Unit 8 Chapter 16 Thermochemistry

1
Unit 8- Chapter 16Thermochemistry
Thermodynamics

• One of Mrs. Dorrs faaaaaaavorite topics!!!

2
The first law of thermodynamics

• Recall the law of conservation of energy- energy
  can be neither created or destroyed.
• The 1st Law of Thermodynamics is simply a
  restatement- The energy of the universe is
  constant.
• We are going to look at the energy involved in
  chemical reactions and prove not only the 1st law
  of thermodynamics, but the 2nd as well

3
Systems

• System ? surroundings open system
• matter
• System ? surroundings closed system
• (matter is trapped but it can
  exchange energy)
• matter
• System ? surroundings Isolated system
• energy (neither the matter or
  energy from the system can be
  exchanged)

4
Boundaries of Systems

• Diathermic (closed system) boundary that permits
  heat transfer
• Adibatic (isolated system) prevents heat or
  matter transfer

5
Work

• Work is defined as force acting over a distance
• W F d it is measured in Joules
  (J)
• note 1 Latm
  101.32 J
• Consider a frictionless piston system with a
  constant Pexternal see side board
• Total work
• W -?Pext dV ? -Pext?dV
• W -Pext (Vf Vi)
• Therefore W -Pext ?V

6

• Example 1 Consider an ideal gas in a piston
  chamber expanding against constant Pext and at
  constant temperature. The gas has an initial
  volume of 2.0L, a final volume of 5.50L, an
  initial pressure equal to 8.00atm and an external
  pressure of 1.75atm. Determine a). the
  work and b). the final pressure.

7

• Work
• Expansion ? W -Pext ?V
• Compression ? W Pext ?V
• If Pext 0 what happens to work?
• There is NO WORK under the condition of free
  expansion (Pext 0)
• The only other time there is NO WORK is when ?V
  0

8
Example

• Consider a can of spray paint
• A. Can of spray discharged (can system)
• B. Can of spray discharged (spray system)
• A. no work being done b/c no ?
• B. work done on atmosphere/surroundings by the
  system/spray
• W -Pext ?V

9
System Processes

• Irreversible ? No Equilibrium
• Reversible ? continuous Equilibrium state with
  the surroundings (small incremental changes)
• For Reversible Changes Pext Pint
• Wrev -?Pint dV
• So we can say Wrev -? nRT/V dV
• Then see side board for full derivation

10
Heat- Its getting hot in here

• Heat, q if heat is flowing in/ gaining heat
• - if heat is flowing out/ losing heat
• Heat is the measure of thermal energy transfer
  that can be determined in the temperature change
  of the object (its a way to follow the energy
  change of a system)

11
Equations with Heat

• 1. q m c ?T ?intensive property
• m is mass, c is specific heat of substance
• 2. q C ?T ?extensive property
• C is the heat capacity of substance
• 3. q IVt ?intensive property
• I is current, V is voltage, t is time

12
Internal Energy The 1st Law of Thermodynamics

• Internal energy, E total energy of system
• Recall adiabatic isolated system no heat or
  matter transfer!
• Recall the 1st Law- For an isolated system, the
  total energy of a system remains constant,
  therefore ?E 0
• ?E q W (general)
• ?E W (adiabatic)

13
Example

• A gas sample changes in volume from 2.0L to 4.0L
  against an external pressure of 1.50 atm, while
  absorbing 1,000J of heat, what is ?E of the
  system?

14
State Functions

• State function- path independent
• Ex- P, V, T, ?E, ?H
• NOT State functions- q and W
• In-exact differentials ?dW W
• ?dq q
• Exact differentials ?dE ?E

15
Enthalpy

• At constant pressure, the change in enthalpy ?H
  of the system is equal to the energy flow as heat
• H E PintV
• ?H ?E ?(PV)
• ?H ?E ?ngRT
• If no gases are involved, or if ?n 0, then ?E
  ?H
• See side of board for chain rule derivation

16
Example

• A piston filled with 0.0400mol of an ideal gas
  expands reversibly from 50.00mL to 375.0mL _at_
  constant temperature of 37?C. As it does so, it
  absorbs 208J of heat. Calculate q, W, ?U, and
  ?H for this process.

