Micro 204 NK cells

1
Micro 204NK cells

• Lewis L. Lanier
• Lewis.lanier_at_ucsf.edu

2
(No Transcript)
3
NK cells - What are they?
Human CD3-,CD56 Mouse CD3-,NKp46 (in B6 mice
NK1.1)

• 3rd lineage of lymphocytes
• Function in innate immunity to protect against
  viruses, bacteria, tumors
• Produce cytokines kill abnormal cells

4
NK Cells - Where do they come from?

• NK/T cell progenitor in bone marrow
• Thymus not required
• nude mice have normal NK cells
• Do not rearrange a,b,g or d-TcR or Ig
• normal NK cells in scid and Rag-/- mice

5
(No Transcript)
6
NK cells - Development

• IL-15 is critical!
• Blocked by gene disruption of
• IL-15 pathway (i.e. IL-15, IL-15R-a, IL-2R-g
  -b, IRF-1, JAK3, Id2 or Ikaros (no IL-2Rg))
• Ets-1
• NOT eliminated by gene disruption of
• CD3z, FceRIg, DAP12
• IL-1, IL-2, IL-7, IL-12, IL-18, IL-21
• lck, fyn, syk, ZAP70, SHP-1, SHIP

7
NK Cells - Where do they live?

• 5-20 peripheral blood lymphocytes
• 5 lymphocytes in spleen
• Abundant in liver
• Low frequency in thymus, bone marrow, uninfected
  lymph nodes and lymphatics
• gt90 of lymphocytes in decidual tissue

8
NK cells - Pregnancy

• Maternal NK cells are the major lymphocyte
  population (90) at the maternal - fetal
  interface in the decidua
• Why?
• Fetal protection?
• Fetal sustenance?
• Vascular remodeling (IFNg)

9
NK Cells - What do they do?

• Cell mediated-cytotoxicity
• Antibody-dependent cellular cytotoxicity (ADCC)
• Early g-interferon production
• Secretion of TNFa, LTa, GM-CSF, IL-5, M-CSF,
  IL-3, IL-10, IL-13, MIP-1a, MIP-1b, RANTES, etc.

10
NK cells- How do they kill?

• Predominantly perforin / granzymes
• Kagi et al Nature 36931, 1994
• Secreted or membrane TNFa
• Degliantoni et al J Exp Med 1621512 1985
• Fas ligand
• Arase et al J Exp Med 1811235, 1995
• TRAIL
• Zamai et al J Exp Med 1882375, 1998

11
NK cells - Cytokine Activation

• Interferon-a/b
• augments cytolytic activity
• IL-15
• required for development, induces proliferation,
  increases cytotoxicity
• IL-12 IL-18
• augments INFg production
• IL-2
• induces proliferation, increases
  cytotoxicity..physiological relevance?

12
(No Transcript)
13
NK cells - what are they good for?

• Protection from viruses
• and maybe bacteria, parasites, tumors

14
What are NK cells are good for?

• Humans lacking NK cells susceptible to Varicella
  zoster CMV
• Biron et al. N Engl J Med 3201731 1989
• Mouse NK cells protect against CMV - requires
  perforin and IFNg
• Bukowski et al. J Immunol 131991 1983, J Exp Med
  16140 1985 Welsh et al. J Exp Med 1731053,
  1991 Scalzo et al. J Exp Med 1711469, 1990
  Orange et al. J Exp Med 1821045, 1995
• Mouse NK cells protect against mousepox -
  requires IFNg
• Jacoby et al. Arch. Virol. 10849, 1989 Chaudhri
  et al. PNAS 1019057, 2004 Fan et al. PLoS
  Pathogen 8e30, 2008
• Mouse NK cells protect against Ebola virus -
  requires perforin, not IFNg
• Warfield et al J Exp 200169, 2004

15
NK cells - Parasites Bacteria

• NK cells protect against certain parasites
• Toxoplasma gondii, Leishmania major, Plasmodium
  falciparum, Trypanosoma cruzi
• NK cells in bacterial infection
• TLR signaling of myeloid cells induces IL-12
• IL-12 induces NK cells to make INFg
• INFg augments macrophage function
• Evidence for NK cell protective role against
  Shigella flexneri, Legionella pneumophila,
  Pseudomonas aeruginosa, Staphylococcus aureus
• In Listeria monocytogenes infection, NK cell
  depletion causes the bacteria to grow LESS well

