Selected Problems in EM Algorithms

1
Selected Problems in EM Algorithms

• By Reynold Cheng
• Feb 24, 2003.

2
Two Problem Categories in EM Algorithms

• Batched Problems
• Process entire file of data items
• Stream data through internal memory in 1 passes
• Example sorting, computational geometry, graphs
• Online Problems
• Immediate response to queries
• Only small portion of data is examined for each
  query
• Data can be static or dynamic
• Example Dictionary operations, range queries

3
Parallel Disk Model (PDM)
4
Parallel Disk Algorithms

• For most problems, parallel disks can be utilized
  effectively by
• Striping round-robin placement on disks
• Distribution and merge paradigm
• In practice, disk striping is sufficient
• We now restrict ourselves to single-disk

5
Talk Outline

• Online Range Queries
• Buffer Trees and Bulk Loading
• String Processing
• Dynamic Memory Allocation

6
Goals of Online Range Search

• Using B-trees for 1-D range search
• Combined search and output cost for queries of
  O(logBN z) I/Os
• Use only a linear amount (O(n) blocks) of disk
  space, and
• Support dynamic updates in O(logBn) I/Os
• Can we achieve the same performance for general
  range search?

7
Categories of Spatial Data Structures

• Space-Driven
• Partitioning of the embedding space
• Quad-trees and grid files
• Data-Driven
• Partitioning of the data items
• R-trees and kd-trees
• We study online range search for data-driven data
  structures

8
Lower bound of general 2-D orthogonal queries

• It was proved that criteria (1) and (2) cannot be
  satisfied simultaneously
• Lower bound
• O(n(log n)/log(logBN 1)) disk space
• O((logBN)cz) I/Os per query for any constant c
• Best algorithm achieves
• O(n(log N) / log logBn) space
• O(logBnz) I/Os per query

9
Range Search Using Linear Amount of Disk Space

• None of these linear-space data structures come
  close to satisfying Criteria 1 and 3 in the worst
  case
• In typical case scenarios they perform well
• Examples R-trees, kd-B-trees, cross trees, grid
  files and linearization

10
Cross Trees

• Data-driven partitioning (weight-balanced
  B-trees) at upper levels of the tree
• Space-driven partitioning (quad trees) at lower
  levels
• d-dimensional range queries done in O(n1-1/dz)
  I/Os
• Inserts and deletes take O(logBN) I/Os

11
Grid Files and Linearization

• A Grid File is a flattened data structure for
  storing the cells of a 2-D grid in disk blocks
• Linearization Impose a total ordering on a n-D
  space with space-filling curves,
• Organize the points into a B-tree
• Worst-case performance is no better than cross
  trees

12
Special Cases of Range Search

• These are all important cases of the general
  orthogonal 2D range search
• Are there any data structures that meet Criteria
  1-3 for these special cases?
• Yes!

13
Diagonal Corner Query Stabbing Query

• Stabbing queries are important
• Facilitate dynamic interval management
• Indexing 1-D constraints in constraint DB
• Arise in graphics and GIS problems

14
Range Searching Results
I/Os
Query
15
Batched Dynamic Operations

• For batched problems in internal memory, we often
  use a dynamic data structure to process a
  sequence of updates
• To sort N items, we perform N insertions to a
  priority queue, followed by N deleteMin
  operations.
• Known as batched dynamic operations, where
  queries do not need to be answered right away or
  in any particular order

16
The Buffer Tree ARGE95

• In external memory, if we use a B-tree as the
  priority queue, resulting I/O is non optimal
• Each update and query takes O(logBN) I/Os
• Building a B-Tree takes N insertions ? O(N logBN)
  I/Os!
• gtgt Sort(N) O(n logBn) I/Os
• We can take advantage of blocking and obtain O(n
  logmn) I/Os in building a B-tree
• Buffer tree ARGE95

17
Main Idea of Buffer Tree

• Logically group nodes together and add buffers
• Balanced tree Degree ?(m) rather than ?(B)
• Each node has a buffer for storing ?(M) items
  (?(m) blocks)
• Insertions done lazily items inserted into
  buffers
• When a buffer is full, its items are pushed one
  level down

