HydroChamber

1
HydroChamber Presentation
Presented by Dermot O Brien MEng M.I.E.I
REV008
2
Company Profile

• Founded 1987
• JFC Head Office Tuam, Co Galway, Ireland
• 3 Manufacturing Plants in UK
• JFC Manufacturing Europe - Oswestry Shropshire
• JFC Plastics Stratford Upon Avon
• JFC Plastics Runcorn
• Manufacturing Plant in Poland
• European Sales Office in Holland
• Approximately 200 People Employed
• Annual Turnover Approx. 36m

3
Industry Sectors

• Civils
• CorriPipe
• Stormwater Management Solutions
• Rotational Moulding
• Bulk Storage
• Materials Handling
• Marine
• Mussel Floats
• Marker Buoys and Anchor Buoys
• Agriculture
• Drinking and feeding equipment
• Recycling
• Post consumer bottles

4
Civils Products

• CorriPipe
• Corrugated Twin Wall Carrier Pipe
• Corrugated Twin Wall Filter Pipe
• Associated Fittings and Junctions
• HydroChamber / HydroCell
• Stormwater Management
• Permeable Attenuation
• Impermeable Attenuation
• Infiltration / Soak-away
• Hydro-Valve
• Vortex Flow Control
• Grease Separators
• Commercial Kitchens

5
CorriPipe

• Features Benefits
• Available in a range of Standard Sizes
• Ø100mm Ø600mm
• Available in Fully Perforated, Half
• Perforated and Unperforated
• Lightweight
• Very Fast Installation Times
• Superior Structural Strength
• 6m Lengths Fewer Joints
• Full range of Associated Fittings
• BBA HAPAS Approved
• Applications
• Storm water and Surface water Drainage
• Residential. Commercial, Industrial, Roads

6
Stormwater Management Solutions

• Configurations
• Soak-away / Infiltration Systems
• Permeable Attenuation Systems
• Impermeable Attenuation Systems
• Applications
• Residential Domestic
• Commercial
• Industrial

7
Soak-away / Infiltration System
Permeable System with all water discharging to
the ground.
8
Permeable Attenuation System
Hydro-Valve Flow Control

• Soak-away / Infiltration system with additional
  discharge
• to a local storm drain or watercourse at a
  controlled rate.
• Source control by minimising the amount of water
  sent to the local storm drain or watercourse

9
Impermeable Attenuation System
Hydro-Valve Flow Control

• Impermeable system with controlled discharge to a
  local
• storm drain or watercourse only.
• Prevents groundwater entering the tank
• Prevents water in tank entering the ground

10
Typical Applications

• Installations Under Trafficked Areas
• Suitable for HGV Traffic
• Suitable for Car Park and Light Commercial
  Traffic
• Minimum covers provided for flexible and rigid
  pavement design
• Installations Under Green Areas
• Suitable for Amenity Areas
• Suitable for Pedestrian Traffic
• Suitable for Playing Fields

11
HydroChamber

• Features Benefits
• WRc Approval
• BBA Certification
• Superior Structural Strength
• Silt / Grit Management
• Visual Camera Inspection
• Flushing Jetting Maintenance
• Stackable for Transport and Storage
• Cost Effective

• Services Offered
• Full Technical Support
• Design and Installation Manuals
• AutoCAD Drawings
• Supply and Install
• Supply and Supervise
• Supply Only

12
HydroChamber Typical Elevation Section
13
HydroChamber Inspection manifold
14
HydroChamber Typical End View Section
15

• HydroChamber Advantages
• Independent Certification
• WRc Approval
• BBA Certification

16
HydroChamber Advantages 2. Superior Structural
Strength No lightweight version
Certified to 11.5 ton axle loads Certified
Safety Factor of 3.5
17
HydroChamber Advantages 3. Superior Silt and
Grit Management System Unique Double
Catchpit Manholes 90 Bend in First
Catchpit Manhole
18

• HydroChamber Advantages
• Inspection and Maintenance
• Visual Inspections of Manholes
• Camera inspected of distribution pipe
• Camera inspection of chambers
• Distribution pipe can be jetted

• 5. Approved Inspection and Maintenance Programme
• Best practice guidelines for inspection and
  maintenance during for
• both during and after construction

19

• HydroChamber Advantages
• Foundation Design Guidelines
• Guidelines provided for depth of foundation
  based on
• strength (CBR) of sub soil.

20

• HydroChamber Advantages
• Watertight Pipe Connection
• HydroSeal flanged coupler provides a 100
  watertight joint

21

• HydroChamber Advantages
• 8. Smaller Storage Space Required
• HydroChambers Stack very efficiently requiring 10
  times less storage space when compared with
  traditional modular box systems

22
Technical Support

• Design Manual
• Installation Manual
• Excel Sizing Calculator
• AutoCAD Section Drawings
• BBA WRc Certificates
• Telephone Support
• Assistance in the design process
• Review proposed designs
• On site consultations

23
(No Transcript)
24
Hydro-Valve Vortex Flow Control

• Application
• Stormwater Flow Control
• Features Benefits
• Easy Installation
• Customised Specification
• Large Orifice Opening
• No Moving Parts
• Self Activating Self Cleansing
• No Power Requirements
• Can reduce storage requirements
• Emergency By-Pass
• Full Scale Test Data

25

• Thank You

• JFC Manufacturing Co. Ltd.
• Weir Road,Tuam
• Co. Galway, Ireland
• Tel [phone]
• Fax[phone]
• Email info_at_jfc.ie
• Website www.jfc.ie

• JFC Europe Ltd. Maes Y Clawdd Ind. Est.
  Maesbury Road, Oswestry Shropshire, SY10 8NN
• United KingdomTel 44 (0)1691 659226 Fax 44
  (0)1691 659344