16
NK cells - Influence on Adaptive Immunity

• Early INFg production by NK cells may skew CD4
  T cells towards Th1
• INFg production by NK cells may cause IgG class
  switching in B cells
• Cross-talk with dendritic cells

17
NK cells - Dendritic Cells

• NK cells are activated by co-culture with DC
• Fernandez et al Nat Med 5405, 1999 Ferlazzo
  et al 195343, 2002
• Mouse CMV infection - CD8 dendritic cells
  produce IL-12 IL-18. activate NK cells in
  vivo
• Depletion of mouse CD8 DC prevents NK cell
  activation and control of infection
• In the absence of mouse NK cells, CD8 DC are
  lost after MCMV infection
• Andrews et al Nat Immunol 4175, 2003
• Human NK cell - DC interactions
• TLR-stimulated pDC or myeloid DC secrete INFa -
  enhances NK cytotoxicity
• TLR-stimulated myeloid DC secrete IL-12 -induces
  NK cell IFNg
• Activated NK cells - mature DC
• Gerosa et al. J Immunol 174727, 2005

18
NK cells can prime Th1

• Upon immunization, NK cells enter the lymph nodes
• Secrete IFNg
• Promote generation of CTL and Th1 response
• Martin-Fontecha et al. Nat Immunol 51260, 2004

19
NK cells and NKT cells-What is the difference?

• NKT cells rearrange TcR genes and express a
  CD3/TcR receptor- NK cells dont
• NKT cells usually refer to a subset of T cells
  with an invariant TcR-a and restricted TcR-b that
  recognize lipid antigens presented by CD1d
• Some people call a T cell an NKT cell if this T
  cell expresses any receptor in common with NK
  cells - a very confusing and imprecise name that
  is meaningless

20
(No Transcript)
21
RBC, neural cells
Normal healthy cells
Virus-infected cells, tumor
Virus-infected cells, tumor
22
Immune surveillance for Missing Self

• NK cells preferentially kill cells that have lost
  MHC class I
• Provides protection against cells escaping T cell
  recognition
• Predicts existence of inhibitory receptors for
  MHC class I that spare normal cells from NK cell
  attack
• Karre et al. Nature 319675, 1986

23
Cytomegalovirus (CMV) infection down-regulates
MHC class I on human fibroblasts
24
Physiological Role for NK cell inhibitory
receptors for MHC class I - detection of
virus-infected cells?

• Virus Protein Effect on class I
• Adenovirus E3-k19 Retain in ER
• HSV-1,2 ICP47 Blocks TAP
• EBV EBNA1 Block peptide generation
• HCMV US2, US11 ER to cytosol
• HCMV US3 Retain in ER
• HCMV US6 Blocks TAP
• HCMV UL83 Blocks proteasome
• MCMV m152 Retain in ER
• MCMV m04 Associates with H-2
• MCMV m06 Lysosomal degradation
• HHV8 K3, K5 Endocytosis
• HIV-1 Nef Endocytosis

25
(No Transcript)
26
Immunoreceptor Tyrosine-based Inhibitory Motif
(ITIM)

• Prototype I/V/L/SxYxxL/V
• pY binds cytoplasmic tyrosine phosphatase (SHP-1
  or SHP-2) - inhibits activation
• Present in receptors on B cells (FcgRII, CD22), T
  cells (CD5, LAIR, PD-1), NK cells (KIR, Ly49,
  NKG2A), myeloid cells (ILT,CD33, SIRPa)
• Prevents autoimmunity
• Ravetch Lanier, Science 29084, 2000

27
Multi-subunit immune receptors with ITAM-bearing
transmembrane adapters
Cytoplasmic ITAM (D/ExYxxL-X6-8-YxxL) Activate
Syk ZAP70 tyrosine kinases
28
ITAM-bearing signaling subunits in NK cells

• DAP12, FceRIg? and z
• Charged D residue in transmembrane required for
  association with receptors
• Phosphorylated ITAMrecruits tyrosine kinases Syk
  and ZAP70 triggers killing, cytokine
  production, proliferation

