1Advanced Input and Output
Lecture 9
2Objectives
- How cout and cin possess the same traits as other
C objects - How to use istream member functions, particularly
get(), ignore(), and getline() - How to use ostream member functions, particularly
setf(), unsetf(), width(), and precision() - How to create your own manipulator functions
3Objectives
- How to use built-in manipulators
- How to create a manipulator that takes an
argument - About computer files and the data hierarchy
- How to perform file output
- How to read a file from within a program
- How to write class objects to files
- How to read a data file into class objects
4Understanding CIN and COUT as Class Objects
- You can think of cout and cin as real-world
objects - Like other C objects you have created, cout and
cin are members of a class - Their class is derived from another class (which
is derived from yet another class), so they use
inheritance - The cout and cin objects can take advantage of
overloaded operators such as ltlt and gtgt which are
used for shifting bits in other contexts
5Understanding CIN and COUT as Class Objects
- When you include iostream.h in a program, you are
including a file that contains the definition for
a derived class named iostream - In C, a stream is a sequence of characters used
to perform input and output operations - The name iostream is short for Input and Output
stream
6Using istream Member Functions
- In C, the easiest way to read in a character is
to use cin with the extraction operator, for
example, cingtgtsomeVariable - The extraction operator is actually an overloaded
function named operatorgtgt()
7Using the get() Function
- Another member function of the istream class is
get() - The get() function takes a character argument and
returns a reference to the object (the istream
class) that invoked the get() function - Therefore more than one get() function can be
included in a statement - Its prototype has the following form
- istream get(char c)
8Using the get() Function
- Most compilers overload get() so that, in
addition to taking a character reference as an
argument, it also can take no argument - The following version of the get() function
returns the character being read in as an integer - Its prototype is
- int get( )
- The third argument is the character that
terminates the entry, often called the delimiter
character - The default value to stop data entry, as you can
see from the prototype, is the Enter key, which
coded as \n
9Using the get() Function
- The second argument of the get() functionthe
number of characters to be storedis very
important - Without the second argument, a user could destroy
memory by entering a string of characters that
was longer than the area prepared to receive it - The output in Figure 10-3 and 10-4 illustrate one
benefit of using the get() function instead of
the extraction operator (gtgt) for keyboard data
entry
Ex9-1.cpp
10Using the get() Function
- One unfortunate side effect of the get() function
is that it leaves unused characters in the input
stream - A subsequent call to get() retrieves the next
(unused) character, whether or not that retrieval
was intended - As shown in Figure 10-6, the program doesnt stop
to obtain your grade, because the second call to
get() already has been satisfied with the newline
character
11The UserNameAndGrade Program
Ex9-2.cpp
12Using the get() Function
- The program output shown in Figure 10-6 includes
your first name and a newline (instead of a
grade) for the letter grade - To allow the user to enter a grade, you could add
a third cin.get() statement to the program, as
shown in Figure 10-7
13Using the get() Function
- Programmers say this call to the get() function
absorbs or consumes the extra character
14Using the get() Function
Ex9-2.cpp
- If you run the program in Figure 10-7 and enter a
name that is too long, the output looks like
Figure 10-9
15Using the ignore() Function
- It is impossible to guess how many cin.get()
statements are needed to consume all the
potential additional letters of a name if you use
the UserNameAndGrade2 programimagine the
challenge of a name such as Barbara Penelope - A superior alternative is to use the ignore()
function to ignore or skip any additional
characters left in the input stream - The prototype of the ignore() function is
- istream ignore(int length 1, char c \n)
16The UserNameAndGrade Program Using ignore()
Ex9-2.cpp
17Using the ignore() Function
18Using the getline() Function
- As an alternative to using an extra call to get()
to absorb the Enter key after character data
entry, or using the ignore() function to absorb
any number of characters, you can include another
istream member, getline() - Its prototype is
- istream getline(char str,int len, char c\n)
- The getline() function reads a line of text at
the address represented by str - It reads text until it reaches either the length
used as the second argument or the character used
as the third argument
19Using the getline() Function
