Project Hints

1
Project Hints
2
Project Hints

• Changes to entry.S1. Modify the entry.S to pass
  control a 'C' function that logs the system call
  2. eax register gives the system call number and
  is passed as a parameter to the logging
  function3. Important step - pop the passed
  parameter from stack after returning from C
  function - common reason for kernel panics
• Getting PID1. Use of "current" pointer that
  points to task_struct of current process.. 2.
  Imp - include asm/uaccess.h and linux/sched.h to
  get the data in current pointer.
• Writing to log fileThere has been lot of
  discussion and almost everybody on net says that
  this would be the last thing to do in kernel
  space. It was a fun and a good exercise for us to
  understand how things work in actual flow.
  http//www.cs.utexas.edu/users/ygz/378-03S/14.pd
  f  and actual browsing of the the implementation
  of write system call i.e. ( sys_write) gives a
  clear idea of all the steps that are required to
  write to file from kernel space.
• Our ApproachSince we are linking our logger
  statically with the kernel image, we have a great
  advantage of using the implementations of these
  system calls as normal functions, Advantage of
  doing so includes     - avoids necessity of
  locking the global data structures and file
  locks    - Not required to install your file
  descriptor (fd) obtained from filp_open (not
  flip_open)    - writing using sys_write instead
  of vfs_write avoids handling for position file
  pointer. As a result, we implemented the logger
  using the standard system call implementation
  functions for sys_open, sys_write and
  sys_closeImportant Hint - You need to change the
  DS to KERNEL_DS so that kernel space buffers
  could be used to write to the file and then
  original DS should be restored after file
  operations.
• For Module WritersWe also tried addressing the
  problems for module writers. sys_write is the
  only required function that is not exported from
  kernel and so we used vfs_write and required
  calls to write to file. ( We did not implement
  the module, but made sure that all the calls in
  our logger were exported and so could be easily
  written in module). A very nice and interesting
  article for writing to files in module could be
  found in LinuxJournal at http//www.linuxjournal.c
  om/article/8110
• Controlling the logger To meet one of the
  important requirement of not logging all the
  system calls, we are controlling the logger with
  start and stop commands implemented using system
  calls. Log file name is passed as an argument to
  the start logging call.
• Locks / Synchronization Though our
  implementation does not have any handling for
  synchronized access to the log file, we would
  surely expect students to do this. It was also
  part of project 2 and should not be a difficult
  task for  them.
• TestingI have written a good and bad echo
  servers in Python - (Ubuntu's default
  installation has Python). Students can easily add
  more calls to these process to see variations.
  Bad echo server tries to connect back to client
  on some port  ( currently defined as a constant
  in the file )
• AnalysisAnalyzer could be written in any
  language and will be user level program that will
  calculate hamming distance and according to some
  threshold generate the alarms if required. Alarm
  could as simple as a print statement )

3
Chapter 8 15 Summary

• Filip Perich

4
Chapter 8 Main Memory

• CPU interacts with the rest of the system through
  main memory
• Address binding
• Compile time, load time, execution time
• Logical vs. physical address space
• Hardware support
• Dynamic loading, linking, shared libraries
• Swapping
• Contiguous memory allocation
• Memory mapping, protection, MMU
• Memory allocation
• First, best, worst fit
• Fragmentation
• Internal, external
• Frame table
• Paging
• Pages, page tables, page-table base register,
  translation look-aside buffer
• Protection valid-invalid bit
• Structure
• Hierarchical paging

5
Chapter 9 Virtual Memory

• Virtual memory vs physical memory vs logical
  memory
• Virtual address space
• Demand paging
• Lazy swapper (pager)
• Valid-invalid bit
• Page fault
• Performance
• Page replacement algorithms
• Basic find a victim
• FIFO, optimal, LRU, MRU, counting algorithms
  (LFU, MFU)
• Frame allocation and trashing
• Fixed allocation, priority
• Global vs. local
• Memory-mapped files
• Kernel memory
• Allocating, buddy system allocator, slub
  allocator
• Other issues
• Prepaging, page size, TLB reach, program
  structure, I/O interlock,

