Electronic Structure of Atoms

1
Electronic Structure of Atoms
2
Electronic Structure

• Our goal
• Understand why some substances behave as they do.
• For example Why are K and Na reactive metals?
  Why do H and Cl combine to make HCl? Why are
  some compounds molecular rather than ionic?
• Atom interact through their outer parts, their
  electrons.
• The arrangement of electrons in atoms are
  referred to as their electronic structure.
• Electron structure relates to
• Number of electrons an atom possess.
• Where they are located.
• What energies they possess.

3
The Wave Nature of Light

• Study of light emitted or absorbed by substances
  has lead to the understanding of the electronic
  structure of atoms.
• Characteristics of light
• All waves have a characteristic wavelength, l,
  and amplitude, A.
• The frequency, n, of a wave is the number of
  cycles which pass a point in one second.
• The speed of a wave, v, is given by its frequency
  multiplied by its wavelength
• For light, speed c.

4
Identifying ? and ?
5
Electromagnetic Radiation

• Modern atomic theory arose out of studies of the
  interaction of radiation with matter.
• Electromagnetic radiation moves through a vacuum
  with a speed of 2.99792458 ? 108 m/s.
• Electromagnetic waves have characteristic
  wavelengths and frequencies.
• Example visible radiation has wavelengths
  between 400 nm (violet) and 750 nm (red).

6
The Electromagnetic Spectrum
7
Class Guided Practice Problem

• The yellow light given off by a sodium vapor lamp
  used for public lighting has a wavelength of 589
  nm. What is the frequency of this radiation?

Class Practice Problem

• A laser used to weld detached retinas produces
  radiation with a frequency of 4.69 x 1014 s-1.
  What is the wavelength of this radiation?

8
Quantized Energy and Photons

• Planck energy can only be absorbed or released
  from atoms in certain amounts chunks called
  quanta.
• The relationship between energy and frequency is
• where h is Plancks constant (6.626 ? 10-34 J.s).
• To understand quantization consider walking up a
  ramp versus walking up stairs
• For the ramp, there is a continuous change in
  height whereas up stairs there is a quantized
  change in height.

9
The Photoelectric Effect

• Plancks theory revolutionized experimental
  observations.
• Einstein
• Used plancks theory to explain the photoelectric
  effect.
• Assumed that light traveled in energy packets
  called photons.
• The energy of one photon

10
Class Guided Practice Problem

• Calculate the energy of a photon of yellow light
  whose wavelength is 589 nm.

Class Practice Problem

• (a)Calculate the smallest increment of energy (a
  quantum) that can be emitted or absorbed at a
  wavelength of 803 nm. (b) Calculate the energy
  of a photon of frequency 7.9 x 1014 s-1. (c) What
  frequency of radiation has photons of energy 1.88
  x 10-18 J? Now calculate the wavelength.

11
Line Spectra and the Bohr Model

• Line Spectra
• Radiation composed of only one wavelength is
  called monochromatic.
• Most common radiation sources that produce
  radiation containing many different wavelengths
  components, a spectrum.
• This rainbow of colors, containing light of all
  wavelengths, is called a continuous spectrum.
• Note that there are no dark spots on the
  continuous spectrum that would correspond to
  different lines.

12
(No Transcript)
13
Specific Wavelength Line Spectra
When gases are placed under reduced pressure in a
tube and a high voltage is applied, radiation at
different wavelengths (colors) will be emitted.
14
Line Spectra

• Balmer discovered that the lines in the visible
  line spectrum of hydrogen fit a simple equation.
• Later Rydberg generalized Balmers equation to
• where RH is the Rydberg constant (1.096776 ? 107
  m-1), h is Plancks constant (6.626 ? 10-34 Js),
  n1 and n2 are integers (n2 gt n1).

15
Bohr Model

• Rutherford assumed the electrons orbited the
  nucleus analogous to planets around the sun.
• However, a charged particle moving in a circular
  path should lose energy.
• This means that the atom should be unstable
  according to Rutherfords theory.
• Bohr noted the line spectra of certain elements
  and assumed the electrons were confined to
  specific energy states. These were called orbits.

16
Line Spectra (Colors)

• Colors from excited gases arise because electrons
  move between energy states in the atom.

17
Line Spectra (Energy)

• Since the energy states are quantized, the light
  emitted from excited atoms must be quantized and
  appear as line spectra.
• After lots of math, Bohr showed that
• where n is the principal quantum number (i.e., n
  1, 2, 3, and nothing else).

18
Limitations of the Bohr Model

• Can only explain the line spectrum of hydrogen
  adequately.
• Electrons are not completely described as small
  particles.

19
The Wave Behavior of Matter

• Knowing that light has a particle nature, it
  seems reasonable to ask if matter has a wave
  nature.
• Using Einsteins and Plancks equations, de
  Broglie showed
• The momentum, mv, is a particle property, whereas
  ? is a wave property.
• de Broglie summarized the concepts of waves and
  particles, with noticeable effects if the objects
  are small.

20
The Wave Behavior of Matter

• The Uncertainty Principle
• Heisenbergs Uncertainty Principle on the mass
  scale of atomic particles, we cannot determine
  exactly the position, direction of motion, and
  speed simultaneously.
• For electrons we cannot determine their momentum
  and position simultaneously.
• If Dx is the uncertainty in position and Dmv is
  the uncertainty in momentum, then

21
Quantum Mechanics and Atomic Orbitals

• Schrödinger proposed an equation that contains
  both wave and particle terms.
• Solving the equation leads to wave functions.
• The wave function gives the shape of the
  electronic orbital.
• The square of the wave function, gives the
  probability of finding the electron,
• that is, gives the electron density for the atom.