- The program in Figure 10-13, and the output in
Figure 10-14, show how the getline() function
correctly accepts characters up to and including
the default newline delimiter
20Using the getline() Function
- When you use a delimiter other than \n with
getline(), the getline() consumes the delimiter
but leaves he subsequent Enter key in the input
stream, so you still must account for it - The program in Figure 10-15 and its output in
Figure 10-16 illustrate the use of get() to
consume the Enter key by getline()
21Using the getline() Function
Ex9-3.cpp
22Other istream Member Functions
- Most compilers support other istream member
functions with names such as eof(), bad(), and
good() - The istream class is not mysterious
- It is just a class, and cin is just an object
that already has been instantiated for you
23Using ostream Member Functions
- The concepts you have learned while studying the
cin object apply to the cout object as well - The ostream class supports member functions and
overloaded operators just like the istream class
or any other class, for that matter
24Using Format Flags with setf() and unsetf()
- Many of the states of the cout object are
contained in a single long integer field, in
which each bit represents some condition of the
object - The arguments that determine the state of the
cout object are called format flags or state
flags - All format flags begin with ios
- One member function of the ios class, the setf()
function, takes arguments that set the bits of
cout that is, the arguments turn the bits in the
flag on or off - Another member function, unsetf(), can be used to
deselect the bit cout.unsetf(iosshowpos) - Using the setf() function, you also can combine
format flags using the bitwise OR operator ()
25Using Format Flags with setf() and unsetf()
- Some commonly used format flags are
- iosleftleft-justifies output within the field
size, which may be set by the width() function
(described in a following section) - iosrightright-justifies output within the
field size - iosdecformats numbers in decimal (base 10)
- ioshexformats numbers in hexadecimal (base 16)
- iosoctformats numbers in octal (base 8)
- iosshowposinserts a before positive numbers
- iosshowpointdisplays the decimal point and six
decimal positions for all floating-point numbers
26Using the width() Function
- You can change the output field width with the
iostream member width() function - This function defines the size of the output
field in which the passed argument will be
displayed - The width() function applies only to the first
subsequent field to be output
27Using the width() Function
Ex9-4.cpp
28Using the precision() Function
- You can use the precision() function to control
the number of significant digits you see in the
output - If you want to control the number of positions
shown to the right of the decimal point (instead
of simply the number of significant positions
visible), you must combine cout.setf(iosfixed)
and cout.precision()
29Using the precision() Function
Ex9-5.cpp
- Declare an array of doubles, assign values with
different numbers of significant digits, and then
display all the values using the same precision
30Creating Manipulator Functions
- If you need to display a variable named
amountMoney in currency format with a dollar
sign, in base 10, in a field size of eight, you
might write the code shown in Figure 10-20 - When you create a manipulator function, the
desired results become much clearer - A manipulator function is used to manipulate, or
change, the state of the cout object
31Creating Manipulator Functions
Ex9-6.cpp
- You could write a manipulator to format output as
currency - The function contains statements that display the
dollar sign, set some ios flags, and set the
width - In the function shown in Figure 10-21, a
reference to ostream is passed into the function
as an argument
32Using Built-In Manipulators
- Some manipulators are so useful that they are
already coded and placed in libraries included
with your C compiler - You already have used the endl manipulator to
output a newline character and flush the output
stream
33Using the setprecision() Manipulator
- You use the setprecision() manipulator to specify
the number of decimals that will print - The setprecision() manipulator works like the
precision() functionit specifies the number of
significant digits to display - It is considered a manipulator instead of a
member function because you chain a call to
setprecision() along with other output and the
insertion operator, rather than using an object
and a dot operator, as you do with
cout.precision()
34The DemoPrecision2 Program
35Using the setprecision() Manipulator
Ex9-7.cpp
- Any C manipulator, such as setprecision(), that
takes an argument requires the inclusion of the
iomanip file in your program - The program in Figure 10-22 produces the output
in Figure 10-23
36Using the setw() Manipulator
- The setw() manipulator allows you to set the
width of a field for output - Use of the setw() manipulator requires inclusion
