Title: Advanced Input and Output


1
Advanced Input and Output
Lecture 9
  • COSC1567
  • C Programming

2
Objectives
  • How cout and cin possess the same traits as other
    C objects
  • How to use istream member functions, particularly
    get(), ignore(), and getline()
  • How to use ostream member functions, particularly
    setf(), unsetf(), width(), and precision()
  • How to create your own manipulator functions

3
Objectives
  • How to use built-in manipulators
  • How to create a manipulator that takes an
    argument
  • About computer files and the data hierarchy
  • How to perform file output
  • How to read a file from within a program
  • How to write class objects to files
  • How to read a data file into class objects

4
Understanding CIN and COUT as Class Objects
  • You can think of cout and cin as real-world
    objects
  • Like other C objects you have created, cout and
    cin are members of a class
  • Their class is derived from another class (which
    is derived from yet another class), so they use
    inheritance
  • The cout and cin objects can take advantage of
    overloaded operators such as ltlt and gtgt which are
    used for shifting bits in other contexts

5
Understanding CIN and COUT as Class Objects
  • When you include iostream.h in a program, you are
    including a file that contains the definition for
    a derived class named iostream
  • In C, a stream is a sequence of characters used
    to perform input and output operations
  • The name iostream is short for Input and Output
    stream

6
Using istream Member Functions
  • In C, the easiest way to read in a character is
    to use cin with the extraction operator, for
    example, cingtgtsomeVariable
  • The extraction operator is actually an overloaded
    function named operatorgtgt()

7
Using the get() Function
  • Another member function of the istream class is
    get()
  • The get() function takes a character argument and
    returns a reference to the object (the istream
    class) that invoked the get() function
  • Therefore more than one get() function can be
    included in a statement
  • Its prototype has the following form
  • istream get(char c)

8
Using the get() Function
  • Most compilers overload get() so that, in
    addition to taking a character reference as an
    argument, it also can take no argument
  • The following version of the get() function
    returns the character being read in as an integer
  • Its prototype is
  • int get( )
  • The third argument is the character that
    terminates the entry, often called the delimiter
    character
  • The default value to stop data entry, as you can
    see from the prototype, is the Enter key, which
    coded as \n

9
Using the get() Function
  • The second argument of the get() functionthe
    number of characters to be storedis very
    important
  • Without the second argument, a user could destroy
    memory by entering a string of characters that
    was longer than the area prepared to receive it
  • The output in Figure 10-3 and 10-4 illustrate one
    benefit of using the get() function instead of
    the extraction operator (gtgt) for keyboard data
    entry

Ex9-1.cpp
10
Using the get() Function
  • One unfortunate side effect of the get() function
    is that it leaves unused characters in the input
    stream
  • A subsequent call to get() retrieves the next
    (unused) character, whether or not that retrieval
    was intended
  • As shown in Figure 10-6, the program doesnt stop
    to obtain your grade, because the second call to
    get() already has been satisfied with the newline
    character

11
The UserNameAndGrade Program
Ex9-2.cpp
12
Using the get() Function
  • The program output shown in Figure 10-6 includes
    your first name and a newline (instead of a
    grade) for the letter grade
  • To allow the user to enter a grade, you could add
    a third cin.get() statement to the program, as
    shown in Figure 10-7

13
Using the get() Function
  • Programmers say this call to the get() function
    absorbs or consumes the extra character

14
Using the get() Function
Ex9-2.cpp
  • If you run the program in Figure 10-7 and enter a
    name that is too long, the output looks like
    Figure 10-9

15
Using the ignore() Function
  • It is impossible to guess how many cin.get()
    statements are needed to consume all the
    potential additional letters of a name if you use
    the UserNameAndGrade2 programimagine the
    challenge of a name such as Barbara Penelope
  • A superior alternative is to use the ignore()
    function to ignore or skip any additional
    characters left in the input stream
  • The prototype of the ignore() function is
  • istream ignore(int length 1, char c \n)

16
The UserNameAndGrade Program Using ignore()
Ex9-2.cpp
17
Using the ignore() Function
18
Using the getline() Function
  • As an alternative to using an extra call to get()
    to absorb the Enter key after character data
    entry, or using the ignore() function to absorb
    any number of characters, you can include another
    istream member, getline()
  • Its prototype is
  • istream getline(char str,int len, char c\n)
  • The getline() function reads a line of text at
    the address represented by str
  • It reads text until it reaches either the length
    used as the second argument or the character used
    as the third argument