17
?H

• ?H ?Hproducts ?Hreactants
• If ?H is positive the reaction is endothermic
• If ?H is negative the reaction is exothermic

18
Enthalpy Calorimetry

• Recall a calorimeter is used to experimentally
  determine the heat associated with a chemical
  reaction
• Calorimetry is the science of measuring heat
• Heat capacity C heat absorbed
• ______________________
• inc. in
  temperature
• Heat capacity can be given per gram specific
  heat capacity c ? J/?Cg or J/Kg
• Or it can be given per mole molar heat capacity
  C ?J/?Cmol or J/Kmol

19
Constant Pressure Calorimetry

• Constant pressure!
• For these reactions ?H qp
• So we can use qp mc?T or qp C?T

20
Example of Constant Pressure Calorimetry

• When 1.00L of 1.00M Ba(NO3)2 solution at 25.0?C
  is mixed with 1.00L of 1.00M Na2SO4 solution at
  the same temperature in a calorimeter, the white
  solid BaSO4 forms and the temperature of the
  mixture increases to 28.1?C. Assuming that the
  calorimeter absorbs only a negligible quantity of
  heat, that the specific heat capacity of the
  solution is 4.18J/?Cg, and that the density of
  the final solution formed is 1.0g/mL, calculate
  the enthalpy change per mole of BaSO4 formed.

21
Constant Volume Calorimetry

• Calorimetry experiments can also be done at
  constant volume
• For a constant volume procses, the ?V 0, so
  work, w 0 also
• ?E q W q qv

22
Constant Volume Example

• Consider the combustion of octane, C8H18. A
  0.5269g sample of octane is placed in a bomb
  calorimeter known to have a heat capacity of
  11.3kJ/?C. The octane is ignited in the presence
  of excess oxygen, and the temperature increase of
  the calorimeter is 2.25?C. Determine the amount
  of energy released per mole of octane.

23
Heat of Reactions

• Standard states ?H?
• For a Compound-
• The standard state of a gaseous substance is a
  pressure of exactly 1 atm
• For a liquid or solid the standard state is the
  pure liquid or solid
• For a substance present in solution, the standard
  state is a concentration of exactly 1M
• For an Element-
• The standard state of an element is the form in
  which the element exists under conditions of 1atm
  and 25?C. (ex- O2(g), Na(s), and Hg(l)

24

• Standard enthalpy of formation, ?Hf? the change
  in enthalpy that accompanies the formation of one
  mole of a compound from its elements with all
  substances in their standard states
• The degree symbol ? indicates standard conditions
• ?H?rxn ??H?products - ??H?reactants
• DO NOT put pure elements in this eqn. ex-O2
• When a rxn is reversed, change the sign on ?H
• When the balanced eqn. is multiplied by an
  integer, the value of ?H must be multiplied by
  the same integer
• Use this equation for heat of fusion, heat of
  formation, heat of vaporization, heat of
  combustion, heat of synthesis ? any enthalpy
  change!

25
Read Chapter 6, section 5 6, pages 267-281 by
Friday.
26
Example

• Determine the standard enthalpy change for the
  combustion of methane.

27
Hesss Law

• Recall enthalpy, ?H is independent of pathway (a
  state function)
• Hesss Law states in going from a particular set
  of reactants to a particular set of products, the
  change in enthalpy is the same whether the
  reaction takes place in one step or in a series
  of steps
• So ?H? ?npH?products - ?nr ?H?reactants

28
Hesss Law Example

• Diborane (B2H6) is a highly reactive boron
  hydride, which was once considered as a possible
  rocket fuel for the U.S. space program.
  Calculate the ?H for the synthesis of diborane
  from its elements according to the equation
• 2B(s) 3H3(g)
• Using the following data
• 2B(s) 3/2O2(g) ? B2O3(s) ?H -1273 kJ
• B2H6(g) 3O2(g) ? B2O3(s) 3H2O(g) ?H -2035 kJ
• H2(g) ½ O2(g) ? H2O(l) ?H -286 kJ
• H2O(l) ? H2O(g) ?H 44 kJ

29
The 2nd Law of Thermodynamics

• Recall that the 1st Law of Thermodynamics deals
  with energy change
• The 2nd Law of Thermodynamics states that in any
  spontaneous process there is always an increase
  in the entropy of the universe
• To reword the entropy of the universe is
  increasing
• Energy is conserved in the universe, but entropy
  is not

30
Entropy

• Spontaneous process is one that occurs without
  outside intervention
• Note a spontaneous process irreversible
  process
• If it is a reversible process ?S 0
• Thermodynamics tells us only about the direction,
  not the speed.
• Entropy, S the thermodynamic function that
  measures randomness or disorder

31
Entropy

• ?Suniv ?Ssys ?Ssurr
• If ?Suniv is , it is spontaneous in the
  direction written
• If ?Suniv is -, it is spontaneous in the opposite
  direction
• If ?Suniv 0, the process has no tendency to
  occur the system is _at_ equilibrium

32
The Effect of Temperature on Spontaneity

• For Reversible Irreversible processes
• ?Ssurr qsurr / Tsurr
• Since _at_ constant P q ?H we can say
• ?Ssurr - ?H / T
• This means that if the rxn is exothermic, ?H -,
  but since heat flows into the surroundings,
  ?Ssurroundings is positive

33
?Ssurr Example

• Antimony, the pure metal is recovered via
  different reactions, depending on the composition
  of the ore.
• Iron is used to reduce antimony in sulfide ores
• Sb2S3(s) 3Fe(s) ? 2Sb(s) 3FeS(s) ?H -125kJ
• Carbon is used as the reducing agent for oxide
  ores
• Sb4O6(s) 6C(s) ? 4Sb(s) 6CO(g) ?H 778kJ
• Calculate ?Ssurr for each of these reactions at
  25?C and 1atm.