6
Chapter 10 File-System Interface

• File
• Attributes name, id, type, location, size,
  protection, time, date, etc.
• Operations create, write, read, reposition
  within, delete, truncate
• Pointer, file-open count, disk location, access
  rights
• Types
• Structure
• Mac resource and data fork
• Others one pointer
• Internal fragmentation
• Access methods
• Sequential vs. direct
• Directory structure
• Storage structure
• Single vs. multi-level vs. tree-structured vs.
  acyclic vs. general directories
• File-system mounting
• File sharing
• Multiple users, remote file systems
  (client-server, peer-to-peer)
• Consistency semantics
• Unix, session, immutable-shared-files semantics

7
Chapter 11 File System Impl.

• File system structure
• Implementation
• Boot control block, volume control block
• File tables
• System vs. per-process open-file table
• Partition, mounting, in-memory, virtual FS
• Directory implementation
• Allocation methods
• Contiguous vs. linked vs. indexed allocation
• Extent-based systems
• Free space management
• Caching
• Recovery
• Consistency check, backup, restore
• Log-structure file systems (transactions)
• NFS

8
Chapter 12 Mass-Storage Systems

• Magnetic disks, magnetic tapes, stable storage,
  tertiary storage
• Disk structure
• Disk attachment
• Host-attached storage, network-attached storage,
  storage-area network
• Disk scheduling
• FCFS, SSTF, SCAN (from one end to the other and
  back), C-SCAN, LOOK, C-LOOK
• Disk management
• Formatting low-level (physical), logical
  formatting, boot block, bad blocks (sector
  sparing vs. slipping)
• Swap-space management
• Swap-space use, location, UNIX example
• RAID
• Reliability via redundancy
• Performance via parallelism
• Levels
• 0 non-redundant stripping
• 1 mirrored disks
• 2 memory-style ECC
• 3 bit-interleaved parity
• 4 block-interleaved parity

9
Chapter 13 I/O Systems

• I/O Hardware
• Port, bus, expansion bus, controller, host
  adapter, memory-mapped i/o
• Polling vs. interrupts
• Direct memory access
• Application I/O interface
• Character-stream vs. block
• Sequential vs. random access
• Synchronous vs. asynchronous (response times)
• Sharable vs. dedicated
• Speed of operation
• Read-write, read-only, write-only
• Blocking vs. non-blocking access
• Clocks, timers
• Kernel I/O subsystem
• I/O scheduling, buffering, caching, spooling and
  device reservation, error handling, i/o
  protection, kernel data structures
• I/O requests to hardware operations
• Performance challenges
• Example STREAMS

10
Chapter 14 Protection

• Key guiding principle
• Principle of least privilege
• Protection Domain
• Specifies membership
• User, process, procedure
• UNIX user id, user, group, everyone
• MULTICS levels / rings
• Rei - rules
• Specifies access rights
• Read, write, execute, share
• Copy, transfer, limited copy of rights
• Access Matrix
• Rows access rights per domain
• Columns access rights per object
• Implementation
• Global table
• Access list for objects
• Capability lists for domains (Hydra, Cambridge
  CAP system)
• Lock-key mechanism

11
Chapter 15 Security

• System is secure if
• Its resources are used and accessed as intended
  under all circumstances
• Threads and attacks
• Breach of confidentiality, breach of integrity,
  breach of availability, theft of service, denial
  of service
• Masquerading (e.g., authentication and reply
  attacks), Man-in-the-middle attack (e.g., session
  hijacking)
• Threads
• Program Trojan horses, trap door, logic bomb,
  stack and buffer overflow, viruses
• Network Worms, port scanning, denial of service
• Security measures
• Cryptography
• Encryption
• Symmetric same key for encrypting and
  decrypting DES, AES
• Asymmetric different keys PKI
• Authentication
• Key distribution
• Out-of-band, key ring
• Digital certificates
• User authentication
• Passwords, encrypted passwords, one-time
  passwords (paired passwords with challenges),
  biometrics