of the iomanip.h file, because setw() requires an
argument that represents the width of the output
field - The setw() manipulator works like the width()
member function you can use with the cout
objects the advantage of using setw() is its
chaining capability in a cout statement
37Using the setiosflags() and resetiosflags()
Manipulators
Ex9-8.cpp
- Two additional manipulators, setiosflags() and
resetiosflags(), each perform several
manipulations, depending on the flags (such as
iosdec or iosshowpoint) they receive as
arguments - The setiosflags() manipulator turns on bit codes
for the attributes named as arguments the
resetiosflags() manipulator turns off those bit
codes
38Understanding Computer Files
- When you store data items in a computer system,
you use a permanent storage device, such as a
disk or a reel of magnetic tape - The term permanent is used to contrast this type
of data storage with the temporary data storage
that exists in computer memory - Data items typically exist in memory for only a
short time - It is common practice to store data in a data
hierarchy, which represents the relationships
between the sizes of data units that business
professionals most often use
39The fstream Family Tree
40Using the getline() Function
- If a file contains data that ends with a newline
character, then its a bit awkward to have a
program that uses the get() function to read data
from a file because you must discard the newline
character - As an alternative, you can use the getline()
member function to read input data - The getline() function takes the form
fileObject.getline(destination, sizeLimit),
where destination is a declared character string,
and sizeLimit is the maximum number of characters
you want to store
41Using the getline() Function
Ex9-9.cpp
- Write a program that uses getline() to read the
name file created in the WriteNameToFile.cpp
program
42Using the getline() Function
Ex9-10.cpp
43Writing Objects to Files
- It is simple and intuitive to use the ofstream
classs overloaded operator to write characters
and strings to files - It makes sense, however, that in object-oriented
programs you should also be able to write objects
to disk files - The write() function allows you to do just that
the prototype is - ostream write(char c, int length)
- The write() function accepts two arguments a
pointer to a character and an integer
44The Customer Class
45Writing Customer Records to a File
Ex9-11.cpp
46Writing Objects to Files
- You can create an array of customer objects,
perform the data entry required for the
Customers, and write the output to a disk (see
the format on page 394 of the textbook) - The program in Figure 10-40 executes a for loop
numCusts times (five times), performing data
entry and writing to the file each time
47Writing an Array of Customer Records to a File
48Reading Objects from Files
Ex9-12.cpp
- It is more convenient to read a data file
directly into an array of class objects - You can accomplish this goal with the read()
function - The read() function prototype is quite similar to
the prototype for the write() function - The prototype for read() is
- istream read(char c, int length)
- The read() function requires a pointer to a
character, so you must perform a cast when you
read an object
49Reading Customer Records from a File
50Reading Objects from Files
- The read() function also requires the size of
the object being read - Instead of reading one record at a time into the
Customer array, you can perform one read for the
entire array
51Reading an Array of Records
52Summary
- The C objects cout and cin possess the same
traits as other C objectsthey are members of a
class, use inheritance, have access to overloaded
operators, and have all other object traits - To input data, you can use the extraction
operator (gtgt) after the cin object - To output data you can use the insertion operator
with the cout object - A manipulator function is used to manipulate, or
change, the state of the cout object
53More examples
- Ex9-13.cpp
- Ex9-14.cpp
- Ex9-15.cpp
54Summary
- Built-in manipulators include endl, newline,
setprecision(), setw(), setiosflags(), and
resetiosflags() - Creating a manipulator that takes an argument
involves writing two functions - The address of the stream and the argument itself
must be passed to the manipulator function - Usually, you store data on a disk (or other
permanent storage device) in a data hierarchy in
which fields are parts of data records that make
up data files
55Summary
- To perform file output, you must instantiate your
own member of the ofstream class - To read a file from within a program, you can
create an object that is an instantiation of the
ifstream class - The write() function allows you to write class
objects to files - The write() function accepts two arguments a
character pointer to the address of the argument
being written to the file, and the size of the
object being written - You can use the read() function to read a data
file into class objects