19
Using the getline() Function
  • The program in Figure 10-13, and the output in
    Figure 10-14, show how the getline() function
    correctly accepts characters up to and including
    the default newline delimiter

20
Using the getline() Function
  • When you use a delimiter other than \n with
    getline(), the getline() consumes the delimiter
    but leaves he subsequent Enter key in the input
    stream, so you still must account for it
  • The program in Figure 10-15 and its output in
    Figure 10-16 illustrate the use of get() to
    consume the Enter key by getline()

21
Using the getline() Function
Ex9-3.cpp
22
Other istream Member Functions
  • Most compilers support other istream member
    functions with names such as eof(), bad(), and
    good()
  • The istream class is not mysterious
  • It is just a class, and cin is just an object
    that already has been instantiated for you

23
Using ostream Member Functions
  • The concepts you have learned while studying the
    cin object apply to the cout object as well
  • The ostream class supports member functions and
    overloaded operators just like the istream class
    or any other class, for that matter

24
Using Format Flags with setf() and unsetf()
  • Many of the states of the cout object are
    contained in a single long integer field, in
    which each bit represents some condition of the
    object
  • The arguments that determine the state of the
    cout object are called format flags or state
    flags
  • All format flags begin with ios
  • One member function of the ios class, the setf()
    function, takes arguments that set the bits of
    cout that is, the arguments turn the bits in the
    flag on or off
  • Another member function, unsetf(), can be used to
    deselect the bit cout.unsetf(iosshowpos)
  • Using the setf() function, you also can combine
    format flags using the bitwise OR operator ()

25
Using Format Flags with setf() and unsetf()
  • Some commonly used format flags are
  • iosleftleft-justifies output within the field
    size, which may be set by the width() function
    (described in a following section)
  • iosrightright-justifies output within the
    field size
  • iosdecformats numbers in decimal (base 10)
  • ioshexformats numbers in hexadecimal (base 16)
  • iosoctformats numbers in octal (base 8)
  • iosshowposinserts a before positive numbers
  • iosshowpointdisplays the decimal point and six
    decimal positions for all floating-point numbers

26
Using the width() Function
  • You can change the output field width with the
    iostream member width() function
  • This function defines the size of the output
    field in which the passed argument will be
    displayed
  • The width() function applies only to the first
    subsequent field to be output

27
Using the width() Function
Ex9-4.cpp
28
Using the precision() Function
  • You can use the precision() function to control
    the number of significant digits you see in the
    output
  • If you want to control the number of positions
    shown to the right of the decimal point (instead
    of simply the number of significant positions
    visible), you must combine cout.setf(iosfixed)
    and cout.precision()

29
Using the precision() Function
Ex9-5.cpp
  • Declare an array of doubles, assign values with
    different numbers of significant digits, and then
    display all the values using the same precision

30
Creating Manipulator Functions
  • If you need to display a variable named
    amountMoney in currency format with a dollar
    sign, in base 10, in a field size of eight, you
    might write the code shown in Figure 10-20
  • When you create a manipulator function, the
    desired results become much clearer
  • A manipulator function is used to manipulate, or
    change, the state of the cout object

31
Creating Manipulator Functions
Ex9-6.cpp
  • You could write a manipulator to format output as
    currency
  • The function contains statements that display the
    dollar sign, set some ios flags, and set the
    width
  • In the function shown in Figure 10-21, a
    reference to ostream is passed into the function
    as an argument

32
Using Built-In Manipulators
  • Some manipulators are so useful that they are
    already coded and placed in libraries included
    with your C compiler
  • You already have used the endl manipulator to
    output a newline character and flush the output
    stream

33
Using the setprecision() Manipulator
  • You use the setprecision() manipulator to specify
    the number of decimals that will print
  • The setprecision() manipulator works like the
    precision() functionit specifies the number of
    significant digits to display
  • It is considered a manipulator instead of a
    member function because you chain a call to
    setprecision() along with other output and the
    insertion operator, rather than using an object
    and a dot operator, as you do with
    cout.precision()

34
The DemoPrecision2 Program
35
Using the setprecision() Manipulator
Ex9-7.cpp
  • Any C manipulator, such as setprecision(), that
    takes an argument requires the inclusion of the
    iomanip file in your program
  • The program in Figure 10-22 produces the output
    in Figure 10-23