18
I/O Cost of Buffer Trees

• Buffer-emptying in O(m) I/Os
• Amortize the cost of distributing M items to ?(m)
  children
• Each item incurs an amortized cost of
  O(m/M)O(1/B) I/Os per level
• The resulting cost for update/query is only
  O((1/B)logmn) I/Os amortized
• Cost of inserting N nB items
• nB O((1/B)logmn) nlogmn I/Os

19
Applications of Buffer Trees

• Efficient DeleteMin operations
• External Heap
• String sorting
• Improved graph algorithms (list ranking)
• Bulk operations on R-trees

20
Bulk Loading of R-Tree

• Repeated (dynamic) insertion into R-tree is
  costly (N logBN I/Os)
• Bulk-loading build the R-tree in bottom-up
  fashion by grouping items into leaf nodes
• Apply space-filling curve to presort the objects
  (e.g., Hilbert curve)
• Also known as static insertion

21
Dynamic vs. Static Insertion

• Dynamic insertion
• Explicitly reduce coverage, overlap, or perimeter
  of the bounding boxes
• Good query performance
• Static insertion
• Does not consider bounding box information at all
• Improved storage utilization (up to 100)
  compensates for a higher degree of node overlap
• Poorer query performance

22
Buffer Tree and Bulk Loading

• To get good query performance and bulk
  construction efficiency, Arge et al. ARGE99
  proposed using buffer trees for fast
  bulk-loading.
• Top-down construction in O(nlogmn) I/Os
• Matches the performance of bottom-up methods to
  within a constant factor

23
Experimental Results I/O Costs
24
Text Indexing in Internal Memory

• Inverted file
• Analogous to the index at the back of a book
• Words of interest in the text are sorted
  alphabetically
• Each item in the sorted list has a list of
  pointers to the occurrences of that word in the
  text

25
Text Indexing in External Memory

• Hybrid approach the text is divided into large
  chunks one or more blocks
• Inverted file is used to specify the chunks
  containing each word
• Use a fast sequential method to search within a
  chunk, such as Knuth-Morris-Pratt and Boyer-Moore
  methods
• Basis of the GLIMPSE search tool MW94

26
B-Tree and Strings (1)

• In a B-tree, ?(B) unit-sized keys are stored in
  each internal node for searching
• The node fits into one or two blocks
• If keys are variable-sized text strings, the keys
  can be arbitrarily long
• Many blocks to store ?(B) strings per node!

27
B-Tree and Strings (2)

• Can we store pointers to ?(B) strings?
• Access to strings during search needs more than
  constant of I/Os per node
• Redesign B-tree to handle strings String
  B-tree or SB-tree FG99
• SB-tree differs from B-tree in the way each
  ?(B)-way branching node is represented

28
Overview of SB-Tree

• B-tree on set of pointers to strings
  (lexicographical order)
• Pointers to ?(B) strings stored in internal nodes
• Every internal node is a variant of the Patricia
  Trie called Blind Trie (BT)

29
Internal Node of SB-Tree Blind Trie

• Achieve B-way branching with only O(B)
  characters, fitting in O(1) blocks
• Contains characters from all B-1 strings
• Pointers to the strings are stored at the leaves

30
Illustrating Blind Trie

• Left subtrie contains strings whose position 4
  (5th character) is a
• Right subtrie contains strings whose position 4
  (5th character) is b
• The 1st 4 characters in all strings in the nodes
  subtrie are bcbc

31
Searching a Blind Trie

• S bcbabcba
• R bcbcbbba

32
Fixing the Search Bug by Sequential Scan

• Sequentially compare S and R
• The index where they differ can be found
• S bcbabcba
• R bcbcbbba
• S is smaller than entire right subtrie of root

Possible location of S
33
I/O Cost of SB-Tree

• Searching a Blind Trie requires one I/O to load
• Additional I/Os to do the sequential scan of the
  string after the leaf is reached
• Each block of the search string examined during
  sequential scan need not be read again for lower
  levels
• Search time for S characters O(logBNS/B)
• Insertions and deletions also optimal

