The Gaseous State

1
The Gaseous State

• Pressure-Volume-Temperature Relationships for
  Gaseous Molecules
• Gaseous Diffusion

2
Automobile Air Bag
Source Courtesy of Chrysler Corporation.
3
Gas Pressure

• Force exerted per unit area of surface by
  molecules in motion.

P Force/unit area
4
Mercury Barometer
Measurement of Gas Pressure
5
Manometer
6
Pressure Units

• Force exerted per unit area of surface by
  molecules in motion.

P Force/unit area

• 1 atmosphere 14.7 psi
• 1 atmosphere 760 mm Hg (torr)
• 1 atmosphere 101,325 Pascals
• 1 Pascal 1 kg/m.s2

7

• Boyles Law
• Compressibility of Gases
• The volume of a sample of gas, at a given
  temperature, varies inversely with the applied
  pressure.

V a 1/P (constant moles and T)
or
8
(No Transcript)
9

• Problem
• A sample of chlorine gas has a volume of 1.8 L at
  1.0 atm.
• If the pressure increases to 4.0 atm (at constant
• temperature), what would be the new volume?

10
(No Transcript)
11

• Charless Law
• The volume occupied by any sample of gas at
  constant pressure is directly proportional to its
  absolute temperature.

V a T(K) (at constant moles and P)
or
12
Linear Relationship of Gas Volume and Temperature
at Constant Pressure
13

• Problem
• A sample of methane gas that has a volume of 3.8
  L at
• 5.0C is heated to 86.0C at constant pressure.
  What is
• its new volume?

14

• Gay-Lussacs Law
• The pressure exerted by a gas at constant volume
  is directly proportional to its absolute
  temperature.

P a Tabs (constant moles and V)
or
15

• Problem
• An aerosol can has a pressure of 1.4 atm at
  25C. What pressure would it have at 1200C,
  assuming the volume remained constant?

16

• Combined Gas Law
• In the event that all three parameters, P, V,and
  T, are
• changing, their combined relationship is defined
  as follows

17

• Problem
• A sample of carbon dioxide occupies 4.5 L at 30C
  and
• 650 mm Hg. What volume would it occupy at 800 mm
  Hg
• and 200C?

18
The Ideal Gas Law

• From the individual gas laws, we see that volume
  varies in
• proportion to pressure, absolute temperature, and
  moles.

19
The Ideal Gas Law

• Combining the three proportionalities, we can
  obtain the following relationship.

or
where R is the proportionality constant
referred to as the ideal gas constant.
20
(No Transcript)
21
The Gas Constant, R

• The numerical value of R can be obtained using
  Avogadros law, which states that one mole of any
  gas at Standard Temperature and Pressure (STP)
  will occupy 22.4 liters (the Molar Volume).

22
A Molar Volume of Gas
23
Problem.How many grams of oxygen gas could
occupy the lungs of an adult with a lung capacity
of 3.80 L at 1 atm pressure and normal body
temperature, 37 oC?

• P 1.0 atm, V 3.8 L, T 37oC, n n mol of
  O2
• g grams of O2
• PV nRT, n PV
• RT
• n 1.0 x 3.8 mol 0.15 mol O2 x 32
  g O2 4.8 g O2
• 0.0821 x 310
  mol

24
Problem.What pressure will be generated by 5.50
g of O2(g) in a 200 mL stoppered flask at 22 oC?

• P P atm, V 0.200 L, T 22oC (295K), n n
  mol of O2
• 5.50 g O2 x 1 mol O2 0.172 mol O2
• 32 g O2
• PV nRT, P nRT
• V
• P 0.172 x 0.0821 x 295
  20.8 atm
• 0.200


25
Problem.What is the pressure generated by 91.3
g of O2 gas in a 8.0 Liter gas cylinder at 21 oC?

• P P atm, V 8.0 L, T 21oC, 91.3 g O2 x 1
  mol O2 2.85 mol O2 n mol
• 32 g
• Units must be in L, atm, mol and K
• PV nRT , P nRT 2.85 x 0.0821 x
  294
•
  V 8.0
• P 8.61 atm

26
Use of Ideal Gas Law to Determine Density and
Molecular Mass of gases
27
Problem.What is the density of UF6 gas (in g/L)
at 100 oC and 1.0 atm?
Units must be in L, atm, mol and K
UF6 (MW 352 g/mol)

• density g g mol (n) g
• L V MW
• PV nRT
• PV g RT
• MW
• d g P. MW 1.0 x 352 11.5
  g/L
• V RT 0.0821 x 373

28
Finding the Vapor Density of a Gas
29
Problem.If 0.495 g of chloroform, CHCl3, fills
completely a 127 mL flask at 98 oC and 754 torr,
what is the molecular weight of chloroform?