29
I
n
h
i
b
i
t
o
r
y

N
K
A
c
t
i
v
a
t
i
n
g

N
K
R
e
c
e
p
t
o
r
s
R
e
c
e
p
t
o
r
s
K
I
R
C
D
9
4
/
N
K
G
2
A
L
y
4
9
C
C

-
S
H
P
-
1
30
Human Chr 19q13
Killer cell Ig-like Receptors (KIR) Activating
inhibitory NK receptors
31
Killer Cell Ig-like Receptors (KIR)

• Ig superfamily
• 7-12 functional genes on human chromosome 19q13
• Extensive allelic polymorphism (no rearrangement)
• Mono-allelic expression possible
• Inhibitory KIR recognize polymorphic HLA-A, -B,
  and C
• Activating receptors have no intrinsic signaling
  capacity..associate with DAP12 ITAM-adapter
  protein
• Expressed by subsets of NK cells and memory T
  cells (usually CD8 T cells)

32
Inhibitory and activating KIRNK cell receptors
KIR2/3DS
KIR2/3DL
DAP12
-
-
-
-
-

-
-

-
ITAM Recruit syk / ZAP70 kinases - activate
ITIM Recruit phosphatases - inhibit responses
33
Human NK Receptors for HLA class I
34
Human KIR Haplotypes Differ in Gene Content and
Organization
3DL1
2DL2
2DS2
2DL5B
2DS3
2DL1
3DP1
2DL5A
2DS4
2DS5
2DS1
3DL2
2DL4
2DP1
2DL3
3DL3
3DS1
A haplotype
2DS4
2DL1
3DL2
3DL1
2DL4
2DL3
3DL3
B haplotype
2DL2
2DS2
2DL1
2DL5A
2DS1
3DL2
3DS1
2DL4
3DL3
2DS5
Generated by gene conversion - exon
swapping Difficult to distinguish loci versus
alleles
Uhrberg et al. 1997 Wilson et al. 2000 Vilches
et al. 2000 Hsu et al. 2002
35
Allelic polymorphism distinguishes 22 Group A
haplotypes having identical gene content
Group A haplotype
2DS4
2DL1
3DL2
3DL1
2DL4
2DL3
3DL3
49
11
38
26
15
7
55
alleles

• 3 x 106 possible combinations in the group A
  haplotypes
• (Courtesy P. Parham)

36
Rapid Expansion of KIR Genes in Primates
Human
3DL1
2DL5A
2DS4
2DS5
2DS1
3DL2
2DL2
2DS2
2DL5B
2DS3
2DL1
2DL4
3DP1
2DP1
2DL3
3DL3
3DS1
Chimpanzee
2DL5
2DL4
KIRCI
2DL6
3DL4
3DL6
Haplotype 1
2DL5
3DL1/2
2DL4
KIRCI
Haplotype 2
Orangutan
2DL
3DL
2DL4
DP1
2DS
3DL3
P. Parham
37
Mice dont have KIR genes Mice have Ly49 genes
that do the same job
38
Humans dont have functional Ly49 genes
39
Ly49 Receptors

• C-type lectin-like superfamily
• Polygenic polymorphic
• Extensive allelic polymorphism (no rearrangement)
• Mono-allelic expression possible
• Inhibitory Ly49 recognize polymorphic H-2D and
  H-2K
• Activating receptors have no intrinsic signaling
  capacity..associate with DAP12 ITAM-adapter
  protein
• Expressed by subsets of NK cells and memory T
  cells (usually CD8 T cells)

40
Inhibitory and activating Ly49 receptors
Ligand MHC class I
Ly49D,H
Ly49A,C,G,I...
DAP12
-
-

-

ITIM Recruit phosphatases - inhibit responses
ITAM
Recruit Syk Zap70 kinases - activate
41
Receptor diversity within the NK population
42
NK cell repertoire - Ground Rules

