Andy Aiken aaikenaqua'org

1
Use of Foam Fractionation for Improving Water
Quality in Marine Aquaria
2
Topics to Cover

• Dissolved Organic Matter (DOM)
• Source
• Characteristics
• Effects of on WQ
• Foam Fractionation
• Removal of DOM
• Disinfection
• Particulate removal
• Ozones role in FF
• Placement of FF within the LSS

3
Dissolved Organic Matter (DOM)
In the water column, excess food and animal
wastes degrade into particulate, semi-solid and
dissolved organic matter. Much of the
semi-solid and DOM disintegrates, forming
long-chain organic molecules that cannot be
mechanically filtered.
4
Natural Processing of DOM

• In natural waters, particulate and DOM become
• part of nutrient cycles
• Food source for phytoplankton
• Geologic and atmospheric element cycles
• Broken down by bacteria and other organisms.

5
Accumulation of DOM in Aquarium LSS

• In a closed or semi-closed aquarium LSS, the
  major
• microbial processing of DOM is bacterial,
  primarily
• in sand filters and biofilters
• Assimilation of DOM into biofilms is slow
  (typically
• does not keep pace with loading).
• Assimilation of DOM into biofilms also produces
• deleterious effects of bacterial respiration
• Consumes Dissolved Oxygen (D.O.)
• Releases CO2 into the water column
• (produces carbonic acid, lowers pH)

6
Net Effect of DOM Accumulation

• ? D.O.
• ? pH
• O.R.P.

? Oxidant Demand ? NH3, NO2, NO3 ? Need for Buffer
7
DOM
Many long-chain organic molecules have a polar
(hydrophilic) head and one or more non-polar
(hydrophobic) tails
Polar head () and (-) charge
Non-polar tails
8
Surfactants
Because of their polar / non-polar structure,
such molecules will associate with a phase
interface such as the air-water interface of an
air bubble, these are called surfactants.
air bubble surface
non-polar tail
air water
polar head () and (-) charge
9
Adsorption Microflocculation
When surfactants in water come in contact with
the surface with an air bubble, they orient
themselves along the bubble surface. When
enough bubbles carrying enough surfactants collect
, they begin to condense into foam
10
Foam Formation
11
Foam Fractionation or Protein Skimming
LSS components that favors the natural processes
of adsorption and accumulation of DOM
which otherwise cannot be mechanically filtered.
FF come in a variety of designs to collect
and condense DOM, and remove them from the water
column.
12
Disinfection By Means of Removal

• During the collection and condensing of DOM,
  other
• small particulates will get caught up in the
  formation of
• sticky foam and will be carried out of the water
  column
• This process includes capturing of coliform
  bacteria or
• any other microorganism that is small enough for
  capture
• Thus, disinfection is achieved via removal rather
  than
• the actual destruction or disruption of the
  organism

13
Disinfection Via Removal
Graph showing decreased oxidant demand in an
outdoor Seal Pool after retrofit of FF outfitted
with flocculation dose ozone injection (December
- May, 1994 and 1995, NAIB) Source McCracken,
RAW, 1995 Albuquerque NM
14
Ozones Role in FF





-


-


-


-

-





-



-

• Small organic and inorganic particles of like
  electrostatic charge will repel each other and
  thus be held in suspension in the water column,
  creating a haze and adding to DOM.
• By applying a VERY SMALL dose of ozone, the
  charge of SOME of the particles can be changed,
  bringing about their destabilization.

15
Disinfection Ozone Dose in FF

• When a higher (disinfection) dose of ozone is
  used in a Foam Fractionator
• The charges of all suspended particles are
  altered and the benefit of microflocculation is
  lost
• Ozone begins to break apart the carbon bonds of
  the long-chain molecules that are adhering to
  bubble surfaces, pieces go back into solution
• Ozone gas is likely to leak into the pump room
• For these reasons, it is very important to dose
  ozone
• very lightly in FF 0.01 - 0.03 mg O3/L

16
Disinfection Via Removal
Coliform counts in a Manatee exhibit (June 99
through June 2000, Columbus Zoo) no ozone contact
chamber, only disinfection unit is foam
fractionator. Source Aiken, IAC, Monaco, 2000
17
Ozones Role in FF
Using ozone as a flocculant is best achieved
using an ORP controller designed for Foam
Fractionation
18
Placement within LSS

• FF works best with independent feed and return
  lines,
• manifolding will cause hydraulic effect between
  fracs
• Fracs should not be set up to run off existing
  pressure of
• other components whose pressure may vary (sand
  filter)
• FF works best with dirty water - placing it first
  in the
• LSS sequence is most effective
• Placing FF first also reduces the workload of
  other
• components which can then be reduced in size or
  number

19
Reduced Need for Other Components Can Make Space
for FF
20
1. Cut a Big Old Hole in the Wall
21
2. Out With the Old
22
3. Make Room for the New
23
4. Retrofit With Foam Fractionators
24
Retrofit With Foam Fractionators
25
5. Add De-Aerating Biofilter
26
Summary Effects Benefits of FF

• FF removes DOM that cannot be mechanically
  filtered
• FF also disinfects by removing infectious
  contaminants
• Suspended particles can also be flocculated and
  removed
• w/ small doses of ozone

? Oxidant Demand ? Nitrogen species ?
Requirement for Buffer ? Size / Number of other
components
? pH ? O.R.P. ? Dissolved Oxygen ? Water Clarity
