

21
  • Endothermic Reaction

PE
Reaction Progress
22
  • Endothermic Reaction

PE
Enthalpy
?H
Reaction Progress
23
Enthalpy
?H is
Endothermic
24
Enthalpy
Exothermic
25
Enthalpy Changes in Reactions
  • All chemical reactions require bond breaking in
    reactants followed by bond making to form
    products
  • Bond breaking requires energy (endothermic) while
    bond formation releases energy (exothermic)

see p. 639
26
(No Transcript)
27
Enthalpy Changes in Reactions
  • endothermic reaction - the energy required to
    break bonds is greater than the energy released
    when bonds form.
  • exothermic reaction - the energy required to
    break bonds is less than the energy released when
    bonds form.

28
Enthalpy Changes in Reactions
  • ?H can represent the enthalpy change for a
    number of processes
  • Chemical reactions
  • ?Hrxn enthalpy of reaction
  • ?Hcomb enthalpy of combustion
  • (see p. 643)

29
  • Formation of compounds from elements
  • ?Hof standard enthalpy of formation
  • The standard molar enthalpy of formation is the
    energy released or absorbed when one mole of a
    compound is formed directly from the elements in
    their standard states.
  • ( see p. 642)

30
  • Phase Changes (p.647)
  • ?Hvap enthalpy of vaporization
  • ?Hfus enthalpy of melting
  • ?Hcond enthalpy of condensation
  • ?Hfre enthalpy of freezing
  • Solution Formation
  • ?Hsoln enthalpy of solution

31
  • There are three ways to represent any enthalpy
    change
  • 1. thermochemical equation - the energy term
    written into the equation.
  • 2. enthalpy term is written as a separate
    expression beside the equation.
  • 3. enthalpy diagram.

32
  • eg. the formation of water from the elements
    produces 285.8 kJ of energy.
  • 1. H2(g) ½ O2(g) ? H2O(l) 285.8 kJ
  • 2. H2(g) ½ O2(g) ? H2O(l) ?Hf -285.8
    kJ/mol

thermochemical equation
33
enthalpy diagram
  • 3.

Enthalpy (H)
examples pp. 641-643 questions p. 643 s 15-18
WorkSheet Thermochemistry 4
34
Calculating Enthalpy Changes
  • FORMULA
  • q n?H
  • q heat (kJ)
  • n of moles
  • ?H molar enthalpy
  • (kJ/mol)

35
  • eg. How much heat is released when 50.0 g of
    CH4 forms from C and H ?
  • p. 642

q n?H (3.115 mol)(-74.6 kJ/mol)
-232 kJ
36
(No Transcript)
37
  • eg. How much heat is released when 50.00 g of
    CH4 undergoes complete combustion?

q n?H (3.115 mol)(-965.1 kJ/mol)
-3006 kJ
38
(No Transcript)
39
  • eg. How much energy is needed to change 20.0 g
    of H2O(l) at 100 C to steam at 100 C ?
  • Mwater 18.02 g/mol ?Hvap 40.7 kJ/mol

q n?H (1.110 mol)(40.7 kJ/mol)
45.2 kJ
40
?Hfre and ?Hcond have the opposite sign of the
above values.
41
  • eg. The molar enthalpy of solution for ammonium
    nitrate is 25.7 kJ/mol. How much energy is
    absorbed when 40.0 g of ammonium nitrate
    dissolves?

q n?H (0.4996 mol)(25.7 kJ/mol)
12.8 kJ
42
  • What mass of ethane, C2H6, must be burned to
    produce 405 kJ of heat?
  • ?H -1250.9 kJ
  • q - 405 kJ

q n?H
n 0.3238 mol m n x M (0.3238
mol)(30.08 g/mol) 9.74 g
43
  • Complete p. 645 s 19 23
  • pp. 648 649 s 24 29
  • 19. (a) -8.468 kJ (b) -7.165 kJ
  • 20. -1.37 x103 kJ
  • 21. (a) -2.896 x 103 kJ
  • 21. (b) -6.81 x104 kJ
  • 21. (c) -1.186 x 106 kJ
  • 22. -0.230 kJ
  • 23. 3.14 x103 g

44
  • 24. 2.74 kJ
  • 25.(a) 33.4 kJ (b) 33.4 kJ
  • 26.(a) absorbed (b) 0.096 kJ
  • 27.(a) NaCl(s) 3.9 kJ/mol ? NaCl(aq)
  • (b) 1.69 kJ
  • (c) cool heat absorbed from water
  • 28. 819.2 g
  • 29. 3.10 x 104 kJ