• KIR Ly49 are arrayed on overlapping NK subsets
• Individual NK clones simultaneously express
  multiple activating or inhibitory receptors for
  self and non-self ligands
• Many NK cells have at least one inhibitory
  receptor for one self MHC class I, but some NK
  cells lack inhibitory receptors for self class I
  - therefore regulated by other inhibitory
  receptors? Anergic?
• Repertoire is genetically determined, with subtle
  alterations caused by host MHC

43
KIR Ly49 receptorsconvergent evolution at work

• Polygenic polymorphic
• Rapidly evolving! Activating Ly49 and KIR are
  evolving faster than inhibitory receptors
• Mono-allelic expression on NK subsets
• Inhibitory ITIM receptors bind polymorphic MHC
• Ligands of activating receptors mostly unknown
  (likely pathogens?) -
• Activating isoforms no intrinsic signaling
  capacity
• associate with DAP12 ITAM-adapter protein

44
Ly49 KIR in Viral Immunity
45
Direct recognition of virus-infected cells by NK
cellsrecognition of viral ligands
46
Ly49H is the receptor for m157 MCMV glycoprotein
m157

• Ligation of Ly49H by m157
• DAP12 phosphorylation
• Recruitment activation of Syk Zap70 tyrosine
  kinases
• Activation of Ca flux, MAP kinase
• Cytotoxicity, cytokine production, proliferation

Ly49H
DAP12
-

-

ITAM
ITAM
47
Proliferation
Lanier Nat Rev Immunol 8259, 2008
48
KIR Involvement in Viral Immunity
49
HLA-Bw4-80I and KIR3DS1 together protect against
progression to AIDS
AIDS
AIDS-related malignancies
Carrington PLoS Pathogens, 2006
50
KIR3DS1, HLA-Bw4, and progression to AIDS in
HIV-infected people
Protection
KIR3DS1 NK cell
Killing ?
Slower progression to AIDS
KIR3DS1
No Effect
HIV-infected cell
No Killing ?
KIR3DS1 NK cell
Usual progression to AIDS
HLA- Bw6
Martin et al. 2002 Nat Genet 31429-34
51
KIR Involvement in Autoimmunity
52
Activating NK receptors - ligands

• Human/mouse CD16-FceRIg/z.IgG
• Human CD2..CD58
• Human 2B4 (CD244)-SAPCD48
• Human/mouse DNAM-1 (CD226).CD112, CD155
• Mouse PILRb-DAP12.PILR-L
• Human NKG2D-DAP10.MICA/B, ULBP
• Mouse NKG2D-DAP10/12RAE-1,H60, MULT1
• Mouse Ly49H-DAP12...MCMV m157
• Mouse Ly49P-DAP12...MCMV ?
• Human/mouse NKp46-FceRIg/z..?
• Human NKp30-FceRIg/z. ?
• Human NKp44-DAP12..?
• Mouse NKR-P1c-FceRIg.?

53

• NKG2D
• C-type lectin-like superfamily
• 1 gene, non-polymorphic, conserved mice - humans
• Homodimer expressed on all NK cells, gd T cells,
  and CD8 T cells
• R in transmembrane associates with D in DAP10
  transmembrane
• DAP10
• 10 kd homodimer
• Cytoplasmic YINM recruits Grb2 p85 PI3-kinase

54
NKG2D ligands in mice and humans
Many genes Many alleles
55
NKG2D ligands

• MHC class I-like
• dont require peptide or b2-microglobulin
• Bind with nM affinity to NKG2D
• Low levels expressed on healthy tissues
• Induced on virus-infected cells and tumor cells
• Induced by DNA damage
• Elevated in autoimmune diseases

56
What is the biological role of the NKG2D ligands?

• Danger signals to alert the immune system to
  infection or genomic damage

57
NKG2D on NK cells, ?? T cells and CD8 T
cells detect NKG2D ligands on abnormal cells
58
NK Cells - Ontogeny FunctionComprehensive
reviews

• Smyth et al. Nat Rev Cancer 2850, 2002
• Di Santo Ann Rev Imm 24257, 2006
• Lanier Nat Rev Immunol 8259, 2008

59
NK Cells - Receptors SignalingComprehensive
Reviews

• Parham, Nat Rev Immunol 5201, 2005
• Vivier, Nat Rev Immunol 9503, 2008
• Lanier, Nature Immunology 9495, 2008