34
Substring Searching

• Suffix Tree
• searches for any substring in time linear in size
  of substring
• apply Patricia tries is to store suffixes of a
  string
• suffixes of hello hello,ello,llo,lo,
  o
• Suffix Array
• compact but static version of suffix tree
• Both built on strings of total length N
  optimally O(nlogmn) I/Os

35
Dynamic Memory Allocation

• In practice, amount of internal memory allocated
  to a program may fluctuate
• Demands by other users/processes
• If memory allocation is reduced, algorithms that
  assume uses fixed memory must resort to virtual
  memory
• Severe performance degradation
• EM algorithms should adapt dynamically to
  whatever resources are available
• Design and analysis of EM algorithms to adapt
  gracefully to changing memory allocations studied
  in BV99

36
Dynamic Memory Allocation Model BV99

• An EM algorithm is allocated memory in an
  allocation sequence s m1,m2,mk of allocation
  phases
• ith phase Algorithm owns mi blocks of memory for
  2mi I/Os
• Dynamically Optimal Algorithms
• Adversary chooses allocation sequence sx
  m1,m2,,mk
• A solves problem P during sx
• A is dynamic optimal for P iff no other algorithm
  A can solve P more than a constant number of
  times during sx
• Barve and Vitter BV99 give dynamically optimal
  strategies for sorting, matrix multiplication and
  buffer tree operations

37
Conclusions (1)

• Linear-space structures cannot provide O(logBn
  z) I/Os for general 2-D orthogonal range
  queries in the worst case
• Linear-space structures achieve O(logBn z)
  I/Os for Corner, 2-sided and 3-sided queries
• Buffer tree provides both good bulk-loading and
  query performance

38
Conclusions (2)

• Inverted files for large file chunks used in EM
  text indexing
• SB-Tree enhances B-tree support for
  variable-length strings with internal node being
  a blind trie
• EM algorithms need to adapt to changing internal
  memory requirement

39
Other Interesting Topics

• External sorting of strings
• Computational geometry and graph problems (e.g.,
  topological sort, BFS, DFS)
• EM algorithms and memory hierarchy
• Translating theoretical gains into observable
  improvements in practice
• New storage devices (e.g., disk drives with
  processing capability) present new challenges

40
References

• JSV2001 J. S. Vitter. External Memory
  Algorithms and Data Structures Dealing with
  MASSIVE DATA, ACM Computing Surveys, 33(2), June
  2001, 209-271.
• JSV1998 J.S. Vitter. External Memory
  Algorithms in an invited tutorial in Proceedings
  of the 17th Annual ACM Symposium on Principles of
  Database Systems (PODS '98), Seattle, WA, June
  1998.
• BV99 Barve, R. D. and Vitter, J. S. 1999. A
  theoretical framework for memory-adaptive
  algorithms. In Proceedings of the IEEE Symposium
  on Foundations of Computer Science (New York,
  Oct.), Vol. 40, 273284.

41
References

• MW94 Manber, U. and Wu, S. 1994. GLIMPSE A
  tool to search through entire file systems. In
  USENIX Association, Ed., Proceedings of the
  Winter USENIX Conference (San Francisco, Jan.),
  23 32.
• FG99 FERRAGINA, P. AND GROSSI, R. 1996. Fast
  string searching in secondary storage
  Theoretical developments and experimental
  results. In Proceedings of the ACM-SIAM Symposium
  on Discrete Algorithms (Atlanta, June), Vol. 7,
  373382.
• ARGE95 Arge, L. 1995. The buffer tree A new
  technique for optimal I/O-algorithms. In
  Proceedings of the Workshop on Algorithms and
  Data Structures, Vol. 955 of Lecture Notes in
  Computer Science, Springer-Verlag, 334345.
• ARGE99 Arge, L., Hinrichs K. H., Vahrenhold,
  J., and Vitter, J. S. 1999. Efficient bulk
  operations on dynamic R-trees. In Workshop on
  Algorithm Engineering and Experimentation, Vol.
  1619 of Lecture Notes in Computer Science
  (Baltimore, Jan.) Springer-Verlag, 328348. IEEE
  Transactions on Knowledge and Data Engineering 1,
  2 (June), 248257.