45
  • p. 638 4 8
  • pp. 649, 650 s 3 8
  • p. 657, 658 s 9 - 18

WorkSheet Thermochemistry 5
46
Heating and Cooling Curves
  • Demo Cooling of p-dichlorobenzene

47
Cooling curve for p-dichlorobenzene
80
Temp. (C )
liquid
50
freezing
solid
20
Time
48
Heating curve for p-dichlorobenzene
80
Temp. (C )
50
20
Time
49
  • What did we learn from this demo??
  • During a phase change temperature remains
    constant and PE changes
  • Changes in temperature during heating or cooling
    means the KE of particles is changing

50
p. 651
51
p. 652
52
p. 656
53
Heating Curve for H20(s) to H2O(g)
  • A 40.0 g sample of ice at -40 C is heated until
    it changes to steam and is heated to 140 C.
  • Sketch the heating curve for this change.
  • Calculate the total energy required for this
    transition.

54
q mc?T
140
100
q n?H
Temp. (C )
q mc?T
q n?H
0
q mc?T
-40
Time
55
  • Data
  • cice 2.01 J/g.C
  • cwater 4.184 J/g.C
  • csteam 2.01 J/g.C
  • ?Hfus 6.02 kJ/mol
  • ?Hvap 40.7 kJ/mol

56
  • warming ice
  • q mc?T
  • (40.0)(2.01)(0 - -40)
  • 3216 J
  • warming water
  • q mc?T
  • (40.0)(4.184)(100 0)
  • 16736 J
  • warming steam
  • q mc?T
  • (40.0)(2.01)(140 -100)
  • 3216 J

57
n 40.0 g 18.02
g/mol 2.22 mol
moles of water
  • melting ice
  • q n?H
  • (2.22 mol)(6.02 kJ/mol)
  • 13.364 kJ
  • boiling water
  • q n?H
  • (2.22 mol)(40.7 kJ/mol)
  • 90.354 kJ

58
Total Energy
  • 90.354 kJ
  • 13.364 kJ
  • 3216 J
  • 3216 J
  • 16736 J
  • 127 kJ

59
Practice
  • p. 655 s 30 34
  • pp. 656 s 1 - 9
  • p. 657 s 2, 9
  • p. 658 s 10, 16 20

WorkSheet Thermochemistry 6
  • 30.(b) 3.73 x103 kJ
  • 31.(b) 279 kJ
  • 32.(b) -1.84 x10-3 kJ
  • 33.(b) -19.7 kJ -48.77 kJ
  • 34. -606 kJ

60
Law of Conservation of Energy (p. 627)
  • The total energy of the universe is constant
  • ?Euniverse 0
  • Universe system surroundings
  • ?Euniverse ?Esystem ?Esurroundings
  • ?Euniverse ?Esystem ?Esurroundings 0
  • OR ?Esystem -?Esurroundings
  • OR qsystem -qsurroundings

First Law of Thermodynamics
61
Calorimetry (p. 661)
  • calorimetry - the measurement of heat changes
    during chemical or physical processes
  • calorimeter - a device used to measure changes
    in energy
  • 2 types of calorimeters
  • 1. constant pressure or simple calorimeter
    (coffee-cup calorimeter)
  • 2. constant volume or bomb calorimeter.

62
SimpleCalorimeter
p.661
63
  • a simple calorimeter consists of an insulated
    container, a thermometer, and a known amount of
    water
  • simple calorimeters are used to measure heat
    changes associated with heating, cooling, phase
    changes, solution formation, and chemical
    reactions that occur in aqueous solution

64
  • to calculate heat lost or gained by a chemical or
    physical change we apply the first law of
    thermodynamics
  • qsystem -qcalorimeter
  • Assumptions
  • the system is isolated
  • c (specific heat capacity) for water is not
    affected by solutes
  • heat exchange with calorimeter can be ignored

65
  • eg.
  • A simple calorimeter contains 150.0 g of water.
    A 5.20 g piece of aluminum alloy at 525 C is
    dropped into the calorimeter causing the
    temperature of the calorimeter water to increase
    from 19.30C to 22.68C.
  • Calculate the specific heat capacity of the
    alloy.