• PV nRT Units must be in L, atm, mol
  and K
• 754 torr 754 atm 0.992 atm
  760
• PV g RT 127 mL 0.127 L
• MW
• MW g RT 0.495 x 0.0821 x 371 119.7
  g/mol
• PV 0.992 x 0.127

30
Problem. A 15.5 gram sample of an unknown gas
occupied a volume of 5.75 L at 25C and a
pressure of 1.08 atm. Calculate its molecular
mass.

31
Gases and Reaction Stoichiometry
32
Problem. How many liters of oxygen can you
produce at 298 K and 1.02 atm from the reaction
of 0.0100 mol of KClO3?

33
Problem.How many liters of CO(g) at 25 oC and
750 mm Hg are needed to reduce 1 kg of Fe2O3?
(Ans 466 L). Fe2O3(s) 3 CO(g) gt 2
Fe(s) 3 CO2(g)

34
Problem.If an air-bag has a volume of 45.5L and
requires a N2 pressure of 828 mm Hg to function
at 22 oC, what mass of sodium azide, NaN3, must
decompose by the reaction 2 NaN3(s) ? 2 Na(s)
3 N2(g)

• P 828/760 atm, V 45.5 L, T 295
  K, n mol of N2(g)
• PV nRT, n PV 1.09 x 45.5 2.05
  mol
• RT
  0.0821 x 295
• 2 NaN3(s) ? 2 Na(s) 3 N2(g)
• 2.05 mol N2(g) x 2 mol NaN3 1.37 mol NaN3 x
  65 g NaN3 88.8 g
• 3 mol N2
  mol NaN3

35
Partial Pressures of Gas Mixtures

• Daltons Law of Partial Pressures the sum of all
  the pressures of all the different gases in a
  mixture equals the total pressure of the mixture.


36
Partial Pressures of Gas Mixtures

• The composition of a gas mixture is often
  described in terms of the mole fraction of its
  components

• The mole fraction, of a component gas is the
  fraction of moles of that component in the total
  moles of gas mixture.

The partial pressure of a component gas, A, is
then defined as
37
Problem. Given a mixture of gases in the
atmosphere at 760 torr, what is the partial
pressure of N2 if its mole fraction, c, 0 .7808.

38
Collection of Gas Over Water
39
Problem.Suppose a 156 mL sample of H2 gas was
collected over water at 19oC and 769 mm Hg. What
is the mass of H2 collected?

• The vapor pressure of water at 19oC as 16.5 mm Hg.

40
Kinetic-Molecular Theory

• Volume of particles is negligible
• Particles are in constant motion
• No inherent attractive or repulsive forces
• The average kinetic energy of a collection of
  particles is proportional to the temperature (K)

41
Molecular Speeds Diffusion and Effusion

• The root-mean-square (rms) molecular speed, u, is
  a type of average molecular speed, equal to the
  speed of a molecule having the average molecular
  kinetic energy. It is given by the following
  formula

42
Maxwells Distribution of Molecular Speeds
43
Molecular Speeds Diffusion and Effusion
Diffusion is the transfer of a gas through space
or another gas over time. Effusion is the
transfer of a gas through a membrane or orifice
into a vacuum. From the equation for the rms
velocity of gases, the following relationship
exists between the rate of effusion and molecular
mass.
44

• Grahams law The rate of effusion or diffusion
  is
• inversely proportional to the square root of its
• molecular mass.

45
Problem.How much faster would H2 gas effuse
through an opening than methane, CH4?

• H2 gas effuses through an opening 2.8 times as
  fast as methane, CH4?

46
Problem.It takes 16.6 min for a 10.0-mL
sample of an unknown gas to effuse through a
pinhole. A 10.0-mL sample of helium, He, required
5.00 min. What is the molecular weight of the
unknown gas?
47
Real Gases
48
Effect of Intermolecular Attractions on Gas
Pressure
49
Pressure-volume Product of Gases at Different
Pressures
50
(No Transcript)
51
Problem.If sulfur dioxide were an ideal
gas, the pressure at 0C exerted by 1.000 mol
occupying 22.41 L would be 1.000 atm. Use the van
der Waals equation to estimate the real
pressure. For SO2 a 6.865 L2.atm/mol2 b
0.05679 L/mol
