Stream Architecture: Rethinking Media Processor Design

1
Stream ArchitectureRethinking Media Processor
Design
Scott Rixner April 9, 2001

• Rice University
• Computer Systems Laboratory

2
Media Processing

• Video/image compression decompression
• MPEG, JPEG, ...
• Signal Processing
• DSL modems, cellular base stations, ...
• Image synthesis
• Polygon rendering, image-based rendering, ...
• Image understanding
• Face recognition, depth extraction, ...

3
Stereo Depth Extraction
Left Camera Image
Right Camera Image

• 640x480 _at_ 30 fps
• Requirements
• 11 GOPS
• Imagine stream processor
• 12.1 GOPS, 4.6 GOPS/W

Depth Map
4
Outline

• Stream Processing
• VLSI Constraints
• Register Organization
• Imagine
• Conclusions

5
Media Processing Characteristics

• Low-precision data
• 24 8-bit integer operations
• 29 16-bit integer operations
• Abundant data-parallelism
• Little global data reuse
• Average of 1.5 references per global data word
• Numerous computations per global reference
• 50-500 operations per global data reference

6
Stream Processing

• Little data reuse (pixels never revisited)
• Highly data parallel (output pixels not dependent
  on other output pixels)
• Compute intensive (gt60 operations per memory
  reference)

7
Locality and Concurrency
Operations within a kernel operate on local data
Kernels can be partitioned across chips to
exploit control parallelism
Image 0
convolve
convolve
Depth Map
SAD
Image 1
convolve
convolve
Streams expose data parallelism
8
Sony PlayStation2
Emotion Engine
FPU
MIPS Core
VPU0
Graphics Synthesizer
VPU1
Display
IPU
RDRAM, I/O, DMAC, etc.
9
Special vs. General Purpose

• Special Purpose
• Fixed function
• High performance
• General Purpose
• Programmable
• Insufficient performance

10
Register Files Dwarf ALUs
11
Register File Area

• Each cell requires
• 1 word line per port
• 1 bit line per port
• Each cell grows as p2
• R registers in the file
• Area p2R µ N3

Register Bit Cell
12
Register File Access Delay

• Signal must traverse
• Word line to access cell
• Bit line to transfer data
• Wire capacitance dominates
• Delay pR1/2 µ N3/2

Register File
13
Register File Power Dissipation

• 100 utilization requires
• driving all pR1/2 bit lines
• Wire capacitance dominates
• Power p2R µ N3

Register File
14
Centralized Register Organization

• Area, Power µ N3, Delay µ N3/2

15
Partitioned Organizations

• SIMD
• Data-parallel axis
• Distributed Register Files (DRF)
• Instruction-level parallel axis
• Hierarchical
• Memory hierarchy axis
• Stream
• Optimizing for streams

16
SIMD Register Organization

• Area, Power µ N3/C2, Delay µ (N/C)3/2

17
Distributed Register Organization

• Area, Power µ N2, Delay µ N

18
Combining SIMD and DRF
Scalar
SIMD
Central
DRF
19
Hierarchical Register Organization
Hierarchical T40

• Area, Power µ N3, Delay µ N3/2

20
Hierarchical Organizations
Scalar
SIMD
Central
DRF
21
Stream Register Organization

• Area, Power µ N2/C, Delay µ N/C

22
Stream Organizations
Scalar
SIMD
Central
DRF
23
Comparison of Organizations

• 48 ALUs (32-bit), 500 MHz
• Stream organization improves central organization
  by
• Area 195x, Delay 20x, Power 430x

24
Performance
16 Performance Drop (8 with latency constraints)
180x Improvement
25
Stream Architecture

• Stream Processing
• Matched to media processing
• Exposes locality and concurrency
• Stream Register Organization
• Efficiency of special-purpose hardware
• Optimized for streaming applications
• Data bandwidth
• Bandwidth hierarchy
• Memory access scheduling
• Conditional streams

26
The Imagine Stream Processor
27
Arithmetic Clusters
Communication Unit
Scratch-pad Register File
Intercluster Network
Local Register File





/
CU
To SRF
Cross Point
From SRF
28
Bandwidth Hierarchy
SDRAM
ALU Cluster
ALU Cluster
SDRAM
Stream Register File
SDRAM
SDRAM
ALU Cluster
2GB/s
32GB/s
544GB/s

• 41.2 32-bit operations per word of memory
  bandwidth

29
Stream Recirculation
30
Bandwidth Demands of FIR Filter
31
Bandwidth Utilization of FIR Filter
32
Performance
floating-point application
16-bit kernels
16-bit applications
floating-point kernel
33
Power
GOPS/W 4.6 6.9 4.1 10.2
9.6 2.4 6.3
34
Relative Performance and Power Efficiency
FFT Performance
Power Efficiency
35
Imagine Floorplan

• Tapeout Q2 01
• 21 million Ts
• 6M SRF SRAM
• 6M UC SRAM
• 6M Clusters
• 3M Other
• Target 32 FO4
• 300 MHz at SSSS
• 500 MHz at TTSS
• TI GS30KA
• 0.15 mm Ldrawn
• 457 Signal Pins

36
Imagine Team

• William J. Dally
• Ujval Kapasi
• Brucek Khailany
• Peter Mattson
• Jinyung Namkoong
• John Owens
• Ben Serebrin
• Brian Towles

• Scott Rixner
• Don Alpert (Intel)
• Ghazi Ben Amor
• Chris Buehler (MIT)
• JP Grossman (MIT)
• Brad Johanson
• Abelardo Lopez-Lagunas
• Ben Mowery
• Manman Ren

37
Conclusions

• Media Processing
• Little data reuse
• Highly data parallel
• Compute intensive
• VLSI
• Stream register organization
• Bandwidth hierarchy
• Imagine
• Stream architecture
• 10 GOPS sustained application performance
• 5 GOPS/W application power efficiency