36
Using the setw() Manipulator
  • The setw() manipulator allows you to set the
    width of a field for output
  • Use of the setw() manipulator requires inclusion
    of the iomanip.h file, because setw() requires an
    argument that represents the width of the output
    field
  • The setw() manipulator works like the width()
    member function you can use with the cout
    objects the advantage of using setw() is its
    chaining capability in a cout statement

37
Using the setiosflags() and resetiosflags()
Manipulators
Ex9-8.cpp
  • Two additional manipulators, setiosflags() and
    resetiosflags(), each perform several
    manipulations, depending on the flags (such as
    iosdec or iosshowpoint) they receive as
    arguments
  • The setiosflags() manipulator turns on bit codes
    for the attributes named as arguments the
    resetiosflags() manipulator turns off those bit
    codes

38
Understanding Computer Files
  • When you store data items in a computer system,
    you use a permanent storage device, such as a
    disk or a reel of magnetic tape
  • The term permanent is used to contrast this type
    of data storage with the temporary data storage
    that exists in computer memory
  • Data items typically exist in memory for only a
    short time
  • It is common practice to store data in a data
    hierarchy, which represents the relationships
    between the sizes of data units that business
    professionals most often use

39
The fstream Family Tree
40
Using the getline() Function
  • If a file contains data that ends with a newline
    character, then its a bit awkward to have a
    program that uses the get() function to read data
    from a file because you must discard the newline
    character
  • As an alternative, you can use the getline()
    member function to read input data
  • The getline() function takes the form
    fileObject.getline(destination, sizeLimit),
    where destination is a declared character string,
    and sizeLimit is the maximum number of characters
    you want to store

41
Using the getline() Function
Ex9-9.cpp
  • Write a program that uses getline() to read the
    name file created in the WriteNameToFile.cpp
    program

42
Using the getline() Function
Ex9-10.cpp
43
Writing Objects to Files
  • It is simple and intuitive to use the ofstream
    classs overloaded operator to write characters
    and strings to files
  • It makes sense, however, that in object-oriented
    programs you should also be able to write objects
    to disk files
  • The write() function allows you to do just that
    the prototype is
  • ostream write(char c, int length)
  • The write() function accepts two arguments a
    pointer to a character and an integer

44
The Customer Class
45
Writing Customer Records to a File
Ex9-11.cpp
46
Writing Objects to Files
  • You can create an array of customer objects,
    perform the data entry required for the
    Customers, and write the output to a disk (see
    the format on page 394 of the textbook)
  • The program in Figure 10-40 executes a for loop
    numCusts times (five times), performing data
    entry and writing to the file each time

47
Writing an Array of Customer Records to a File
48
Reading Objects from Files
Ex9-12.cpp
  • It is more convenient to read a data file
    directly into an array of class objects
  • You can accomplish this goal with the read()
    function
  • The read() function prototype is quite similar to
    the prototype for the write() function
  • The prototype for read() is
  • istream read(char c, int length)
  • The read() function requires a pointer to a
    character, so you must perform a cast when you
    read an object

49
Reading Customer Records from a File
50
Reading Objects from Files
  • The read() function also requires the size of
    the object being read
  • Instead of reading one record at a time into the
    Customer array, you can perform one read for the
    entire array

51
Reading an Array of Records
52
Summary
  • The C objects cout and cin possess the same
    traits as other C objectsthey are members of a
    class, use inheritance, have access to overloaded
    operators, and have all other object traits
  • To input data, you can use the extraction
    operator (gtgt) after the cin object
  • To output data you can use the insertion operator
    with the cout object
  • A manipulator function is used to manipulate, or
    change, the state of the cout object

53
More examples
  • Ex9-13.cpp
  • Ex9-14.cpp
  • Ex9-15.cpp

54
Summary
  • Built-in manipulators include endl, newline,
    setprecision(), setw(), setiosflags(), and
    resetiosflags()
  • Creating a manipulator that takes an argument
    involves writing two functions
  • The address of the stream and the argument itself
    must be passed to the manipulator function
  • Usually, you store data on a disk (or other
    permanent storage device) in a data hierarchy in
    which fields are parts of data records that make
    up data files

55
Summary
  • To perform file output, you must instantiate your
    own member of the ofstream class
  • To read a file from within a program, you can
    create an object that is an instantiation of the
    ifstream class
  • The write() function allows you to write class
    objects to files
  • The write() function accepts two arguments a
    character pointer to the address of the argument
    being written to the file, and the size of the
    object being written
  • You can use the read() function to read a data
    file into class objects
Write a Comment
User Comments (0)
About PowerShow.com