34
Summary of Entropy

• Recall ?Suniv ?Ssurr ?Ssys
• _______________________________________
• ?Ssys ?Ssurr ?Suniv Spontaneous?
• Yes
• - - - No
• - ? Yes, if ?Ssys is larger
  than ?Ssurr
• - ? Yes, if ?Ssurr is larger than
  ?Ssys

35
Free Energy

• Free energy, G is defined by the following
  relationship ?GRxn ??Gproducts -
  ??Greactants
• And G H - TS
• For a process that occurs _at_ constant T, the
  change in free energy ?G is
• ?G? ?H? - T?S? This is called the
  Gibbs-Helmholtz Eqn.
• To relate it to spontaneity
• ?Suniv - ?G / T _at_ constant T P
• This means _at_ constant T P a process is
  spontaneous only if ?G is NEGATIVE.

36

• We can re-phrase this to say a process (_at_
  constant T P) is spontaneous in the direction
  in which the free energy decreases (-?G means
  ?Suniv).
• We now have two variables that determine
  spontaneity (?G), ?S ?H
• Case Result
• ?S , ?H - Spontaneous _at_ all temps.
• ?S , ?H Spontaneous _at_ high temps.
• ?S -, ?H - Spontaneous _at_ low temps.
• ?S , ?H NOT Spontaneous _at_ ANY Temperature

37
Example

• At what temperatures is the following process
  spontaneous _at_ 1atm?
• Br2(l) ? Br2(g)
• ?H? 31.0kJ/mol ?S? 93.0J/Kmol
• What is the normal boiling point of liquid Br2?

38
Entropy the States of Matter

• Solids have low entropy, liquids have higher
  entropy, solutions have higher entropy, gases
  have the highest entropy
• If the of gaseous molecules in the products is
  greater than the of gaseous molecules in the
  reactants, the forward rxn favors entropy, its
• The reverse rxn is favored if the opposite is
  true
• Ex Predict the sign of ?S? for each rxn
• CaCO3(s) ? CaO(s) CO2(g)
• 2SO2(g) O2(g) ? 2SO3(g)

39
Free Energy Chemical Reactions

• Standard free energy change, ?G?, the change in
  free energy that will occur if the reactants in
  their standard states are converted to the
  products in their standard states
• Note you can use Hesss Law with ?G?!
• ?G? ?npG?products - ?nr ?G?reactants
• ?G? 0 for the formation of an element in its
  standard state

40
Pressure Free Energy

• Free energy is affected by Pressure
• G G? RTln(P)
• G is the free energy of the gas _at_ pressure P, G?
  is the free energy of the gas _at_ 1atm, and R is
  the universal gas constant, use 3.14 J/molK
• Also, ?G nRTln(Pf/Pi)
• ?G ?G? RTlnQ ? Q is the rxn quotient
• For 2A 3B ? 4C Q C4/ A2B3

41
Pressure Example

• Calculate ?G at 25?C for this rxn where carbon
  monoxide gas at 5.0 atm and hydrogen gas at
  3.0atm are converted to liquid methanol
• CO(g) 2H2(g) ? CH3OH(l)

42
Free Energy Equilibrium

• Equilibrium represents the lowest free energy
  value available
• _at_ equilibrium ?G 0 and Q K
• So, ?G 0 ?G ? RTln(K) or ?G ? -RTln(K)
• K is the equilibrium constant where
  eA fB ? gC hD
• Cg Dh
• K ------------
• Ae Bf

43
?G ? and K yes, memorize these!!!

• ?G ? K
• --------------------------------------------------
  -------
• ?G ?0 K 1
• ?G ? lt 0 K gt 1
• ?G ? gt 0 K lt 1

44

• Also, when ?G 0, then then ?H T?S or T ?H
  / ?S

45
Equilibrium Example

• The overall reaction for the corrosion (rusting)
  of iron by oxygen is
• 4Fe(s) 3O2(g) ? 2Fe2O3(s)
• Using the following data, calculate the
  equilibrium constant for this reaction at 25?C.
• Substance ?H?f (kJ/mol) S? (J/Kmol)
• Fe2O3(s) -826 90
• Fe(s) 0 27
• O2(g) 0 205

46
(No Transcript)
