Planet Scale Software Updates

1
Planet Scale Software Updates

• Christos Gkantsidis
• Thomas Karagiannis
• Pablo Rodriguez
• Milan Vojnovic

SIGCOMM 2006
2
Patches

• Patches (program snippets) upgrade existing
  software with the intention to
• Fix security vulnerabilities
• Update drivers
• Distribute new virus definitions
• Release new functionality
• Patches are crucial to maintain high level of
  protection, since they offer updated service and
  applications
• _

3
Problems with Dissemination of software updates

• Large scale and fast dissemination of software
  updates to millions of Internet users
• During certain period of times, patch
  distribution can account for a large fraction of
  the traffic on servers and across Internet
• Growing popularity of software update requires us
  to know more about
• Process of creating and
• releasing pathes
• Traffic characteristics of
• patch distribution
• Potential of alternative
• distribution strategies
• _

4
Motivation and Contribution

• Goal Find general principles and properties that
  can be used as guidelines to design better
  architect fast and cost effective planet scale
  patch dissemination
• Contributions
• Clustering patches into groups improves
  effectiveness of system
• Approximately 80 of IPs appear during the first
  day of a patch release
• Percentage of machines that are always online is
  approximately 20
• Computers using update service seem to be highly
  updated
• Using an existing cache decreases workload on
  servers by 25 to 35, while full cache by ISP
  would result in almost 70
• P2P can considerably reduce the load on the
  server and P2P locality can reduce inter-ISP
  traffic while disseminating patches

5
Outline

• Introduction
• System and Data Description
• Characteristics of Patches
• User Characterization
• Patch Dissemination Strategies
• Conclusion

6
Windows Update System

• System Description
• Update servers Query for new updates
• Distribution servers Download updates
• _

7
Traffic on Update and Distribution servers
Number of update queries and corresponding
downloads over three days
8
Dataset Characteristics

• Some definitions
• Knowledge Base Set of patches to fix a
  vulnerability
• Service packs large collection of knowledge
  bases
• Datasets
• _

9
Characteristics of Patches

• Two ways to update a file
• Replacing actual file
• Download and install the files that are
• required to be updated
• Using a Patch file
• Patch file(delta) decribes difference between the
  existing version in the user computer and the
  newest version
• More efficient to send patches instead of file
  itself
• XP SP2 Mean File size73.2 KB, while Mean Patch
  Size32.9 KB

10
Characteristics of Patches

• Designing efficient mechanisms requires
• Number and size of files affected
• Frequency of update release
• Relation between the individual patches
• Problem
• User machine can have a large set of
  configuration states due to patching at different
  times
• Solution
• Examine relationships between updates for
  individual files and cluster the ones which are
  updated together

11
Clustering of Files

• Used traces of requests for Windows XP SP2
  distribution and full history of updates in XP
  source tree (Data Set-II and Set-IV)
• To quantify set of files that are clustered
  together, compute cosine correlation between any
  pair of files i and j using
• Assumed that files are correlated if
  gt0.9
• _

12
Clustering of Files

• Dataset has requests for 2029 files
• 26 non-overlapping groups identified for 2003
  files
• The 5 largest groups account for 1877 files and
  responsible for 95 of the requests
• _

Number of requests satisfied by publishing an
increasing number of groups for File Clustering
Group size distribution for File Clustering
13
Clustering of patches

• Repeated same analysis with patch dataset
• For 3379 patches, identified 125 groups for 3188
  patches
• Analysis indicates that
• Decreasing clustering efficiency
• Increasing complexity of system
• _

Group size distribution for Patch Clustering
Number of requests satisfied by publishing an
increasing number of groups for File Clustering
14
User Characterization

• Traffic Properties
• Extract arrival patterns of update queries
• Queries arrive from two types of machines
• Always online machines(AOM) Have an automatic
  update service that periodically queries for
  updates
• Non-AOM Go ON and OFF and stay offline for a
  period greater than pre-specified query interval

15
Distinct IPs over time

• Examined aggregate volume of user queries with
  respect to distinct IPs using Set-I
• Approximately 80 of observed IPs appear within
  the first day
• Number of fresh IPs within a day decreases
  abruptly with number of days since initial
  observation day
• _

Rate of distinct IPs observed over three
days (Peaks are due to the local time differences)
16
Time-of-day effects