66
  • eg.
  • The temperature in a simple calorimeter with a
    heat capacity of 1.05 kJ/C changes from 25.0 C
    to 23.94 C when a very cold 12.8 g piece of
    copper was added to it.
  • Calculate the initial temperature of the
    copper. (c for Cu 0.385 J/g.C)

67
Homework
  • p. 664, 665 s 1b), 2b), 3 4
  • p. 667, s 5 - 7

68
  • (60.4)(0.444)(T2 98.0) -(125.2)(4.184)(T2
    22.3)
  • 26.818(T2 98.0) -523.84(T2 22.3)
  • 26.818T2 - 2628.2 -523.84T2 11681
  • 550.66T2 14309.2
  • T2 26.0 C

69
  • 6. System (Mg)
  • m 0.50 g or 0.02057 mol
  • Find ?H
  • Calorimeter
  • 100 ml or m 100 g
  • c 4.184
  • T2 40.7
  • T1 20.4

70
  • 7. System
  • ?H -53.4 kJ/mol
  • n CV (0.0550L)(1.30 mol/L) 0.0715 mol
  • Calorimeter
  • 110 ml or m 110 g
  • c 4.184
  • T1 21.4
  • Find T2

71
  • 6.
  • qMg -qcal
  • n?H -mc?T

72
  • Bomb Calorimeter

73
Bomb Calorimeter
  • used to accurately measure enthalpy changes in
    combustion reactions
  • the inner metal chamber or bomb contains the
    sample and pure oxygen
  • an electric coil ignites the sample
  • temperature changes in the water surrounding the
    inner bomb are used to calculate ?H

74
  • to accurately measure ?H you need to know the
    heat capacity (kJ/C) of the calorimeter.
  • must account for all parts of the calorimeter
    that absorb heat
  • Ctotal Cwater Cthermom. Cstirrer
    Ccontainer
  • NOTE C is provided for all bomb
  • calorimetry calculations

75
  • eg. A technician burned 11.0 g of octane in a
    steel bomb calorimeter. The heat capacity of the
    calorimeter was calibrated at 28.0 kJ/C. During
    the experiment, the temperature of the
    calorimeter rose from 20.0 C to 39.6 C.
  • What is the enthalpy of combustion for octane?

76
  • Eg.
  • 1.26 g of benzoic acid, C6H5COOH(s) (?Hcomb
    -3225 kJ/mol), is burned in a bomb calorimeter.
    The temperature of the calorimeter and its
    contents increases from 23.62 C to 27.14 C.
    Calculate the heat capacity of the calorimeter.

77
Homework
  • p. 675 s 8 10

WorkSheet Thermochemistry 6
78
Hesss Law of Heat Summation
  • the enthalpy change (?H) of a physical or
    chemical process depends only on the beginning
    conditions (reactants) and the end conditions
    (products)
  • ?H is independent of the pathway and/or the
    number of steps in the process
  • ?H is the sum of the enthalpy changes of all the
    steps in the process

79
eg. production of carbon dioxide
  • Pathway 1 2-step mechanism
  • C(s) ½ O2(g) ? CO(g) ?H -110.5 kJ
  • CO(g) ½ O2(g) ? CO2(g) ?H -283.0 kJ
  • C(s) O2(g) ? CO2(g) ?H -393.5 kJ

80
eg. production of carbon dioxide
  • Pathway 2 formation from the elements
  • C(s) O2(g) ? CO2(g) ?H -393.5 kJ

81
Using Hesss Law
  • We can manipulate equations with known ?H to
    determine the enthalpy change for other
    reactions.
  • NOTE
  • Reversing an equation changes the sign of ?H.
  • If we multiply the coefficients we must also
    multiply the ?H value.

82
  • eg.
  • Determine the ?H value for
  • H2O(g) C(s) ? CO(g) H2(g)
  • using the equations below.
  • C(s) ½ O2(g) ? CO(g) ?H -110.5 kJ
  • H2(g) ½ O2(g) ? H2O(g) ?H -241.8 kJ

83
  • eg.
  • Determine the ?H value for
  • 4 C(s) 5 H2(g) ? C4H10(g)
  • using the equations below.
  • ?H (kJ)
  • C4H10(g) 6½ O2(g) ? 4 CO2(g) 5 H2O(g)
    -110.5
  • H2(g) ½ O2(g) ? H2O(g) -241.8
  • C(s) O2(g) ? CO2(g) -393.5

Switch
Multiply by 5
Multiply by 4
84
  • 4 CO2(g) 5 H2O(g) ? C4H10(g) 6½ O2(g)
    110.5
  • 5(H2(g) ½ O2(g) ? H2O(g) -241.8)
  • 4(C(s) O2(g) ? CO2(g) -393.5)