22
Electron Density Distribution
Probability of finding an electron in a hydrogen
atom in its ground state.
23
The Three Quantum Numbers

• Schrödingers equation requires 3 quantum
  numbers
• Principal Quantum Number, n. This is the same as
  Bohrs n. As n becomes larger, the atom becomes
  larger and the electron is further from the
  nucleus. (n 1, 2, 3)
• Azimuthal Quantum Number, l. This quantum number
  depends on the value of n. The values of l begin
  at 0 and increase to (n - 1). We usually use
  letters for l (s, p, d and f for l 0, 1, 2, and
  3). Usually we refer to the s, p, d and
  f-orbitals. (l 0, 1, 2n-1). Defines the shape
  of the orbitals.
• Magnetic Quantum Number, ml. This quantum number
  depends on l. The magnetic quantum number has
  integral values between -l and l. Magnetic
  quantum numbers give the 3D orientation of each
  orbital in space. (m -l01)

24
Orbitals and Quantum Numbers
25
Class Guided Practice Problem

• (a) For n 4, what are the possible values of l?
  (b) For l 2. What are the possible values of
  ml? What are the representative orbital for the
  value of l in (a)?

Class Practice Problem

• (c) How many possible values for l and ml are
  there when (d) n 3 (b) n 5?

26
Representations of Orbitals The s-Orbitals

• All s-orbitals are spherical.
• As n increases, the s-orbitals get larger.
• As n increases, the number of nodes increase.
• A node is a region in space where the probability
  of finding an electron is zero.
• At a node, ?2 0
• For an s-orbital, the number of nodes is (n - 1).

27
The s-Orbitals
28
The p-Orbitals

• There are three p-orbitals px, py, and pz.
• The three p-orbitals lie along the x-, y- and z-
  axes of a Cartesian system.
• The letters correspond to allowed values of ml of
  -1, 0, and 1.
• The orbitals are dumbbell shaped.
• As n increases, the p-orbitals get larger.
• All p-orbitals have a node at the nucleus.

29
The p-Orbitals
Electron-distribution of a 2p orbital.
30
The d and f-Orbitals

• There are five d and seven f-orbitals.
• Three of the d-orbitals lie in a plane bisecting
  the x-, y- and z-axes.
• Two of the d-orbitals lie in a plane aligned
  along the x-, y- and z-axes.
• Four of the d-orbitals have four lobes each.
• One d-orbital has two lobes and a collar.

31
(No Transcript)
32
Orbitals and Quantum Numbers

• Orbitals can be ranked in terms of energy to
  yield an Aufbau diagram.
• As n increases, note that the spacing between
  energy levels becomes smaller.
• Orbitals of the same energy are said to be
  degenerate.

33
Orbitals and Their Energies
34
Electron Spin and the Pauli Exclusion Principle

• Line spectra of many electron atoms show each
  line as a closely spaced pair of lines.
• Stern and Gerlach designed an experiment to
  determine why.
• A beam of atoms was passed through a slit and
  into a magnetic field and the atoms were then
  detected.
• Two spots were found one with the electrons
  spinning in one direction and one with the
  electrons spinning in the opposite direction.

35
Electron Spin and the Pauli Exclusion Principle
36
Electron Spin and the Pauli Exclusion Principle

• Since electron spin is quantized, we define ms
  spin quantum number ? ½.
• Paulis Exclusions Principle no two electrons
  can have the same set of 4 quantum numbers.
• Therefore, two electrons in the same orbital must
  have opposite spins.

37
Electron Configurations Hunds Rule

• Electron configurations tells us in which
  orbitals the electrons for an element are
  located.
• Three rules
• electrons fill orbitals starting with lowest n
  and moving upwards
• no two electrons can fill one orbital with the
  same spin (Pauli)
• for degenerate orbitals, electrons fill each
  orbital singly before any orbital gets a second
  electron (Hunds rule).

38
(No Transcript)
39
(No Transcript)
40
Electron Configurations and the Periodic Table

• The periodic table can be used as a guide for
  electron configurations.
• The period number is the value of n.
• Groups 1A and 2A (1 2) have the s-orbital
  filled.
• Groups 3A - 8A (13 - 18) have the p-orbital
  filled.
• Groups 3B - 2B (3 - 12) have the d-orbital
  filled.
• The lanthanides and actinides have the f-orbital
  filled.

41
Class Guided Practice Problem

• Write the electron configurations for the
  following atoms (a) Cs and (b) Ni

Class Practice Problem

• Write the electron configurations for the
  following atoms (a) Se and (b) Pb

42
Condensed Electron Configurations

• Neon completes the 2p subshell.
• Sodium marks the beginning of a new row.
• So, we write the condensed electron configuration
  for sodium as
• Na Ne 3s1
• Ne represents the electron configuration of
  neon.
• Core electrons electrons in Noble Gas.
• Valence electrons electrons outside of Noble
  Gas.

43
Transition Metals

• After Ar the d orbitals begin to fill.
• After the 3d orbitals are full, the 4p orbitals
  begins to fill.
• Transition metals elements in which the d
  electrons are the valence electrons.

44
Lanthanides and Actinides

• From Cs onwards the 4f orbitals begin to fill.
• Note La Xe6s25d14f0
• Elements Ce - Lu have the 4f orbitals filled and
  are called lanthanides or rare earth elements.
• Elements Th - Lr have the 5f orbitals filled and
  are called actinides.
• Most actinides are not found in nature.