• Europe exhibits the largest query arrival rates
  at the beginning and at the end of the day, due
  to inititial observation time
• Peak of North America is within interval 1300 to
  1600 hours
•
  _

Fraction of distinct IPs per continent observed
within the first day versus time
17
Uniformity and burstiness of queries

• For 50 of the ASes that account for more than
  90 of distinct IP population, uniformity of
  query arrival is not obtained
• Burstiness is in many cases larger if the
  AS-aggregate query rates are uniform in time
• _

Number of queries for two European ISPs in the
same country over time. Two geographically
collocated ISPs results in dissimilar query
arrival pattern within the day because of
different profiles of subscribers.
(Residential?ISP1 vs. Corporate?ISP2)
18
Estimated Always on-line Machines

• Important since they can be instantaneously
  patched using an ideal push patching system
• Approximately 20 of the population is always
  online thus could be patched immediately.
• _

Estimated percentage of distinct IPs classified
as AOM per country versus the total number of
distinct IPs per country
19
Frequency of computer updates

• How up-to-date computers are kept around the
  world
• US and Japan users(90) keep their machines
  highly updated
• Percentage in China or France is 50-70
• _

Distribution of the number of requests for
different delta sizes across different countries
20
Frequency of computer updates

• 90 of the population is highly updated.
• Importance of automatic patching schemes
• During SP2 distribution, the number of users that
  were updated with most recent updates is less
  than 5, with 22 of users updating from SP1
  versions and 60 from XP RTM versions
• _

Requests per delta included in SP2
21
Patch Dissemination Strategies

• Alternative update delivery strategies
• Caching
• Peer-to-Peer
• Peer-to-Peer with locality
• To evaluate the alternative strategies,
• assumed that hosts are partioned into
• groups called subnets
• Effects of alternative policies in reducing
• Server load
• Inter-subnet traffic
• _

22
Caching-Web Caching

• Currently deployed web caches are used for update
  dissemination
• Load reduction at the server(a)
• Experimental results
• _

Fraction of updates needed in subnets covered
by caches
Mean number of updates per subnet over subnets
that deploy caches
23
Caching-Full Deployment

• GoalAn ideal caching deployment (µ1)
• If every subnet has a cache, the server needs to
  serve at most as many copies of an update as the
  number of subnets
• Using the dataset Set-II (manual downloads),
• For file distribution
• S4.18 ? a 76
• For delta distribution
• S3.01 ? a 67
• _

24
Peer-to-Peer

• P2P is attactive to disseminate update
• Advantages
• Self scalable
• Capacity increases with number of users
• Copes well with flash-crowds
• Challenges
• Average patch size is small
• Potentially large set of patches
• Multiple versions per patch
• Secure and Timely patch delivery
• Protecting user privacy
• Only if a large number of peers target the same
  version of the same patch at the same time, then
  significant savings for content provider and
  end-users

25
Peer-to-Peer with Locality

• Augment peer matching algorithm to give
  preference to local connections
• Experiments
• Estimate amount of data downloaded from remote
  subnets and amount of data uploaded to other
  subnets
• performed trace-driven simulations to estimate
  the workload reduction
• Findings
• Locality decreases the amount of data uploaded
  per subnet by a factor that decreases
  exponentially with the mean number of active
  users per subnet
• With locality, the ratio of uploads to downloads
  per subnet increases as a function of the size of
  the subnet

26
Comparison of Strategies

• Aggregate server load for the distribution of one
  patch with (i) client-server (ii) caching (iii)
  p2p with upload time equal to download time (iv)
  p2p with upload time twice as download time and
  (v) p2p with uploaded data as much as
  downloaded(full).

27
Conclusion

• Characterized a large commercial update
  service(WU)
• Patch distribution systems
• Use a near-push functionality
• Have distinct traffic patterns
• Require minimun delivery time
• Automatic software updating is one of the
  prominent architectures
• To reduce complexity, patches can be clustered
  into groups
• Evaluated applicability of caching and P2P to
  disseminate patches
• P2P have great potential for fast and effective
  patch delivery

28
Comments

• Pros
• Includes a good motivation, experiments,
  practical usage for companies, theory and math
• Emphasizing how important having a good dataset
  is
• Well organized
• The ideas are summarized before getting deeper
  into the details
• Figures explain most of the written stuff
• Cons
• Some of the formulas given were too abstract
• Too many references to technical report
• Except appendix, no difference between paper and
  technical report

29
Happy End! Thank you for your patience!
