Storage management and caching in PAST

1
Storage management and caching in PAST

• Antony Rowstron and Peter Druschel
• Presented to cs294-4 by Owen Cooper

2
Outline

• PAST goals
• PAST api
• File storage overview
• File and replica diversion
• Replica management
• Caching
• Performance
• Discussion

3
PAST (non)goals

• P2P global storage network
• Use properties of existing p2p systems (Pastry)
• Support for strong persistence
• Via a core set of replicas
• High availability
• Via local caching
• Scalable
• Obtain high storage utilization via local
  cooperation
• Secure
• Design goals do not include
• Replacing the file system
• Updatable files
• Directory or lookup service

4
Security Model

• Pastry node ids are a hash of a public key
• Smartcard based security
• Provides keys
• Quota management
• Nodeid and fileid generation controlled
• Try to stop nodes from getting consecutive ids
• Or clients from overloading parts of the network
• But node id and real world identity may not be
  linked
• Data not encrypted

5
PAST APIs

• In PAST, files are immutable
• FileidInsert(filename,credentials, k, file)
• Insert k copies of the file into the network, or
  fail.
• Fileid a signed (filename, credentials, salt)
• Successful if ack with receipts from k nodes
• Filelookup(fileid)
• Return a copy of the file if it exists
• Reclaim(fileid, cradentials)
• Reclaim accepted if requested by the owner
• Allows, but does not require, storage reclamation

6
File insertion

• Insert(name, c, k, file)
• Computes a storage certificate
• Contains fileid, hash of content, k, salt
• Deducts kfilesize from quota
• Routes file and storage certificate using pastry
  using fileid.
• Node verifies the integrity of the file, stores
  it, and asks k-1 closest nodes to store the file.

• K-1 nodes in leaf set (k-1 lt l)
• Node returns ack with k signed storage receipts,
  or a nak.

7
Lookup and Reclamation

• Pastry ensures replica is found
• Since a lookup is routed to the closest nodeid
• Reclamation
• Client generates a reclaim certificate
• Sends it to the fileid via pastry
• Recipients verify the certificate issue receipt
• Client reclaims quota

8
Diversion

• A file or replica can be relocated
• For a replica, to another close node
• If one of the K closest is overloaded
• For a file, to another set of nodes in the
  idspace
• If the nodes around a fileid are (possibly
  locally) congested
• Why is this necessary?
• Differing storage capacity at nodes
• Differing file size for inserted files

9
Replica Diversion

• Node responsible for fileid asks k-1 neighbors to
  store the file
• Neighbor (N) may divert a copy to a node in its
  leaf set
• Pointer to copy inserted at N
• N issues storage certificate
• N also inserts a pointer on the k1th closest
  node
• No orphan if N fails
• N remains responsible for pointer maintenance

10
File Diversion

• Replica diversion is local
• Allows storage choice between nodes around fileid
• File Diversion
• Triggered when an insert with a fileid fails
• Insert is tried a total of three times
• New fileid generated by changing the salt

11
Storage Policy

• How does a node choose to accept or reject a
  replica?
• Computes sizeof(file)/sizeof(free_space)
• Compares to Tpri or Tdiv depending nodes role
• Tpri gt Tdiv
• How is node chosen for replica diversion
• Search leaf set for the node that
• Has maximal free space
• Doesnt already hold a diverted or primary
  replica
• File diversion
• K copies cannot be located (via primary or
  diversion)

12
Replica maintenance

• Node join/leave causes responsibility shift
• Pastry node failure detection will cause leaf set
  updates
• Past detects responsibility shifts this way
• Newly responsible node must copy files
• Make a copy immediately, OR
• pointer to old owner copy lazily
• Diverted replicas
• Target of diversion may move out of leaf set
• Node to store repica can be any one in leaf set
• Must exchange keepalive messages themselves
• Should be relocated

13
Replica maintenance (2)

• Node failure may cause storage shortage
• No node in leaf set can take over ownership
• Search space is widened
• Ask most extreme nodes to locate storage
• Increases search space to 2l nodes
• If no storage space found, fail.

14
Caching

• Pastrys locality based routing will tend to
  direct requests to nearby copies
• PAST also stores cached copies
• Along routing path between client and fileid
• For insert and lookup operations
• Cache maintained using GD-size algorithm
• Weight per file 1/size(file)
• Eviction
• Pick file with minimum weight
• Subtract weight of evicted file from all others

15
Experiments without diversion

• Experiments use
• Large trace from web server
• Files from local web server
• The case for diversion with web trace
• Without diversion
• 51.1 of insertions failed
• 60.8 storage utilization

16
Experiments (2) with diversion

• With diversion
• Bigger leaf set size a plus

17
Experiments (3)varying Tpri

• Effects of varying Tpri
• files stored v.s. size of file

18
Experiments (4) Varying Tdiv

• Varying Tdiv
• Tpri is constant

19
File and Replica Diversion
20
caching

• 8 traces combined
• Requests from clients in each trace are mapped to
  close PAST nodes