4 CO2(g) 5 H2O(g) ? C4H10(g) 6½ O2(g)
110.5 5 H2(g) 2½ O2(g) ? 5
H2O(g) -1209.0 4C(s) 4 O2(g) ? 4
CO2(g) -1574.0
Ans -2672.5 kJ
85
Practice
  • pg. 681 s 11-14

WorkSheet Thermochemistry 7
86
Review
  • ?Hof (p. 642, 684, 848)
  • The standard molar enthalpy of formation is the
    energy released or absorbed when one mole of a
    substance is formed directly from the elements in
    their standard states.
  • ?Hof 0 kJ/mol
  • for elements in the standard state
  • The more negative the ?Hof, the more stable the
    compound

87
Using Hesss Law and ?Hf
  • Determine the ?H value for
  • C4H10(g) 6½ O2(g) ? 4 CO2(g) 5 H2O(g)
  • using the formation equations below.
  • ?Hf (kJ/mol)
  • 4 C(s) 5 H2(g) ? C4H10(g) -2672.5
  • H2(g) ½ O2(g) ? H2O(g) -241.8
  • C(s) O2(g) ? CO2(g) -393.5

88
Using Hesss Law and ?Hf
  • ?Hrxn ??Hf (products) - ??Hf (reactants)
  • eg. Calculate the enthalpy of reaction for the
    complete combustion of glucose.
  • C6H12O6(s) 6 O2(g) ? 6 CO2(g) 6 H2O(g)

89
  • Use the molar enthalpys of formation to
    calculate ?H for the reaction below
  • Fe2O3(s) 3 CO(g) ? 3 CO2(g) 2 Fe(s)
  • p. 688 s 21 22

90
  • Eg.
  • The combustion of phenol is represented by the
    equation below
  • C6H5OH(s) 7 O2(g) ? 6 CO2(g) 3 H2O(g)
  • If ?Hcomb -3059 kJ/mol, calculate the heat of
    formation for phenol.

91
Bond Energy Calculations (p. 688)
  • The energy required to break a bond is known as
    the bond energy.
  • Each type of bond has a specific bond energy
    (BE).
  • (table p. 847)
  • Bond Energies may be used to estimate the
    enthalpy of a reaction.

92
Bond Energy Calculations (p. 688)
  • ?Hrxn ?BE(reactants) - ?BE (products)
  • eg. Estimate the enthalpy of reaction for the
    combustion of ethane using BE.
  • 2 C2H6(g) 7 O2(g) ? 4 CO2(g) 6 H2O(g)
  • Hint Drawing the structural formulas for all
    reactants and products will be useful here.

93
? 4 OCO 6 H-O-H
7 O O
2
2(347) 2(6)(338) 7(498)
- 4(2)(745) 6(2)(460)
8236 - 11480
-3244 kJ
p. 690 s 23,24, 26 p. 691 s 3, 4, 5, 7
94
Energy Comparisons
  • Phase changes involve the least amount of energy
    with vaporization usually requiring more energy
    than melting.
  • Chemical changes involve more energy than phase
    changes but much less than nuclear changes.
  • Nuclear reactions produce the largest ?H
  • eg. nuclear power, reactions in the sun

95
STSE
  • What fuels you? (Handout)
  • s 1 4, 7, 9, 10, 13, 14, 16
  • (List only TWO advantages for 2)

96
  • aluminum alloy water
  • m 5.20 g m 150.0 g
  • T1 525 ºC T1 19.30 ºC
  • T2 ºC T2 22.68 ºC
  • FIND c for Al c 4.184 J/g.ºC
  • qsys - qcal
  • mc?T - mc ?T
  • (5.20)(c)(22.68 - 525 ) -(150.0)(4.184)(22.68
    19.30)
  • -2612 c -2121
  • c 0.812 J/g.C

97
  • copper
  • m 12.8 g
  • T2 ºC
  • c 0.385 J/g.C
  • FIND T1 for Cu
  • qsys - qcal
  • mc?T - C?T
  • (12.8)(0.385)(23.94 T1) -(1050)(23.94
    25.0)
  • 4.928 (23.94 T1) 1113
  • 23.94 T1 1113/4.928
  • 23.94 T1 225.9
  • T1 -202 ºC

calorimeter C 1.05 kJ/C T1 25.00 ºC T2
23.94 ºC
98
(No Transcript)
99
  • Group 2 Total Mass 2.05 g
  • Group 5 Total Mass 1.86 g
Write a Comment
User Comments (0)
About PowerShow.com
